WORKSHOP MANUAL
TRACTOR,MOWER,
FRONT LOADER
BX1870,BX2370,BX2670,
RCK48-18BX,RCK54-23BX,
RCK60B-23BX,
RCK48P-18BX,RCK54P-23BX,
RCK54D-26BX,RCK60D-26BX,
LA203A,LA243A
KiSC issued 02, 2017 A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX1870 and is the answer not in the manual?

Questions and answers

Related Manuals for Kubota BX1870

Summary of Contents for Kubota BX1870

  • Page 1 WORKSHOP MANUAL TRACTOR,MOWER, FRONT LOADER BX1870,BX2370,BX2670, RCK48-18BX,RCK54-23BX, RCK60B-23BX, RCK48P-18BX,RCK54P-23BX, RCK54D-26BX,RCK60D-26BX, LA203A,LA243A KiSC issued 02, 2017 A...
  • Page 2 All illustrations, photographs and specifications contained in this manual are of the newest information available at the time of publication. KUBOTA reserves the right to change all information at any time without notice. Since this manual includes many models, information or illustrations and photographs can show more than one model.
  • Page 3 Record of Revisions For pdf, use search function {Search word} to find all the revised locations. Last digit Issue Reference of the Main Revised Point and Corrective Measures {Search word} month Page Code No. 2013.08 Change to the Quick Hitch type at "[2] FRONT LOADER (1) Bucket, 8-S6 Boom and Hydraulic Cylinders".
  • Page 4 INFORMATION KiSC issued 02, 2017 A Find manuals at https://best-manuals.com...

  • Page 5: Table Of Contents

    INFORMATION CONTENTS 1. SAFETY FIRST ..........................I-1 2. SAFETY DECALS .......................... I-4 [1] BX TRACTOR .......................... I-4 [2] MOWER ........................... I-8 [3] FRONT LOADER ........................I-12 3. SPECIFICATIONS........................I-14 [1] BX TRACTOR ........................I-14 [2] MOWER ..........................I-15 (1) RCK48-18BX, RCK54-23BX, RCK60B-23BX, RCK48P-18BX and RCK54P-23BX ..I-15 (2) RCK54D-26BX and RCK60D-26BX .................

  • Page 6: Safety First

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 1. SAFETY FIRST SAFETY FIRST • This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully.
  • Page 7 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM OPERATE SAFELY • Do not use the machine after you consume alcohol or medication or when you are tired. • Put on applicable clothing and safety equipment. • Use applicable tools only. Do not use alternative tools or parts.
  • Page 8 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM KEEP A GOOD AIRFLOW IN THE WORK AREA • If the engine is in operation, make sure that the area has good airflow. Do not operate the engine in a closed area. The exhaust gas contains poisonous carbon monoxide.

  • Page 9: Safety Decals

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 2. SAFETY DECALS The following safety decals are installed on the machine. If a decal becomes damaged, illegible or is not on the machine, replace it. The decal part number is listed in the parts list. WSM000001INI0013US0...
  • Page 10 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0002US0 KiSC issued 02, 2017 A Find manuals at https://best-manuals.com...
  • Page 11 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0003US0 KiSC issued 02, 2017 A...
  • Page 12 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0004US0 CARE OF DANGER, WARNING AND CAUTION LABELS 1. Keep danger, warning and caution labels clean and free from obstructing material. 2. Clean danger, warning and caution labels with soap and water, dry with a soft cloth.

  • Page 13: Mower

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM [2] MOWER 9Y1210855INI0006US0 KiSC issued 02, 2017 A...
  • Page 14 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0007US0 KiSC issued 02, 2017 A...
  • Page 15 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0008US0 I-10 KiSC issued 02, 2017 A...
  • Page 16 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0018US0 CARE OF DANGER, WARNING AND CAUTION LABELS 1. Keep danger, warning and caution labels clean and free from obstructing material. 2. Clean danger, warning and caution labels with soap and water, dry with a soft cloth.

  • Page 17: Front Loader

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM [3] FRONT LOADER 9Y1210855INI0009US0 I-12 KiSC issued 02, 2017 A...
  • Page 18 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 9Y1210855INI0010US0 CARE OF DANGER, WARNING AND CAUTION LABELS 1. Keep danger, warning and caution labels clean and free from obstructing material. 2. Clean danger, warning and caution labels with soap and water, dry with a soft cloth.

