Planet WDAP-C7210E User Manual

1200mbps 802.11ac wavw 2 dual band w/802.3at poe+
Hide thumbs Also See for WDAP-C7210E:
Table of Contents

Advertisement

Quick Links

Download this manual
1200Mbps 802.11ac Wave 2 Dual Band
Wireless Access Point w/802.3at PoE+
WDAP-C7210E
WDAP-W1200E
WDAP-850AC

Advertisement

Table of Contents
loading

Related Manuals for Planet WDAP-C7210E

Summary of Contents for Planet WDAP-C7210E

  • Page 1 1200Mbps 802.11ac Wave 2 Dual Band Wireless Access Point w/802.3at PoE+ WDAP-C7210E WDAP-W1200E WDAP-850AC...
  • Page 2 Copyright Copyright  2020 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User Manual of PLANET 802.11ac Dual Band Ceiling-mount Wireless Access Point Model: WDAP-C7210E/WDAP-W1200E/WDAP-850AC Rev: 3.0 (Nov., 2021) Part No. EM-WDAP-C7210E_ WDAP-W1200E_WDAP-850AC _v1.1...
  • Page 4 CONTENTS Chapter 1.Product Introduction ......................1 Package Contents ....................... 1 Product Description ......................3 Product Features ......................... 9 Chapter 2.Hardware Installation ......................19 Product Outlook ........................ 19 Chapter 3.Connecting to the AP ......................22 System Requirements ...................... 26 Installing the AP ........................ 26 Chapter 4.Quick Installation Guide ....................
  • Page 5 Appendix A: Planet Smart Discovery Utility ................... 101 Appendix B: FAQs ..........................102 Q1: How to Set Up the AP Client Connection ................ 102 Q2: How to Set Up the WDS Connection ................108 Appendix C: Troubleshooting ......................114 Appendix D: Glossary ........................116...
  • Page 6 FIGURE 2-1 WDAP-C7210E T ..................... 19 IGURE RIPLE IEWING 2-2 WDAP-C7210E F ......................20 IGURE RONT ANEL 2-3 WDAP-C7210E R ......................21 IGURE ANEL 3-1 M ......................... 26 IGURE OUNTING THE RACKET 3-2 C ....................27 IGURE ONNECTING THE THERNET...
  • Page 7 6-13 C ....................... 94 IGURE ONNECTED TO THE ETWORK 6-14 S ........................95 IGURE YSTEM REFERENCES 6-15 S -- N ....................95 IGURE YSTEM REFERENCES ETWORK 6-16 S ..................... 96 IGURE ELECTING THE IRELESS ETWORK 6-17 – S ......................... 97 IGURE HONE ETTINGS ICON...
  • Page 8 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Chapter 1. Product Introduction Package Contents Thank you for choosing PLANET Wireless AP. Please verify the contents inside the package box. Package Contents of WDAP-C7210E Package Contents of WDAP-W1200E...
  • Page 9 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Package Contents of WDAP-850AC If there is any item missing or damaged, please contact the seller immediately.
  • Page 10 WDAP-C7210E provides a maximum wireless speed of 867Mbps at 5GHz and 300Mbps at 2.4GHz. Benefits of MU-MIMO under 802.11ac Wave 2 With the MU-MIMO Wave 2 technology, the WDAP-C7210E, installed in public areas such as hotspots, airports and conferences, reduces the frustration that Wi-Fi users often experience in downloading web pages, e-mail file attachments and media contents.
  • Page 11 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Powerful Dual-band WLAN Solution PLANET WDAP-C7210E, adopting the IEEE 802.11ac Wave 2 standard, provides a high-speed transmission of power and data, meaning two remote nodes in the 5GHz frequency band can be bridged. The 2.4GHz wireless connection can also be used simultaneously.
  • Page 12 WDAP-C7210E can be powered and networked by a single UTP cable, effectively eliminating the needs of dedicated electrical outlets on the ceiling and reducing the cabling cost. Furthermore, the system administrator is able to arrange the PoE schedule of the WDAP-C7210E by working with the managed PoE switch.
  • Page 13 With the automatic transmission power mechanism, distance control and scheduled reboot setting, the WDAP-C7210E is easy for the administrator to deploy and manage without on-site maintenance. Moreover, you can use PLANET NMS-500 or NMS-1000V AP control function to deliver wireless...
