Installation

FOUNDATION

Each Vyper Variable Speed Drive unit is shipped mounted
™
on a wooden skid, or mounted to the refrigeration package.
All shipping materials must be removed prior to unit instal-
lation. NOTE: Allow space for servicing both sides of the
Vyper Cabinet.
™
The Frick Vyper is offered in two mounting configurations.
™
The first mounting method is Package mounted. The units
are preassembled, prewired, and tested at the factory. Please
consult standard compressor package installation procedures
for this mounting method. The second mounting method is
Remote mounting where the Vyper
a steel stand specifically designed for the VSD. The primary
requirement for the Vyper
™
to support the weight of the cabinet and stand. In addition,
the remote stand and Vyper
that no more than 50 feet of motor wiring length is needed
between the VSD cabinet and the package motor.
Anchor bolts are recommended to firmly mount the unit to the
base. Anchoring the cabinet to a firm foundation by proper
leveling and employment of fastening bolts is the best as-
surance for trouble-free installation. Package-mounted units
are premounted at the factory. Remote-mounted units have
fastener holes located on the bottom feet for floor anchors,
and on the rear stand legs for wall anchoring of the stand.
Foundations must be in compliance with local building codes
and materials must be of industrial quality. All electrical
conduits must be metallic, no PVC or other materials are
permitted.
Model No.
VYA_PG_-46
VYA_RG_-46
VYA_PGF-46
VYA_RGF-46
VYB_PG_-50
VYB_RG_-50
VYB_PGF-50
VYB_RGF-50
VYC_PG_-46
VYC_RG_-46
VYC_PGF-46
VYC_RGF-46
VYD_PG_-50
VYD_RG_-50
VYD_PGF-50
VYD_RGF-50
VYPER
™ cabinet is mounted on
foundation is that it must be able
™ cabinet must be located so
Frick P/N
720C0105G05 305 HP, Liquid Cooled, 460 Volts, Package Mount
720C0105G06 305 HP, Liquid Cooled, 460 Volts, Remote Mount
720C0105G07 305 HP, Liquid Cooled, w/ Filter, 460 Volts, Package Mount
720C0105G08 305 HP, Liquid Cooled, w/ Filter, 460 Volts, Remote Mount
720C0105G17 254 HP, Liquid Cooled, 400 Volts, Package Mount
720C0105G18 254 HP, Liquid Cooled, 400 Volts, Remote Mount
720C0105G19 254 HP, Liquid Cooled, w/ Filter, 400 Volts, Package Mount
720C0105G20 254 HP, Liquid Cooled, w/ Filter, 400 Volts, Remote Mount
720C0133G05 437 HP, Liquid Cooled, 460 Volts, Package Mount
720C0133G06 437 HP, Liquid Cooled, 460 Volts, Remote Mount
720C0133G07 437 HP, Liquid Cooled, w/ Filter, 460 Volts, Package Mount
720C0133G08 437 HP, Liquid Cooled, w/ Filter, 460 Volts, Remote Mount
720C0133G17 362 HP, Liquid Cooled, 400 Volts, Package Mount
720C0133G18 362 HP, Liquid Cooled, 400 Volts, Remote Mount
720C0133G19 362 HP, Liquid Cooled, w/ Filter, 400 Volts, Package Mount
720C0133G20 362 HP, Liquid Cooled, w/ Filter, 400 Volts, Remote Mount
VARIABLE SPEED DRIVE
™
INSTALLATION
The Vyper ™
top sides of the cabinet. Special care must be exercised not
to damage the pump or peripheral equipment on the rear of
the cabinet. Never move the unit by pushing or forking against
the Vyper ™
FRICK VYPER
VYA_RGF_46
UNIT (WITH FIlTER) WEIGHTS (lb)
MODEl
305/254
437/362
Description

RIGGING AND HANDlING

cabinet unit is best moved via lifting lugs on the
Cabinet.
MODElNUMBER DEFINITIONS
™
Input Voltage -46 (460V)
IEEE 519 Filter Installed (F)
Or Not (Blank)
Cooling Method Liquid (G)
Mounting Package (P)
Remote (R)
Drive Type VYA 305 HP
Drive Type VYB 254 HP
Drive Type VYC 437 HP
Drive Type VYD 362 HP
UNIT UNIT AS SHIPPED
1,240
1,362
-50 (400V)
1,669
1,791
