Windows 98 USB Software Installation Instructions
GCC Elite 12ppm Series Printers
This document is intended to provide instructions for downloading and installing
the Windows 98 USB driver software for GCC's Elite 12ppm Series of laser
printers. Please follow all instructions in this document in order to assure that the
software is properly installed and configured onto your Windows 98 PC. Please
contact GCC Technical Support directly at (781)276-8620 or on-line at
www.gccprinters.com/support for assistance with this installation.
Part One - Download Software
Start by downloading the GCC USB software from GCC's web site at the
following address:
ftp://ftp.gccprinters.com/pub/postscript-pcl/elite-12ppm/windows/Elite12USB.exe
This will give you a file called "Elite12USB.exe". This file is a self-extracting
archive. Double-click the file's icon in Windows to extract the software. When
prompted for a location to extract the files to, type in:
C:\windows\desktop
This will place the driver files in a folder on your desktop called "Elite12USB".
Once this is done, proceed to the installation instructions starting on the next
page.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GCC Technologies Elite 12N
Summary of Contents for GCC Technologies Elite 12N
- Page 1 GCC Elite 12ppm Series Printers This document is intended to provide instructions for downloading and installing the Windows 98 USB driver software for GCC’s Elite 12ppm Series of laser printers. Please follow all instructions in this document in order to assure that the software is properly installed and configured onto your Windows 98 PC.
- Page 2 Part Two - Uninstall Previous GCC USB Software If you have previously installed GCC’s USB software on your PC from an older software download or disk, you will need to uninstall this software in order for this newer software version to be used. To uninstall the older software, follow these steps: 1.
- Page 3 When the printer is plugged into the PC, the PC should automatically begin a two-step Plug and Play installation. The first step is to install the USB printing software, and the second step is to install specific software for your GCC printer model. The steps for these installations are as follows: 1.
- Page 4 Support. Click Next to install the USB driver. Once this driver is installed, the PC should automatically sense the printer and start the second Plug and Play installation, for the specific printer software. This process is covered in Part Four of these...
- Page 5 Part Four - Install Printer Software 1. The Add New Hardware Wizard will start once again, this time to install software specific to your GCC printer. Click Next to continue. 2. The next window will ask what you want Windows to do. Choose “Search for the best driver for your device”...
- Page 6 4. The next window will inform you that a driver has been found for your GCC printer model. Click Next to install the driver. 5. The next window will ask for a name for the printer. You can type in a new name, or keep the default name.
- Page 7 7. A dialog box may appear asking you to insert the Windows 98 CD. Insert the CD and click OK. 8. A dialog box may appear telling you that necessary files on the CD cannot be found. Make sure the Windows CD is inserted, then use the Browse button to access the Windows CD.
- Page 8 Step 8). If the page prints, click Yes in this window. If not, click No and follow the Windows troubleshooting steps that appear. 13. When the installation is complete, you will be returned to the Printers window and a new icon for the printer will appear.
