- Page 1 Manufacturer of Quality Medical Products Image Diagnostics, Inc. IDI 1000F Series Monitor Suspension System Model IDI 1000F-1 thru 1000F-6 With Adapter to IDI-03 Rails Installation and Maintenance Guide D000-554 REV C May-2018 Image Diagnostics, Inc. Page...
-
Page 2: Table Of Contents
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails The text of this manual was originally written, approved and published by the manufacturer in English. The information in this manual is subject to change without notice. - Page 3 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails A. INTRODUCTION The IDI 1000F Flat Panel Suspension System transports monitors used in medical imaging procedures. The system features a counterbalanced arm with vertical travel and internal cable routing.
-
Page 4: Symbols
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails B. SYMBOLS Attention, consult accompanying documents. Failure to follow these instructions can cause accidents resulting in serious injury to patient, user, and damage to equipment. -
Page 5: General Safety
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails C. GENERAL SAFETY Attention, consult accompanying documents. Failure to follow these instructions can cause accidents resulting in serious injury to patient, user, and damage to equipment. -
Page 6: Safety Hazards
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails D. SAFETY HAZARDS Installers and Operators using this equipment should understand the safety issues and operating instructions provided. Comments and questions regarding safety should be addressed to: Customer Support Image Diagnostics, Inc. -
Page 7: Installation
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails E. INSTALLATION UNPACK No special handling is required for unpacking this equipment at the site. Conventional shipping materials are used. Recycle or disposal of shipping material per local regulations... - Page 8 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails BUILD TRANSVERSE BRIDGE (Refer to Adapter Assembly Drawing) Remove the two wheel shaft/guide wheel mounts (item 6) from the rail adapter carriage (item 2). Tilt the two wheel shaft/guide wheel mounts into the rail.
- Page 9 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Slide the rails back and forth to center them under the adapter carriages and to align both ends. Make adjustments at the triangulation bars and rail clips until the rails are spaced 17 1/8"...
- Page 10 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails INSTALL MONITOR MOUNT (Refer to Monitor Mount Assembly Drawing) NOTE TO INSTALLER: It is important that the load be balanced on the monitor mount. Take into account any differences in size and weight of the monitors.
- Page 11 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails INSTALL MONITOR (Refer to Monitor Mount Assembly Drawing) 11 kg Maximum weight of any individual monitor. 25 LBS Maximum total weight of monitors.
- Page 12 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails SET ROTATIONAL LIMITS (Refer to Monitor Mount Assembly Drawing) If desired, the stop pin (item 4) can be relocated to another of its four possible mounting locations.
- Page 13 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails MAIN GROUND WIRE First attach main ground wire FROM SERVICE under split lockwasher and nut "A". Attach all other ground wires NUT "B"...
- Page 14 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails INSTALL MOBILE CABLE HANDLING ASSEMBLY (Refer to Cable Handling Kit Assembly Drawing) Slide nut plate of two hanger standoff assemblies (items 1&2) into rail track.
- Page 15 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Position shaft/cable handling subassemblies (items 1-5) to desired location on rail. Without disrupting alignment, remove shaft and shaft supports. Torque standoffs to ~35-50 inch pounds, 4.2-6.0(Nm). Use LOCTITE #242 on hardware.
- Page 16 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Reattach shaft supports. Install one end of shaft to a shaft support. Tighten socket head cap screw (item 5). Slide cable trolley assembly(s) onto cable hanger shaft (item 4).
- Page 17 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails BALANCE SYSTEM (Refer to Gantry Core Assembly) Note: System balance has been set at factory based upon quoted monitor weight. Note initial settings from Spring Data label (item 18). Substantial increases in payload may require spring change.
-
Page 18: Cleaning
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails MONITOR MOUNT ASSEMBLY ROTATION RESISTANCE The setscrews (item 24) installed in step 6 of "INSTALL MONITOR MOUNT" on page 12 can be loosened or tightened to adjust the rotation resistance of the suspended monitor mount assembly. - Page 19 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Daily Maintenance Checks: 1. Pre-Operational and Post-Operational Checks Perform daily checks of the monitor suspension BEFORE and AFTER operating the equipment. CAUTION! If any abnormality is found in the monitor suspension, stop using it.
- Page 20 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Pad attached to the underside of the monitor mount bracket must be complete and undamaged 3. Operational check Move all the movable sections and confirm the following: ...
- Page 21 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Annual Maintenance Check: Clean carriage wheels and guides and the rails where carriage wheels and guides ride inside the rails. Check that the rail mounting hardware has not become loose.
- Page 22 Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails Perform a complete functional inspection: -Rotate monitor mount assembly through complete range. -Raise and lower monitor mount assembly. -Roll carriages through complete range of rails.
-
Page 23: Customer Support
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails The procedures mentioned in these instructions are based on the recommendations of HHS, I.E.C., etc. In cases of increased wear or where severe working conditions exist, maintenance checks should be made at shorter than the specified intervals. -
Page 24: Approvals
Installation and Maintenance Guide for IDI 1000F Series Suspension System for use with adapter to IDI-03 Rails APPROVALS SGS Testing Service The system was tested and found to be in compliance with the requirements of all relevant directives and standards in effect within the European Union at the time of manufacture.
