GE Appliances

AJCS08ACA—GE 115 Volt "J Series" Built-In Room Air Conditioner with Mechanical Controls

Wall Case Dimensions (in inches)

16-7/8

Note: When installing slide-out chassis units in through- the-wall

applications. Do not restrict air flow areas.

Specification Created 5/01

15-5/8

Parallel

115V

15 Amp

For answers to your Monogram,

GE Profile

GE appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center

service, 800.626.2000.

Total capacity and E.E.R.

ratings are calculated

based on the Association

of Home Appliance

Manufacturers' standards.

™

Listed by

Underwriters

Laboratories

Need help?

Do you have a question about the AJCS08ACA and is the answer not in the manual?

Page 1 GE Appliances AJCS08ACA—GE 115 Volt ”J Series” Built-In Room Air Conditioner with Mechanical Controls Wall Case Dimensions (in inches) 16-7/8 Note: When installing slide-out chassis units in through- the-wall applications. Do not restrict air flow areas. Specification Created 5/01 15-5/8...
Page 2 GE Appliances AJCS08ACA—GE 115 Volt ”J Series” Built-In Room Air Conditioner with Mechanical Controls Dimensions (in inches) Make frame if desired or caulk between case and siding 15-3/4 26-1/8 Frame Construction Lintel 15-3/4 26-1/8 Fill open cells with mortar Brick Block and Brick...
Page 3 GE Appliances AJCS08ACA—GE 115 Volt ”J Series” Built-In Room Air Conditioner with Mechanical Controls Features and Benefits • 8,000 BTUH, 115 Volts • 9.2 E.E.R. • Mechanical Controls with Variable Setting Thermostat • 2 Cooling/2 Fan Only Speeds • Fan Cycle Switch for Reduced Energy Consumption •...
