Page 1 Cold Storage Refrigeration EVOT EVOP EVAPORATOR EVXV DISTRIBUTOR OPERATION & SERVICE MANUAL For The VECTOR 8100 Cold Storage Refrigeration Units 62-11785 Rev B...
Page 3 OPERATION & SERVICE MANUAL For The VECTOR 8100 Cold Storage Refrigeration Units © Carrier Corporation, 2017 Printed in U. S. A. June 2017...
Page 5: Table Of Contents
TABLE OF CONTENTS PARAGRAPH NUMBER Page SAFETY PRECAUTIONS ............. . . 1–1 SAFETY PRECAUTIONS .
Page 6 OPERATION ................3–1 DISPLAY .
Page 7 USER SELECTED OVERRIDE OPERATION ........4–9 4.8.1 Supply Air Limit Control...
Page 8 00023 A/C CURRENT OVER LIMIT ..........7–10 00024 COMPRESSION RATIO EXCEEDED .
Page 9 P00179 CHECK LIV ............. 7–43 P00180 CHECK SUCTION MOD VALVE .
Page 10 07009 RETURN AIR SENSORS OUT OF RANGE (RAT & RAT2) ..... . . 7–77 P11000 CHECK CONDENSER FAN MOTOR 2 ........7–78 P13000 CHECK CONDENSER FAN 2 CIRCUIT .
Page 11 8.7.5 Economizer Heat Exchanger ..........8–18 8.7.6 Stepper Test Harness...
Page 12 62-11785 viii...
Page 13 LIST OF ILLUSTRATIONS FIGURE NUMBER Page Figure 1.1 Lockout/Tagout ............. . . 1–2 Figure 2.1 Front View - Refrigeration System Components .
Page 14 Figure 8.20 Megohmmeter Connection to Ground Plate ........8–31 Figure 8.21 Light Bar Connections .
Page 15 LIST OF TABLES TABLE NUMBER Page Table 2–1 Model Chart ..............2–1 Table 2–2 Additional Support Manuals .
Page 16 62-11640...
Page 17: Safety Precautions
SECTION 1 - SAFETY PARAGRAPH NUMBER Page SAFETY PRECAUTIONS ............1–1 SPECIFIC WARNING, CAUTION, AND NOTICE STATEMENTS .
Page 18 62-11785...
Page 19 Follow safe work practices and utilize the appropriate protective equipment at all times. Your Carrier Transicold refrigeration unit has been designed with the safety of the operator in mind. During normal operation, all moving parts are fully enclosed to help prevent injury. During all pre-trip inspections, daily inspections, and problem troubleshooting, you may be exposed to moving parts.
Page 20: Figure 1.1 Lockout/Tagout
Power Figure 1.1 Lockout/Tagout Be aware of HIGH VOLTAGE supplied at the power plug. Even with the unit off, power is present from the plug to the inside of the control box. Whenever practical, disconnect the high voltage source when performing service or maintenance procedures and lockout/tagout the receptacle in accordance with your company procedures.
Page 21 WARNING Do not connect power plug to any electrical outlet without checking that it meets the 460/3/60 and 30 Amp electrical requirements of the unit. WARNING Ensure the power plug is clean and dry before connecting to any electrical outlet / receptacle. WARNING Do not toggle the START/RUN - OFF switch out of the OFF position when in PC Mode or the unit will start.
Page 22 WARNING Only a refrigerant cylinder containing R404A should be connected to this refrigeration unit in order to pressurize the system. However, dry nitrogen may be used to increase pressure. Any other gas or vapor will contaminate the system and require additional removal and evacuation. WARNING Do not use a nitrogen cylinder without a pressure regulator.
Page 23 Do not bend the copper tubing on the condenser coil when installing the new condenser. Bend the unit tubing if tubes do not align correctly. Under no circumstances should anyone attempt to repair sealed module internal components. Should a problem develop with these components, contact your nearest Carrier Transicold dealer for replacement. 1–5...
Page 24: Safety Decals
SAFETY DECALS 62-11785 1–6...
Page 25 1–7 62-11785...
Page 26 62-11785 1–8...
Page 27 1–9 62-11785...
Page 28 62-11785 1–10...
Page 29: Figure 8.13 Evaporator Expansion Valve
SECTION 2 - UNIT DESCRIPTION PARAGRAPH NUMBER Page INTRODUCTION ............. 2–1 GENERAL DESCRIPTION .
Page 30 62-11785...
Page 31: Unit Description
2.1. GENERAL DESCRIPTION The Vector 8100 unit is an all electric, fully charged, pre-wired, refrigeration/heating “nose mount” unit. The unit is used on insulated refrigerated compartments to maintain cargo temperatures within very close limits. Electrical power is supplied to the unit from an external source, at the power supply receptacle (PSR).
Page 32: Figure 2.1 Front View - Refrigeration System Components
Figure 2.1 Front View - Refrigeration System Components MOUNT ATT AS SHOWN PARTITION 10, 11, 12 5, 6, 7 1. Condenser Fans and Motors (CDM1 & CDM2) 12. Compressor Discharge Pressure Transducer (CDP - Located in discharge line) 2. Ambient Air Temperature Sensor (AAT) 13.
