  • Page 1 User Manual Commercial Smart Wi-Fi Thermostat PSP4272C Up to 4-heat / 2-cool with Humidity Control OPTIONAL Wi-Fi and Local API with module Read all instructions before proceeding. Store this manual for future reference © Copyright 2021 All Rights Reserved. Made in China PSP4272C User Manual.indd 1 PSP4272C User Manual.indd 1 6/9/21 11:05 AM...
  • Page 2 Notice: Only peripherals complying with FCC limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by ProStat + ™, is likely to result in interference to radio and TV reception. Changes or modifications to the product, not expressly approved by ProStat + could void the user’s authority to operate the equipment.
  • Page 3 We, ProStat + , declare under our sole responsibility that the device to which this declaration relates: Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Table Of Contents

    Contents 3 Setup Step Table ...........15 Features ...............5 Terms ................6 How to Change Settings in the Setup Screens .....18 Programming a Daily Schedule ........19 1 About Your Thermostat Backlight ..............21 Front Panel ..............7 Display .................9 4 Advanced Features & Operation Emergency Heat ............21 2 Basic Operation Wi-Fi Module .............22...

  • Page 5: Features

    Congratulations and thank you for purchasing your new ProStat + Smart Wi-Fi thermostat. This guide is intended to help you install and setup the basic features of your thermostat. Features • Choose 7-Day, 5/1/1 day or 1-Day Programming • Controls Humidification, Dehumidification &...

  • Page 6: Terms

    Terms Auto-Changeover: A mode in which the thermostat will turn on the heating or cooling based on room temperature demand. Cool Setpoint: The warmest temperature that the space should rise to before cooling is turned on (without regard to deadband). Deadband: The number of degrees the thermostat will wait, once a setpoint has been reached, before energizing heating or cooling.

  • Page 7: About Your Thermostat

    1 About Your Thermostat Front Display 1 Ambient Light Sensor 2 Backlit, Scrolling LCD Display 3 OVERRIDE Button 4 Warmer & Cooler Buttons 5 Heat or Cool Indicator Heat = Red, Cool = Green 6 Setup Buttons behind door TO ENTER MENUS BUTTON PRESS Setup Steps Press SETUP button...
  • Page 8 Button Callouts Inside Doors User Manual PSP4272C User Manual.indd 8 PSP4272C User Manual.indd 8 6/9/21 11:05 AM 6/9/21 11:05 AM...

  • Page 9: Display

    5 Room Temperature Display Indicates the current room temperature and displays the outdoor temperature when selected. 6 Outdoor icon Indicates the temperature displayed is from the optional outdoor sensor or the ProStat + Web Portal. User Manual PSP4272C User Manual.indd 9 PSP4272C User Manual.indd 9...
  • Page 10 Display Features Desired Set Temperature Indicates desired room temperature(s). Also displays the highest and lowest temperatures for the day. Wi-Fi icons One dot indicates the thermostat recognizes the wireless module. The “full” icon indicates the thermostat is currently connected to the Local access point, via the optional Wi-Fi Module. Setup Step icon Indicates the step number when the thermostat is in the setup mode.
  • Page 11 Indicates constant, continuous fan operation. When Fan On is not lit - indicates the fan will only operate when necessary to heat or to cool. * Hi and Lo Temperatures for the day reset at midnight and require an outdoor sensor or ProStat+ Skyport connectivity. User Manual PSP4272C User Manual.indd 11 PSP4272C User Manual.indd 11...

  • Page 12: Basic Operation

    Setting the Clock and Day* *Not available when connected to a ProStat + Account Press the SET CLOCK button. Adjust the clock using the WARMER or COOLER buttons. Press MODE to advance to the day setting. Adjust the day using the WARMER or COOLER buttons. Press the SET CLOCK button to confirm settings.

  • Page 13: Selecting Your Desired Temperature

    Selecting Your Desired Temperature (adjusting the setpoints) Auto-Changeover Mode Pressing the WARMER or COOLER buttons in Auto mode will adjust both the heat and cool setpoints simultaneously. To adjust the heat and cool setpoints individually, choose HEAT mode to adjust the heat setpoint, and COOL mode to adjust the cool setpoint, then return to AUTO mode.

