Window Installation Instructions

WINDOW REQUIREMENTS

1
• These instructions are for a standard
double-hung window. You will need to
modify them for other types of windows.
CAUTION:
bolts do not contact the window sill or
if you have a window without a sill, you
must order accessory kit RAK87 to
properly install this air conditioner.
Call 800.626.2002 or visit ge.com.
• All supporting parts must be secured
to firm wood, masonry or metal.
• The electrical outlet must be within
reach of the power cord.
27" to 36"
(With accordion panels)

STORM WINDOW REQUIREMENTS

2
A storm window frame will not allow the
air conditioner to tilt toward the outside,
and will keep it from draining properly.
To adjust for this, attach a piece of wood
to the stool.
WOOD PIECES–
WIDTH: 2"
LENGTH: Long enough to fit inside the
window frame.
THICKNESS: To determine the thickness,
place a piece of wood on the stool to
make it 1/2" higher than the top of the
storm window frame or the vinyl frame.
Attach securely with nails or screws
provided by the installer.
1/2" higher
than storm
window
frame
Storm window
frame
If the sill support
17" min.
1/2" higher
than vinyl frame
(on some windows)
Wood
Stool
Vinyl frame
REMOVE THE AIR CONDITIONER
3
FROM THE CASE
A Remove and save the 2 screws from the
lower sides of the front grille.
Remove the two control knobs.
B
C Grasp the lower corners of the grille while
pressing in on the case sides with your
finger tips. Pull out to release and lift it up.
NOTE: Do not pull the bottom edge
toward you more than 3" or you may
damage the tabs of the grille.
D
Remove the screw from each side of the
case. Keep them in a safe location.
8
FRONT
FRONT
FRONT
FRONT
