New Leader NL600 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model NL600
Operator's Manual
UNIT SERIAL NUMBER ___________________________
MANUAL NUMBER: 317491-A
EFFECTIVE 09/2021
1330 76TH AVE SW
CEDAR RAPIDS, IA 52404-7052
PHONE (800) 363-1771 | FAX (319) 286-3350
www.newleader.com
Copyright 2019 Highway Equipment Company, Inc.
Now doing business as New Leader Manufacturing

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NL600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for New Leader NL600

Summary of Contents for New Leader NL600

  • Page 1 Operator’s Manual UNIT SERIAL NUMBER ___________________________ MANUAL NUMBER: 317491-A EFFECTIVE 09/2021 1330 76TH AVE SW CEDAR RAPIDS, IA 52404-7052 PHONE (800) 363-1771 | FAX (319) 286-3350 www.newleader.com Copyright 2019 Highway Equipment Company, Inc. Now doing business as New Leader Manufacturing...

  • Page 2: Table Of Contents

    NL600 Table of Contents Interactive Features �����������������������������������������������������������������������������������������������������������������������������������5 Warranty �����������������������������������������������������������������������������������������������������������������������������������������������������6 Preface ��������������������������������������������������������������������������������������������������������������������������������������������������������7 Safety ����������������������������������������������������������������������������������������������������������������������������������������������������������8 Important Safety Information ����������������������������������������������������������������������������������������������������������8 Safety Alert Symbols ������������������������������������������������������������������������������������������������������������������������8 General Safety Rules ���������������������������������������������������������������������������������������������������������������������������������9 Safety Decals ��������������������������������������������������������������������������������������������������������������������������������������������19 Safety Decal Maintenance �������������������������������������������������������������������������������������������������������������19 Safety Decal Installation ����������������������������������������������������������������������������������������������������������������19 Connecting Implement ���������������������������������������������������������������������������������������������������������������������������25 Hydraulic Requirements �����������������������������������������������������������������������������������������������������������������25 Hitch Requirements ������������������������������������������������������������������������������������������������������������������������25...
  • Page 3 NL600 Table of Contents Enable/Disable Bins ����������������������������������������������������������������������������������������������������������������������� 61 Valve Calibration Adjustment ������������������������������������������������������������������������������������������������������� 61 Alarm Settings �������������������������������������������������������������������������������������������������������������������������������� 64 Reconfigure System ����������������������������������������������������������������������������������������������������������������������� 64 Switch Assignment ������������������������������������������������������������������������������������������������������������������������� 65 Component Calibration ����������������������������������������������������������������������������������������������������������������� 66 Spinner Disc Calibration ���������������������������������������������������������������������������������������������������������������� 66 Conveyor Calibration ��������������������������������������������������������������������������������������������������������������������� 67 Operations/Features ���������������������������������������������������������������������������������������������������������������������� 70 Hydraulics ����������������������������������������������������������������������������������������������������������������������������������������...
  • Page 4 NL600 Table of Contents PWM Spinner Valve ���������������������������������������������������������������������������������������������������������������������� 138 Hydraulic Reservoir ���������������������������������������������������������������������������������������������������������������������� 140 Hydraulic Reservoir w/ Cooler ����������������������������������������������������������������������������������������������������� 142 Hydraulic Reservoir w/ Cooler Cont. ������������������������������������������������������������������������������������������ 144 Hydraulic Reservoir Mounting Hardware ������������������������������������������������������������������������������������ 145 Hydraulic Reservoir ISO ��������������������������������������������������������������������������������������������������������������� 146 Hydraulic Reservoir ISO w/ Cooler ��������������������������������������������������������������������������������������������� 148 Hydraulic Reservoir ISO w/ Cooler Cont.

  • Page 5: Interactive Features

    Electronic format viewers can Hyperlinks within the content are denoted by click these links for direct access to New Leader online features� Internet access is required� www.NewLeader.com 317491-A (800) 363-1771 - 5 -...

  • Page 6: Warranty

    Warranty Insert Current New Leader Warranty...

  • Page 7: Preface

    New Leader Manufacturing reserves the right to make alterations or modifications to this equipment at any time. The manufacturer shall not be obligated to make such changes to machines already in the field.

  • Page 8: Safety

    Figure 1�1 - The need for safety cannot be stressed strongly enough in this manual� At New Leader Manufacturing, we urge you to make safety your top priority when operating any equipment. We firmly...

  • Page 9: General Safety Rules

    NL600 General Safety Rules Operations PREPARE FOR EMERGENCIES Figure 1.2 - Be prepared if a fire starts. Keep a fully charged fire extinguisher and first aid kit in accessible place on the vehicle at all times� Fire extinguisher must be Type ABC or Type BC.
  • Page 10 NL600 General Safety Rules Operations HANDLE HAZARDOUS MATERIALS SAFELY Figure 1�5 - Materials to spread can be dangerous� Improper selection, application, use or handling may be a hazard to persons, animals, plants, crops or other property� A Safety Data Sheet (SDS) provides specific details on chemical products: physical and health hazards, safety procedures and emergency response techniques�...
  • Page 11 NL600 General Safety Rules Operations AVOID MOVING PART HAZARDS Figure 1�8 - Entanglement in rotating drive lines or moving parts will cause serious injury or death� Stay clear of all moving parts, such as shafts, couplings and universal joints� Make sure all personnel are clear of machine before starting�...
  • Page 12 NL600 General Safety Rules Operations DO NOT CLIMB OR STAND ON MACHINE Figure 1�12 - Never allow any personnel to ride in or on the machine� Use inspection ladder or portable ladder to view the unit� Use caution when getting on and off the ladder, especially in wet, icy, snowy or muddy conditions�...
  • Page 13 NL600 General Safety Rules Transportation & Handling TRAVELING & TRANSPORTING ON PUBLIC ROADS Always walk around and visually inspect the machine before traveling on public roads� Check for damage and/or faulty components that can fail and create a hazard or unsafe condition. Make sure all machine systems operate properly, including but not limited to: headlights, tail and brake lights, hazard warning lights, turn indicators, parking brake, horn and rear view mirrors�...
  • Page 14 Never modify any equipment or add attachments not approved by New Leader Manufacturing� Figure 3�1 DO NOT SERVICE OR ADJUST MACHINE WHILE IN MOTION Figure 3�2 - Never lubricate, service or adjust the machine or any of its components while they are moving�...
  • Page 15 Use power tools only to loosen threaded parts and fasteners� Using power tools to tighten may cause over-tightening and component damage� Use only service parts meeting New Leader specifications. Figure 3�6 www.NewLeader.com 317491-A (800) 363-1771...
  • Page 16 NL600 General Safety Rules Maintenance HIGH PRESSURE FLUID HAZARDS Figure 3.7 - Escaping fluid under pressure can penetrate the skin causing serious injury� Always stop machine, allow to cool and relieve pressure before servicing hydraulic system� Never open hydraulic lines under pressure�...
  • Page 17 NL600 General Safety Rules Maintenance CLEAN MACHINE OF HAZARDOUS CHEMICALS During application of hazardous chemicals, residue can build up on the inside or outside of the vehicle� Clean vehicle according to use instructions of hazardous chemical� Failure to comply with this requirement may result in minor or moderate injury�...
  • Page 18 NL600 General Safety Rules Storage PARK VEHICLE SAFELY Figure 4�1 - When leaving the vehicle unattended for any reason, be sure to: • Shut down PTO� • Shut off vehicle’s engine, and unit’s engine if applicable� • Place vehicle transmission in “Neutral” or “Park”�...

