hole 0 is the initial position, 167cm
hole 1 is 1 position, 178cm
hole 2 is 2 position, 189cm
hole 3 is 3 position 200cm
(note: 1 and 2 positons are for normal use).
2. To open the stretcher, open the lock buttons placed in the head part and in the foot part.
(fig.6, fig.7)
3. Place the two parts on each side of the patient.
4. Lift up the body of the patient and close the upper safety catch.
5. Lift up the foot of the patient and close the lower safety catch.
6. Immobilize the patient with safety belts.
WARNINGS!
When adjusting the length of the stretcher to prohibit more than 3 position,
•
that is the length is than 200cm.
Be sure the clutch button is in lock state when transport the patients.
•
After using, can be stored as folded. stretching the length to the maximum
state then folded
(fig.5)
(fig.5)
(fig.6)
.
(fig.9)
(fig.9)
11
ENGLISH
(fig.7)