  • Page 14 Extremely High-speed and Dual Band Make Wi-Fi Transmission More Powerful The WDAP-C7210E delivers the dual band technology to avoid signal interference and ensure the best Wi-Fi performance. It allows you to check e-mails and surf the Internet via the 2.4GHz band and simultaneously watch high-definition (HD) video and any other multimedia application via 5GHz band.
  • Page 15 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC...
  • Page 16 Supports DMZ and Port forwarding  Bandwidth control per IP address to increase network stability Easy Deployment and Management  Supports PLANET AP Controllers in AP mode  Easy discovery by PLANET Smart Discovery  Self-healing mechanism through system auto reboot setting ...
  • Page 17 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Product Specifications WDAP-C7210E Product 1200Mbps 802.11ac Wave 2 Dual Band Ceiling-mount Wireless Access Point Hardware Specifications 2 x 10/100/1000BASE-T RJ45 port Interfaces Auto-negotiation and auto MDI/MDI-X Antennas Gain: 4 x Internal 5dBi antenna (2.4G x2, 5G x2)
  • Page 18 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC ETSI: < 20dBm (EIRP) (dBm) Network Mode Data Rate Receive Sensitivity (dBm) 2.4GHz 1Mbps 802.11b 11Mbps 6Mbps 802.11g 54Mbps MCS0/MCS8 802.11n HT20 MCS7/MCS15 MCS0/MCS8 802.11n HT40 MCS7/MCS15 5GHz 6Mbps Receive Sensitivity 802.11a 54Mbps MCS0/MCS8 802.11n HT20 MCS7/MCS15 MCS0/MCS8 802.11n HT40...
  • Page 19 IEEE 802.1Q VLAN (VID: 3~4094) VLAN SSID-to-VLAN mapping up to 4 SSIDs Self-healing Supports auto reboot settings per day/hour Remote management through PLANET DDNS/ Easy DDNS Configuration backup and restore Supports UPnP Management Supports IGMP Proxy Supports PPTP/L2TP/IPSec VPN Pass-through...
  • Page 20 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC WDAP-W1200E Product Dual Band 802.11ac 1200Mbps Wave 2 In-wall Wireless Access Point (EU Type, 802.3af/at) Hardware Specifications 2 x 10/100/1000BASE-T RJ45 port Auto-negotiation and auto MDI/MDI-X 1 x 10/100/1000Mbps auto MDI/MDI-X RJ45 port (rear panel) Interfaces PoE Port ※...
  • Page 21 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 1Mbps 802.11b 11Mbps 6Mbps 802.11g 54Mbps MCS0/MCS8 802.11n MCS7/MCS15 MCS0/MCS8 802.11n HT40 MCS7/MCS15 5GHz 6Mbps 802.11a 54Mbps MCS0/MCS8 802.11n HT20 MCS7/MCS15 MCS0/MCS8 802.11n HT40 MCS7/MCS15 MCS0 802.11ac VHT20 MCS8 MCS0 802.11ac VHT40 MCS9 MCS0 802.11ac VHT80 MCS9 Software Features Static IP/DHCP Client...
  • Page 22 IEEE 802.1Q VLAN (VID: 3~4094) VLAN SSID-to-VLAN mapping to up to 4 SSIDs Self-healing Supports auto reboot settings per day/hour Remote management through PLANET DDNS/Easy DDNS Configuration backup and restoration Supports UPnP Management Supports IGMP Proxy Supports PPTP/L2TP/IPSec VPN Pass-through...
  • Page 23 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC WDAP-850AC Product 1200Mbps Dual Band 802.11ac Wave 2 Outdoor Wireless AP Hardware IEEE 802.11ac IEEE 802.11n IEEE 802.11a IEEE 802.11b IEEE 802.11g Standard Support IEEE 802.11i IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x flow control Material Aluminum Dimensions (W x D x H)
  • Page 24 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 2.4GHz: FCC: 1~11 Channels ETSI: 1~13 Channels 5GHz: Operating Channels FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165 (9 Channels) ETSI: 36, 40, 44, 48, 100, 104, 108, 112, 116, 132, 136, 140 (12 Channels) 5GHz channel list may vary in different countries depending on their regulations.