Page 33: Figure 2.2 Evaporator Section - Grille Removed
Figure 2.2 Evaporator Section - Grille Removed MOUNT DTT AS SHOWN TUBE SHEET 1. Evaporator Coil 11. Return Air Temperature Sensor 2 (RAT2) (located behind bracket, if equipped) 2. Evaporator High Temperature Switch* (EVHTS) 12. Drain Pan Heater (HTR1) 3. Supply Air Temperature Sensor (1SAT) 13.
Page 34: Figure 2.3 Control And Standby Boxes
Figure 2.3 Control and Standby Boxes CONTROL BOX STANDBY BOX 1. Condenser Motor Contactor (CDCON1) 13. AC Current Sensor (CT 1, 2, 3) 2. Condenser Motor Contactor (CDCON2) 14. Compressor Contactor (CCON) 3. Evaporator Motor Contactor (1EVCON) 15. High Voltage Transformer (HVT) 4.
Page 35: Condensing Section
CONDENSING SECTION The condensing section (see Figure 2.1) consists of the compressor, condenser fans, condenser, economizer, refrigerant controls defrost air switch, piping, wiring, and associated components. 2.3.1 Compressor The unit is fitted with a scroll compressor equipped with suction and discharge service valves and an economizer connection.
Page 36: Economizer Transducer And Sensor
2.3.6 Economizer Transducer and Sensor a. Economizer Outlet Pressure Transducer (ECOP) The ECOP is located in the vapor injection line leaving the economizer. It provides the control system with economizer outlet pressure information to be displayed, recorded in DataLink data, and used to determine the required position of the economizer expansion valve.
Page 37: Evaporator Switches, Transducers And Sensors
It is located in the supply air outlet housing. SYSTEM OPERATING CONTROLS AND COMPONENTS Temperature control is provided by the Carrier Transicold APX™ Control System. Once the system is set at the desired temperature, the unit will operate automatically to maintain the desired temperature within very close limits.
Page 38: Special Features
2.5.3 Special Features The following additional special features are incorporated into the Carrier Transicold APX control system: • An easy to read LCD display MessageCenter which clearly displays all required information • Unit Data and Advanced User selectable Functional Parameters •...
Page 39: Figure 2.4 Power Control Module
Figure 2.4 Power Control Module 1. Relay, Power Enable (PER) 8. Battery Negative Connection (T2) 2. Fuse (F1 = 5 amp), Module Logic Circuit and 9. Battery Charger Output Connection (T3) Buzzer Power 10. Fuse (F12 = 5 amp), Satellite Communications 3.
Page 40: Figure 2.5 Ogf Module
b. Main Microprocessor Module The main microprocessor module (MM) houses the main system microprocessor. The module is totally self contained and does not contain any serviceable components. c. SVM Module The stepper valve module (SVM) houses the CSMV, EVXV & ECXV operating microprocessor. The module is totally self contained and does not contain any serviceable components.
Page 41 Figure 2.6 Display Module START/STOP ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT STATUS OK 1. Display Screen 7. Arrow Keys 2. MENU key 8. “=” (Select) Key 3. DEFROST key 9. START/RUN-OFF Switch 4. START/STOP - CONTINUOUS Key 10. Soft Keys 5.
Page 42: Options
k. Display Module Keys • ALARM - The ALARM key allows viewing of the alarms stored in the system. • UP ARROW and DOWN ARROW - These keys allow scrolling through the selections presented. • EQUAL (ENTER) - The EQUAL key is used to confirm a selection and lock it into memory. •...
Page 43: Remote Panel
The system may be configured to display the sensor reading in the Unit Data and to record the sensor reading in the DataLink data recorder. A user specified name may be configured for each sensor. This name will be displayed, rather than the default Remote Sensor #1, #2 or #3, name in the unit data list.
Page 44 Unit Specification Detail Full Load Amps (FLA) 1.9 amps @ 460 VAC, 60 Hz Horsepower 1.1 hp (820 watts) at 60 Hz Speed 1700 rpm @ 60 Hz Condenser Fan Motors (Each) Bearing lubrication Factory lubricated, additional grease not required Rotation Clockwise when viewed from stator end Resistance...
Page 45: 2.10 Component Resistance & Current Draw Data
2.10 COMPONENT RESISTANCE & CURRENT DRAW DATA Component Ohms Amps Contactor Coil (HTCON1, HTCON2, CDCON, 48 Ohms ±10% 0.25 Amps ±10% 1EVCON) Contactor Coil (PSCON, PSCON2, CCON) 0.6 Ohms ±10% Contacts Open 0.25 Amps ±10% 48 Ohms Contacts Held Closed Liquid Injection Solenoid Valve (LIV) 7.2 Ohms ±3% 1.65 Amps ±3%...
Page 46: Economized Mode
The refrigerant pressure drop caused by the expansion valve is accompanied by a drop in temperature so the low pressure, low temperature liquid that flows into the evaporator tubes is colder than the air that is circulated over the evaporator tubes by the evaporator fan. The evaporator tubes have aluminum fins to increase heat transfer; therefore heat is removed from the air circulated over the evaporator.
