CA UTION
Manufacturers of Lakeshore Products
855 East Chicago Road, Quincy, MI 49082
www.lakeshoreproducts.com • tel: 517.639.3815 • fax: 517.639.4576
LS5004B/VPRB
LS1504B/VPRB-50
Aluminum Bunk Assembly
PARTS LIST
ref. part no.
A
BUNKAV
B
20676/20902 Bunk Socket Bracket
C
20678/20904 Bunk Socket Plate
D 20852
DO NOT INSTALL bunks without studying Owner's Manual.
Improperly adjusting or overtightening bunks may cause bunks
to fail and cause damage that is not covered by WARRANTY.
part name
Bunk Aluminum Assembly 2
Bolt Pkg Step 5
qty.
4
4
1
Advertisement
Related Manuals for LSP inc. LS5004B
Summary of Contents for LSP inc. LS5004B
- Page 1 LS5004B/VPRB LS1504B/VPRB-50 Aluminum Bunk Assembly PARTS LIST ref. part no. part name qty. BUNKAV Bunk Aluminum Assembly 2 20676/20902 Bunk Socket Bracket 20678/20904 Bunk Socket Plate D 20852 Bolt Pkg Step 5 CA UTION DO NOT INSTALL bunks without studying Owner’s Manual.
- Page 2 LS5004B/VPRB LS1504B/VPRB-50 tools needed 9/16 Ratchet CAUTION : DO NOT OVERTIGHTEN U CHANNEL. 3/4 Ratchet BUNKS MAY FAIL IF NOT ALLOWED TO CONFORM TO 9/16 Wrench YOUR BOAT. THIS WILL VOID YOUR WARRANTY 3/4 Wrench Install 4 BUNK SOCKET BRACKETS and PLATES on front and rear CRADLES using Step 5 Bolt Package.
