Savant PAV-VIMAP8S Quick Reference Manual page 2

Rear Panel
A B C D
1 2 3 4
HDMI HDMI HDMI HDMI
In In In In
Rx Tx Rx Tx Rx Tx Rx Tx
10 10 10 10
GbE GbE GbE GbE
1 1 1 1
GbE GbE GbE GbE
RS232 RS232 RS232 RS232
IR IR IR IR
Rx Rx Rx Rx
Tx Out Tx Out Tx Out Tx Out
G G G G G G G G
P1 P1 P1 P1
P2 P2 P2 P2
F G H
Item Description
1G of reserved network data bandwidth.
Commonly used to connect any network
compliant device to transmit its data onto the
Ethernet network by sharing the 10G network
link. 8-Pin RJ-45 female connection.
1 Gigabit
A
IMPORTANT NOTES:
Ethernet
– Do not connect these ports to a network
switch.
– This is a courtesy port. It will not work for all
network functions. For example, Spanning
tree devices are not supported by this port.
SFP+ Housing; Used for connectivity to the 10G
Ethernet Network Switch.
10 Gigabit IMPORTANT! For all 10G connections, use only
B
Ethernet Savant certified SFP+ Direct-Attach Copper
(DAC) cables, or Savant certified fiber and fiber
connectors along with Savant certified SFP+
modules.
Rx – Link Activity LED indicator for all data
Rx/Tx LEDs received on the 10G connection
C
(10 GbE) Tx – Link Activity LED indicator for all data
transmitted from the 10G connection
19-Pin Type A HDMI female digital audio/video
input.
D
HDMI In Supports HDMI 2.0a
HDMI 2.0 compliant cable is required for 4K
content.
100-240V AC 5A 50/60Hz power input module
with On/Off switch.
I – Applies power to the device.
Power Input O – Removes power to the device.
E
Module
NOTE: Includes a field replaceable 5A 250V Fast
acting fuse. For replacement information see the
Replacing the Fuse section below.
RS232 – 3-pin Screw down plug-in connection.
Transmits and receives serial data to and
RS-232
F
from serial controllable devices. For pin-out
Control Port
information, refer to the RS-232 Wiring section
below.
IR - 3-pin Screw down plug-in connection.
Transmits IR signals via an IR Flasher
IR Control
G
(5V tolerant) to devices with an IR input or IR
Port
receiver. For pin-out information, refer to the IR
Wiring section below.
H
Push Buttons Push buttons – Reserved for future use.
8-Pin RJ-45 female connection. Used to
communicate with the Savant System Host.
I
Ethernet
Supports Audio Video Bridging (AVB)/Time
Sensitive Networking (TSN).
J
Grounding Chassis Ground (optional)
Savant Video Input IP Transmitter QRG | 009-1604-03
Copyright 2021 Savant Systems, Inc. | 210416
5 6 7 8
Serial Number
HDMI HDMI HDMI HDMI
In In In In
HIPOT
Rx Tx Rx Tx Rx Tx Rx Tx
100 - 240 V ~
10 10 10 10
50/60 Hz
GbE GbE GbE GbE Max Current: 5A
Fuse: 250V, 5A
Fast Acting
1 1 1 1
GbE GbE GbE GbE
Compliance
RS232 RS232 RS232 RS232
IR IR IR IR
Rx Rx Rx Rx
Tx Out Tx Out Tx Out Tx Out
G G G G G G G G
P1 P1 P1 P1
P2 P2 P2 P2
Wiring and Connections
The following is a description of connections that can be made to the
E
Audio/Video over IP Switch:
IR Wiring
IR connections are made using a 3-pin
Control Connector supplied with the device.
The wire slips into the hole and locks with a
screw located at the top of the connector.
IMPORTANT: IR Wiring Precautions
Ethernet
Ensure that all IR emitters are within 15 feet
(4.6 meters) from the controller's location.
Use of 3rd party blinking IR emitters with
I J
Talk Back is not recommended. These types of emitters can draw
voltage away from the IR signal that can degrade IR performance.
RS-232 Wiring
Serial control connections are made using
a 3-pin Control Connector supplied with
the device. The wire slips into the hole and
locks with a screw located at the top of the
connector.
SFP+ 10 GbE
Enhanced small form-factor pluggable connection. Use
a Savant certified Direct Access Copper (DAC) SFP+
cable to connect the chassis to the 10G switch, or Savant
certified fiber and fiber connectors along with Savant
certified SFP+ modules.
Transport Distance
DAC cable
OM3 multi-mode Fiber
Installation
The Savant Audio/Video over IP 8-Port / 4-port Transmitter chassis
can be mounted using the included rack mounting ears and hardware
in a 3U rack style enclosure and is compatible with all standard 19-inch
National Electrical Manufacturers Association (NEMA) rack mounts.
For more information see the
on the Savant Customer
Supported Audio and Video Formats
Video
HDR
Supported
Formats
1 = at 24 Hz
2 = at 25 Hz
Audio (Pass-through)
– DTS®
– DTS-X®
–
DTS-HD Master Audio™
– DTS-HD (LBR)
– DTS-HD (HRA)
– DTS Digital Surround 96/24™
Audio (Down Mix)
– DTS®
– DTS-X®
– DTS-HD Master Audio™
–
DTS-HD (LBR)
– DTS-HD (HRA)
– DTS Digital Surround 96/24™
2 of 2
PIN 1
PIN 2
PIN 3
Rx
Tx
G
PIN 1
PIN 2
PIN 3
6 ft (2 m)
1000ft (300 m)
Savant Video over IP Deployment Guide
Community.
Supported
5 5
640x480 1280x1024
5 1
720x480 1920x1080
4 3
720x576 1920x1080
5 4
800x600 1920x1080
5 5
1024x768 1920x1080
4 5
1280x720 1920x1200
5 1
1280x720 3840x2160
Dolby® Vision
3 = at 30 Hz
5 = at 60 Hz
4 = at 50 Hz
– Dolby® Atmos
– Dolby® TrueHD™
–
Dolby® Digital (AC-3)
– Dolby® Digital Plus (E-AC-3)
– Multi-Channel PCM
– All HDMI Audio Formats
– Dolby® TrueHD™
– Dolby® Digital (AC-3)
– Dolby® Digital Plus (E-AC-3)
–
Multi-Channel PCM
45 Perseverance Way, Hyannis, MA 02601
Savant.com
1
Out 2
G
3
Not Used
IR +
IR -
1
2
3
Receive
Transmit
Ground
1
3840x2160
2
3840x2160
3
3840x2160
4
3840x2160
5
3840x2160
3
4096x2160
5
4096x2160
| 508.683.2500