  • Page 14: Viewing The Temperature Sensors

    The high and low temperatures reset at 12:00 am. If connected to a ProStat+ Skyport account, the temperatures for your zipcode will be shown unless a wired sensor is connected. Press the MODE button to view any connected remote or supply sensors ACCSRY and other accessories.

  • Page 15: Setup Step Table

    3 Setup Step Table FD = Factory Default Setting Step# Description Range Prog Mode Non, 1 Day, 5/1/1 Day, 7 Day 7 Day Available Modes Heat/Cool/Auto/Off, Heat/Cool/ Heat/Cool/Off, Heat/Off, Cool/Off Auto/Off Backlight On, Off Backlight Level Off thru 7 levels of brightness Level 5 Night Dimmer On/Off...
  • Page 16 Step# Description Range Cycles Per Hour No Limit, 2, 3, 4, 5, 6 Compressor Minimum Off Minutes 0, 3, 5 Minutes Min. Heat/Cool Setpoint Difference 0 - 6 Degrees Number of Heat Stages 0 - 3 Number of Cool Stages 0 - 2 Number Of Compressor Stages 1, 2...
  • Page 17 Open Dehumidify only with Cooling On, Off Light Activation Sensitivity Press Fan button to set current light level Light Activation to Occupied On/Off ProStat+ Skyport On, Off Local API On, Off On, Off ADR Action Observe Setpoint Offset, Observe Observe Set-...

  • Page 18: How To Change Settings In The Setup Screens

    How to Change Settings in the Setup Screens To enter Setup screens, press the SETUP button, then press WARMER WARMER MODE. Use the WARMER or COOLER buttons to adjust the value of your selection. Press MODE to advance to the next setup step. MODE MODE Clock...

  • Page 19: Programming A Daily Schedule

    Programming a Daily Time Period Schedule To enable (RUN) or turn ON the Time Period Schedule press the Program button momentarily. To turn Off the Time Period Schedule press this button again. To alter the Time Period Schedule settings; press & hold this button for 5 seconds until the SET PROGRAM prompt appears. Modify the settings with the Warmer and Cooler buttons.
  • Page 20 Select the Mode for the Occupied period – Press the Warmer or Cooler buttons to choose the mode for the occupied period. The choices are: Off, Heat only, Cool only and AUTO changeover. Adjust the Occupied Cool Setpoint – Press the Warmer or Cooler buttons to adjust the Cooling setpoint for comfort. Adjust the Occupied Heat Setpoint –...

  • Page 21: Backlight

    Backlight (Setup Steps 3-8): Press Setup and then Mode over and over to advance to step #3 Backlight (Setup Step 3) Off - Backlight turns on only with a button press and turns off after 8 seconds. On - Backlight is on continuously. Backlight Intensity Level (Setup Step 4) - The backlight can be adjusted between Off and seven levels of brightness Night Dimmer (setup step 5) - Selecting On allows for automatic dimming of the display at night.

  • Page 22: Wi-Fi Module

    Press the Cooler button to configure Wi-Fi settings. Press the Warmer button to join this thermostat to a ProStat+ account. If the thermostat is connected to Wi-Fi and the Internet, a Device ID will appear on the scrolling display of the thermostat. You will enter this code to add this thermostat to your ProStat+ account via a browser or the ProStat+ mobile app.

  • Page 23: Factory Defaults

    Resetting the thermostat to Factory Defaults (for default values see Advanced Setup Table) If, for any reason, you desire to return all the stored settings back to the factory default settings, follow the instructions below. WARNING: This will reset all Time Period and Advanced Programming to the default settings. Any information entered prior to this reset will be permanently lost.
  • Page 24 Innovation, Science and Economic Development Canada ICES-003 Compliance Label: CAN ICES-3 (B)/NM8-3(B) rev. 2 06/09/2021 88-1380 PSP4272C User Manual.indd 24 PSP4272C User Manual.indd 24 6/9/21 11:05 AM 6/9/21 11:05 AM...
