SHOP PRESS
ASSEMBLY INSTRUCTIONS
CP201 - 20 TON AIR OVER SHOP PRESS
PRESS SPECIFICATIONS
Arcan Model No.
A
B
C
D
E
F
G
H
CP201
66.5"
24"
24"
11.25"
4.75"
1"
Air Assist
Y (2)
A - Total Height
B - Inside Width
C - Press Feet Length
D - Bed Width
E - Stroke (ram travel distance from fully retracted position to fully extended position)
F - Pin Diameter
G - Motor Control
H - Press Plates Included
P.O. Box 58
Travelers Rest, SC 29690
Phone: (800) 879-7316
Fax: (864) 834-0073
© Copyright 2007, Arcan Professional Tools
Advertisement
Table of Contents
Related Manuals for Arcan CP201
Summary of Contents for Arcan CP201
- Page 1 SHOP PRESS ASSEMBLY INSTRUCTIONS CP201 - 20 TON AIR OVER SHOP PRESS PRESS SPECIFICATIONS Arcan Model No. CP201 66.5" 24" 24" 11.25" 4.75" 1" Air Assist Y (2) A - Total Height B - Inside Width C - Press Feet Length...
-
Page 2: Safety Information
We want to know if you have any problems with our products. • Release hydraulic pressure before loosening any fittings. If you are missing any parts or find any damage, call Arcan directly, • Maintain proper hydraulic fluid levels. and we will remedy the situation. Please do not call the store where •... -
Page 3: Parts List
Bearing Shield - 1 Accessory only - Not needed for assembly TOOLS NEEDED Washers - 10 1" x 12" Press Pins - 2 3/4" and 9/16" sockets and wrenches Examine box contents, then proceed with the following instructions. CP201 Operation Manual... - Page 4 Wear safety gloves and safety goggles. Note: Position press feet on each side of the press. Attach one bolt, washer and nut on each side. Bolts should be attached OFFSET from one another. Front view CP201 Operation Manual...
- Page 5 Front view WARNING Note: When sliding bed to frame Bed must be at the BOTTOM of the frame bottom, DO NOT use bed handles. before proceeding to the next step. Slide bed down to bottom of frame CP201 Operation Manual...
- Page 6 Do not disconnect hoses prior to assembly. This end up 1. Place ram frame 2. Drop ram into 3. Ram should sit sideways on bed. frame, between inside ram frame. parallel bed bars. CP201 Operation Manual...
- Page 7 Attach bolts up through ram frame to matching holes in press. Hand tighten. Wrench tighten after both bolts have been installed. This end up Ram is now able to move left and right within ram frame. CP201 Operation Manual...
- Page 8 Pump ram against press control. Pump ram against press Ram will retract as Do not allow the ram to plates until gauge reads "5 Tons". plates until gauge reads "10 Tons". pressure is released. extend more than 5.5". CP201 Operation Manual...
-
Page 9: Pump Instructions
4. Once ram is in contact with the item to be pressed, comes into contact with item to be pressed. insert pump handle into high pressure cradle. Using the high pressure pump moves the ram less with each stroke and requires less effort to apply pressure. CP201 Operation Manual... -
Page 10: Replacement Parts List
REPLACEMENT PARTS LIST CP201 - 20 TON AIR OVER SHOP PRESS ITEM NO. ARCAN PART NO. DESCRIPTION QTY. ITEM NO. ARCAN PART NO. DESCRIPTION QTY. RS345009 Spring RS550051 Z Bar * CP20102 Press Bed RSCBP1209 Pump Handle * CP20103 Press Frame... - Page 11 NOTES CP201 Operation Manual...
- Page 12 NOTES CP201 Operation Manual...