Page 47: Figure 2.8 Refrigeration Circuit Standard Mode
Figure 2.8 Refrigeration Circuit Standard Mode Evaporator EVOP EVOT EVXV Distributor Condensor Fusible Plug Subcooler Reciever Liquid Line Filter Drier Service Valve LIV N/C ECXV Compressor Discharge Service Valve Economizer CSMV Economizer ECOP Connection ECOT Compressor 2–17 62-11785...
Page 48: Figure 2.9 Refrigeration Circuit Economized Mode
Figure 2.9 Refrigeration Circuit Economized Mode Evaporator EVOP EVOT EVXV Distributor Condensor Fusible Plug Subcooler Reciever Liquid Line Filter Drier Service Valve LIV N/C ECXV Compressor Discharge Service Valve Economizer CSMV Economizer ECOP Connection ECOT Compressor 62-11785 2–18...
Page 49: Operation
SECTION 3 - OPERATION PARAGRAPH NUMBER Page DISPLAY ..............3–1 DISPLAY SCREENS .
Page 50 62-11785...
Page 51: Figure 3.1 Display Module
SECTION 3 OPERATION DISPLAY WARNING Unit may start automatically at any time even if the switch is in the OFF position. Use proper lockout/tagout procedures before inspection/servicing. All unit inspection/servicing by properly trained personnel only. Figure 3.1 Display Module START/STOP ELECTRIC COOL .3 34...
Page 52: Display Screens
DISPLAY SCREENS START/STOP ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT STATUS OK Default Screen START/STOP ELECTRIC COOL Viewing Menu Soft Key Selections Press Menu Key to Scroll INTELLISET PRETRIP HOUR UNIT METER DATA Typical Menu Screen SAMPLE SCREEN (1 OF 3) DISPLAYED ITEM #1 DISPLAYED ITEM #2 DISPLAYED ITEM #3...
Page 53: Starting Unit
1. Place the START/RUN-OFF switch in the START/RUN position. 2. The system will display the Carrier Transicold logo, display the default screen, present language selection and the hour meter readings (if configured to do so) along with a test flash of the alarm light and light bar amber LED’s.
Page 54: Inspect Mode
INSPECT MODE Inspect Mode provides an additional layer of safety for operators and technicians. Inspect Mode should be used during all pretrip inspections of the unit. Inspect Mode is a user activated feature that forces the unit to shutdown and remain in shutdown regardless of operating state.
Page 55: Intelliset
NOTES • The above settings are examples of possible settings. Factory IntelliSets are available from your authorized Carrier Transicold Truck/Trailer dealer • IntelliSet may be pre-programmed as “IntelliSleep” which allows Sleep Mode to be entered by simply changing to that IntelliSet.
Page 56 3.5 INTELLISET - Continued START/STOP ELECTRIC COOL Viewing Menu Soft Key Selections Press Menu Key to Scroll INTELLISET PRETRIP HOUR UNIT METER DATA 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode and the default screen displayed, press the “=”...
Page 57: Pretrip
PRETRIP Pretrip is a set of tests run by the control system to check unit operation. It is recommended that a Pretrip is run prior to loading the refrigerated compartment. It will indicate a failure if one is detected. A Pretrip can be started at any box temperature. If Pretrip is started while the unit is in a Start-Stop off cycle the unit will start during the course of the test.
Page 58 3.6 PRETRIP - Continued 3. If “Start Pretrip” is selected, Pretrip will begin and the Pretrip Status screen will be displayed. NOTE At any time during Pretrip, the UNIT DATA soft key may be pressed to allow the user to view the unit data screen (refer to Section 3.14).
Page 59 3.6 PRETRIP - Continued Test 2 - 12VDC Electrical Component Amperage Check - Test 2 will check the amperage (current) draw of the fol- lowing components: • Battery Amp Draw (All Components Turned Off). • Compressor Contactor • Liquid Injection Valve •...
Page 60: Changing Setpoint
CHANGING SETPOINT START/STOP ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT STATUS OK 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode and the default screen displayed (press the Back soft key if required): 2.
Page 61: Start-Stop Operation
START-STOP OPERATION START/STOP ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT START/STOP MODE SELECTED 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode press the START-STOP/CONTINUOUS key until “START/STOP” is highlighted. 2. The message “START/STOP MODE SELECTED” will be displayed in the MessageCenter for 10 seconds. 3.
Page 62: Continuous Operation
CONTINUOUS OPERATION CONTINUOUS ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT CONTINUOUS RUN MODE SELECTED 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode press the START-STOP/CONTINUOUS key until “CONTINUOUS” is highlighted. 2. The message “CONTINUOUS RUN MODE SELECTED” will be displayed in the MessageCenter for 10 seconds. 3.
Page 63: 3.10 Data Recorder
3.10 DATA RECORDER The APX Control System contains a built-in DataLink data recorder with 3 megabytes of memory. The recorded data can be downloaded from the DataLink data recorder using either the TRU-Tech/TRU-View program or a Data Transfer USB memory device. The DataLink data recorder reads the same input information as the control system (Functional Parameters, Con- figurations, and Unit Data) at all times.