  • Page 19: Safety Decals

    Replace safety decals and signs that are missing or have become illegible� Replaced parts that displayed a safety sign should also display the current sign� Safety decals or signs are available from your dealer’s Parts Department or from New Leader Manufacturing by calling (800) 363-1771�...
  • Page 20 NL600 Safety Decals Cancer and Reproductive Harm - www.P65Warning.ca.gov 315865-A 1. CAUTION: TO AVOID INJURY OR MACHINE DAMAGE: • Do not operate or work on this machine without reading and understanding the operator’s manual� • Keep hands, feet, hair and clothing away from moving parts�...
  • Page 21 NL600 Safety Decals 4. WARNING: HIGH-PRESSURE FLUID HAZARD To prevent death or serious injury: • Do not check leaks with hands while system is operating as high pressure oil leaks can be dangerous! • Relieve pressure before disconnecting hydraulic lines or working on system�...
  • Page 22 NL600 Safety Decals 7. DANGER: FLYING MATERIAL AND ROTATING SPINNER HAZARD To prevent death or serious injury: • Wear eye protection� • Stop machine before servicing or adjusting� • Keep bystanders at least 60 feet away� 8. WARNING: FALLING HAZARD To prevent death or serious injury: •...
  • Page 23 Refer to the “How to Check your Spread Pattern” manual for adjustment instructions� A spread pattern test kit is available from your New Leader dealer� Wind, humidity, rain and other adverse weather conditions can affect spread pattern, resulting in uneven crop growth and loss of yields�...
  • Page 24 NL600 Informational Decals 2. NOTICE: CONVEYOR CHAIN LUBRICATION To avoid machine damage and premature wear: • Conveyor chain life will be noticeably extended by periodic lubrication. • Use a 75% diesel fuel and 25% number 10 oil mixture on the links and rollers.

  • Page 25: Connecting Implement

    NL600 Connecting Implement Hydraulic Requirements • Low pressure drop motor return port� • Zero pressure case drain port� • Equipped with hydraulic trailer brake system� Tractor Side Implement Side User Supplied Factory Supplied FUNCTION DESCRIPTION COUPLER COUPLER DESCRIPTION Spreader Tractor High Flow...

  • Page 26: Implement Preparation And Connection

    NL600 Connecting Implement Implement Preparation and Connection DO NOT wear loose clothing� Keep hands and other body parts away from connecting parts of tractor and implement� Entanglement could cause serious injury� DO NOT stand on PTO, PTO driveline, tongue, or draw bar� Falling could cause death or serious injury�...
  • Page 27 NL600 Connecting Implement 7� Lube implement hitch� 8� Retract jack to storage position� Figure 1 Figure 2 Figure 3 Figure 4 9� Attach safety chain� 10� On left side of hitch, loop safety chain through tractor intermediate support (Figure 5)�...
  • Page 28 NL600 Connecting Implement ISOBUS Connections A: Factory Supplied CAN-ISO Connector Connects to: ISOBUS Implement Extension Harness, Supplied with implement� • Pin 1 - Battery Ground • Pin 2 - ECU Return (ECU Ground) • Pin 3 - 60-amp fused power •...
  • Page 29 NL600 Connecting Implement Power Take-Off Connection 1� Inspect, clean and lubricate PTO and PTO driveline� 2� Inspect all guards, making sure they are in proper working order� 3� Lift tractor’s PTO cover� 4� Slide PTO driveline coupler onto tractor PTO and lock into place on driveline groove (Figure 10-12)�...
  • Page 30 NL600 Connecting Implement Hydraulic Hose Installation Guide 1� Use elbows and adapters in the installation to 2� Install hose runs to avoid rubbing or abrasion� relieve strain on the assembly, and to provide Clamps are often needed to support long runs...

  • Page 31: General Description

    NL600 General Description The NL600 is a hopper type spreader that can be setup for spreading either Compost or Fertilizer� The unit is hydraulically powered and provides independent variable speed control for the spinner and full automatic ground speed control for the conveyor�...

  • Page 32: Dimensions & Capacities

    NL600 Dimensions & Capacities (2997mm) (OUTSIDE) (1778mm) 128 (3251mm) (FENDER WIDTH) 118” (2997mm) (OUTSIDE) Unit Overall Lenth Body Length Length 21’ 292” (7417mm) 240” (6096mm) 129” (3251mm) (FENDER WIDTH) Struck Capacity Approximate Weight Unit Length Cu Ft (Cu M) Pounds (kilograms) 8400 (3810) 21’...

  • Page 33: Initial Start

    NL600 Initial Start-up Stand clear of moving machinery� NOTE: Do not load spreader with material� 1� Check entire unit to make sure all fasteners are in place and properly tightened per “Standard Torques” in this manual� 2� Make sure no other persons are in vicinity of spreader�...

  • Page 34: Field Testing

    NL600 Field Testing The following procedure is a guide: NOTE: Do NOT fill speader with material 1� Field test over any suitable course which allows vehicle to be driven at speeds to be used while spreading� 2� Ensure unit has been properly serviced, that the hydraulic reservoir is full and gate valve under reservoir is fully open as applicable�...

  • Page 35: General Operating Procedures

    NL600 General Operating Procedures 1� Make sure unit has been properly serviced and is in good operating condition� It is highly recommended to run the spreader prior to loading material to ensure acceptable operation� 2� Program controller with correct data for material(s) and application�...

  • Page 36: Lubrication & Maintenance

    NL600 Lubrication & Maintenance Preventative Maintenance Pays! The handling and spreading of commercial fertilizers is a most severe operation with respect to metal corrosion� Establish a frequent, periodic preventative maintenance program to prevent rapid deterioration to spreading equipment� Proper cleaning, lubrication and maintenance will yield longer life, more satisfactory service and more economical use of your equipment�...

  • Page 37: Hydraulic Hose

    NL600 Lubrication & Maintenance Hydraulic Hose Hose assemblies in operation should be inspected frequently for leakage, kinking, abrasion, corrosion or other signs of wear or damage� Worn or damaged hose assemblies should be replaced immediately� Testing should be conducted in approved test stands with adequate guards to protect the operator�...
  • Page 38 NL600 Lubrication & Maintenance Lubrication Make sure unit is clean and completely dry� Lubricate conveyor chain at the end of each day of usage using a mixture of 75% diesel fuel and 25% SAE 10 oil� Shut down spinner and run...

  • Page 39: Conveyor Gearcase

    NL600 Lubrication & Maintenance Conveyor Gearcase Drain oil in a new unit after first two weeks (or not more than 100 hours) of operation, and flush gear case thoroughly with light oil. Refer to “Lubricant and Hydraulic Oil Specifications” section for proper grade oil and recommended amounts of lubricant�...

  • Page 40: Lubricant & Oil Specifications

    Extreme environments or dirty conditions may require the use of different oils� Consult your New Leader dealer or the Product Support Department at Highway Equipment Company for systems operating outside normal conditions�...

  • Page 41: Lubrication Chart

    NL600 Lubrication Chart Shut off all power and allow all moving parts to come to rest before performing any maintenance operation� The spreader should be regularly lubricated with the lubricants recommended in this manual in accordance with the following chart:...

  • Page 42: Conveyor Selection

    NR indicates the conveyor and/or spreader is not recommended for the specified application. The density provided was used to make the conveyor recommendation� If the density of the material to be spread is outside of those in the table, contact your New Leader dealer for the best conveyor for your application�...

  • Page 43: Troubleshooting

    NL600 Troubleshooting Hydraulic Schematic - PTO/SCV www.NewLeader.com 317491-A (800) 363-1771 - 43 -...
  • Page 44 NL600 Troubleshooting Hydraulic Schematic - SCV www.NewLeader.com 317491-A - 44 - (800) 363-1771...
  • Page 45 NL600 Troubleshooting Hydraulic Schematic - SCV Feedgate www.NewLeader.com 317491-A (800) 363-1771 - 45 -...
  • Page 46 NL600 Troubleshooting Spinner motors do not turn when spinner control valve is in running position or conveyor does not run when placed in “On” position� See reasons 1, 2, 3, 4, 6, 7, 8 & 9� Spinners turn but conveyor does not run in manual mode� See reasons 5, 7, 9 & 10�...
  • Page 47 NL600 Troubleshooting Reason: Correction: 10� In line relief valve set too low� In line relief valve pressure should be 3100 PSI (214 bar)� Set spinner control valve to “0”� Disconnect pressure line, coming from rear port on spinner control valve, at control�...

