B
E
A
D
G
C
www.lakeshoreproducts.com • tel: 517.639.3815 • fax: 517.639.4576
F
Manufacturers of Lakeshore Products
855 East Chicago Road, Quincy, MI 49082
LS5013BU
Under Deck Poly Rail Kit
For use with LS5004BU Leg Bundle.
Under Deck Poly Rail Kit Package
PARTS LIST
ref.
part no.
part name
A
8' Poly Rail with cap
B
21032
Bunk Poly Rail Connector
C
21026
Bunk U Channel
D Y412
3/8" x 3" Hex Bolt
E
Y403
3/8" x 3/4" Hex Bolt
F
Y451
3/8" Nylon Lock Nut
G Y452
3/8" Flat Washers
qty.
8
4
4
8
28
36
12
