❹
The LED KNX lights up green when KNX bus voltage is present. If this LED flickers, telegram
traffic is taking place on the KNX bus.
Summary of the states of the LED KNX ❹:
LED Status
LED lights green
LED flickers green
2.2.2 Test mode
In test mode, the Wi-Fi channel can be changed and the connection status of the tunneling
connection can be displayed.
If many participants are using the same Wi-Fi channel, switching to a less heavily used channel
can improve the connection quality:
Pressing and holding the button Test
❸
the LED WiFi flashing green. The selected Wi-Fi channel is activated after exiting the test
mode. This is not stored in the device (selection only temporary).
Summary of the states of the LED WiFi ❸:
LED Status
LED is off
LED flashes 1x green
LED flashes 2x green
LED flashes 3x green
The LED KNX ❹ lights up green when the KNXnet/IP tunneling connection is active.
Summary of the states of the LED KNX ❹:
LED Status
LED lights green
LED is off

3 Reset to factory default settings

It is possible to reset the device to its factory default settings.
▪
Disconnect the KNX bus connection
▪
Press the button Prog. Mode
▪
Reconnect the KNX bus connection
▪
Keep the button Prog. Mode
▪
A short flashing of all LEDs (❷❸❹❼) visualizes the successful reset of the device to
factory default settings.
© 2021 WEINZIERL ENGINEERING GmbH
Meaning
KNX bus voltage present.
Telegram traffic on the KNX bus.
❺
switches through the Wi-Fi channels. This is indicated by
Meaning
The Wi-Fi channel configured via ETS is selected.
Wi-Fi channel 1 is selected.
Wi-Fi channel 6 is selected.
Wi-Fi channel 11 is selected.
Meaning
At least one KNXnet/IP tunneling connection is active.
No KNXnet/IP tunneling connection is active.
❽
from the device.
❻
and keep it pressed down.
❽
to the device.
❻
pressed for at least another 6 seconds.
