- Page 1 SEED MONITORING SYSTEM ISOFLOW application USER MANUAL...
-
Page 2: Copyright Information
Copyright owner: Digitroll Ltd. Bánomkerti st. 63. Hajdúszoboszló 4200, Hungary E-mail: info@digitroll.hu Webpage: www.digitroll.hu Document: N am e : XeedSystem (v1.6.x) ISOBUS application User manual Last modification: 2021.08.27 Printed in the EU. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 3: Table Of Contents
Finishing the installation ____________________________ 14 License _________________________________________ 15 What is license? ___________________________________ 15 Performance view _________________________________ 15 Expected application _______________________________ 16 License management _______________________________ 16 License details ____________________________________ 19 License key activation ______________________________ 19 ISOFLOW application – User manual for XeedSystem v1.6... - Page 4 Fertilizer settings _________________________________ 39 10.4 System diagnostic _________________________________ 41 System settings ________________________________ 43 11.1 System overview __________________________________ 43 11.2 Machine settings __________________________________ 44 11.2.1 Speed calibration ____________________________________ 44 11.3 Distributor binding ________________________________ 46 ISOFLOW application – User manual for XeedSystem v1.6...
- Page 5 Copyright information 11.4 Alarm settings ____________________________________ 47 11.4.1 Seed alarms _________________________________________ 47 11.4.2 Fertilizer alarms _____________________________________ 48 ISOFLOW and SeedView cooperation _______________ 48 ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 6: The Isobus Application
Digitroll can provide two type of (Y) connectors: • 4-pole deutsch connector. • 9-pole in-cab connector. These Y cables, expand the ISOBUS so the communication line get to the XeedGATE, and back. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 7: The Xeedgate's Led Signal
As soon as the terminal has connected to the XeedGATE, the XeedGATE’s ISOBUS LED turns to green in a few seconds, indicating that the connection has created, and it is ready to work. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 8: Installing The Isoflow Application
If an error occurred during the system installation, it can be checked with the alarms button . Press the Sensor type change button to change the type of the sensors (seed fertilizer) attached to the system. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 9: Change Sensor Type
It performs a quick system restart. After the system restart the system installation can be continued. Press the cancel button to cancel the sensor type changes return system overview screen. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 10: X-Line Module Setup
By pressing the next button the system installation continues with the next step. By pressing the back button, the application goes back to the previous step of the system installation. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 11: Seed Settings
(Depends on the machine parameters, seed quality, litter, deviation of seed sizes etc.) ISOFLOW application – User manual for XeedSystem v1.6... -
Page 12: Seed Alarms Settings
Show under- and overflow status swtch. (See: Chapter 6.7: Legends ) Press the Back button to go back to the seed settings. Press the Reset button to reset the alarm settings. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 13: Fertilizer Settings
(Depends on the machine parameters, seed quality, litter, deviation of seed sizes etc.) ISOFLOW application – User manual for XeedSystem v1.6... -
Page 14: Fertilizer Alarms Settings
Finishing the installation The installation’s final step. Press the “Start using XeedSystem” to finish the installation and start using the system. Press the Back button to go back to the fertilizer settings. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 15: License
In case of blockage sensors in absence of license key only the status colors can be seen on the performance view. In case of Pro sensors however the seed application or the fertilizer performance can be seen. Blockage sensors Pro sensors ISOFLOW application – User manual for XeedSystem v1.6... -
Page 16: Expected Application
In case of seed counting sensors or active license key the actual application rate can be seen too. Blockage function Seed counting/Fertilizer performance function License management The License management screen can be accessed by Settings > License management. ISOFLOW application – User manual for XeedSystem v1.6... - Page 17 On license management screen the following can be seen depending on the sensors in the system (blockage or Pro sensors). Blockage sensors In case of blockage sensors the following icon can be seen: This means the function is not active, license key must be bought. ISOFLOW application – User manual for XeedSystem v1.6...
