Summary of Contents for Discount Car Stereo VOL-AUX
Page 1
Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 VOL-AUX QUICK START AUXILIARY INSTALLATION GUIDE FOR SELECT 1984-01 VOLVO...
Page 2
With this adapter you keep the factory radio and enjoy music content stored on audio device or from the internet if using Smartphone. The VOL-AUX replaces factory CD changer (if present). Installation: Radio must be pulled from the dash to connect the adapter.
Page 3
Fig. 6 3 ft. Aux cable Fig. 4 Radio’s 8-pin Changer port Tap the yellow wire from adapter (See Fig. 3) to either GREEN/BROWN wire at pin 3 or 9 on “SC” radio harness (See Fig. 5) Other Volvo radios use GREEN/RED wire at pin 9 Fig.
Page 4
Disconnect the YELLOW wire (from step 4) and connects Red wire output and “CR” changer controls radios (8-pin port on back of the radio). side of filter. 2. My radio has a built-in 6 CD changer, will the VOL-AUX work? Connect the wire on filter input side to...
