- Page 1 Manufacturer of Quality Medical Products Image Diagnostics, Inc. IDI 1000F Series Monitor Suspension System Model IDI 1000F-1 thru 1000F-6 With OTC Adapter Installation and Maintenance Guide D000-571 REV E MAY-2018 Image Diagnostics, Inc. Page...
-
Page 2: Table Of Contents
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter The text of this manual was originally written, approved and published by the manufacturer in English. The information in this manual is subject to change without notice. - Page 3 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter A. INTRODUCTION The IDI 1000F Flat Panel Suspension System transports monitors used in medical imaging procedures. The system features a counterbalanced arm with vertical travel and internal cable routing. A dual-axis flat panel monitor mount permits independent panel mounting and positioning.
-
Page 4: Symbols
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter B. SYMBOLS Attention, consult accompanying documents. Failure to follow these instructions can cause accidents resulting in serious injury to patient, user, and damage to equipment. -
Page 5: General Safety
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter C. GENERAL SAFETY Attention, consult accompanying documents. Failure to follow these instructions can cause accidents resulting in serious injury to patient, user, and damage to equipment. -
Page 6: Safety Hazards
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter D. SAFETY HAZARDS Installers and Operators using this equipment should understand the safety issues and operating instructions provided. Comments and questions regarding safety should be addressed to: Customer Support Image Diagnostics, Inc. -
Page 7: Installation
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter E. INSTALLATION UNPACK No special handling is required for unpacking this equipment at the site. Conventional shipping materials are used. Recycle or disposal of shipping material per local regulations... - Page 8 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter INSTALL X/Y STOP & GUIDE WHEELS Determine which rail faces the opposing system in the room, then slide the X/Y stop (item 20) down the outside groove of that transverse rail. Leave hardware loose;...
- Page 9 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter INSTALL RAIL END PLATE (Refer to End Plate Assembly Drawing) Install one end plate (item 22) at the far end of the rails, making sure rubber bumper (item 23) faces in towards the rails.
- Page 10 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter Take the thicker thrust ring (item 20) and put around rotation bearing (item 50). Place the stainless-steel thrust ring (item 47) below the thicker thrust ring (item 20).
- Page 11 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter If monitor rotation resistance is inadequate and it fails to stay in the desired position, tighten bolt (item 22). NOTE TO INSTALLER: Ground stud (item 27) has been provided to properly ground monitors as a group.
- Page 12 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter ELECTRICAL CONNECTIONS Colors of conductors in power supply cords shall be in accordance with IEC publication 60227 (amendment #1) or with IEC publication 60245. Wiring Color Codes:...
- Page 13 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter 4. Place section of cable hose into clamp (item 1). 5. Reinstall retainer (item 2) screws (item 3). STATIONARY CABLE HANDLING KIT ASSEMBLY INSTALL MOBILE CABLE HANDLING ASSEMBLY (Refer to Cable Handling...
- Page 14 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter 48 [122cm] MOBILE CABLE HANDLING KIT ASSEMBLY Position shaft/cable handling subassemblies (items 1-8) to desired location on rail Without disrupting alignment, remove shaft and shaft supports. Tighten safety bracket (item 6) screws (item 8).
- Page 15 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter DRESS CABLES (Refer to Gantry Core Assembly) When the monitors have been properly installed, it is recommended that the cables be brought through the pivot tube (item 43). 2" (5cm) flexaust (provided) is to be attached to pivot tube and to be routed underneath the arm (item 51) via the cable clamps (items 46, 50).
- Page 16 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter BALANCE SYSTEM (Refer to Gantry Core Assembly) Note: System balance has been set at factory based upon quoted monitor weight. Note initial settings from Spring Data label (item 18). Substantial increases in payload may require spring change.
-
Page 17: Cleaning
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter MONITOR MOUNT ASSEMBLY ROTATION RESISTANCE The setscrews (item 24) installed in step 6 of "INSTALL MONITOR MOUNT" on page 12 can be loosened or tightened to adjust the rotation resistance of the suspended monitor mount assembly. - Page 18 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter Daily Maintenance Checks: Pre-Operational and Post-Operational Checks Perform daily checks of the monitor suspension BEFORE and AFTER operating the equipment. CAUTION! If any abnormality is found in the monitor suspension, stop using it.
- Page 19 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter Pad attached to the underside of the monitor mount bracket must be complete and undamaged Operational check Move all the movable sections and confirm the following: ...
- Page 20 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter Check that the rail mounting hardware has not become loose. Check that the hardware securing the end plates are tight. Perform a complete functional inspection: -Rotate monitor mount assembly through complete range.
- Page 21 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter Check the pad attached to the underside of the monitor mount. If there is any damage to the pad or if the pad is not properly attached to the unit, it must be replaced.
-
Page 22: Customer Support
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter H. CUSTOMER SUPPORT For technical assistance, be sure you have the complete model and serial number before contacting the local or national service office. DISPOSAL GUIDELINES... - Page 23 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with OTC Adapter May 2018 ECO E571 Added warnings for pad D000-571 REV E MAY-2018 Image Diagnostics, Inc. Page...