  • Page 48: Standard Torques

    NL600 Standard Torques CAP SCREW GRADE IDENTIFICATION - MARKINGS ON HEAD NO MARKINGS GRADE 2 THREE MARKS - 120 DEGREES APART GRADE 5 SIX MARKS - 60 DEGREES APART GRADE 8 USE GRADE 2 TORQUES FOR STAINLESS STEEL FASTENERS AND CARRIAGE BOLTS�...
  • Page 49 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 49 -...
  • Page 50 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A - 50 - (800) 363-1771...

  • Page 51: Controller Operations

    UI (User Interface) - The displayed information and controls the user interacts with on the Display Monitor to make any necessary changes to implement performance� • ECU (Electronic Control Unit) - New Leader module that controls specific functions of the implement and is attached to the BUS� •...

  • Page 52: Cab To Enclosure Diagram

    NL600 Controller Operations Cab to Enclosure Diagram Battery www.NewLeader.com 317491-A - 52 - (800) 363-1771...

  • Page 53: Modules To Function Diagram

    NL600 Controller Operations Modules to Function Diagram www.NewLeader.com 317491-A (800) 363-1771 - 53 -...

  • Page 54: Requirements

    NL600 Controller Operations Requirements System Requirements: Function: • Virtual Terminal version 3 that supports • VT will load New Leader UI and assign AUX-N functionality functions to in-cab switches� • Task Control (Multi-product up to 4 bins) • TC-BAS •...

  • Page 55: Navigation

    NL600 Controller Operations Navigation To activate the New Leader Controller Interface, power up the monitor and activate the VT settings� For instructions on how to activate the VT, see the Manufacturer’s Operations Manual for the specific monitor being used� Activation of VT will bring up the New Leader Home Screen, also called the “Run...

  • Page 56: Navigation Control Buttons

    NL600 Controller Operations An on-screen Numeric Keypad is made available for changing configuration settings and calibration numbers� Press the keypad button to access the on-screen numeric entry screen� Keypads may look different depending on VT being used� Figure 3 - Numeric Keypad...

  • Page 57: Machine Configuration

    NL600 Controller Operations Machine Configuration NOTE: Refer to default settings table at end of controller section for factory setup defaults� Before use, Display Monitor must be setup to enable VT connection and a machine configuration NOTE: may need to be built� See Manufacturer’s Operations Manual for detailed instructions on these processes�...

  • Page 58: Bin Settings

    NL600 Controller Operations Bin Settings Bin settings include Name, Capacity, Bin Sensor, Feedgate enabled/disabled, Pressure Transducer calibration� • Enter Capacity for Main Bin using keypad� Enable or disable bin level sensor as required� Press to edit pressure transducer settings� If standard transducers are being used, press to continue�...
  • Page 59 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 59 -...

  • Page 60: Gps Offsets

    NL600 Controller Operations GPS Offsets Editing the task controller GPS offset settings will determine drop point of material behind chassis� • Select Towed or Self Propelled and enter GPS Offset using keypad� Towed • For single axle towed units, enter the distance from the center of the hitch pin to the center of the axle (a).

  • Page 61: Settings

    NL600 Controller Operations Settings Changing machine calibrations allows operator to enable/disable bins, adjust valve calibration numbers, change alarm settings and reset modules� On the Home Screen, press to change these settings: Press to to enable/disable bins. Enable/Disable Bins • Each Installed Bin (as set up in Step 4) will appear�...
  • Page 62 NL600 Controller Operations • Press to set spinners� Enter appropriate settings: • PWM Valve settings: • “Monitor” - no PWM control • “Control” - tries to maintain spinner speed at all times regardless of available hydraulic flow. Best for hydrostatic or CVT drives�...
  • Page 63 NL600 Controller Operations Response Threshold setting� Represents slow speed of servo valve� Decreasing value causes servo valve to run slower� Default setting is 8%� • Response Threshold - Determines where control channel switches between using Valve Response 1 and Valve Response 2 speed setting� Leaving all other valve control settings at default value and making small adjustments to this setting is usually all that is required to fine-tune system performance�...

  • Page 64: Alarm Settings

    Pressing “Reset” under “System Settings will restore all settings to factory default and all NOTICE! calibration numbers will be lost� It should only be pressed if instructed to do so by service technician or New Leader product support� • Press to reset/reconfigure system.

  • Page 65: Switch Assignment

    • Press to show connected devices� • Connected devices will appear in the device list� • If using a New Leader switch box, press to automatically map the switches to the correct function� www.NewLeader.com 317491-A (800) 363-1771 - 65 -...

  • Page 66: Component Calibration

    NL600 Controller Operations Component Calibration NOTE: Before regular use, system must be calibrated to ensure accurate spreading� • Power up Display Monitor and activate VT� • The Run screen will appear� Press to continue� Spinner Disc Calibration • Press to calibrate spinner discs�...

  • Page 67: Conveyor Calibration

    NL600 Controller Operations Conveyor Calibration For best results, a catch test must be done for each product to be spread IMPORTANT! before season begins, or any time a new supply of product is received� • Press to calibrate conveyor� •...
  • Page 68 NL600 Controller Operations • Using the control buttons (Reset, Run, Stop), run a catch test� If spreading product that has already been tested, press continue� To begin a test, press � Conveyor will run� • Once controller dispenses specific amount, conveyor will stop�...
  • Page 69 NL600 Controller Operations • After dispensing product in field, screen displays system perceived total of dispensed product� To enter actual dispensed amount, press � • Using keypad, enter actual weight of product dispensed� Press to continue� • New cubic feet per revolution (CFR) rate will be displayed�...

  • Page 70: Operations/Features

    NL600 Controller Operations Operations/Features Create New Job The following is a guide for running system for first time. 1� Create Job in display� This operation will vary from display to display� Refer to display manual on how to create a job using Task Control.
  • Page 71 NL600 Controller Operations 3� Verify task control in Target Rate 1� • Rate will be driven by job setup in display� To verify this, TC should show in place of target rate 1� If not, verify job has been created correctly� Refer to display manual�...
  • Page 72 NL600 Controller Operations • Use keypad to set feedgate opening to correct reading� 6� Verify CFR number is correct: Different products may require different calibration numbers� Verify the CFR number is correct before applying product� • Press then � •...
  • Page 73 NL600 Controller Operations • To view unlocked features, press � • Current unlocked features will display� Press “Unlock” to display module serial number and registration number� Press to return� www.NewLeader.com 317491-A (800) 363-1771 - 73 -...

  • Page 74: Hydraulics

    NL600 Controller Operations Hydraulics This program will show a visual representation of hydraulic monitoring, including system pressure, NOTE: temperature, conveyor pressure, and indicators for low fluid level and filter restriction. Individual bins can be viewed by pressing the bin icons along the bottom of the screen�...

  • Page 75: Bin Flush

    NL600 Controller Operations Bin Flush This program is used to quickly empty each bin� Spinners will automatically shut off and allow the NOTE: operator to select which bins to empty� 1� Power up Display Monitor and activate VT� • The Run screen will appear� Press to continue�...
  • Page 76 NL600 Controller Operations 2� Select bins: • Select bins to be flushed by pressing enable buttons next to each. To adjust conveyor RPM for flush, press � 3� Set conveyor RPM: • Use keypads to set conveyor RPM for each bin� 20 RPM is default�...

  • Page 77: Body Module

    NL600 Controller Operations Body Module 1� Power up Display Monitor and activate VT� • The Run screen will appear� Press to continue� • The Tools main screen will appear� Press to continue� Bin Cover Control • If equipped, press (A) to open and close tarp�...

  • Page 78: Chain Oiler

    NL600 Controller Operations Chain Oiler NOTE: This program is used to manually oil the chain, set alarm frequency, and set auto-lube settings� 1� Power up Display Monitor and activate VT� • The Run screen will appear� Press to continue� •...
  • Page 79 NL600 Controller Operations 3� Set conveyor dimensions: • Press “Dimensions” to input conveyor dimensions� Use keypads to input conveyor length and sprocket diameter� Press to return to Chain Oiler screen� Press to return to Tools Screen� 4� Set service reminder: •...

