March 2025 Kubota BX70 Installation Manual

Kubota BX2370/BX2670 ROPS Cab

Please note: BX2670 is shown in photo.

Kubota KuBX-025 ROPS Cab

This ROPS cab is designed and built to fit:

Kubota BX2370 and BX2670.

Designed and built by:

Tektite Manufacturing Inc:

P.O. Box 639, 427 Buffalo Street

Winkler, MB, Canada

R6W 4A8

PH: 204-331-3463

parts@tektite.ca

One-year standard product warranty provided by Tektite Manufacturing Inc.

www.tektite.ca

www.tektitecabs.com

Need help?

Do you have a question about the BX2670 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kubota BX2670

Page 1 March 2025 Kubota BX70 Installation Manual Kubota BX2370/BX2670 ROPS Cab Please note: BX2670 is shown in photo. Kubota KuBX-025 ROPS Cab This ROPS cab is designed and built to fit: Kubota BX2370 and BX2670. Designed and built by: Tektite Manufacturing Inc: P.O.
Page 2 March 2025 Kubota BX70 Installation Manual DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW. 1) Always wear personal protective equipment. 2) A minimum of two people is necessary to safely install the cab. 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
Page 3 March 2025 Kubota BX70 Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota BX series ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of protection.
Page 4 March 2025 Kubota BX70 Installation Manual Parts List Standard Cab: Weather Seal Components: Description PTO Selector 90° Weather seal 8” PTO Engage 90° Weather seal 7 ½” Back Inner RH 90° Weather seal 4 ¾” Throttle 90° Weather seal 8 ¼”...
Page 5 March 2025 Kubota BX70 Installation Manual Parts List Optional Winter Front Kit: Description Winter Front Button Snap Back w/Screw...
Page 6 March 2025 Kubota BX70 Installation Manual Seal Kit Installation Instructions: 1. Take the under-seat upholstery and position it under the seat. Ensure there is adequate clearance for the seat and controls, and then glue into place. 2. Go to the left fender and take the 8” piece of 90° weather seal and slide it onto the edge of the PTO selector lever cover.
Page 7 March 2025 Kubota BX70 Installation Manual 5. Take the 8 ¼” piece of 90° weather seal and slide it onto the edge of the throttle lever cover. 6. Take the 7 ½” piece of 90° weather seal and slide it onto the edge of the 3-pt lever cover.
Page 8 March 2025 Kubota BX70 Installation Manual Standard Cab Installation Instructions: Prior to starting, park tractor in a well-ventilated location, lower all tractor attachments. 1. Disconnect rear flasher light harness and remove two-post ROPS from machine. Save fasteners to re-use later.
Page 9 March 2025 Kubota BX70 Installation Manual 4. Remove the two cab doors by un-hooking the gas shock at the ball stud mounted to the door. To remove the gas shock on the left cab door, slide a flat screwdriver underneath the small clip on the end cap that must be pulled UP order to pop the shock off of the ball stud.
Page 10 March 2025 Kubota BX70 Installation Manual 8. Once all isolators are started, torque the isolator fasteners to 200 ft-lbs. The M12 rear nuts should be torqued to 98 ft-lbs. The front bracket M14 fasteners should be torqued to 130 ft- lbs.
Page 11 March 2025 Kubota BX70 Installation Manual 14. Take the SMV mount plate and apply bend to part that fits into sign mount. Adjust until such time that the SMV sign sits fairly straight when installed onto cab. 15. Remove off the factory fuel cap. Take the pre-assembled fuel fill assembly inside of the cab and check for tolerance to install onto fuel cap.
Page 12 March 2025 Kubota BX70 Installation Manual NOTE: the cab for the BX is designed to provide protection from the winter elements. The tractor air intake will draw air through the cab. If cab is used in the summer, remove all vinyl panels, side glass pieces, and doors to ensure engine receives enough fresh air.
Page 13 March 2025 Kubota BX70 Installation Manual 19. Route 3/8” ID hoses connect to the heater from the heater, through the large hole in the floorboard, behind the brake pedal, and to the open fittings on the engine. Connect the hoses to the fittings with provided HS-6 hose clamps.
Page 14 March 2025 Kubota BX70 Installation Manual Optional Winter Front: Remove the air intake cover shroud from tractor. Located the plastic panel shown in the next photo on the left side and remove from the tractor. Remove the plastic panel from the right side as well.
