Prostat OEM Series Installer Manual

Non-programmable thermostats
Hide thumbs Also See for OEM Series:

Advertisement

Non-Programmable Thermostats
PSP1100
Up to 1-heat / 1-cool
PSP2100
Heat Pump, Up to 2-heat / 1-cool
1 Specifications 2 Safety Warnings 3 About Your Thermostat
4 Preparation & Installation 5 Sample Wiring & Jumpers
6 Test Operations 7 Troubleshooting 8 Warranty
WARNING
CAUTION
Follow Installation Instructions carefully. Disconnect Power to the
Heater/Air Conditioner before removing the old thermostat and
installing the new thermostat.
1 Specifications
model PSP1100
• Manual-changeover
• 1 heat, 1 cool
• Non-programmable
• Compatible with gas/elec, millivolt, and heat pump systems with no aux heat
• Battery or 24vac system powered
model PSP2100
• Manual-changeover
• 2 heat, 1 cool
• Non-programmable
• Compatible with heat pumps with 2nd stage aux heat
• Battery or 24vac system powered
Installer Manual
© Copyright 2021, All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OEM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Prostat OEM Series

  • Page 1 Installer Manual Non-Programmable Thermostats PSP1100 Up to 1-heat / 1-cool PSP2100 Heat Pump, Up to 2-heat / 1-cool 1 Specifications 2 Safety Warnings 3 About Your Thermostat 4 Preparation & Installation 5 Sample Wiring & Jumpers 6 Test Operations 7 Troubleshooting 8 Warranty WARNING CAUTION Follow Installation Instructions carefully.
  • Page 3: Table Of Contents

    Table of Contents 2 Safety Warnings Safety Warnings ............4 3 About Your Thermostat Front Panel ..............5 Display ..............6 Normal Operation............7 Fahrenheit or Celsius ............8 Aux Heat ...............9 4 Preparation and Installation Remove Old Thermostat ..........10 Battery Replacement ..........11 Wire Connections ............12 Thermal Insulating Sheet ..........13 5 Sample Wiring Diagrams Sample Wiring Diagrams for PSP1100 ......14...
  • Page 4: Safety Warnings

    2 Safety Warnings Follow Installation Instructions carefully. DISCONNECT POWER TO THE HEATER - AIR CONDITIONER BEFORE REMOVING THE OLD THERMOSTAT AND INSTALLING THE NEW THERMOSTAT. The two Alkaline “AA” batteries must be replaced at least once every 12 months to ensure proper operation. The Low Battery icon will appear on the display when it is time to replace the batteries.
  • Page 5: About Your Thermostat

    3 About Your Thermostat Front Panel (AUX HEAT FAN SWITCH DISPLAY on PSP2100 On or Auto model only) AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT COOL HEAT BATTERIES BATTERY DOOR COOLER & MODE SWITCH WARMER Cool, Off, or Heat BUTTONS BI-COLOR LED Heat or Cool demand indicator when system...
  • Page 6: Display

    Display SET TEMP HEAT COOL BATTERY Heat and Cool indicators. In normal operation, Heat or Cool appears, depending on the Mode Switch position. When heat or cool is energized, the Heat or Cool indicator will flash. Current room temperature. Desired set temperature indicator. When this indicator is on, the large numbers represent the desired room temperature.
  • Page 7: Normal Operation

    Normal Operation FAN SWITCH On or Auto AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT COOL HEAT BATTERIES COOLER & WARMER MODE SWITCH BUTTONS Cool, Off, or Heat Operation Select Cool or Heat with the Mode Switch. Normally leave the fan switched to Auto. In Fan Auto, the fan will turn on only with a heat or cool demand.
  • Page 8: Fahrenheit Or Celsius

    Fahrenheit or Celsius AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT COOL HEAT BATTERIES COOLER & WARMER MODE SWITCH BUTTONS Cool, Off, or Heat Operation Select Off with the Mode Switch. Press and hold the COOLER and WARMER buttons at the same time until the temperature is displayed in degrees Celsius.
  • Page 9: Aux Heat

    Aux Heat (PSP2100 only) AUX HEAT HEAT AUTO NORM EMRGC’Y LOCKOUT AUX HEAT SWITCH COOL HEAT BATTERIES Emergency - Disables all compressor functions* and energizes only Aux Heat to satisfy the heat demand. Normal - Aux Heat is allowed to run, if necessary, along with the heat pump to satisfy the heat demand.
  • Page 10: Preparation And Installation

    4 Preparation and Installation • Proper installation of the thermostat will be accomplished by following these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. • These tools will be required: Wire Cutter Flat Blade &...
  • Page 11: Battery Replacement

