- Page 1 PRELIMINARY INSTALLATION MANUAL MODEL P300 2.1 Version 0.1/fsm Steinway & Sons P300 2.1 OWNER’S MANUAL [Skriv tekst] Version 2.0...
-
Page 2: Table Of Contents
Installation via Web Interface HOME Screen SETUP Source Create Source name Lipsync offset Volume offset Audio input Default post processing Default voicing Video input Preset vTuner station Speaker configuration Trigger out Edit Arrange Delete Steinway & Sons P300 2.1 Owner’s manual... - Page 3 Default volume settings HDMI CEC settings Display timeout Password protection Control of speaker setups Show bypass Enable front IR sensor OSD info level Trigger In Setup Trigger Out Setup Network Configuration Streaming Setup Steinway & Sons P300 2.1 Owner’s manual...
- Page 4 3D Compatibility Not Detected Remote Control Doesn’t Work Network Setup Connecting to Model P300 2.1 with a Network Cable Set Up a Fixed IP Address in Windows XP or Windows 7 Set Up a Fixed IP Address in Windows Vista or Windows 10...
-
Page 5: Compliance
Steinway Lyngdorf products and accessories comply with parts 15 and 68 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference;... -
Page 6: Pre-Installation
Red: Standby / On Orange: Switching on Blinking: Updating software Operating Voltage Steinway Lyngdorf products must be connected to the mains power system only. The Model P300 2.1 will automatically detect the voltage between 110-230v. Steinway & Sons P300 2.1 Owner’s manual... -
Page 7: Ventilation Requirements
Ventilation Requirements The Model P300 2.1 does not have a built-in fan, nor does it require special measures to ensure proper heat dissipation. However, it should be placed according to the guidelines below: It should always have at least one inch of free space on all sides. -
Page 8: Home Automation System Integration
P300 2.1 Serial Control Manual). Use Telnet, Putty, or similar programs to open the TCP connection. If you do not know the IP address of the Model P300 2.1 on your local network, the Model P300 2.1 supports Apple’s Bonjour Discovery service, which must be on the computer you want to set up the Model P300 2.1 with. -
Page 9: Rear Panel
Rear Panel On the back of the Model P300 2.1, you will find a range of inputs and outputs: Various optical, coaxial, and analog stereo audio inputs. 5 HDMI inputs and 2 HDMI outputs. eARC on HDMI OUT 1 1 trigger input and 4 trigger outputs... -
Page 10: Remote
Remote The Model P300 2.1 comes with a dedicated RF and IR remote control for installations and everyday use. Setup Access the installation menu. Standby Turn the Model P300 2.1 on and into standby. Audio Access the post-processing menu. “Picture-in-picture” and other multi-view formats. -
Page 11: How To Pair Remote
How to Pair Remote The remote control is paired to the Model P300 2.1 at the factory, and you only need to pair it again if you have a new Model P300 2.1 or remote. To pair the RF remote control to a Model P300 2.1: Turn on the Model P300 2.1. -
Page 12: Setup Procedure
Connect all external equipment, such as a Blu-ray player or home automation system, to the Model P300 2.1, including inputs, outputs, and mains. Connect power to the Model P300 2.1, the amplifiers, and all connected audio and video sources. Switch on the Model P300 2.1. -
Page 13: Installation Via Osd
If you do not know the IP address of the Model P300 2.1 on your local network, the Model P300 2.1 supports Apple’s Bonjour Discovery service, which must be on the computer you want to set up the Model P300 2.1 with. -
Page 14: Home Screen
The SETUP screen refers to all basic settings and option in the installation of the processor. Source In the Source menu, you can register the individual sources connected to the Model P300 2.1 by the audio and/or video input sockets they use. -
Page 15: Video Input
This procedure must be followed for all connected sources. Edit Edit all enabled sources. Arrange Arrange the order of sources by making a prioritized list. Delete Delete enabled sources. Remember to press accept after making selections. Steinway & Sons P300 2.1 Owner’s manual... -
Page 16: Speaker And Room
Speaker and Room The Speaker and Room menu provides information about the current speaker configuration, allowing you to select a configuration that is stored on the Model P300 2.1, on a laptop, or on a connected memory stick. Speaker Configuration Manage Add or delete speaker config files. - Page 17 If the subwoofers are lower than the listening position, measure the distance from the listening position to the top dust cap of the top subwoofer. If in doubt, contact your Steinway Lyngdorf representative for guidance. Do not measure distances at floor level, as these measurements will not give acoustically accurate results.
