- Page 1 ASSEMBLY INSTRUCTIONS Description : ADIRONDACK ROCKER Item No. : R-52581 ITEM NO : R-52581 Printed in Vietnam REVISED AUG 2, 2013 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO : R-52581 Printed in Vietnam REVISED AUG 2, 2013 - 2 -...
- Page 3 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Back Front leg frame (L-R) Supporter (L-R) (L-R) Seat Runner frame Crossbar ITEM NO : R-52581 Printed in Vietnam REVISED AUG 2, 2013 - 3 -...
- Page 4 Allen key ( ɸ 6.5x19mm) (4x80mm) STEP 1 Attach supporters (D) to the seat (E) with bolts (2) and Canopy (3). Tighten with Allen key (5). ITEM NO : R-52581 Printed in Vietnam REVISED AUG 2, 2013 - 4 -...
- Page 5 (B) with bolts (1) and washers (6). Attach runners (F) to seat frame (E) with bolts (1), washers (6), and canopy (3) as shown below. Tighten with Allen key (5). ITEM NO : R-52581 Printed in Vietnam REVISED AUG 2, 2013...
- Page 6 STEP 3 Attach back (A) to the seat (E) and supporters (D) with bolts (1) and (2) as shown below. Tighten with Allen key (5). ITEM NO : R-52581 Printed in Vietnam REVISED AUG 2, 2013 - 6 -...
- Page 7 Attach arms (C) to supporters (D) with bolts (2) as shown below. Tighten with Allen key (5). Attach arms (C) to front legs (B) with screws (4) as shown below. Tighten with a screwdriver ITEM NO : R-52581 Printed in Vietnam...