- Page 18 There is no need to purchase license key. In case of a successfully activated key the following icon can be seen: This icon mean the function has been successfully activated by a license key. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 19: License Details
In case there is already a new license key available, the feature can be activated on the license management and the license details (belonging to the feature) screen by pressing button. License management License details ISOFLOW application – User manual for XeedSystem v1.6... - Page 20 In case of successful license activation, a green check mark appears beside the key icon on the license management screen. This icon means that there is an active license key to the given feature. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 21: Time Limited License Keys
In case a time limited key expires, the feature related to the license key persist until the next system start. After a system restart the related feature becomes unavailable and a new license key must be bought to activate it again. ISOFLOW application – User manual for XeedSystem v1.6... - Page 22 The expired license keys can be checked on the License management screen. The expired key’s remaining time is (0:00). After a license key has expired, on the license details screen, the ordering information can be seen again. License management License details ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 23: Main Screen
Every blue rectangle represents a fertilizer distributor head. The little squares inside the orange/blue rectangles represent the sensors. During seeding, many unpredictable errors may occur. The seed monitoring screen or main screen primarily helps to detect these errors. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 24: Header
By holding the area button (at least for 2 secs), the sowed area can be set to zero. Press the Back button to return to the main screen. Press the “ Go to Machine Settings ” to access the machine settings screen. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 25: The Working Position Icon
The rate icon shows the applied rate of the seeds during sowing. This is a calculated value from the seed, speed and machine attributes. For precise applied rate calculation, calibrate the speed and set the seed and machine values accurately. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 26: Main Screen
Every occurred error can be seen on the main screen. More details can be seen about the errors at the error list screen. To know more about the sensor colors, check the legends screen. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 27: Legends
Gray: it could mean the sensor is dusty and it needs to be cleared or the sensor doesn’t perceive seed flow. Red: seeding error, blockage. Burgundy: hardware error, low voltage or missing sensor. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 28: Details Screen
If more than 12 distributor heads are used, the paging button will be active and with it the user has the possibility to swap between the first and the second seed monitoring screen, so that all of the distributor heads can be seen. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 29: Confirm Performance
(big enough to close the way of the seeds) in the tube. Blockage can be formed before and after the sensor as well, in the latter case don’t have to wait to the seeds reach the sensor, because the XeedSystem is able to perceive blockage in a few seconds. - Page 30 This makes sure that only real alerts can be seen. Since the blockage is always an unexpected change in the seed flow, the XeedSystem won’t report blockage on that row, where the sensor sees no seed flow from the beginning. The system reports “no flow”.
-
Page 31: Alerts
IMPORTANT The „Ignore” and „Ignore all” buttons only disable the appearing ALERT screen. The errors will still be displayed on the main screen and in the alarm list. ISOFLOW application – User manual for XeedSystem v1.6... - Page 32 Press the home button to return to the main screen. The error screen can be accessed from the Alert screen, or from the main screen by pressing one of the Error list buttons. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 33: Troubleshooting
(modules and sensors), then the create new system is the only option. For more information to choose the correct option for the situation, check the HELP by pressing the HELP button . ISOFLOW application – User manual for XeedSystem v1.6... - Page 34 (See chapter 4. Installation) Press the confirm button to perform the reset. Press the cancel button to cancel the reset process. ISOFLOW application – User manual for XeedSystem v1.6...
- Page 35 X-LiNE modules and/or sensors in the system than it was before. Press the reset button to perform a reset and create a new system installation. (See chapter 4. Installation) ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 36: 10. Settings
This page provides basic information about the legal and Digitroll Ltd. from, such as accessibility, website. Press the Home button to return to the main screen. Press the Back button to return system settings screen. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 37: Seed Settings
(Depends on the machine parameters, seed quality, litter, deviation of seed sizes etc.) ISOFLOW application – User manual for XeedSystem v1.6... - Page 38 (See: Chapter 6.7: Legends ) Press the Back button to go back to the seed settings. Press the Home button to return to the main screen. Press the Reset button to reset the alarm settings. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 39: Fertilizer Settings
(Depends on the machine parameters, seed quality, litter, deviation of seed sizes etc.) ISOFLOW application – User manual for XeedSystem v1.6... - Page 40 (See: Chapter 6.7: Legends ) Press the Back button to go back to the fertilizer settings. Press the Home button to return to the main screen. Press the Reset button to reset the alarm settings. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 41: System Diagnostic
Use the Back and Next buttons to see the other device’s diagnostics. Use the paging buttons to page through device’s list. Press the Home button to return to the main screen. ISOFLOW application – User manual for XeedSystem v1.6... - Page 42 Use the Back and Next buttons to see the other device’s diagnostics. Use the paging buttons to page through device’s list. Press the Home button to return to the main screen. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 43: 11. System Settings
Press the Reset button to perform a device reset. The device reset resets the XeedGATE and erase all settings. After device reset the system must be installed again from the beginning. ISOFLOW application – User manual for XeedSystem v1.6... -
Page 44: Machine Settings
Speed calibration The seeder’s speed calibration can be modified or set here. Press the Back button to return to the machine settings screen. Press the Home button to return to the main screen. ISOFLOW application – User manual for XeedSystem v1.6... - Page 45 The impulse/meters value can be set in the input field on the bottom of the screen. IMPORTANT For the most precise area measurement it is crucial to set the working-width and do the speed calibration accurately. ISOFLOW application – User manual for XeedSystem v1.6...
-
Page 46: Distributor Binding
The binding of the sensors can be modified here Use the paging buttons to page through the device’s list. Press the Back button to return to the system settings screen. ISOFLOW application – User manual for XeedSystem v1.6... - Page 47 Press the reset button to restore the seed alarm settings to the default option. Press the Home button to return to the main screen. Press the Back button to return to the Alarm settings screen. ISOFLOW application – User manual for XeedSystem v1.6...
- Page 48 Upon disconnecting the SeedView from the system, the “iPad SeedView is in use” screen disappears from the terminal, and the ISOFLOW continues the seed monitoring. ISOFLOW application – User manual for XeedSystem v1.6...