  • Page 25 Supports auto reboot settings per day/hour Supports PLANET Hardware Controller Applicable controllers :WS-1232P/WS-2864PVR/NMS-500/NMS-1000V Remote management through PLANET DDNS/ Easy DDNS Configuration backup and restoration Management Supports UPnP Supports IGMP Proxy Supports PPTP/L2TP/IPSec VPN pass-through SNMP v1/v2c/v3 support, MIB I/II, Private MIB Remarks...
  • Page 26 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Chapter 2. Hardware Installation Product Outlook WDAP-C7210E Dimensions: 186 x 186 x 35.8mm Weight: 380 ±5g  Triple Viewing Figure 2-1 WDAP-C7210E Triple Viewing -19-...
  • Page 27 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC  Front Panel Figure 2-2 WDAP-C7210E Front Panel LED Definition STATUS FUNCTION On ( The access point is on. System is operating. Wireless LAN is initializing. Blinking (Blue/Green) 2.4GHz/5GHz wireless LAN is working. -20-...
  • Page 28 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC  Rear Panel Figure 2-3 WDAP-C7210E Rear Panel  Bottom Panel Figure 2-4 WDAP-C7210E Bottom Panel Port definition Object Description 12V DC 12V DC port for the power adapter( DC-Jack 5.5 x 2.1mm ) The access point is on.
  • Page 29 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC WDAP-W1200E Dimensions(W x D x H): 86 x 45 x 86 mm Weight: 168 ±5g Front Panel Rear Panel -22-...
  • Page 30 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4-wire RJ11 Connection diagram LED definition STATE FUNCTION Power On Power Off On/Flash WAN connected / data transmitting WAN disconnected On/Flash LAN 1 connected / data transmitting LAN 1 LAN 1 port disconnected On/Flash LAN 2 connected / data transmitting LAN 2 LAN 2 port disconnected Button definition...
  • Page 31 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC WDAP-850AC Dimensions(W x D x H): 231 x 80 x 295 mm Weight: 2.3kg ± 0.1kg Appearance -24-...
  • Page 32 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Port & Connector Hardware Interface Definition Object Description Antenna Connectors 4 N-type (female) antenna connectors 10/100/1000Mbps RJ45 port, auto MDI/MDI-X PoE LAN Port 802.3at PoE+ supported, 48VDC In Press and hold the Reset button for over 10 seconds to return to the Reset Button factory default setting.
  • Page 33 PCs running Windows 98/ME, NT4.0, 2000/XP, Windows Vista / Win 7, MAC OS 9 or later, Linux, UNIX or other platforms compatible with TCP/IP protocols 1. The AP in the following instructions refers to PLANET WDAP-C7210E. (Please refer to WDAP-W1200E/WDAP-850AC QIG to install the AP) 2.
  • Page 34 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 2. Load the device into the mounting bracket, and be sure the device is mated with fixed screws. Then, lock the device in position and plug the Ethernet cable into the WDAP-C7210E. Figure 3-2 Connecting the Ethernet Cable Step 3.
  • Page 35 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your AP within minutes. A computer with wired Ethernet connection to the Wireless AP is required for the first-time configuration.
  • Page 36 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 4-1 TCP/IP Setting Now click OK to save your settings. Now, you can run the ping command in the command prompt to verify the network connection between your PC and the AP. The following example is in Windows 10 OS. Please follow the steps below: Click on Start >...
  • Page 37 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 4-2 Windows Start Menu Open a command prompt, type ping 192.168.1.253 and then press Enter. If the result displayed is similar to Figure 4-3, it means the connection between your PC and the AP has been established well. Figure 4-3 Successful Result of Ping Command -30-...
  • Page 38 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC If the result displayed is similar to Figure 4-4, it means the connection between your PC and the AP has failed. Figure 4-4 Failed Result of Ping Command If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your AP. Some firewall software programs may block a DHCP request on newly installed adapters.
  • Page 39 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Starting Setup in the Web UI It is easy to configure and manage the AP with the web browser. Step 1. To access the configuration utility, open a web-browser and enter the default IP address http://192.168.1.253 in the web address field of the browser.