Page 64: Data Downloading
3.10 DATA RECORDER - Continued 3.10.3 Data Downloading The data within the DataLink data recorder can be downloaded using either the TRU-Tech/TRU-View program with a PC-USB service cable connected to the USB interface port or with a Data Transfer USB memory device (refer to Section 5.3.3).
Page 65 3.10 DATA RECORDER - Continued MARK TRIP START Trip Start places the present time and date as a stamp in the data recorder memory to allow easy review of the data from the last trip, and to allow downloading data from a specific trip. A trip begins at a Trip Start and ends at the next Trip Start.
Page 66: 3.11 Manual Defrost
3.11 MANUAL DEFROST START/STOP ELECTRIC DEFROST DEFROST SETPOINT DEFROST CYCLE STARTED 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) press the MANUAL DEFROST key. NOTE This procedure may be demonstrated in PC Mode but the unit will not actually enter defrost. 2.
Page 67: 3.12 Language Selection
3.12 LANGUAGE SELECTION START/STOP ELECTRIC COOL Viewing Menu Soft Key Selections Press Menu Key to Scroll LANGUAGE DATA EXIT RECORDER 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode press the MENU key until LANGUAGE is displayed. 2.
Page 68: 3.13 Advanced User
3.13 ADVANCED USER START/STOP ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT STATUS OK NOTES • As shipped from the factory, the system will operate in the Driver Mode. In the Driver Mode, some data and menu items covered in this publication will not be available. •...
Page 69: 3.14 Unit Data
3.14 UNIT DATA START/STOP ELECTRIC COOL Viewing Menu Soft Key Selections Press Menu Key to Scroll INTELLISET PRETRIP HOUR UNIT METER DATA 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode, press the MENU key until UNIT DATA is displayed. 2.
Page 70: Table 3-1 Unit Data
Table 3–1 Unit Data DATA DEFINITION POWER BATTERY Battery voltage AMP DRAW Battery charging or discharging amps UNIT AC CURRENT #1 (or 2 or 3) High Voltage Current Draw on the numbered circuit UNIT AC VOLTAGE Voltage in the high voltage circuit REFRIGERATION SENSORS AMBIENT AIR TEMP Ambient (air entering condenser) air temperature...
Page 71: 3.15 View Active Alarms
3.15 VIEW ACTIVE ALARMS ACTIVE ALARMS (2 OF 3) A00013 HIGH DISCHARGE PRESSURE A00022 LOW SUCTION PRESSURE A00028 CHECK REFRIG SYSTEM BACK CLEAR ALARMS 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode press the ALARM key.
Page 72: 3.16 View Hour Meters
3.16 VIEW HOUR METERS START/STOP ELECTRIC COOL Viewing Menu Soft Key Selections Press Menu Key to Scroll INTELLISET PRETRIP HOUR UNIT METER DATA 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode, press the MENU key until HOUR METERS is displayed.
Page 73: 3.17 Functional Parameters
3.17 FUNCTIONAL PARAMETERS START/STOP ELECTRIC COOL Viewing Menu Soft Key Selections Press Menu Key to Scroll LANGUAGE DATA FUNCTIONS EXIT RECORDER 1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode, and in the Advanced User Mode, press the MENU key until FUNCTIONS is displayed. 2.
Page 74 Table 3–2 Functional Parameters PARAMETER FUNCTION DESCRIPTION SELECTIONS TEMPERATURE SETTINGS DEFROST TIMER 1.5HRS The defrost timer will automatically put the unit into the defrost SET FOR 3HRS cycle at the interval selected if DTT is below 40°F (4.4°C) or the 6HRS SAT is below 45°F (7.2°C).
Page 75 Table 3–2 Functional Parameters PARAMETER FUNCTION DESCRIPTION SELECTIONS • RESTART 0.5 to 18°F (.28 to 10°C) Following the Minimum Off Time, should a compartment tem- TEMP: (in 0.5° increments) perature drift this far above or below setpoint in the Perishable 5.4°F (3°C) Range or above setpoint in the Frozen Range, the unit will re- start.
Page 76: 3.18 Stopping Unit
3.18 STOPPING UNIT START/STOP ELECTRIC COOL .3 34 BOX TEMPERATURE SETPOINT STATUS OK SROS To stop the unit, place the START/RUN-OFF switch in the OFF position. The unit will shutdown immediately while the system completes a shutdown sequence and then the display will go blank. The display will turn off. NOTE The system will close the compressor suction modulation valve (CSMV) and evaporator expansion valve (EVXV) to 0% open before turning off.
Page 77: 3.19 Option - Datatrak
Carrier Transicold has worked with approved communication providers with recommended installation locations, and wiring connections to Carrier units. Instructions for installing this equipment is supplied by each individual pro- vider, and not by Carrier Transicold. Communications electrical harnesses are available from Carrier Transicold Performance Parts Group (PPG).