  • Page 80: General Alarms

    NL600 Controller Operations General Alarms Alarm Title Description WSM Spreader Local CAN Bus Error Check the local CAN bus connection� Module WSM Spreader The module software reset due to an Module Software Reset Module unhandled error� WSM Spreader Local CAN Bus Warning Check the local CAN bus connection�...

  • Page 81: General Product Control Alarms

    NL600 Controller Operations General Product Control Alarms Alarm Description Trigger “Calibration error, lost or intermittent Rate sensor signal is lost for a period Rate sensor error signal from rate sensor� Check sensor of two or more consecutive seconds during calibration...

  • Page 82: Spinner Alarms

    NL600 Controller Operations Spinner Alarms Alarm Description Trigger Automatic control for spinners must be enabled� [CLF Mode] [Basic Single] must be selected� At least one product CLF Basic Single bin must be commanded on� Perceived Spinners Not “Spinners Not Responding”...

  • Page 83: Hydraulic Alarms

    NL600 Controller Operations Hydraulic Alarms Alarm Description Trigger Conveyor Conveyor hydraulic pressure exceeds Hydraulic “Conveyor Hydraulic Pressure Exceeds [Max Conveyor Hydraulics Pressure] Pressure Exceeds Maximum Operating Range.” setting for a period of five consecutive Maximum seconds or longer� System hydraulic pressure exceeds [Max System Hydraulic “System Hydraulic Pressure Exceeds...

  • Page 84: Default Settings

    NL600 Controller Operations Default Settings NOTE: Compatible Insert Bin configurations vary per model. See “General Description” in Operations section of this manual for details� Refer to “Dimensions & Capacities” in Operations section of this manual for capacities on all applicable bin configurations.

  • Page 85: Calibration

    NL600 Controller Operations Calibration CFR Values Value Main Bin 0�291 Control Valve Settings Control Valve Control Variable Main Control Valve Type Servo Valve Response 1 Valve Response 2 Response Threshold 4�0 Allowable Error Sensor Settings Encoder pulses 180 or 360 - verify by looking on encoder...
  • Page 86 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A - 86 - (800) 363-1771...

  • Page 87: Spread Pattern

    NOTE: An optional calibration chute (P/N 312688) is available to simplify the catch test process. The calibration chute fits all New Leader spreader models with 30” wide conveyor bottoms. Contact your local New Leader dealer for details�...

  • Page 88: Spread Pattern

    NL600 Spread Pattern Use great caution while working around the spreader� Contact with spinners and other moving parts is very dangerous� Do not adjust while machinery is moving, wear eye protection and avoid discharge from spinners� Do not ride on moving spreader� Failure to comply with this requirement could result in death or serious injury�...

  • Page 89: Spinners

    NL600 Spread Pattern Spinners Spinner discs and fins must be kept clean and polished. Even a small build-up on a spinner fin can significantly affect the spread pattern. Rusty, rough, bent or worn fins will produce poor spread patterns� In general, critical spinner speed will fall somewhere between 600 and 900 RPM� Spinner speed is adjusted by changing the settings in the controller�...
  • Page 90 NL600 Spread Pattern NOTE: This chart is to be used as a reference only to begin testing� SIMPLE START SETTINGS Material Density Ground Rate (lbs) Feedgate Spinner Spinner Speed (in) Frame (mph) Setting Lime 1000-5000 �5" 2000-8000 �5" Urea 2�5 2�5...

  • Page 91: Test Procedure

    Using the data sheets supplied with the kit, document all spreader information and adjustments as necessary� See Figure 1� SPREAD PATTERN DATA SHEET 1330 76th Ave SW Cedar Rapids, IA 52404-7052 New Leader Manufacturing (319) 363-8281 L4000G4 Rev. Spreader Model:...
  • Page 92 NL600 Spread Pattern Four-Wheeled Vehicles 60’ 60’ For four-wheeled application vehicles, position the spreader at the beginning of the course so that the vehicle will straddle the center collection tray� See Figure 2� 100’ 75’ 20’ (3m) Engage spinners before navigating the course� As the 10’...
  • Page 93 NL600 Spread Pattern Test Results After navigating the course, shut the spreader down and park in a secure location� Using the funnel, transfer the contents of each collection tray into its corresponding test tube beginning at one end of the trays and working towards the opposite end�...

  • Page 94: Troubleshooting

    NL600 Spread Pattern Troubleshooting NOTE: It is highly recommended that ONLY ONE ADJUSTMENT be made between test samples taken� If more than one adjustment is made, it will be difficult to determine which adjustment was responsible for the change in pattern shape�...
  • Page 95 NL600 Spread Pattern Determining Driving Centers Once an acceptable pattern is obtained, as shown in Figure 5, driving centers can be determined� To determine optimum driving centers (effective swath width), determine the average amount of material in the center of the pattern. Figure 8 shows an example data sheet recorded from the profile shown in Figure 9.

  • Page 96: Verifying Driving Centers

    NL600 Spread Pattern Verifying Driving Centers Once optimum driving centers (effective swath width) have been established, conduct a final “S” pass over the trays to verify� Refer to Figure 10� 1� With both the spinners and conveyor turned off, drive the...

  • Page 97: Instructions For Ordering Parts

    If your claims are not being handled (by the transportation company) to your satisfaction, please call our Product Sales & Support Department at New Leader Manufacturing at 888-363-8006 for assistance� In the parts list the following symbols and abbreviations stand for: * - Not Shown AR –...

  • Page 98: Body

    NL600 Body Mounting ITEM PART NO� DESCRIPTION 20683 Nut - Lock �75-10NC 58560 Capscrew - �75-10NC X 7 20698 Washer - Flat �75 305220 Spring - Compression 20209 Capscrew - �75-10NC X 3 310487 Washer - Flat �781 X 2 www.NewLeader.com...

  • Page 99: Sight Window

    NL600 Body Sight Window ITEM PART NO� DESCRIPTION 302686 Window - Sight 5 x 12 42033 Screw - Truss Head 1/4 x 1 SS 42034 Nut - Lock 1/4 SS www.NewLeader.com 317491-A (800) 363-1771 - 99 -...

  • Page 100: Feedgate - Hydraulic

    NL600 Body Feedgate - Hydraulic www.NewLeader.com 317491-A - 100 - (800) 363-1771...
  • Page 101 NL600 Body Feedgate - Hydraulic Cont. ITEM PART NO� DESCRIPTION 70287-X1 70287 Slide – Wldmt Feedgate RH w/ chain shields 70289-X1 70289 Slide – Wldmt Feedgate LH w/ chain shields 55377 55377 Cylinder – Hydraulic 305486 305488 Feedgate – Wldmt 34” w/ chain shields...

  • Page 102: Feedgate - Manual

    NL600 Body Feedgate - Manual 16 20 24 24 20 23 24 17 18 25 25 13 18 15 20 24 24 www.NewLeader.com 317491-A - 102 - (800) 363-1771...
  • Page 103 NL600 Body Feedgate - Manual Cont. ITEM PART NO� DESCRIPTION 317277 Spacer - Shim Plastic 317276 Bar - Feedgate Guide 304 317275 Bar - Feedgate Slide 304 317273 Feedgate - Wldmt 34" 304 317274 Bracket - Jack 304 312994 Jack - Assy 13�38 304...

  • Page 104: Fenders

    NL600 Body Fenders www.NewLeader.com 317491-A - 104 - (800) 363-1771...
  • Page 105 NL600 Body Fenders Cont. ITEM PART NO� DESCRIPTION 306365-X2 Support - 124" Rear RH 304 306366-X2 Support - 124" Rear LH 304 96969 Angle - Fender 124" 30" BTM 96966 Bracket - Fender Front LH 304 96965 Bracket - Fender Front 124"...

  • Page 106: Mudflaps

    NL600 Body Mudflaps www.NewLeader.com 317491-A - 106 - (800) 363-1771...
  • Page 107 NL600 Body Mudflaps Cont. ITEM PART NO� DESCRIPTION 317413-AA Mudflap - RH 34 x 30 317413-AB Mudflap - LH 34 x 30 317414 Retainer - Mudflap 34858 Capscrew - �375-16NC X 1�5 SS 36420 Washer - Lock �375 SS 36414 Nut - Hex .375-16NC SS...