  • Page 40 Chapter 4. Configuring the AP This chapter delivers a detailed presentation of AP’s functionalities and features 3 main items below, allowing you to manage the AP with ease. (The below web GUI and topology uses WDAP-C7210E as an example) Figure 5-1 Main Menu...
  • Page 41 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Wizard The Wizard guides you to configuring the WDAP Series in a different mode, including Gateway, Super WDS, WISP, Repeater, AP modes. Figure 5-2 Operation Mode The default operation mode is AP Mode. -34-...
  • Page 42 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Gateway Mode (Router) Click “Wizard”  “Gateway Mode” and the following page will be displayed. This section allows you to configure the Gateway mode. Figure 5-3 Gateway Mode -35-...
  • Page 43 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.2.1 WAN Settings Static IP If your ISP offers you static IP Internet connection type, select “Static IP" and then enter IP address, subnet mask, default gateway and primary DNS information provided by your ISP in the corresponding fields. Figure 5-4 Gateway -- Static IP The page includes the following fields: Object...
  • Page 44 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-5 Gateway – PPPoE (ADSL) The page includes the following fields: Object Description Username Enter the PPPoE User Name provided by your ISP Password Enter the PPPoE password provided by your ISP Server Name Enter the server name by your ISP, or not Service Name Enter the service name by your ISP, or not -37-...
  • Page 45 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC DHCP Choose “DHCP” and the router will automatically obtain IP addresses, subnet masks and gateway addresses from your ISP. Figure 5-6 Gateway – DHCP 4.2.2 Wireless -38-...
  • Page 46 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-7 Gateway – Wireless The page includes the following fields: Object Description Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN It is the wireless network name. The default SSID is PLANET_2.4G SSID and PLANET_5G Hide your SSID...
  • Page 47 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Super WDS Mode In the Super WDS mode, the wireless interface can be connected with other wireless APs through WDS, and the wireless interface and cable interface. Click “Wizard”  “Super WDS Mode” and the following page will be displayed.
  • Page 48 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description Select Network Select network for using 2.4G or 5G to do connection. WDS SSID It is the WDS wireless network name. The default SSID is “Wireless2.4G_WDS” or “Wireless5.8G_WDS”. AP BSSID/Mark Press the “Scan”...
  • Page 49 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-10 Super WDS Mode – 5G SSID The page includes the following fields: Object Description Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN SSID It is the wireless network name. The default SSID is “PLANET_5G” Hide your SSID Select ON (Green) or OFF (Gray) to hide wireless LAN or not Bandwidth...
  • Page 50 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-17 Super WDS Mode The page includes the following fields: Object Description IP Mode Select “Static IP” or “DHCP Client” for setting up device IP Set time to restart Timing Connection section for example, AP1 – Enter the WDS SSID and encrypt password. -43-...
  • Page 51 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-18 Super WDS Mode – AP1 AP2 -- Press the “Scan” button to find AP1 BSSID and choose it to connect. Enter the encrypt password. Figure 5-19 Super WDS Mode – AP2 -44-...
  • Page 52 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC WISP Mode Click “Wizard”  “WISP Mode” and the following page will be displayed. This section allows you to configure the WISP mode. -45-...
  • Page 53 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-20 WISP Mode The page includes the following fields: Object Description Bandwidth Select network for using 2.4G or 5G to do connection. Repeater SSID Enter the root AP’s SSID or press “Scan” to select. Check to lock the root AP’s MAC address. Lock BSSID Encryption Select...
  • Page 54 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-21 WISP Mode – Select Internet Mode (Set up WAN type) -47-...
  • Page 55 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-22 WISP Mode – Setting up Wi-Fi -48-...
  • Page 56 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Repeater Mode (Universal Repeater) Click “Wizard”  “Repeater Mode” and the following page will be displayed. This section allows you to configure the Repeater mode. -49-...
  • Page 57 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-23 Repeater Mode The page includes the following fields: Object Description Select Network Select “2.4G” or “5.8G” wireless LAN. Repeater SSID Enter the root AP’s SSID or press “Scan” to select. Lock BSSID Check to lock the root AP’s MAC address. Encryption Select wireless...
  • Page 58 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-24 Repeater Mode -- Scan Root AP -51-...
  • Page 59 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Set up the repeater wireless network Figure 5-25 Repeater Mode – Setting up Wi-Fi -52-...