    Battery Replacement The batteries are easily accessible from the battery door located on the bottom front of the thermostat (fig. 1). To open the battery slot, pull out on the battery door (fig. 1) and swing down (fig. 2). FIG. 1 FIG.
  • Page 12: Wire Connections

    Wire Connections PSP1100 If the terminal designations on your old thermostat do not match those on the new thermostat, refer to the chart below or the wiring diagrams that follow. Wire from the Install on the old thermostat Function new thermostat terminal marked connector marked Common...
  • Page 13: Thermal Insulating Sheet

    Thermal Insulating Sheet FIG. 1 A label is provided on the backplate that prevents drafts originating inside the wall MODEL: PSP1100 from entering the thermostat. 97061606 4Z95 USE SIZE “AA” MADE IN CHINA ALKALINE BATTERIES These drafts, left unchecked, may cause incorrect room temperature readings.
  • Page 14: Sample Wiring Diagrams

    5 Sample Wiring Diagrams Sample Wiring Diagrams PSP1100 Conventional Heating and Cooling Systems and Heat Pump Systems with no Aux Heat 4 Wire, 1 Stage Cool, 1 Stage Heat 4 Wire, 1 Stage Cool, 1 Stage Heat Heat Pump with B reversing valve Heat Pump with O reversing valve Residential Heat Pumps, split systems &...
  • Page 15 Sample Wiring Diagrams PSP1100 Conventional Heating and Cooling Systems and Heat Pump Systems with no Aux Heat 2 Wire, 1 Stage Gas Heat Dual Transformer 5 Wire, 1 Stage Cool, 1 Stage Heat Residential Gas or Millivolt units Residential Gas or Electric Heat, Electric GAS OR ELECTRIC HEAT Cool, split systems &...
  • Page 16: Sample Wiring Diagrams For Psp2100

    Sample Wiring Diagrams PSP2100 Heat Pump Systems 4 Wire, 1 Stage Cool, 1 Stage Heat 5 Wire, 1 Stage Cool, 1 Stage Heat Heat Pump with O reversing valve Heat Pump with O reversing valve and Auxiliary Heat Residential Heat Pumps, split systems & package units, with no auxiliary heat Residential Heat Pumps, split systems &...
  • Page 17: Jumper Configuration

    Check Jumpers (ONLY for PSP1100) Ensure which jumper is correct for your system. Jumpers are located on the back of the thermostat. ASDF ASDF ASDF GAS/ELEC ELEC GAS/ELEC ELEC J1 = GAS the thermostat will not energize the Fan (G) terminal in heating.
  • Page 18: Test Operation

    6 Test Operation • Turn on the power to the Heating/Air Conditioning (or Heat Pump for PSP2100) system. • On the thermostat, slide the Mode Switch to HEAT. Press the COOLER or WARMER button until the set temperature is 10 degrees above room temperature.
  • Page 19 For the PSP2100 • TWO STAGE OPERATION - The 2nd stage of heat (auxiliary heat) is turned on when the room temperature is equal to or less than: the setpoint minus the 1st stage deadband (one degree, non-adjustable), minus the 2nd stage deadband (two degrees, non-adjustable).
  • Page 20: Troubleshooting

    7 Troubleshooting • SYMPTOM: The slide switches on the thermostat are very difficult to move. CAUSE: The backplate of the thermostat is screwed too tightly into a wall that is not perfectly flat. REMEDY: Loosen the screws holding the thermostat into the wall. •...
  • Page 21: Warranty

    8 Limited Warranty PSP Series - Thermostat Models: PSP1100, PSP1152, PSP2100, PSP2152, PSP2270, PSP2270C, PSP2111, PSP4272, PSP4273, PSP4271C, PSP4272C, PSP4272RT, PSP4273RT, PSP4272CT, PSP4273CT Who Is Providing The Warranty? For further information about this warranty contact This warranty is provided to you by Goodman Consumer Affairs at (877) 254-4729 or by mail to 19001 Manufacturing Company, L.P.
  • Page 22 NOT LIMITED TO LOST PROFITS, LOSS OF USE OF A (3) For products on which a manufacture date is CONTROL, EXTRA UTILITY EXPENSES, OR DAMAGES indicated, if the date the owner purchases the TO PROPERTY. residence from the builder or the date the product is originally installed cannot be verified, the installation Some states and provinces do not allow the exclusion or date is three months after the manufacture date.
  • Page 23 or controversy arising from or relating to your purchase org), JAMS (1920 Main Street, Ste. 300, Irvine, CA of this control, any warranty upon the unit, or the unit’s 92614, www.jamsadr. com), or, subject to our approval, condition. It also includes determination of the scope or any other arbitration organization.
  • Page 24 Battery Stat Tested to Comply with FCC Standards FOR HOME OR OFFICE USE 4Z95 P/N 88-1430 Rev. 2 06/07/21...