  • Page 108: Lights - Group W/O Fenders

    NL600 Body Lights - Group W/O Fenders www.NewLeader.com 317491-A - 108 - (800) 363-1771...
  • Page 109 NL600 Body Lights - Group W/O Fenders Cont. ITEM PART NO� DESCRIPTION 306365-X2 Support - Rear RH 124" 306366-X2 Support - Rear LH 124" 305213 Guard - Tail Light 304 JD 305276 Angle - Decal Mnt 304704 Grommet - Super 45...

  • Page 110: Lights - Group With Fenders

    NL600 Body Lights - Group With Fenders www.NewLeader.com 317491-A - 110 - (800) 363-1771...
  • Page 111 NL600 Body Lights - Group With Fenders Cont. ITEM PART NO� DESCRIPTION 305213 Guard - Tail Light 304 JD 304704 Grommet - Super 45 304715 Light - Super 45 300150 Light - STT Red 36393 Capscrew - �25-20NC X �75 SS 36418 Washer - Lock �25 Ss...

  • Page 112: Poly Floor Assy

    NL600 Body Poly Floor Assy www.NewLeader.com 317491-A - 112 - (800) 363-1771...
  • Page 113 NL600 Body Poly Floor Assy Cont. ITEM PART NO� DESCRIPTION 317255 FLOOR - POLY CONV 21' 42639-X1 BOLT - ELEVATOR 5/16-18 x 1 SS 36419 WASHER - LOCK �313 SS 36413 NUT - HEX �313-18NC SS www.NewLeader.com 317491-A (800) 363-1771...

  • Page 114: Inverted - V

    NL600 Body Inverted - V ITEM PART NO� DESCRIPTION 317253 V - Inverted 21' 304 302371 Bracket - V Bolt-On 304 308646 Bar - Mounting 304 317251 Hanger - Wldmt V 304 *302375 Hardware - Kit 13-16' Inv V SS * - Not Shown www.NewLeader.com...
  • Page 115 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 115 -...

  • Page 116: Electrical Group - Non Iso

    NL600 Body Electrical Group - Non ISO www.NewLeader.com 317491-A - 116 - (800) 363-1771...
  • Page 117 NL600 Body Electrical Group - Non ISO Cont. ITEM PART NO� DESCRIPTION 99674 Tie - Wire 312887 Plug - Stor-A-Way 7 Pole 20003 Capscrew - �25-20NC X �75 20037 Capscrew - �313-18NC X 1�25 20039 Capscrew - �313-18NC X 1�75 20676 Nut - Lock �25-20NC...

  • Page 118: Electrical Group - Iso

    NL600 Body Electrical Group - ISO www.NewLeader.com 317491-A - 118 - (800) 363-1771...
  • Page 119 NL600 Body Electrical Group - ISO Cont. ITEM PART NO� DESCRIPTION 313047 Mount - Cable Tie �375 73797 Liner - Edge 311806 Tie - Wire Fir Tree 99674 Strap - Zip Tie 8 Black 313050 Receptacle - Assy 312887 Plug - Stor A Way 7 Pole 20039 Capscrew - �313-18nc X 1�75...

  • Page 120: Switch Box

    NL600 Body Switch Box www.NewLeader.com 317491-A - 120 - (800) 363-1771...
  • Page 121 Body Switch Box Cont. ITEM PART NO� DESCRIPTION 318604 Switchbox - Kit 6 Pin Deutsch Universal 310742 Switchbox - New Leader G5 313884 Mount - Switch Box *318432 Harness - Iso Aux Console *318602 Harness - Extension *313581 Hardware - Kit Switch Box * Not Shown www.NewLeader.com...

  • Page 122: Grommet Group

    NL600 Body Grommet Group ITEM PART NO� DESCRIPTION 34129 Grommet - Rubber www.NewLeader.com 317491-A - 122 - (800) 363-1771...
  • Page 123 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 123 -...

  • Page 124: Body Hydraulics

    NL600 Body Hydraulics Pressure Gauge Kit www.NewLeader.com 317491-A - 124 - (800) 363-1771...
  • Page 125 NL600 Body Hydraulics Pressure Gauge Kit - Cont. ITEM PART NO� DESCRIPTION 317406 Pressure - Kit Gauge Dual 5000psi 29795 Fitting - 4-4- 070220 304948 Bracket - Wldmt Gauge 76044 Gauge - Hyd� 5000 PSI 29765 Fitting - 4-4 070102 307509 Hose - 1/4”...

  • Page 126: Tube Group 21

    NL600 Body Hydraulics Tube Group 21’ www.NewLeader.com 317491-A - 126 - (800) 363-1771...
  • Page 127 NL600 Body Hydraulics Tube Group 21’ Cont. ITEM PART NO� DESCRIPTION 305502-AF Tube - Assy 1�25"OD 304 98121-X5 Tube - 1" OD X �083 X 125" 304 305504-AF Tube - �75"OD X �049" X 74" ASSY 304 317404 Tube - Assy �75"OD X �049" X 160" ASSY 304 75036 Clamp - Tubing Twin �75"...

  • Page 128: Main Bin Pto

    NL600 Body Hydraulics Main Bin PTO www.NewLeader.com 317491-A - 128 - (800) 363-1771...
  • Page 129 NL600 Body Hydraulics Main Bin PTO Cont. www.NewLeader.com 317491-A (800) 363-1771 - 129 -...

  • Page 130: Main Bin Pto With Iso

    NL600 Body Hydraulics Main Bin PTO with ISO www.NewLeader.com 317491-A - 130 - (800) 363-1771...
  • Page 131 NL600 Body Hydraulics Main Bin PTO with ISO - Cont. www.NewLeader.com 317491-A (800) 363-1771 - 131 -...
  • Page 132 NL600 Body Hydraulics Main Bin PTO / includes ISO ITEM PART NO� DESCRIPTION 36419 Washer - Lock �313” SS 36418 Washer - Lock �25 SS 36413 Nut - Hex .313-18nc SS 36412 Nut - Hex, .25-20nc SS 38576-X4 Valve - Pwm...
  • Page 133 NL600 Body Hydraulics Main Bin PTO / includes ISO ITEM PART NO� DESCRIPTION 95958 Hose - 1”Dia 100r2 X 72�7” Assy 305752 Hose - �75”Dia 100r12 X 71�5” Assy 88315 Hose - Assy .75 x 36 100R2 98710-X2 Hose - �75”Dia 100r12 X 33�5” Assy...

  • Page 134: Main Bin Tractor

    NL600 Body Hydraulics Main Bin Tractor www.NewLeader.com 317491-A - 134 - (800) 363-1771...
  • Page 135 NL600 Body Hydraulics Main Bin Tractor - Cont. www.NewLeader.com 317491-A (800) 363-1771 - 135 -...
  • Page 136 NL600 Body Hydraulics Main Bin Tractor - Cont. ITEM PART NO� DESCRIPTION 36419 Washer - Lock �313” SS 36418 Washer - Lock �25 SS 36413 Nut - Hex .313-18nc SS 36412 Nut - Hex, .25-20nc SS 38576-X4 Valve - Pwm...
  • Page 137 NL600 Body Hydraulics Main Bin Tractor - Cont. ITEM PART NO� DESCRIPTION 95958 Hose - 1”Dia 100r2 X 72�7” Assy 305752 Hose - �75”Dia 100r12 X 71�5” Assy 88315 Hose - Assy .75 x 36 100R2 98710-X2 Hose - �75”Dia 100r12 X 33�5” Assy...

  • Page 138: Pwm Spinner Valve

    NL600 Body Hydraulics PWM Spinner Valve ITEM PART NO� DESCRIPTION 38576-X4 Valve - Flow Control Electric Actuated 53960 Spring 90696 Shim 90697 Spool 90698 O-Ring 90699 Plug 38576-AA Cartridge 38576-AG Nut - Cartridge 38576-AC O-Ring 38576-AD Screw - Set 38576-AE...
  • Page 139 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 139 -...