  • Page 60 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN. SSID It is the wireless network name. The default SSID is “PLANET_5G”. Hide your SSID Select ON (Green) or OFF (Gray) to hide wireless LAN or not.
  • Page 61 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description IP Mode Select “Static IP” or “DHCP Client” for setting up device IP. LAN IP Enter the AP static IP address. Subnet Enter the network mask. Gateway Enter the default gateway IP address. Enter the primary DNS IP address, or not.
  • Page 62 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC AP Mode In the AP mode, the AP wireless interface and cable interface bridge together. Click “Wizard”  “AP Mode” and the following page will be displayed. This section allows you to configure the AP mode. Figure 5-27AP Mode -55-...
  • Page 63 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description IP Mode Select “Static IP” or “DHCP Client” for setting up device IP. LAN IP Enter the AP static IP address. Subnet Enter the network mask. Gateway Enter the default gateway IP address. Enter the primary DNS IP address, or not.
  • Page 64 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-28 AP Mode – Set up Wi-Fi The page includes the following fields: Object Description Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN. SSID It is the wireless network name. The default SSID is “PLANET_5G”. Hide your SSID？...
  • Page 65 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Wi-Fi 4.7.1 2.4G/5G Wi-Fi 4.7.1.1. Basic Figure 5-29 Basic -58-...
  • Page 66 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN. SSID It is the wireless network name. The default SSID is “PLANET_2.4G” or “PLANET_5G”. Hide your SSID？...
  • Page 67 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.2 MAC ACL 4.7.2.1. MAC ACL Figure 5-11 MAC ACL The page includes the following fields: Object Description Press the “Add” button to add end-device that is scanned from wireless network and mark them. Delete Press the “Delete” button to delete device from list. Apply Press the “Apply”...
  • Page 68 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.3 Wi-Fi Timer Off 4.7.3.1. Wi-Fi Timer Off Figure 5-33 Wi-Fi Timer Off The page includes the following fields: Object Description Wi-Fi Timer Off Select ON (Green) or OFF (Gray) to enable or disable timer. Time Frame Choose the time frame of Wi-Fi.
  • Page 69 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.4 Advanced 4.7.4.1. Advanced Figure 5-34 Advanced The page includes the following fields: Object Description 2.4G Mode Select 802.11B/G or 802.11N/G in CPE. 5G Mode Select 802.11A or 802.11AN or 802.11AC in CPE. Maximum 2.4G per AP The maximum users are 64.
  • Page 70 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 5G TX Power The range of transmit power is Max (100%), Efficient (75%), Enhanced (50%), Standard (25%) or Min (12.5%). In case of shortening the distance and the coverage of the wireless network, input a smaller value to reduce the radio transmission power. Multicast Fast A part of the 802.11n standard that allows sending multiple frames per single access to the medium by combining frames together into one...
  • Page 71 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.5 Network 4.7.5.1. LAN Settings Figure 5-35 LAN Settings The page includes the following fields: Object Description IP Mode Select “Static IP” or “DHCP Client” for setting up device IP. Enter the AP static IP address. LAN IP Subnet Enter the network mask.
  • Page 72 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description Read Community Enter the read community, default is public. Write Community Enter the write community, default is private. Trap Destination Address Enter the SNMP trap IP address, default is 192.168.1.100. 4.7.5.3.
  • Page 73 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.5.4. WAN Settings Static IP If your ISP offers you static IP Internet connection type, select “Static IP" and then enter IP address, subnet mask, default gateway and primary DNS information provided by your ISP in the corresponding fields. Figure 5-38 Static IP The page includes the following fields: Object...
  • Page 74 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-39 PPPoE (ADSL) The page includes the following fields: Object Description Username Enter the PPPoE User Name provided by your ISP. Password Enter the PPPoE password provided by your ISP. Server Name Enter the server description or not. Service Name Enter the service description or not.
  • Page 75 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-40 DHCP The page includes the following fields: Object Description Maximum Transmission Unit. Default is 1452. Set DNS Manually Enable/Disable DNS Manually. Primary DNS Enter the necessary DNS address provided by your ISP. Secondary DNS Enter the secondary DNS address provided by your ISP.
