Window Installation Instructions
INSTALL THE AIR CONDITIONER
9
IN THE CASE
Slide the air conditioner into the case by
A
the base pan. Do not push on the controls,
styrofoam air discharge housing or the finned
coils. Make sure the air conditioner is firmly
seated.
Base Pan
Replace the 2 screws removed earlier, one
B
on each side of the case.
Reattach the ground wire to the unit using
C
the ground wire screw.
Ground
wire
Ground
screw
Do not press on
these areas—
damage to the
unit may result
11
INSTALL THE AIR CONDITIONER
9
IN THE CASE (CONT.)
Attach the front grille to the case by inserting
D
the tabs on the grille into the slots on the
front top of the case. Push the grille in.
Secure the front grille to the case by
E
replacing the 2 screws removed earlier.
Press on the top of the grille to help with
side screw installation.
Replace the two control knobs.
F
Connect power.
G