  • Page 140: Hydraulic Reservoir

    NL600 Body Hydraulics Hydraulic Reservoir www.NewLeader.com 317491-A - 140 - (800) 363-1771...
  • Page 141 NL600 Body Hydraulics Hydraulic Reservoir Cont. ITEM PART NO� DESCRIPTION 317402 Tank - Assy Hydraulic 305050 Tank - Hydraulic Wldmt 88838 Filter - Return In Tank 306186 Gasket Maker - Silicone Rtv 0�06 305066 Filter - Element 305058 Pipe - 1�5 Sch40 10"...

  • Page 142: Hydraulic Reservoir W/ Cooler

    NL600 Body Hydraulics Hydraulic Reservoir w/ Cooler www.NewLeader.com 317491-A - 142 - (800) 363-1771...
  • Page 143 NL600 Body Hydraulics Hydraulic Reservoir w/ Cooler Cont. www.NewLeader.com 317491-A (800) 363-1771 - 143 -...

  • Page 144: Hydraulic Reservoir W/ Cooler Cont

    NL600 Body Hydraulics Hydraulic Reservoir w/ Cooler Cont. ITEM PART NO� DESCRIPTION 317401 Tank Assy with Cooler 317402 Tank - Assy Hyd� 43534 Indicator - Service 38575 Gauge - Sight & Temperture 305767 Cooler - Assy Hydac Eld4�5 305760 Bracket - Cooler Rh...

  • Page 145: Hydraulic Reservoir Mounting Hardware

    NL600 Body Hydraulics Hydraulic Reservoir Mounting Hardware ITEM PART NO� DESCRIPTION 317401 Tank - Assy W/ Cooler 39159 Belt - Spacer 36403 Capscrew - �5-13nc X 2 Ss 36426 Washer - Flat �5 Ss 39016 Nut - Lock �5-13nc Ss...

  • Page 146: Hydraulic Reservoir Iso

    NL600 Body Hydraulics Hydraulic Reservoir ISO www.NewLeader.com 317491-A - 146 - (800) 363-1771...
  • Page 147 NL600 Body Hydraulics Hydraulic Reservoir ISO Cont. ITEM PART NO� DESCRIPTION 317399 Tank - Assy Hydraulic ISO 311736 Tank - Wldmt Hydraulic 88838 Filter - Return In Tank 306186 Gasket Maker - Silicone Rtv 0�06 305066 Filter - Element 305058 Pipe - 1�5 Sch40 10"...

  • Page 148: Hydraulic Reservoir Iso W/ Cooler

    NL600 Body Hydraulics Hydraulic Reservoir ISO w/ Cooler www.NewLeader.com 317491-A - 148 - (800) 363-1771...
  • Page 149 NL600 Body Hydraulics Hydraulic Reservoir ISO w/ Cooler Cont. www.NewLeader.com 317491-A (800) 363-1771 - 149 -...

  • Page 150: Hydraulic Reservoir Iso W/ Cooler Cont

    NL600 Body Hydraulics Hydraulic Reservoir ISO w/ Cooler Cont. ITEM PART NO� DESCRIPTION 317398 Tank Assy with Cooler ISO 317399 Tank - Assy Hyd� Iso 38575 Gauge - Sight & Temperture 305761 Bracket - Cooler Lh 305767 Cooler - Assy Hydac Eld4�5...
  • Page 151 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 151 -...

  • Page 152: Trailer

    NL600 Trailer ITEM PART NO. DESCRIPTION 318959 Trailer - TR0859 W/Brakes 318960 Trailer - TR0859 W/O Brakes 318591-AA Inner Bearing 318591-AB Inner Race 318591-AC Hub (with Races) www.NewLeader.com 317491-A - 152 - (800) 363-1771...
  • Page 153 NL600 Trailer ITEM PART NO. DESCRIPTION 318591-AD Outer Race 318591-AE Outer Bearing 318591-AF Washer - Spindle 318591-AG Nut - Spindle 2�5” - 12 318591-AH Cotter Pin 318591-AI Dust Cap 318591-AJ Dust Cap Gasket 318591-AK Seal 318591-AL Bolts 318591-AM Wheel Stud...
  • Page 154 NL600 Trailer www.NewLeader.com 317491-A - 154 - (800) 363-1771...
  • Page 155 NL600 Trailer ITEM PART NO� DESCRIPTION 4,5,10 318590-AA Brake - Kit Micro Repair Seal Kit 318590-AB Brake - Micro Piston Service 318590-AC Brake - Kit Micro Lining 2 318590-AD Brake - Assy Micro Tubing 318590-AE Brake - Micro Connector Fittng...

  • Page 156: Trailer Decals

    NL600 Trailer Decals ITEM PART NO� DESCRIPTION 305281 Decal - Caution Braking 313858 Decal - Caution Tow Requirements 305289 Decal - Caution Tipping 39017 Decal - No Step 305239 Decal - Grease 305298 Decal - Weight Restrictions www.NewLeader.com 317491-A - 156 -...
  • Page 157 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 157 -...

  • Page 158: Trailer Hydraulics

    NL600 Trailer Hydraulics Hydraulics-GRP Spinner-PTO www.NewLeader.com 317491-A - 158 - (800) 363-1771...
  • Page 159 NL600 Trailer Hydraulics Hydraulics-GRP Spinner-PTO-Hydraulic Feedgate - Cont. www.NewLeader.com 317491-A (800) 363-1771 - 159 -...
  • Page 160 NL600 Trailer Hydraulics Hydraulics-GRP Spinner-PTO-Hydraulic Feedgate - Cont. ITEM PART NO� DESCRIPTION 20068 Capscrew - �375-16NC X 1�25 20678 Nut - Lock �375-16NC 304921 Hydraulic Pump 305173 Support - Pump 20697 Washer - Flat �625 20674 Nut - Hex .625-11NC Plain 20129 Capscrew - �5-13NC X 1�5...
  • Page 161 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 161 -...

  • Page 162: Hydraulics-Grp Conveyor-Hydraulic Feedgate

    NL600 Trailer Hydraulics Hydraulics-GRP Conveyor-Hydraulic Feedgate www.NewLeader.com 317491-A - 162 - (800) 363-1771...
  • Page 163 NL600 Trailer Hydraulics Hydraulics-GRP Conveyor-Hydraulic Feedgate - Cont. www.NewLeader.com 317491-A (800) 363-1771 - 163 -...
  • Page 164 NL600 Trailer Hydraulics Hydraulics-GRP Conveyor-PTO-Hydraulic Feedgate - Cont. ITEM PART NO� DESCRIPTION 312885 Angle - Upright 313843 Channel - Hose Guide 305266 Clamp - Hose 1�18" Double 305267 Plate - Cover Hose Clamp 304 310583 Capscrew - �313-18NC X 4�0 SS 42221 Nut - Lock �313-18NC SS...
  • Page 165 NL600 Trailer Hydraulics Hydraulics-GRP Conveyor-PTO-Hydraulic Feedgate - Cont. ITEM PART NO� DESCRIPTION 99674 Tie - Wire 317293 Hose - Assy �38" X 200" 100r1 310452 Valve - Cross Relief 1000psi 41669 Capscrew - �25-20NC X 1�75 SS 36418 Washer - Lock �25 SS 36412 Nut - Hex .25-20NC SS...

  • Page 166: Hydraulics-Grp Conveyor-Manual Feedgate

    NL600 Trailer Hydraulics Hydraulics-GRP Conveyor-Manual Feedgate www.NewLeader.com 317491-A - 166 - (800) 363-1771...
  • Page 167 NL600 Trailer Hydraulics Hydraulics-GRP Conveyor-Manual Feedgate - Cont. ITEM PART NO� DESCRIPTION 312885 Angle - Upright 313843 Channel - Hose Guide 305266 Clamp - Hose 1�18" Double 305267 Plate - Cover Hose Clamp 304 71830 Capscrew - �313-18NC X 2�5 SS 42221 Nut - Lock �313-18NC SS...