  • Page 76 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description Enable web server access on Enable to access from WAN, default port is 8080 WAN port MAC clone Enable and scan to clone the MAC address Enable Ping Access on WAN Enable or Disable this function Enable IPsec passthrough on Enable or disable IPSec to pass through IPSec communication data.
  • Page 77 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-24 URL Filtering The page includes the following fields: Object Description Press the “Add” button to add the rule Delete Press the “Delete” button to delete the rule Apply Press the “Apply” button to enable/disable the rule Status Select ON (Green) or OFF (Gray) to enable or disable Rule Name...
  • Page 78 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.6.2. IP/Port Filtering Figure 5-44 IP/Port Filtering The page includes the following fields: Object Description Press the “Add” button to add the rule in the black or white list Delete Press the “Delete” button to delete the rule Apply Press the “Apply”...
  • Page 79 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Port Range Enter the web port to access Protocol Select TCP, UDP or TCP+UDP Mark Enter the mark string, or not IP/Port Filtering Status Select the rule of IP/Port Filtering, default is Disable. Whitelist: Allow the devices to pass in the rule Blacklist: Prohibited rules within the device through Figure 5-45 IP/Port Filtering 4.7.6.3.
  • Page 80 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-46 MAC Filtering The page includes the following fields: Object Description Press the “Add” button to add the rule in the black or white list Delete Press the “Delete” button to delete the rule Apply Press the “Apply”...
  • Page 81 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-47 IP/Port Filtering 4.7.6.4. Security (Port Mapping/Port Forwarding) Figure 5-48 Port Mapping The page includes the following fields: Object Description Press the “Add” button to add the rule in the black or white list Delete Press the “Delete”...
  • Page 82 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC LAN IP Enter the IP address that you need for port forwarding External Port Enter the external port range Internal Port Enter the internal port range Mark Enter the mark string, or not Enable/disable Port Mapping function Figure 5-49 Port Mapping 4.7.6.5.
  • Page 83 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.7 Management 4.7.7.1. Configure Figure 5-14 Configure The page includes the following fields: Object Description Backup Save the configuration file to your computer Restore Reload the configuration from your computer Reset Default Restore the factory default settings, please press this button Enabling Telnet could be hacked, Use it carefully! Telnet (Only for support using, default is disable)
  • Page 84 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.7.2. Reboot Figure 5-15 Reboot The page includes the following fields: Object Description Reboot Reboot device immediately Timed Reboot Select Enable or Disable to start schedule reboot Reboot Time Select reboot time for clock Restart Interval Select reboot duty by day 4.7.7.3.
  • Page 85 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Confirm Password Enter new password again 4.7.7.4. Upgrade Figure 5-54 Upgrade Firmware The page includes the following fields: Object Description Choose File Press to select the firmware file Whether to resume the Select to reset the device to default when upgrading firmware factory configuration Upgrade Press to upgrade the firmware...
  • Page 86 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description System Time Show system time of device NTP Enable Select Enable or Disable NTP function Time Zone Select Select time zone Manual IP Settings Enable to manual IP setting NTP Server Select NTP server Sync with Host...
  • Page 87 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Export Export a log.bin file to you PC Delete Press to delete all of the system log Refresh Press to refresh the system log 4.7.7.7. Flow Control Figure 5-57 Setup Flow Control The page includes the following fields: Object Description Press the “Add”...
  • Page 88 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-59 Adding rule of flow control(Speed Limit) The page includes the following fields: Object Description Status Select enable or disable flow control rule IP Group Select custom or Add an IP group IP Address Enter an IP address range or use scan to select Time Group Select any or custom or Add a Time group Select limited mode for shared limited bandwidth or exclusive limited...
  • Page 89 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC 4.7.7.8. IP Group Figure 5-60 IP Group The page includes the following fields: Object Description Press the “Add” button to add IP group in list Delete Press the “Delete” button to delete the group Figure 5-17 Add IP Group -82-...
  • Page 90 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC The page includes the following fields: Object Description Group Name Enter an IP group description IP Address Enter an IP address range or use scan to select Mark Enter the mark string, or not 4.7.7.9. Time Group Figure 5-62 Time Group The page includes the following fields: Object...
  • Page 91 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-18 Add Time Group The page includes the following fields: Object Description Time Group Enter an time group description Time Range Select start time and end time for time range Work Date Select work day by option table Mark Enter the mark string, or not -84-...