-
Page 18: How To Set Up Roomperfect
The RoomPerfect™ microphone is a very sensitive and finely calibrated device which must be treated with utmost care. If the microphone has been dropped on the floor, it may be damaged. If this is the case, obtain a new microphone from your Steinway Lyngdorf representative before performing the system calibration. -
Page 19: Measuring The Focus Position
The microphone should be in random and varying positions, heights, and orientations. Point it up/down/sideways, the more random positions the better. The measurements should cover the entire room, not only your listening area. Do not take measurements behind plants, furniture, etc. Steinway & Sons P300 2.1 Owner’s manual... -
Page 20: Calculation Of Focus And Global Filters
There should be at least 50cm/1.5ft between each measurement. Do not take symmetrical measurements in the room. Calculation of Focus and Global Filters When room measurements are complete, the system will calculate the focus and global filters automatically. Steinway & Sons P300 2.1 Owner’s manual... -
Page 21: Video Setup
Video Setup The Video Setup menu allows you to register the video system settings for the Model P300 2.1 video inputs and outputs, which in turn dictates which video formats can be shown on the screen when these inputs and outputs are activated. -
Page 22: Audio
HDMI Bandwidth If the HDMI signal chain cannot support the full resolution due to cable length or connected components, you can limit the maximum bandwidth to 300 MHz or 150 MHz to avoid dropouts. Steinway & Sons P300 2.1 Owner’s manual... -
Page 23: Audio Setup
This equalization is an addition to the RoomPerfect™ corrections. Voicings can be edited, deleted, added or loaded in the Model P300 2.1. Editing and adding voicings In the intuitive GUI for the voicing tool, you can edit or add a voicing by combining up to eight filter sections. -
Page 24: System Configuration
Enable front IR sensor Turn the Model P300 2.1’s IR sensor Off or On. This function is useful if you are using a home automation system and other remotes are using the same IR codes as the Model P300 2.1 remote. -
Page 25: Osd Info Level
Allows you to set up the system so that it can be switched on via an external device in the system. Trigger Out Setup Allows you to set up the system so that the Model P300 2.1 can control other devices in the system. Network Configuration Change the network mode to “Manual”... -
Page 26: Manage Software
Please don’t unzip or change the name of the file. Simply save it and upload it to the Model P300 2.1. If you are using a Mac, please right-click and “save as” rather than downloading the file to avoid automatic unzipping. -
Page 27: Update Via Osd Interface
Select the file in the menu and press OK on the remote control. Note: System settings and RoomPerfect™ data remain intact during software updates. Update from Remote Files When connected to the internet, the Model P300 2.1 can automatically download and update the software. Steinway & Sons P300 2.1 Owner’s manual... -
Page 28: Troubleshooting
Raise the measuring signal volume or reduce the noise in the environment before continuing with the measurement. Steinway & Sons P300 2.1 Owner’s manual... -
Page 29: Can't Turn On Via Lan Or Control System
Can’t Turn on via LAN or Control System The Model P300 2.1 needs to be set to Network mode to be able to turn on via a control system. It will not turn on when in Deep Sleep. This is set up in Device Management -> Power. -
Page 30: Network Setup
Connecting to Model P300 2.1 with a Network Cable It is possible to get access to the Model P300 2.1’s web interface via a direct cable connection between the Model P300 2.1 and a computer, or a connection via a hub or switch. -
Page 31: Set Up A Fixed Ip Address In Windows Xp Or Windows 7
Click “Use the following IP address” and enter the following: IP address: 192.168.1.2 Subnet mask: 255.255.255.0 Default gateway: 192.168.1.1 Click “OK” to close the configuration windows. You should now be able to access the Model P300 2.1 via your Internet browser. Steinway & Sons P300 2.1 Owner’s manual... -
Page 32: Set Up A Fixed Ip Address In Windows Vista Or Windows 10
Click “Use the Following IP address” and enter the following: IP address: 192.168.1.2 Subnet mask: 255.255.255.0 Default gateway: 192.168.1.1 Click “OK” to close the configuration windows. You should now be able to access the Model P300 2.1 via your Internet browser. Steinway & Sons P300 2.1 Owner’s manual... -
Page 33: Trademarks
Macrovision. Reverse engineering or disassembly is prohibited. This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. Steinway & Sons P300 2.1 Owner’s manual... -
Page 34: Service Information
Service Information In order to obtain warranty service, you must contact your original dealer or the Steinway Lyngdorf distributor of the region or country where you are located. If you have trouble locating an authorized representative, please contact service@steinwaylyngdorf.com. Steinway Lyngdorf... - Page 35 Steinway & Sons P300 2.1 Owner’s manual...