  • Page 168: Hydraulics-Grp Spinner-Tractor-Hydraulic Feedgate

    NL600 Trailer Hydraulics Hydraulics-GRP Spinner-Tractor-Hydraulic Feedgate www.NewLeader.com 317491-A - 168 - (800) 363-1771...
  • Page 169 NL600 Trailer Hydraulics Hydraulics-GRP Spinner-Tractor-Hydraulic Feedgate - Cont. ITEM PART NO� DESCRIPTION 317488 Hydraulics - GRP Spinner 305266 Clamp - Hose 1�18" Double 305267 Plate - Cover Hose Clamp 304 71830 Capscrew - �313-18NC X 2�5 SS 42221 Nut - Lock �313-18NC SS 309294 Disconnect - Quick �75 Male...

  • Page 170: Conveyor

    NL600 Conveyor #1 Bar Chain Conveyor #1 – Cross bars every 3rd link ITEM PART NO� DESCRIPTION 305774-AF #1 Pintle Chain – 21’ Unit 36699 Link – Pintle 36697 Pin – Chain 20817 Pin – Cotter 95850-X1 Cross Bar Wldmt AR –...

  • Page 171: #2 & #3 Bar Chain Conveyors

    NL600 Conveyor #2 & #3 Bar Chain Conveyors #2 – Cross bars every other link #3 – Cross bars every link ITEM PART NO� DESCRIPTION Chain – Assy 304465-AF 304466-AF 21’ Unit 95850 95850 Crossbar Wldmt 36699 36699 Link – Pintle Chain...

  • Page 172: Guard - Group Front

    NL600 Conveyor Guard - Group Front www.NewLeader.com 317491-A - 172 - (800) 363-1771...
  • Page 173 NL600 Conveyor Guard - Group Front Cont. ITEM PART NO� DESCRIPTION 308379 Guard - Front Conveyor Top 308380 Guard - Front Conveyor Bottom 36408 Bolt - Carriage �375-16NC X 1 36425 Washer - Flat �375 SS 36420 Washer - Lock �375 SS 36414 Nut - Hex .375-16NC SS...

  • Page 174: Chain Shields

    NL600 Conveyor Chain Shields PART NO� PART NO� ITEM DESCRIPTION NON ISO Chain Shield - Chain 305450-AF 305450-AF 71829 Screw - Truss Head �375-16NC X 1 SS 71829 Screw - Truss Head �375-16NC X 1 SS 36420 Washer – Lock 3/8 SS 36420 Washer –...

  • Page 175: Conveyor Drive

    NL600 Conveyor Conveyor Drive ITEM PART NO� DESCRIPTION 305324 Drive - Assy 34” W/D667k Sprockets 303319 Shaft - Assy Drive 34" Bottom 82882 Guide - Wldmt Bearing CS 82550 Mount - Wldmt Torque Arm LH 82549 Mount - Wldmt Torque Arm RhH CS 20833 Pin - Cotter �25 X 1�5 ZN...

  • Page 176: Conveyor Idler

    NL600 Conveyor Conveyor Idler 8, 9 8, 9 ITEM PART NO� DESCRIPTION 303320 Idler - Shaft Assy, Includes 1 - 4 310640 Shaft - Idler 1-1/2 22511 Bearing - Take Up Zerk - Grease 1/8 x 45° 2135 Key - Sq 5/16 x 2-1/2...

  • Page 177: Encoder

    NL600 Conveyor Encoder ENCODER REMOVED ITEM PART NO� DESCRIPTION 303994 Encoder – 180 with Hardware 310601 Coupler - Rate Sensor SS 310603 Screw - Set 1/4-20NC x 5/16 SS 81949 Bracket - Sensor, Idler Mount 2696 Collar - Set 1”...

  • Page 178: Gearcase Assembly

    NL600 Conveyor Gearcase Assembly ITEM PART NO� DESCRIPTION 305578 Gearcase Assy - 9�6 CID 2000 Series, Includes Items 1 - 7 36671 Gearcase - 6�1 56270 Motor – Hydraulic 2000 Series 9�6 CID 305098 Cap Screw – 1/2-13 x 1-3/4 30227 Washer –...

  • Page 179: Gearcase Service Parts

    NL600 Conveyor Gearcase Service Parts ITEM PART NO� DESCRIPTION 36671 Gearcase – Assy Single Pinion 304269-AB Parts – Service, Includes 1–17 304559 Housing – Outboard 304560 Housing – Inboard 304561 Gear – Pinion 11 Tooth 304562 Gear – Driven 67 Tooth...

  • Page 180: Conveyor Chain Oiler

    NL600 Conveyor Conveyor Chain Oiler 22 - 24 22 - 24 20, 21 20, 21 18 - 20 18 - 20 NOTE: LEFT HAND SHOWN. RIGHT HAND REVERSE. 30 - 32 30 - 32 1 38 24 - 26 24 - 26 ITEM PART NO�...
  • Page 181 NL600 Conveyor Conveyor Chain Oiler Cont. ITEM PART NO� DESCRIPTION 314014 Fitting - Outlet 1/4 NPT Fem x 1/4 TT Fem Nylon 314013 Plate - Orifice SS 306651 Strainer - w/ Check Valve 314015 Fitting - Adapter 1/4 NPT Male x 1/4 TT Male Nylon...

  • Page 182: Oiler - Control

    NL600 Conveyor Oiler - Control www.NewLeader.com 317491-A - 182 - (800) 363-1771...
  • Page 183 NL600 Conveyor Oiler - Control Cont. ITEM PART NO� DESCRIPTION 304392 Panel - Front 304393 Cover - Wldmt Control Panel 99491 Bushing - �27 Strain Relief 99492 Holder - Fuse 87340 Screw - Self Tapping #10-24nc 20572 Screw - Round Head #10-24nc X �75 ZN...

  • Page 184: Rear Wipers

    NL600 Conveyor Rear Wipers www.NewLeader.com 317491-A - 184 - (800) 363-1771...
  • Page 185 NL600 Conveyor Rear Wipers Cont. ITEM PART NO� DESCRIPTION 304440 Lip - Rear Assy, Includes 5-8 304441 Wiper – Assy Rear, Includes 1-4 304444 Mount - 34” Internal Wiper 304443 Rubber - 34” Internal Wiper 56258 Screw - Truss Head 1/4-20 x 1/2 SS...

  • Page 186: Wiper Front

    NL600 Conveyor Wiper Front ITEM PART NO� DESCRIPTION 303317 Wiper – Belt 303316 Retainer – Belt 36393 Cap Screw - 1/4-20NC x 3/4 SS 36412 Nut – Hex 1/4-20NC SS 36418 Washer - Lock �25 SS www.NewLeader.com 317491-A - 186 -...
  • Page 187 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 187 -...

  • Page 188: Controller - Main Bin Iso W/Tank

    NL600 Controller - Main Bin ISO W/Tank www.NewLeader.com 317491-A - 188 - (800) 363-1771...
  • Page 189 NL600 Controller - Main Bin ISO W/Tank ITEM PART NO� DESCRIPTION 316571 Module - Group Master 18’- 21’ 310718 Bracket - Module 304 44483 Screw - Panhead Phlp #10-24NC X �75 SS 310734 Module - Master Control 36296 Capscrew - �38-16NC X 2�75 SS 36425 Washer - Flat �375 SS...

  • Page 190: Controller - Main Bin Iso Without Tank

    NL600 Controller - Main Bin ISO Without Tank www.NewLeader.com 317491-A - 190 - (800) 363-1771...
  • Page 191 NL600 Controller - Main Bin ISO Without Tank ITEM PART NO� DESCRIPTION 317392 Module - Group Master W/O Tank 18’- 21’ 310718 Bracket - Module 304 44483 Screw - Panhead Phlp #10-24NC X �75 SS 310734 Module - Master Control 36296 Capscrew - �38-16NC X 2�75 SS...

  • Page 192: Controller - Enclosure Assembly

    Cover - Wldmt 304 310740 Post - Power Distribution 44483 Screw - Panhead Phlp #10-24nc X �75 SS 310739 Harness - New Leader Ecu Enclosure 310732 Pin - Lynch �188 X 1�25 SS 310733 Screw - Panhead Phlp #10-32 X �5 SS 308085 Ferrule - �185 X �374...