  • Page 92 DDNS Option Select PLANET DDNS or Easy DDNS function User Name Enter user account for PLANET DDNS. If you use Easy DDNS it was not necessary. Password Enter password for PLANET DDNS. If you use Easy DDNS it was not necessary.
  • Page 93 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 5-65 PLANET EasyDDNS -86-...
  • Page 94 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Chapter 5. Quick Connection to a Wireless Network In the following sections, the default SSID of the WDAP series is configured to “default”. Windows XP (Wireless Zero Configuration) Step 1: Right-click on the wireless network icon displayed in the system tray Figure 6-1 System Tray –...
  • Page 95 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 4: Enter the encryption key of the wireless AP (1) The Wireless Network Connection box will appear (2) Enter the encryption key that is configured in section 5.7.2.1 (3) Click the [Connect] button Figure 6-3 Entering the Network Key Step 5: Check if “Connected”...
  • Page 96 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Windows 7/8/10 (WLAN AutoConfig) WLAN AutoConfig service is built-in in Windows 7 that can be used to detect and connect to wireless network. This built-in wireless network connection tool is similar to wireless zero configuration tool in Windows XP. Step 1: Right-click on the network icon displayed in the system tray Figure 6-5 Network Icon Step 2: Highlight and select the wireless network (SSID) to connect...
  • Page 97 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 4: Enter the encryption key of the wireless AP (1) The Connect to a Network box will appear. (2) Enter the encryption key that is configured in section 5.7.2.1 (3) Click the [OK] button. Figure 6-7 Typing the Network Key Figure 6-8 Connecting to a Network -90-...
  • Page 98 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 5: Check if “Connected” is displayed. Figure 6-9 Connected to a Network -91-...
  • Page 99 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Mac OS X 10.x In the following sections, the default SSID of the WDAP series is configured to “default”. Step 1: Right-click on the network icon displayed in the system tray The AirPort Network Connection menu will appear. Figure 6-10 Mac OS –...
  • Page 100 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 4: Enter the encryption key of the wireless AP (1) Enter the encryption key that is configured in section 5.7.2.1 (2) Click the [OK] button. Figure 6-12 Enter the Password If you will be connecting to this Wireless AP in the future, check [Remember this network].
  • Page 101 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 5: Check if the AirPort is connected to the selected wireless network. If “Yes”, then there will be a “check” symbol in front of the SSID. Figure 6-13 Connected to the Network -94-...
  • Page 102 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC There is another way to configure the MAC OS X wireless settings: Step 1: Click and open the [System Preferences] by going to Apple > System Preference or Applications Figure 6-14 System Preferences Step 2: Open Network Preference by clicking on the [Network] icon Figure 6-15 System Preferences -- Network -95-...
  • Page 103 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 3: Check Wi-Fi setting and select the available wireless network (1) Choose the AirPort on the left menu (make sure it is ON) (2) Select Network Name [default] here If this is the first time to connect to the Wireless AP, it should show “No network selected”. Figure 6-16 Selecting the Wireless Network -96-...
  • Page 104 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC iPhone/iPod Touch/iPad In the following sections, the default SSID of the WDAP series is configured to “default”. Step 1: Tap the [Settings] icon displayed in the home screen Figure 6-17 iPhone – Settings icon Step 2: Check Wi-Fi setting and select the available wireless network (1) Tap [General] \ [Network] (2) Tap [Wi-Fi] If this is the first time to connect to the Wireless AP, it should show “Not Connected”.
  • Page 105 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Figure 6-19 Wi-Fi Setting – Not Connected Step 3: Tap the target wireless network (SSID) in “Choose a Network…” (1) Turn on Wi-Fi by tapping “Wi-Fi” (2) Select SSID [default] Figure 6-20 Turning on Wi-Fi -98-...
  • Page 106 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 4: Enter the encryption key of the Wireless AP (1) The password input screen will be displayed. (2) Enter the encryption key that is configured in section 5.7.2.1 (3) Tap the [Join] button. Figure 6-21 iPhone -- Entering the Password -99-...
  • Page 107 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 5: Check if the device is connected to the selected wireless network. If “Yes”, then there will be a “check” symbol in front of the SSID. Figure 6-22 iPhone -- Connected to the Network -100-...
