Robus R4EMLED-01 Instruction Manual

R4EMLED-01
4W MAINTAINED LED EXIT BOX, C/w
4pcs legend stickers
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
! Electrical products can cause death or injury, or damage to property. If in any doubt about the installation or use of this product,
consult a competent electrician
Product technical information and specification may change over time without prior notification. For the latest technical
information please visit our web site www.ledgrouprobus.com or robusdirect.com
5°C < Ta < +40°C, 220V – 240V ~ 50/60Hz, Class I, IP20
Suitable for mounting on a normally flammable surface
Green LED indicator indicates battery charging mode
Complies with AS/NZ2293.3.

Installation

1. Ensure mains supply is switched off before commencing
installation.
2. Remove the PC tray from the body of fitting.
3. Remove the cover of terminal from the PC tray by removing
the screw.
4. Knock out the intended cable entry hole suitable for your
installation (Fit cable gland if weatherproofing necessary).
5. Mark appropriate fixing points on wall or ceiling; check that
fixings will not impinge on concealed cables or pipes before
drilling holes.
6. Fix the PC tray to ceiling/wall using suitable screws.
7. Connect wires from unswitched supply to terminals on gear
tray, Brown to PL, Blue to N and green/yellow to Earth.
There is a link between switched live (SL) and permanent
live (PL) terminals (maintained). LEDs controlled by switch,
connect switched live wire to terminal SL and permanent
live to PL. Note: if "SL" terminal not connected, fitting works
as non-maintained.
8. Write installation date on battery and connect battery.
9. Insert the legends into the ivory diffuser.
10. Attach the body of fitting into the PC tray.
11. Switch on supply: the green LED should come on
indicating correct battery charge has started. In the
non-maintained unit, the LEDs only lights if the mains
supply fails. In the maintained unit, the LEDs will always
be on .When mains supply fails, battery will operate LEDs
in emergency mode.
The Installation must be carried out by a qualified electrician
LED Group Australasia
9/210 Queensport Road North Tel: 07 3890 5444
Murarrie Fax: 07 3890 4777
QLD 4172 Email: purchases@ledgrouprobus.com.au
Australia Website: www.ledgrouprobus.com.au
Issue 3 150317
INSTRUCTION MANUAL
Note:

Testing

The emergency lighting must be inspected and
tested regularly in accordance with local codes
of practice: note: for safety reasons tests should
be carried out during daylight hours.
The minimum recommended test schedule is as
follows:
After installation, allow 16 hours to ensure full
battery charge and then interrupt the supply; the
maximum duration time is 90-minutes check that
LEDs are still lighting.
1. Daily check that charge indicator LED is
working
2. Monthly, interrupt mains for a short period and
check LED lights
3. 6-month and 12-month check, full duration test.
Interrupt mains supply, LEDs will light and
should last for a minimum 90-minutes operation:
batteries must be replaced when they can no
longer support 90-minutes operation.
4. Complete record sheet on installation and
retain in maintenance file.
5. Update file with ongoing test records for
inspection by fire officer or other duly
authorised person

Installation and Maintenance Record:

Installer
Installation Type
Installation test duration & Date
1 st Year 2 nd Year
Test
Month
Signed Date Signed
1 Short
2 Short
Short
3
Short
4
Short
5
Short
6
90 min.
7 Short
8
Short
Short
9
10 Short
11 Short
Short
12
90 min.
3 rd Year
4 th Year
Date Signed Date Signed Date
5 th Year
Signed Date
Page 1
