DLE DLE20 User Manual

DLE20

DLE20RA

Users Manual

SAFETY NOTICE

This engine is not toy. For your own safety, please read the manual carefully before oper-

ation. Never allow children under the age of 18 to operate this engine without supervi-

sion. You are responsible for the safe operation of this engine.

Before every use, check the engine assembly, propeller and airframe carefully for loose

screws and nuts. Loctite 242 Blue (or similar) is strongly recommended on all the screws.

Table of Contents

Do you have a question about the DLE20 and is the answer not in the manual?

Page 1 DLE20 DLE20RA Users Manual SAFETY NOTICE This engine is not toy. For your own safety, please read the manual carefully before oper- ation. Never allow children under the age of 18 to operate this engine without supervi- sion. You are responsible for the safe operation of this engine.
Page 2 ENGINE MOUNTING During the break-in process the engine must be installed in an environment where vibration can be ab- sorbed i.e. in the model or with soft mount if bench running. Hard mounting to a bench without adequate vibration damping may cause vibration damage to internal parts and shorten the life of the engine. The best way for break-in process is mount the engine in the model.
Page 3 ENGINE ADJUSTMENT Every engine has been adjusted to average mixture settings which will most likely allow the engine to start and run in most locations. However, as altitudes and barometric pressures vary by location, it is very likely that the carburetor mixture settings will need to be adjusted to obtain optimum performance. (1) Choke Lever (2) Throttle Lever (3) Idle Speed Adjustment Screw...
Page 4 (inlet side of the carburetor), gasket and pump membrane. The screen will be visible and can be cleaned WARRANTY INFORMATION All the DLE engines enjoy one year parts and labour warranty when run as per factory instructions, used with specified propellers, correct lubricants and lubricant ratios.