Page 78: 3.20 Emergency Bypass Mode
Once Emergency Bypass Mode has been activated, the unit will operate normally for 24 hours, a countdown timer will be shown on the display. This 24 hour window of operation will keep the load safe, and provide enough time to contact the nearest Carrier Transicold Service Center for repair of the unit. START/STOP...
Page 79: 3.21 Remote Panel
3.21 REMOTE PANEL The unit may be fitted with an optional remote control panel. The remote panel, which is very similar to the display module, displays compartment setpoints, compartment temperatures and operating modes (heat, cool or defrost). The setpoint may be modified and the unit may be started and stopped using the remote panel. This compact remote panel can be mounted to suit the individual operator’s preferences - on the front bulkhead, or in the compartment (even in the wall itself).
Page 80 3.21 REMOTE PANEL - Continued The following unit functions are controlled the same as the main display: • Display compartment temperatures, Section 3.2 • Display the current mode of operation for each compartment, Section 3.2 • Intelliset selection, Section 3.5 •...
Page 81: Temperature Control
SECTION 4 - TEMPERATURE CONTROL PARAGRAPH NUMBER Page INTRODUCTION ............. 4–1 SEQUENCE OF OPERATION - ELECTRICAL .
Page 82 62-11785...
Page 83: Sequence Of Operation - Electrical
SECTION 4 TEMPERATURE CONTROL NOTES 1. If the unit is in an alarm condition, the control system alarm response may override the operation described herein. If an alarm is displayed in the MessageCenter, refer to the specific alarm description in Section 7 for “Unit Control”...
Page 84: Operation
OPERATION The APX Control System will energize the condenser fan motors in order to determine the phase sequence of the incoming power. If incoming power is not correct, the system will shutdown and restart, energizing the other power supply contactor (PSCON or PSCON2). If the phase sequence is not corrected by this action, the A00074 - “PHASE REVERSED”...
Page 85: Start-Stop Configuration
4.4.1 Start-Stop Configuration Start-Stop Operation is dependent on both Configuration and Functional Parameter settings. The first setting to be considered is the START-STOP PARAMETERS Configuration. This setting determines control actions when in the Perishable Range or Frozen Range. The available settings are TOGETHER and SEPARATE. •...
Page 86: Re-Start Parameters
3. Battery is fully charged - Amperage The control system will calculate the average current draw over a 20 second period. Once this average drops below the selected value, shutdown will be allowed. The CURRENT FOR START-STOP SHUTOFF is selected in the control system Configurations.
Page 87: Continuous Operation
3. Minimum Off Time has expired The MINIMUM OFF TIME Functional Parameter setting allows the unit to remain off for extended periods of time, maximizing power economy. The unit may not be restarted until the MINIMUM OFF TIME has expired and the compartment temperature is greater than the PERISHABLE RESTART TEMPERATURE value selected in the Functional Parameters away from setpoint.
Page 88: Cool/Heat/Null Mode Switching Logic
4.6.3 Cool/Heat/Null Mode Switching Logic When not in Pulldown and in Continuous Run Mode, operation in cool, heat and null modes is determined in accor- dance with the calculated Controlling Temperature value (CT), the difference between this value and Setpoint (SP) and the FUEL SAVER (ECO) MODE Functional Parameter setting in accordance with: Control Temperature with Fuel Saver OFF COOL MODE...
Page 89: Defrost
4.6.5 Heat Mode When Heat Mode is required the system operates with evaporator fans energized. Operation of heaters is deter- mined in accordance with the calculated Controlling Temperature (CT) and the difference between Setpoint (SP) in accordance with the following table: Control Temperature with Fuel Saver OFF HTCON1 Switch On when CT-SP is equal to or less than -0.54°F (-...
Page 90: Defrost Modes
Ice is not the only thing that will cause the air differential to increase across the evaporator coil. Shrink wrap, paper, plastic bags, and other such items when caught in the return air stream and pulled up against the evaporator coil or the return air grille can also cause the DAS contacts to close. b.
Page 91: User Selected Override Operation
USER SELECTED OVERRIDE OPERATION Three optional software override programs are available to the user. These programs include: Supply Air Limit Con- trol, Temperature Range Lock and Product Shield. Information on how the unit operates under these programs is pro- vided in the following sub-paragraphs. 4.8.1 Supply Air Limit Control Supply Air Limit Control is available when the setpoint is at or between 32 to 65°F (0 to 18.4°C) and the unit is...
Page 92: Temperature Range Lock 1 & 2
4.8.2 Temperature Range Lock 1 & 2 Range Lock is a group of Configurations which may be set to lock the unit into Start-Stop or Continuous Operation for various setpoint ranges. Two ranges are available for selection, Range Lock 1 and Range Lock 2. Each Range can be independently set to lock it’s setpoint temperatures into either Start-Stop or Continuous operation.
Page 93: Productshield
Figure 4.2 Range Lock Settings - Overlapping Range 1 always has priority when Range 1 & 2 overlap Range 1 is set for 32 to 42 F Range 2 is set for -22 to (0 to 5.6 C) 89.6 F (-30 to 32 C) Set for Continuous Set for Start-Stop Range 2...
