2.1 KNX programming mode

The KNX programming mode is activated/deactivated by pressing the KNX programming button
❻. When programming mode is active, the programming LED

2.2 Manual operation and status display

Summary of the states of the programming LED ❼:
LED Status
LED lights red
LED flashes red (fast)
Pressing the button Test
active mode is indicated by the LED Run
Summary of the states of the LED Run ❷:
LED Status
LED lights green
LED flashes green (slowly)
LED flashes green (fast)
2.2.1 Normal operating mode
The LED WiFi ❸ lights up green when a Wi-Fi connection is available. If this LED flickers,
telegram traffic is taking place via Wi-Fi. If this LED flashes slowly in green, the device is not
connected via Wi-Fi.
Pressing and holding the button Test
❸
by the LED WiFi flashing fast in green.
Summary of the states of the LED WiFi ❸:
LED Status
LED lights green
LED flashes green (slowly)
LED flashes green (fast)
LED flickers green
© 2021 WEINZIERL ENGINEERING GmbH
Meaning
The programming mode is active.
The programming mode is not active.
The device is not loaded correctly, e.g. after aborting a download.
❺
briefly switches between normal operating mode and test mode. The
❷
lighting up or flashing slowly in green.
Meaning
The device operates in normal operating mode.
The device is in test mode.
The device is currently loaded by the ETS.
❺ executes WPS (Wi-Fi Protected Setup). This is indicated
Meaning
The device is connected via Wi-Fi.
The device is not connected via Wi-Fi.
WPS is in progress.
Telegram traffic via Wi-Fi.
❼ lights up red.
