Kubota BX Series ROPS Cab
** Shown with optional equipment
Please note: BX2670 is pictured above.
Caution
** Please read installation instructions and follow all safety statements before attempting operating
this ROPS product.
** A copy of this operator manual should be kept with the machine operating manuals.
** If this manual is lost, please contact your local Kubota dealer for a replacement.
Kubota BX Series ROPS Cab Operator Manual
Kubota BX Series Cab
This ROPS cab is designed and built
to fit the Kubota BX1860/1870 and
Kubota BX2360/2370/2660/2670.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
One year standard product
warranty provided by Tektite.
www.tektite.ca