  • Page 193: Controller - Enclosure-Grp Mounting

    NL600 Controller - Enclosure-GRP Mounting ITEM PART NO� DESCRIPTION 311839 Enclosure - Group Mounting 311850 Mount - Wldmt 304 310717 Channel - Mount 304 36425 Washer - Flat �375 SS 36398 Capscrew - �375-16NC X 1 SS 72054 Nut - Lock �375-16NC SS www.NewLeader.com...

  • Page 194: Spinners

    NL600 Spinners Spinner Assembly www.NewLeader.com 317491-A - 194 - (800) 363-1771...

  • Page 195: Spinner Assembly - Cont

    NL600 Spinners Spinner Assembly - Cont www.NewLeader.com 317491-A (800) 363-1771 - 195 -...
  • Page 196 NL600 Spinners Spinner Assembly Cont. ITEM PART NO� DESCRIPTION 314772 Spinner Assembly - 304 304911 Plate - Wldmt Back 34" 304 305757 Motor - Lh Style II Assy 305756 Motor - Rh Style II Assy 304897 Mount - Wldmt Motor 30" Disc 304898 Shaft - Wldmt 30"...
  • Page 197 NL600 Spinners Spinner Assembly Cont. ITEM PART NO� DESCRIPTION 34810 Fitting - 16-16 S1040-30 Non Standard 34750 Fitting - 16-16-16 070429 29840 Fitting - 16-16 070220 56103-X1 Hose - Assy 1"100r2 X 16�75" 304907 Hose - �375 X 35�1 Assy 304905 Hose - 1�00 X 33�5 Assy...

  • Page 198: Motor Assembly

    NL600 Spinners Motor Assembly ITEM PART NO� DESCRIPTION 305756 Motor - Assy Style II RH 6�375 3 Displ 313513 Motor - Spinner 6�375 Cid 29803 Fitting - 16-16 070120 34763 Fitting - 6-4 070102 34816 Fitting - 6-6 070221 305758 Fitting - 16-16-16 070428 www.NewLeader.com...
  • Page 199 NL600 Spinners Motor Assembly - Cont ITEM PART NO� DESCRIPTION 305757 Motor - Assy Style II LH 6�375 3 Displ 313513 Motor - Spinner 6�375 Cid 29803 Fitting - 16-16 070120 34763 Fitting - 6-4 070102 29836 Fitting - 16-16-16 070433...

  • Page 200: Disc Assembly

    NL600 Spinners Disc Assembly ITEM PART NO� DESCRIPTION 304899 Disc - Assy 30 Lh 304894 Disc - Spinner 30 10877 Hub - Wldmt 307265 Fin - Wldmt Lh 304 20005 Capscrew - �25-20nc X 1 Gr5 Zn 20676 Nut - Lock �25-20nc Zn 20036-X1 Capscrew - �313-18nc X 1 Gr8...
  • Page 201 NL600 Spinners Disc Assembly - Cont ITEM PART NO� DESCRIPTION 304900 Disc - Assy 30 Rh 304894 Disc - Spinner 30 10877 Hub - Wldmt 307266 Fin - Wldmt Rh 304 20005 Capscrew - �25-20nc X 1 Gr5 Zn 20676 Nut - Lock �25-20nc Zn...

  • Page 202: Spinner Guards & Deflectors-Compost

    NL600 Spinners Spinner Guards & Deflectors-Compost ITEM PART NO� DESCRIPTION 305309 Divider – Wldmt w/Guard 34” 304913 Guard – Wldmt 30” Spinner 304 305320 Shield – Wldmt RH 304 305321 Shield – Wldmt LH 304 87068 Bracket – Shield 304 305040 Bar –...

  • Page 203: Spinner Guards & Deflectors-Fertilizer

    NL600 Spinners Spinner Guards & Deflectors-Fertilizer ITEM PART NO� DESCRIPTION 317239 Divider – Wldmt w/Guard 34” 304913 Guard – Wldmt 30” Spinner 304 305320 Shield – Wldmt RH 304 305321 Shield – Wldmt LH 304 87068 Bracket – Shield 304 305040 Bar –...

  • Page 204: Spinner Speed Sensor

    NL600 Spinners Spinner Speed Sensor ITEM PART NO� DESCRIPTION 305830 Sensor – Kit Spinner W/O CABLE 36412 Nut – Hex 1/4 SS 36418 Washer – Lock 1/4 SS 36423 Washer – Flat 1/4 SS 36393 Cap Screw – 1/4 x 3/4 SS 42448 Cap Screw –...

  • Page 205: Divider Assembly - Fertilizer

    NL600 Divider Assembly - Fertilizer ITEM PART NO� DESCRIPTION 317749 Divider - Wldmt 304 317750 Deflector - Wldmt Rear 304 36425 Washer - Flat �375 SS 36420 Washer - Lock �375 SS 20673 Nut - Wing 3/8" SS *36398 Capscrew - �375-16nc X 1 SS *36425 Washer - Flat �375 SS...

  • Page 206: Divider Storage Mount Kit

    NL600 Divider Storage Mount Kit ITEM PART NO� DESCRIPTION 317744 Kit - Mount Divider Storage 317745 Mount- Wldmt Storage 304 36398 Capscrew - �375-16nc X 1 SS 36425 Washer - Flat �375 SS 36414 Nut - Hex .375-16nc SS www.NewLeader.com...
  • Page 207 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 207 -...

  • Page 208: Scale System

    NL600 Scale System www.NewLeader.com 317491-A - 208 - (800) 363-1771...
  • Page 209 NL600 Scale System www.NewLeader.com 317491-A (800) 363-1771 - 209 -...
  • Page 210 NL600 Scale System ITEM PART NO. DESCRIPTION 318738 Scale - Kit 6 Cell Hd 318016 Bracket - Group Scale Link 318654 Scale - Assy Point 318655 Cable - Scale Dt6 318656 Mount - Wldmt Scale Display 318739 Harness - Point Scale Isobus...

  • Page 211: Scale Link Bracket

    NL600 Scale Link Bracket ITEM PART NO. DESCRIPTION 318017 Bracket - Scale Link 304 36399 Capscrew - �375-16nc X 1�25 SS 36425 Washer - Flat �375 SS 36420 Washer - Lock �375 SS 36414 Nut - Hex .375-16nc SS 44454...

  • Page 212: Decals

    NL600 Decals www.NewLeader.com 317491-A - 212 - (800) 363-1771...
  • Page 213 NL600 Decals Cont. ITEM PART NO� DESCRIPTION 312561 Decal - New Leader, Black 87122 Decal - G4, Black / Red 317834 Decal - NL600, Black 302601 Decal - Patent 6,817,551 Decal - Danger, Flying Material 71526 Decal - Notice, Spread Pattern 150034 Decal - Caution ,Operation &...
  • Page 214 NL600 Decals Cont. ITEM PART NO� DESCRIPTION 304264 Decal - Important Cooler 39378 Decal - Change Filter Element 8664 Decal - Important Keep Valve Open www.NewLeader.com 317491-A - 214 - (800) 363-1771...
  • Page 215 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A (800) 363-1771 - 215 -...

  • Page 216: Antislab

    NL600 Antislab Compost www.NewLeader.com 317491-A - 216 - (800) 363-1771...
  • Page 217 NL600 Antislab Compost Cont. ITEM PART NO� DESCRIPTION 316008 Support - Wldmt 304 316006 Round - �5 X 34�00 304 312960 Chain - �625 X 11 Links www.NewLeader.com 317491-A (800) 363-1771 - 217 -...

  • Page 218: Fertilizer

    NL600 Antislab Fertilizer www.NewLeader.com 317491-A - 218 - (800) 363-1771...
  • Page 219 NL600 Antislab Fertilizer Cont. ITEM PART NO� DESCRIPTION 317241 Divider - Assy Hillside Antislab 304 317242 Antislab - Assy 317243 Support - Wldmt 304 316006 Round - �5 X 34�00 304 312960 Chain - �625 X 11 Links 317248 Panel - Flow Divider 304...
  • Page 220 NL600 Notes This page is intentionally left blank. www.NewLeader.com 317491-A - 220 - (800) 363-1771...

Table of Contents
