Service and Maintenance Instructions
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . 2
UNIT ARRANGEMENT AND ACCESS . . . . . . . . . . . . 3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 3
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SUPPLY FAN (BLOWER) SECTION . . . . . . . . . . . . . . 4
Supply Fan (Direct-Drive) . . . . . . . . . . . . . . . . . . . . . . 4
COOLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Recommendation . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Evaporator Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
THERMOSTATIC EXPANSION VALVE (TXV) . . . . . 10
TXV Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacing TXV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Refrigerant System Pressure Access Ports . . . . . . 11
PURON (R-410A) REFRIGERANT . . . . . . . . . . . . . . 12
Refrigerant Charge . . . . . . . . . . . . . . . . . . . . . . . . . . 12
COOLING CHARGING CHARTS . . . . . . . . . . . . . . . . 12
COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Replacing Compressor . . . . . . . . . . . . . . . . . . . . . . . 14
Compressor Rotation . . . . . . . . . . . . . . . . . . . . . . . . 14
Filter Drier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Condenser-Fan Adjustment . . . . . . . . . . . . . . . . . . . 14
Troubleshooting Cooling System . . . . . . . . . . . . . . 15
CONVENIENCE OUTLETS . . . . . . . . . . . . . . . . . . . . 16
Convenience Outlets . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing Weatherproof Cover . . . . . . . . . . . . . . . . . 16
Non-Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Unit-Powered Type . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Duty Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fuse on Powered Type . . . . . . . . . . . . . . . . . . . . . . . 17
ELECTRIC HEATERS . . . . . . . . . . . . . . . . . . . . . . . . 17
Completing Heater Installation . . . . . . . . . . . . . . . . 18
SMOKE DETECTORS . . . . . . . . . . . . . . . . . . . . . . . . 19
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Smoke Detector Sensor . . . . . . . . . . . . . . . . . . . . . . 19
Smoke Detector Locations . . . . . . . . . . . . . . . . . . . . 19
Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
FIOP Smoke Detector Wiring and Response . . . . . 21
SENSOR AND CONTROLLER TESTS . . . . . . . . . . . 22
Sensor Alarm Test . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Controller Alarm Test . . . . . . . . . . . . . . . . . . . . . . . . 22
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53500275-01
Single Package Rooftop Electric Cooling Unit
Printed in U.S.A.
Form 50JC-4-6-01SM
with Puron
Dirty Controller Test . . . . . . . . . . . . . . . . . . . . . . . . .22
Dirty Sensor Test . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Changing the Dirt Sensor Test . . . . . . . . . . . . . . . . .22
Remote Station Test . . . . . . . . . . . . . . . . . . . . . . . . .22
SD-TRK4 Remote Alarm Test Procedure . . . . . . . . .22
Remote Test/Reset Station Dirty Sensor Test . . . . .23
Dirty Sensor Test Using an SD-TRK4 . . . . . . . . . . .23
Detector Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
PROTECTIVE DEVICES . . . . . . . . . . . . . . . . . . . . . . .24
Compressor Protection . . . . . . . . . . . . . . . . . . . . . . .24
Relief Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Control Circuit, 24-V . . . . . . . . . . . . . . . . . . . . . . . . .25
SYSTEMVU CONTROL SYSTEM . . . . . . . . . . . . . . . .25
SystemVu Interface . . . . . . . . . . . . . . . . . . . . . . . . . .25
Air Temperature Sensors . . . . . . . . . . . . . . . . . . . . . 25
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .25
COMPRESSOR VFD . . . . . . . . . . . . . . . . . . . . . . . . . .27
Drive Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Converter Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Filter Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Capacitor Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
ECONOMIZER SYSTEMS . . . . . . . . . . . . . . . . . . . . .35
EconoMi$er2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
PRE-START-UP/START-UP . . . . . . . . . . . . . . . . . . . .36
START-UP, GENERAL . . . . . . . . . . . . . . . . . . . . . . . .36
Unit Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Additional Installation/Inspection . . . . . . . . . . . . . .36
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Outdoor-Air Inlet Screens . . . . . . . . . . . . . . . . . . . . .36
Compressor Mounting . . . . . . . . . . . . . . . . . . . . . . . .36
Internal Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Refrigerant Service Ports . . . . . . . . . . . . . . . . . . . . . 36
Compressor Rotation . . . . . . . . . . . . . . . . . . . . . . . .37
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Ventilation (Continuous Fan) . . . . . . . . . . . . . . . . . .37
FASTENER TORQUE VALUES . . . . . . . . . . . . . . . . .37
START-UP, SYSTEMVU CONTROLS . . . . . . . . . . . .37
APPENDIX A - MODEL NUMBER
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . .38
APPENDIX B - PHYSICAL DATA . . . . . . . . . . . . . . .39
APPENDIX C - FAN PERFORMANCE . . . . . . . . . . .40
APPENDIX D - WIRING DIAGRAMS . . . . . . . . . . . .53
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . .CL-1