  • Page 108 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Appendix A: Planet Smart Discovery Utility To easily list the WDAP series in your Ethernet environment, the Planet Smart Discovery Utility is an ideal solution. The following installation instructions guide you to running the Planet Smart Discovery Utility.
  • Page 109 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Appendix B: FAQs Q1: How to Set Up the AP Client Connection Topology: -102-...
  • Page 110 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 1. Use static IP in the PCs that are connected with AP-1(Site-1) and AP-2(Site-2). In this case, Site-1 is “192.168.1.100”, and Site-2 is “192.168.1.200”. Step 2. In AP-2, change the default IP to the same IP range but different from AP-1. In this case, the IP is changed to 192.168.1.252.
  • Page 111 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC AP-2 Step 4. In AP-2, press Scan AP to search the AP-1. You can also enter the MAC address, SSID, encryption and bandwidth if you know what they are. -104-...
  • Page 112 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 5. Click “Next” to finish the setting. Step 6. Click “Repeater Information” to check connection status. 【Remark】If the signal was too high or too low that will effects the connection quality, please adjust the Tx power from web GUI or antenna to get best value about -60~-65 dBm. Wireless Signal Status Signal (dBm) Too Strong...
  • Page 113 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 7. Use command line tool to ping each other to ensure the link is successfully established. From Site-1, ping 192.168.1.200; and in Site-2, ping 192.168.1.100. Step 8. Configure the TCP/IP settings of Site-2 to “Obtain an IP address automatically”. -106-...
  • Page 114 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 9. Use command line tool to ping the DNS (e.g., Google) to ensure Site-2 can access internet through the wireless connection. The following hints should be noted: The encryption method must be the same as that of both sites if configured. Both sites should be Line-of-Sight.
  • Page 115 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Q2: How to set up the WDS Connection Topology: Step 1. Use static IP in the PCs that are connected with WDAP-C7210E-1 (Site-1) and WDAP-C7210E-2 (Site-2). In this case, Site-1 is “192.168.1.100”, and Site-2 is “192.168.1.200”. -108-...
  • Page 116 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 2. In AP-2, change the default IP to the same IP range but different from AP-1. In this case, the IP is changed to 192.168.1.252. Step 3. In both APs, go to “Wizard” to configure it in Super WDS Mode. Step 4.
  • Page 117 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 5. Finish the 2.4G/5G Wi-Fi and LAN setting. Step 6. Click “Home” to check WDS status. Step 7. In AP2 scan AP1 WDS SSID, for example WDS-1. Select Encrypt for WEP and enter password. -110-...
  • Page 118 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC -111-...
  • Page 119 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 8. Confirm SSID and MAC. Select Encrypt for WEP and enter password. Step 9. Finish the 5G Wi-Fi and LAN setting. Step 10. Go to “WDS Information” to check connection status. -112-...
  • Page 120 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Step 11. Use command line tool to ping each other to ensure the link is successfully established. From Site-1, ping 192.168.1.200; and in Site-2, ping 192.168.1.100. The following hints should be noted: The encryption method must be the same as that of both sites if configured. Both sites should be Line-of-Sight.
  • Page 121 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Appendix C: Troubleshooting If you find the AP is working improperly or stop responding to you, please read this troubleshooting first before contacting the dealer for help. Some problems can be solved by yourself within a very short time. Scenario Solution a.
  • Page 122 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Scenario Solution Try to use IP address instead of host name. If you can use IP address to communicate with a remote server, but can’t use host name, please check DNS setting. a. ‘Broadcast ESSID’ set to off? I can’t locate my AP by my b.
  • Page 123 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC Appendix D: Glossary  802.11ac wireless networking 802.11 under the - 802.11ac is a standard in the family (which is marketed brand name Wi-Fi), developed in the IEEE Standards Association process, providing high-throughput wireless local area networks 5 GHz band (WLANs) on the ...
  • Page 124 User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC  NAT (Network Address Translation) - NAT technology translates IP addresses of a local area network to a different IP address for the Internet.  PPPoE (Point to Point Protocol over Ethernet) - PPPoE is a protocol for connecting remote hosts to the Internet over an always-on connection by simulating a dial-up connection.