Page 94 When the unit restarts, it will return to Continuous Operation for a minimum of 15 minutes or the Minimum Run Time Functional Parameter setting, whichever time is longer. The original activation conditions must then be met in order for the unit to return to ProductShield Econo: Start/Stop. ProductShield Econo Go To Start/Stop Examples: The following examples apply in situations where all other Start/Stop conditions have been met.
Page 95: Preprogrammed Software Overrides
PREPROGRAMMED SOFTWARE OVERRIDES 4.9.1 High Discharge Temperature The control system monitors the signal provided by the compressor discharge temperature sensor. If compressor temperature rises to the limit, the system will enter Liquid Injection Mode. In this mode the normally closed liquid injection valve (LIV) will be opened to allow flow of refrigerant into the economizer connection to cool the compres- sor.
Page 96 62-11785 4–14...
Page 97: Interface Methods Technician Mode
SECTION 5 - CONTROL SYSTEM INTERFACE PARAGRAPH NUMBER Page INTERFACE METHODS ............5–1 TECHNICIAN MODE .
Page 98 62-11785...
Page 99: Technician Mode
SECTION 5 CONTROL SYSTEM INTERFACE INTERFACE METHODS There are four methods for interfacing with the APX Control System: 1. Driver/Advanced User Interface - Driver & Advanced User Interface activities such as start, stop, Pretrip, reading alarms, reading data and changing Functional Parameters may all be performed using the display mounted keys (refer to Section 2.
Page 100: Figure 5.2 Technician Hour Meters
Technician Mode should be canceled when work is complete. If Technician Mode is not canceled, Technician Mode will be available for 60 minutes after the last key press without requiring a code, even after placing the SROS in the OFF and then back in the RUN/STOP position.
Page 101: Inactive Alarms
3. The hour meter screen will display with a 15 second timeout. Press the ▲ or ▼ key to scroll through the available selections. With the desired sub-menu highlighted, press the “=” key to view the data. Standby Protect Hours STANDARD HOUR METERS (1 OF 3) OTHER METERS &...
Page 102 Figure 5.3 Inactive Alarms ACTIVE ALARMS NO ACTIVE ALARMS BACK CLEAR INACTIVE ALARMS ALARMS INACTIVE ALARMS I00093 CHECK START-UP BUZZER P00144 CHECK UL1 CIRCUIT P00141 PRETRIP STOPPED BY USER CLEAR CLEAR BACK EXIT INACTIVE 1. Enter the Technician Mode, as described in Figure 5.1, then press the ALARM key.
Page 103: Figure 5.4 Setting Configurations
5.2.3 Configuration Settings Configuration settings match the APX Control System to the unit and define APX Control System action under various operational conditions. Instructions for working with Configurations are provided in Figure 5.4. 1. Enter the Technicians Menu, highlight CONFIGURATION SETTINGS and then press the “=” key as described in Figure 5.1.
Page 104 11. To change a value selection screen, press the “=” key with the desired Configuration sub-menu highlighted as in Sample Screen A. The individual Configurations within the sub-menu will display as in Sample Screen B. Press the ▲ or ▼ key to scroll through the individual Configurations. The individual Configurations will highlight as the list is scrolled.
Page 105: Component Test Mode
5.2.4 Component Test Mode Component Test Mode allows the technician to energize individual circuits for 5 minutes at a time. The unit is not allowed to start when the System is in Component Test Mode. Instructions for entering the Component Test Mode are provided in Figure 5.5.
Page 106 4. When a component is energized in Component Test Mode, the AMP DRAW display initially shows the cur- rent draw of the system, after a few seconds the display will change to reflect the current draw of the system plus the added component. For example, if CCON is energized in Component Test Mode, the AMP DRAW display might initially show .75 Amps, then after a few seconds, the AMP DRAW display will change to 1.0 Amps.
Page 107: Usb Memory Devices
Instructions for using USB memory devices with the APX Control System are provided in the following sub- paragraphs. 5.3.1 Data Transfer USB Memory Device Carrier Transicold APX USB Flash Drive, CTD P/N 12-00734-00 must be used: • The device may be used to enter PC Mode. •...
Page 108: Figure 5.6 Pc Mode
1. With the START/RUN - OFF switch in the OFF position, remove protective cover from the USB interface port and insert a Data Transfer USB. The USB activity LED will flash, the Carrier Transicold logo will display and then the MessageCenter will display one or more USB soft key descriptions.
Page 109 2. Press the “PC MODE’ soft key. DO NOT remove USB or cable at this time. 3. The MessageCenter will display “PC MODE”. The System is now in PC Mode. The purpose of PC Mode is to allow demonstration of the System features and allow changes to the System while the unit is not actually running.
Page 110: Figure 5.7 Downloading Data Files
1. Data may be downloaded with the system powered up or turned off. Remove protective cover from the USB interface port and insert the Carrier Transicold APX USB Flash Drive, CTD P/N 12-00734-00. The Mes- sageCenter will display READING USB.
Page 111: Figure 5.8 Installing Software
Whenever installing new software, it is always a good idea to start the unit and give it a quick check over prior to performing the operation. All units should have the software upgraded to the latest ver- sion, provided for Carrier Transicold dealers on the TransCentral web site. Figure 5.8 Installing Software...
