- Page 1 Installation and Maintenance Guide Information for Installation and Users IDI 1000F Series Monitor Suspension System Model IDI 1000F-1H WOR (without rails)
-
Page 2: Table Of Contents
Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR The text of this manual was originally written, approved and published by the manufacturer in English. The information in this manual is subject to change without notice. - Page 3 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR A. INTRODUCTION The IDI 1000F-1H Flat Panel Suspension System transports monitors used in medical imaging procedures. The system features a counterbalanced arm with vertical travel and internal cable routing.
-
Page 4: Symbols
Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR B. SYMBOLS Attention, consult accompanying documents. Failure to follow these instructions can cause accidents resulting in serious injury to patient, user, and damage to equipment. Warning! Information or instructions shown near this symbol must be adhered to in order to prevent a potentially hazardous situation which if not avoided, could result in death, personal injury or damage to the equipment. -
Page 5: General Safety
Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR C. GENERAL SAFETY Attention, consult accompanying documents. Failure to follow these instructions can cause accidents resulting in serious injury to patient, user, and damage to equipment. -
Page 6: Installation
Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR SAFETY HAZARDS ALERTS Alert Circumstances for use DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. - Page 7 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR INSTALL MONITOR MOUNT NOTE TO INSTALLER: It is important that the load be balanced on the monitor mount. C 6X Remove wireway cover at top of monitor mount.
- Page 8 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR MOUNTING MONITOR Maximum total weight of monitors. To mount a monitor to the system, first remove the monitor mount brackets (front and rear and on each side of the central pivot body) by unscrewing the two screws that hold the front bracket to the rear bracket as shown below.
- Page 9 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR NOTE TO INSTALLER: Ground stud has been provided to properly ground monitor. Terminal strip has been provided for distribution of line voltage to monitor. Cut and strip monitor power cord to fit.
- Page 10 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR BALANCE SYSTEM Note: System balance has been set at factory based upon quoted monitor weight. Note initial settings written on Spring Data label (blank label is shown on right for reference). Substantial increases in payload may require spring change.
- Page 11 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR YOKE BALANCE ADJUSTMENT WARNING! Yoke has been leveled at manufacturers. Make adjustment only absolutely necessary to compensate for an unbalanced load. NOTE: Prior to yoke adjustment - payload must be secure.
-
Page 12: Maintenance
Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR G. MAINTENANCE "Authorized Technician" All maintenance procedures should be done by an experienced technician with demonstrated knowledge and skills (electrical and mechanical) relative to this type of equipment. - Page 13 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR Annual Maintenance Check: Clean carriage wheels and guides and the rails where carriage wheels and guides ride inside the rails. Check that the rail mounting hardware has not become loose.
- Page 14 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR C 6X Should the screws labeled above as “A” become loose, there will be an opening of the mechanical junction between the gantry core arm and the monitor mount assembly.
-
Page 15: Customer Support
Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR H. CUSTOMER SUPPORT For technical assistance, be sure you have the complete model and serial number before contacting the local or national service office. Customer Support Image Diagnostics, Inc. - Page 16 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR D000-1099 REV C 06-SEP-2018 Image Diagnostics, Inc.
- Page 17 Installation and Maintenance Guide for IDI 1000F Series Suspension System Model IDI 1000F-1H WOR REVISIONS TO THIS MANUAL Date Description December 2011 Preliminary Release May 2012 ECO 324 Removed references to “Toshiba.” September 2018 D000-1099 REV C 06-SEP-2018 Image Diagnostics, Inc.
