- Page 1 TITAN INDUSTRIAL RACK 6-FOOT TALL / 4-SHELF DXST10000 INSTRUCTION IMPORTANT: Please read this manual carefully before assembling this MANUAL storage rack and save it for reference...
- Page 3 TABLE OF CONTENTS TECHNICAL SPECIFICATIONS SAFETY PARTS LIST ASSEMBLY OPTIONS WARRANTY SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions. Read all instructions and follow them with use of this product.
-
Page 4: Technical Specifications
DXST10000 TECHNICAL SPECIFICATIONS TOTAL CAPACITY 10,000 lb (4,535.9 kg) *WHEN WEIGHT IS EVENLY DISTRIBUTED CAPACITY PER SHELF 2,500 lb (1,133.9 kg) *WHEN WEIGHT IS EVENLY DISTRIBUTED HEIGHT 72” (182.8 cm) WIDTH 77" (195 cm) DEPTH 24" (61 cm) WEIGHT 180.78 lb (82 kg) -
Page 5: General Safety
GENERAL SAFETY • Keep work area clean and dry. • Use correct/recommended tools for the job. • Never leave tools unattended. • Never force a part into place. • Wear safety apparel. • Wear safety glasses/goggles. • Never crawl, sit, stand, or climb on a rack. •... -
Page 6: Before You Begin
DXST10000 No. Description No. Description Qty. Qty. Vertical Beam Locking Shelf Pin Pre-Bolted Vertical Assembly Locking Grid Clip Vertical Assembly Bolt Carriage Bolt Crossbeam 10 mm Nut 10 mm Wrench Shelf Support Strap Safety Strap With Weld Nut 4 mm Hex Key... - Page 7 Tools Required for Rack Assembly: 4 mm Hex Key (included) OR 4 mm Hex Bit (included); Rubber Mallet (not included)
- Page 8 DXST10000 EXPANDABLE UPRIGHT FRAME INSTRUCTIONS • Note: For ease of assembly, two (2) Vertical Beams feature pre-bolted horizontal and diagonal beams. 2 ft (61 cm) (60.9 CM) STEP 1 • Place one (1) Vertical Beam and one (1) Pre-Bolted Vertical Beam on the floor, parallel to one another (about 24”/60.9 cm...
- Page 9 CROSSBEAM INSTRUCTIONS • Note: It is recommended for one person to hold the upright frames in place while a second person installs the crossbeams. LOCKING PIN HOLE STEP 1 • There is a set of locking tabs at both ends of every crossbeam.
- Page 10 DXST10000 SHELF SUPPORT AND SAFETY STRAP INSTRUCTIONS • Note: There are five (5) Shelf Support Straps and three (3) Safety Straps with Weld Nuts for every set of crossbeams. STEP 1 • Starting with the lowest set of crossbeams, place one shelf support strap perpendicular to the crossbeams and insert each end into the slots on each side of the crossbeam.
-
Page 11: Wall Mounting Instructions
WALL MOUNTING INSTRUCTIONS • Note: Drywall anchors and anchor screws are included with this rack; however, different wall materials require different types of fasteners. Use fasteners suitable for your specific type of wall. If you are uncertain about what type of fasteners to use, then please contact your local hardware store. - Page 12 DXST10000 LAMINATE DECK INSTRUCTIONS • Please the first laminate deck onto the top ridge of any set of crossbeams. If seated properly, it will “pop” into place and lay evenly. WIRE GRID INSTRUCTIONS • Note: Each wire grid consists of two sides. On one side, the wire runs the length of the crossbeams (the long side).
- Page 13 MAXIMIZE YOUR DEWALT STORAGE OPTIONS NOTE: Connect multiple racks together to create the ultimate storage solution.
-
Page 14: One-Year Limited Warranty
DXST10000 ONE YEAR LIMITED WARRANTY DEWALT will replace this industrial rack due to faulty materials or workmanship for one year from the date of purchase (please be sure to keep your receipt). This warranty does not cover part failure due to normal wear or rack abuse. This warranty does not apply to accessories or damage caused where repairs have been made or attempted.