Page 112 NOTE If Configured to do so, the System will prompt for entry of the data protect PIN code (refer to “PRO- TECT DATA WITH PIN”, Table 5–1). 3. In less than two minutes time, the MessageCenter will display the USB soft keys. (The INSTALL SETTINGS soft key will not display if files are not loaded in the CONFIG folder and DOWNLOAD DATA does not display if the DATAEXT folder is not present).
Page 113: Transferring Configuration Files
5.3.5 Transferring Configuration Files Instructions for installing configuration files into the APX Control System from a Data Transfer USB memory device are provided in Figure 5.9. Configuration (*.set) files consist of one of the following types of files. A “Configuration” file contains a complete set of Configuration, Functional Parameter and Data Recorder settings for the system.
Page 114: Tru-Tech
TRU-TECH & TRU-VIEW The TRU-Tech & TRU-View program allows the user to access and download data using a computer, when the unit is not running and without starting the eight-hour DataLink data recorder timer. The application interface will pro- vide additional programming and configuring capabilities that will not be available using the display mounted keys. The DataLink data recorder may also be configured using the TRU-Tech program.
Page 115: Main Microprocessor Replacement / Setup
When field diagnosis of a Carrier Transicold refrigeration unit determines that an APX main microprocessor is not performing properly and must be replaced the replacement microprocessor must be setup for this unit and customer by entering the required Configurations, Functional Parameters and DataLink data recorder settings.
Page 116: Pre-Replacement Steps
The preferred method for setup of the main microprocessor is to use the display mounted keys or a Data Transfer USB memory device. All required changes, except unit specific and time sensitive data, may be performed using the USB memory device. If a USB is not available the main microprocessor may be setup using TRU-Tech.
Page 117: Main Microprocessor Setup
5.5.3 Main Microprocessor Setup 1. Ensure that the replacement main microprocessor is in place, all wires connected and the negative battery cable is reconnected. 2. Make sure the latest software has been loaded to ensure all modules are compatible. When a module is replaced, software should be upgraded before switching the unit on. This will ensure software compatibility of all modules.
Page 118: Configurations Using Display Mounted Keys
NOTES 1. If a Data Transfer USB memory device will be used to setup the remainder of the main microprocessor set- tings, proceed to Section 5.5.7 after the settings are entered. 2. After the unit specific and time sensitive configuration settings are complete use the UP or DOWN ARROW keys until “CONFIGS COMPLETE, = TO EXIT”...
Page 119 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description CONFIGURATION SETTINGS Press the ▲ or ▼ keys to display configurations: UNIT IDENTIFICATION CONFIGURATION SETTINGS (1 OF 11) SETPOINT(S) & RANGE LOCK UN IT IDENTIFICATION START-STOP SETTINGS SETPOINT(S) &...
Page 120 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description SETPOINT(S) & RANGE LOCK DECIMAL DISPLAYED DISPLAYED = setpoint will be shown with a decimal and temperatures may be selected to a tenth of a degree. NOT DISPLAYED NOT DISPLAYED = setpoint will not be shown with a decimal.
Page 121 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description S/S PARAMETERS TOGETHER TOGETHER = When the Minimum Run Time, Minimum Time, Restart Temperature, SEPARATE Maximum Off Time, and Override Temperatures are set in the Functional Parameter List, the same values will be used for both Frozen and Perishable setpoints.
Page 122 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description ECONO MAX. TEMP OFF = There is no upper limit for this parameter. -20°F +119.0°F Select the highest ambient temperature desired to 28.9°C to activate ProductShield Econo +48.4°C 0.5°...
Page 123 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description REFRIGERATION YES / NO When alarm 00028 CHECK SHUTDOWN REFRIGERATION SYSTEM is activated the alarm light will illuminate and the unit will shut down. When alarm 00028...
Page 124 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description SWITCH ON RESET VALUE When the switch on maintenance hour meter is reset, the value selected here will be added to the 50 TO 30,000 hours in 50 present meter reading...
Page 125 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description DOOR SWITCH ALARM ONLY ALARM ONLY = When Door switch indicates that the door is open, a warning alarm will be displayed in the MessageCenter. UNIT SHUTDOWN = When Door switch indicates UNIT SHUTDOWN the door is open a warning alarm will be displayed...
Page 126 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description OTHER SETTINGS Configuration Selections Description ENABLE ADVANCED USER YES / NO YES = Advanced User Mode is automatically MODE: enabled when the unit is powered on. NO = Driver Mode is automatically enabled when the unit is powered on and Advanced User Mode may be enabled manually.
Page 127 Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description BATT CHARGER NO TEMP SENSOR NO TEMP SENSOR = Use this setting when the battery charger does not have the temperature (Applicable to unit - not lift gate - sensor wire.
Page 128: Table 5-1 Configuration Settings
Table 5–1 Configuration Settings (Refer to Section 5.2.3 for instructions on entering Configuration settings) Configuration Selections Description SUPPLY AIR LIMIT FOR CONT -2.7° to -21.6°F (-1° to - Value to be used to calculate the lowest allowable 12°C) (in 0.5°F or °C supply air temperature, when in Continuous increments) Operation, in accordance with the formula “Setpoint...