  • Page 19: Specifications

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 3. SPECIFICATIONS [1] BX TRACTOR Model BX1870D BX2370D BX2670D PTO power 10.2 kW (13.7 HP)* 13.2 kW (17.7 HP)* 14.5 kW (19.5 HP)* Maker KUBOTA Model D722-E4-BX-1 D902-E4-BX-1 D1005-E4-BX-1 Type Indirect Injection, vertical, water-cooled, 4-cycle diesel Number of cylinders 67 ×...

  • Page 20: Mower

    SAE 1-3/8, 6 splines Rear Revolution 1 speed (540 min (rpm) at engine 3142 min (rpm)) PTO shaft USA No. 5 (KUBOTA 10-tooth) involute spline Revolution 1 speed (2500 min (rpm) at engine 3043 min (rpm)) NOTE • The company reserves the right to change the specifications without notice.

  • Page 21: Rck54D-26Bx And Rck60D-26Bx

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM (2) RCK54D-26BX and RCK60D-26BX Model RCK60D-26BX RCK54D-26BX Suitable tractor BX2370, BX2670 Drive Over Quick-Joint, Parallel linkage Mounting method Drive over suspended linkage Adjustment of cutting height Dial gauge 1524 mm 1372 mm Cutting width (60 in.) (54 in.) Cutting height 25 to 102 mm (1.0 to 4.0 in.)

  • Page 22: Front Loader

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM [3] FRONT LOADER Loader Specifications Loader Model LA203A LA243A BX2370D and BX2670D Tractor Model BX1870D (BX1860) (BX2360 and BX2660) Wheel Base (WB) 1340 mm (52.8 in.) 1400 mm (55.1 in.) Front Tires 16 × 7.5-8 18 × 8.5-10 Rear Tires 24 ×...
  • Page 23 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM Dimensional Specifications Loader Model LA203A LA243A BX2370D and BX2670D Tractor Model BX1870D (BX1860) (BX2360 and BX2660) Maximum lift height (To bucket pivot pin) 1810 mm (71.3 in.) Maximum lift height under level bucket 1680 mm (66.1 in.) Clearance with bucket dumped 1350 mm (53.1 in.)
  • Page 24 INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM (1) Height (mm) (3) At Pivot Pin (5) Rollback Force (kN) [A] LA203A (2) Lift Capacity (kg) (4) 500 mm Forward of Pivot Pin [B] LA243A 9Y1210855INI0015US0 I-19 KiSC issued 02, 2017 A...

  • Page 25: Traveling Speeds

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 4. TRAVELING SPEEDS (At rated engine rpm) Model BX1870D BX2370D and BX2670D Tire size (Rear) 24 × 12.00 – 12 26 × 12.00 – 12 Range gear shift lever km/h km/h 0 to 6.0 0 to 3.7 0 to 6.5...

  • Page 26: Dimensions

    INFORMATION BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 5. DIMENSIONS 9Y1210855INI0017US0 I-21 KiSC issued 02, 2017 A...
  • Page 27 GENERAL KiSC issued 02, 2017 A...
  • Page 28 GENERAL CONTENTS 1. IDENTIFICATION ......................... G-1 [1] TRACTOR IDENTIFICATION....................G-1 (1) Serial Number and Hour Meter..................G-1 (2) Cylinder Number....................... G-2 [2] MOWER IDENTIFICATION ....................G-2 [3] FRONT LOADER IDENTIFICATION ..................G-2 2. GENERAL PRECAUTIONS......................G-3 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING ........G-4 [1] WIRING ..........................
  • Page 29 (12)Check Point of Every 1 Year ..................G-38 (13)Check Points of Every 4 Years..................G-39 (14)Others..........................G-40 [2] MOWER..........................G-42 (1) Check Points of Daily or Each Use................. G-42 (2) Check Point of Initial 50 Hours ..................G-46 (3) Check Point of Every 150 Hours..................G-46 (4) Check Point of Every 1 Year...................
  • Page 30 BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM 1. IDENTIFICATION [1] TRACTOR IDENTIFICATION (1) Serial Number and Hour Meter When contacting your local KUBOTA distributor, always specify engine serial number, tractor serial number and hour meter reading. (1) Tractor Identification Plate [A] BX1870D (2) Tractor Serial Number...