Page 15 March 2025 Kubota BX70 Installation Manual Wrap the winter front around the shroud, ensure it is tight, and mark the holes for the opposite side retainers. Drill 1/16” holes and fasten button snap backs to the plastic shroud. Install winter front onto shroud...
Page 16 March 2025 Kubota BX70 Installation Manual NOTE: the cab for the BX is designed to provide protection from the winter elements. The tractor air intake draws air through the cab. If cab is used in the summer, remove all side windows and doors to ensure engine receives enough fresh air.
Page 17 March 2025 Kubota BX 50/60/70 Operator Manual Kubota BX Series ROPS Cab Please note: BX2670 is pictured above. ** Shown with optional equipment Kubota BX Series Cab This ROPS cab is designed and built to fit: Kubota BX1860/1870 and Kubota BX2360/2370/2660/2670.
Page 18 March 2025 Kubota BX 50/60/70 Operator Manual DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW. 1) Always wear personal protective equipment. 2) A minimum of two people is necessary to safely install the cab. 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
Page 19 March 2025 Kubota BX 50/60/70 Operator Manual Tektite Limited Warranty Tektite Manufacturing Inc. (“Tektite”) warrants to the original purchaser (the “Claimant”), that Tektite products will be free from defective materials or workmanship, under normal use and service, for a period of (1) full year from the original invoice date.
Page 20: Safety Precautions
March 2025 Kubota BX 50/60/70 Operator Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS.
Page 21 March 2025 Kubota BX 50/60/70 Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the tractor. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
Page 22 March 2025 Kubota BX 50/60/70 Operator Manual Safe Operation on Rough Terrain 1. Drive the tractor slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
Page 23 March 2025 Kubota BX 50/60/70 Operator Manual Safety Decals 1. Keep decals clean. Remove dirt with a wet clean cloth when necessary. 2. Replace safety decals if destroyed, missing, painted over or unreadable. If any safety decals are covered or obscured when the ROPS is mounted, it is recommended that you purchase replacement decals from the tractor manufacturer.
Page 24 March 2025 Kubota BX 50/60/70 Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
Page 25 March 2025 Kubota BX 50/60/70 Operator Manual 5. Washer Momentary Switch (Front and Rear optional) Low position: On Mid position: Off High Position: On 6. Beacon Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on.
Page 26 March 2025 Kubota BX 50/60/70 Operator Manual After your ROPS Cab has been installed: Before starting a tractor equipped with a Tektite ROPS cab: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and tractor can cause operator interference which could lead to bodily injury and/or damage the machine.
Page 27 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality KUBX-ASM-020_OPMANUAL Daryl Furkalo...
Page 28 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality KUBX-ASM-019_OPMANUAL Daryl Furkalo...
Page 29 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0045 TEKT-0004 Side Window Slider Bracket A00-0046 TEKT-ASM-002R Side Window Hinge Right A00-0056 TEKT-0020 Side Window Latch, L60775 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD...
Page 30 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0044 TEKT-ASM-002 Side Window Hinge Weldment A00-0045 TEKT-0004 Side Window Slider Bracket A00-0057 TEKT-0020MIR Side Window Latch, L60776 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD...
Page 31 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0003 RIGHT-LATCH Suicide Door Right Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4"...
Page 32 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0002 LEFT-LATCH Suicide Door Left Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4"...
Page 33 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality KUBX-ASM-024_OP Daryl Furkalo...
Page 34 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality TEKT-ASM-088_OP Daryl Furkalo...
Page 35 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality TEKT-ASM-099_OP Ana Laura Peters...
