READ CAREFULLY - FAILURE TO FOLLOW INSTRUCTIONS AND SAFETY RULES MAY RESULT IN SERIOUS INJURY
Manufacturers of Lakeshore Products
855 East Chicago Road, Quincy, MI 49082
www.lakeshoreproducts.com • tel: 517.639.3815 • fax: 517.639.4576
Cantilever Pontoon Lift
3600 lbs. load capacity
LSP16H
LS3001
mainframe bundle
LS3002H
H-unit bundle
LS3003
accessory box
LSP21H
LS3101
mainframe bundle
LS3102H
H-unit bundle
LS3103
accessory box
LSP24H
LS3201
mainframe bundle
LS3102H
H-unit bundle
LS3103
accessory box
LSP28H
LS3301
mainframe bundle
LS3302H
H-unit bundle
LS3303
accessory box
Advertisement
Related Manuals for LSP inc. LSP16H
Summary of Contents for LSP inc. LSP16H
- Page 1 Cantilever Pontoon Lift 3600 lbs. load capacity LSP16H LS3001 mainframe bundle LS3002H H-unit bundle LS3003 accessory box LSP21H LS3101 mainframe bundle LS3102H H-unit bundle LS3103 accessory box LSP24H LS3201 mainframe bundle LS3102H H-unit bundle LS3103 accessory box LSP28H LS3301 mainframe bundle...
-
Page 2: Tools Needed
– 3/8" x 3" hex bolts – 3/8" washers – 3/8" nylon lock nuts Place the washers under the heads of the bolts on the outside of the lift. LSP16H, LSP21H, LSP24H, LSP28H Owner's Manual... - Page 3 1/2" x 5 1/2" hex bolts – 1/2" flat washers – 1/2" nylon lock nuts place one wsher under the bolt head, one under the nut, and one between the tubes. Attach the V units in the same manner. LSP16H, LSP21H, LSP24H, LSP28H Owner's Manual...
- Page 4 1/2" x 3 1/2" carriage bolts – 1/2" flat washers – 1/2" nylon lock nuts Be sure to place the nuts on the inside of the lift with the washers underneath them. Repeat for each set of tabs. LSP16H, LSP21H, LSP24H, LSP28H Owner's Manual...
- Page 5 Attach the wheel support tube and the other end of the upper spreader tube to the mainframe with bolt package #5: – 1/2" x 3 1/2" hex bolts – 1/2" nylon lock nuts the bolt heads should be on the outside of the lift. LSP16H, LSP21H, LSP24H, LSP28H Owner's Manual...
-
Page 6: Final Adjustments
2 at the top of the mainframe and 2 on the cradle tubes. Move your lift into the water and position it so that the lift is level. If your lake bottom is uneven, we offer Leg Kits that enable you to level your pontoon lift. The installation is now complete. LSP16H, LSP21H, LSP24H, LSP28H Owner's Manual... -
Page 7: Helpful Hints
1-5 wheel extension tube 24" wheel support bracket aluminum winch cable with loop in one end 3" pulley kit 6" pulley kit 2" x 2.5" plastisol caps 2" x 5" plastisol caps caution decal LSP16H, LSP21H, LSP24H, LSP28H Owner's Manual... - Page 8 LSP16H, 21H, 24H, 28H Cantilever Pontoon Lift, 3600 lbs. Capacity, 47.75" Width, 60" Lift Height PARTS LIST BOLT LIST ref. part no. part name qty. ref. part no. part name qty. CAPS2050 2" x 5" plastisol cap Y310 5/16 X 2 1/2 Hex Bolt PUL6 6"...