Page 129 5–31 62-11785...
Page 130 62-11785 5–32...
Page 131: Messagecenter Messages
SECTION 6 MESSAGECENTER MESSAGES MESSAGECENTER MESSAGES The following table lists common messages which do not appear in other lists in this manual and a description of their meaning. Refer to Section 7 for a list of Alarm messages. Refer to Section 3.14 for a list of Unit Data mes- sages.
Page 132 Table 6–1 MessageCenter MESSAGES Message Description The unit is in Service Mode, and the refrigeration system is ready to EVAC / CHARGE MODE be evacuated then charged with refrigerant. Refer to Section 5.2.5. EXITING PRETRIP MODE Pretrip has been aborted either by user or by a pretrip alarm. Service Mode has been turned off and unit is returning to normal op- EXITING SERVICE MODE eration.
Page 133 Table 6–1 MessageCenter MESSAGES Message Description This message will be displayed when the unit is in Service Mode and RECOVER / LEAK CHK / EVAC MODE the system is ready for recovery and leak testing. Remote switch is open. May be connected to a refrigerated compart- REMOTE SWITCH 1 OPEN ment door or a remote control switch.
Page 134 62-11785 6–4...
Page 135 SECTION 7 - ALARM TROUBLESHOOTING PARAGRAPH NUMBER Page INTRODUCTION ............. 7–1 NOTES .
Page 136: Figure 2.6 Display Module
00133 CHECK REMOTE TEMP SENSOR 1 ........7–39 00134 CHECK REMOTE TEMP SENSOR 2 .
Page 137 05008 BAD F10 FUSE ............7–67 05009 CHECK STANDBY CONTACTOR ONE (PSCON) .
Page 138 62-11785...
Page 139: Alarm Troubleshooting
SECTION 7 ALARM TROUBLESHOOTING WARNING APX Control System equipped units may start automatically at any time the START/RUN-OFF switch is in the START/RUN position. Also, the unit may be fitted with two way communication equipment that will allow starting of the unit from a remote location even though the switch is in the OFF position.
Page 140: Notes
NOTES NOTE Note 1: The active alarm list may be cleared when in the Driver Mode or Advanced User Mode by pressing the CLEAR ALARMS soft key. That is: the alarm is “cleared” from the active alarm list and moved to the inactive alarm list for later review if the condition that caused the alarm has been cor- rected.
Page 141: Alarms
ALARMS 00013 HIGH DISCHARGE PRESSURE • ACTIVATION: Compressor discharge pressure switch (HPS) contacts are open. HPS contacts open when the discharge pressure rises. Refer to Section 2.8. • UNIT CONTROL: Refrigeration system shutdown and alarm with PSCON still energized. CSMV at 50% and EVXV controls superheat.
Page 142: High A/C Amps
00014 HIGH A/C AMPS • ACTIVATION: AC Current Sensor 1, 2, or 3 is greater than 28.5A for 3 seconds. • UNIT CONTROL: Refrigeration system shutdown and alarm with PSCON still energized. • RESET CONDITION: Auto reset after 14 minutes if AC Current Sensor 1, 2, and 3 reading is less than 27 amps or alarm may be manually reset via keypad or by turning unit off then back on.
Page 143: Battery Voltage Too Low
00016 BATTERY VOLTAGE TOO LOW • ACTIVATION: Voltage at the main microprocessor is less than 10 VDC. • UNIT CONTROL: Shutdown and alarm • RESET CONDITION: Auto reset after 15 minutes when the voltage at the main microprocessor is between 11 and 14 VDC, or alarm may be manually reset using the display mounted keys or by turning the unit off, then back on again.
Page 144: High Comp Discharge Temp
00017 HIGH COMP DISCHARGE TEMP • ACTIVATION: “Check Compressor Discharge Sensor” alarm not active (if alarm is active, refer to 00125 CHECK COMP DISCHARGE SENSOR first) and: discharge temp rises above 285.1°F (140.6°C) for 30 seconds, or discharge temp rises above 295.0°F (146.1°C). •...
Page 145: Low Refrigerant Pressure
00018 LOW REFRIGERANT PRESSURE • ACTIVATION: Suction Pressure has been less than -6.3 psig (-0.43 bar) for the Low Suction Pressure Configuration time or 10 seconds (whichever is less). • UNIT CONTROL: Alarm only or (if configured for shutdown) refrigeration system shutdown and alarm with PSCON still energized.
Page 146: Maximum Compressor Alarms
00020 MAXIMUM COMPRESSOR ALARMS • ACTIVATION: This option must be installed and alarm must be enabled by configuring the Compressor Alarm Shutdown to YES. Alarms 00013 HIGH DISCHARGE PRESSURE, 00017 HIGH COMP DIS- CHARGE TEMP, 00018 LOW REFRIGERANT PRESSURE, 00027 HIGH SUCTION PRESSURE, or 00028 CHECK REFRIGERATION SYSTEM individually occur 3 times within the last 2 hours.
Page 147: Low Suction Superheat
00022 LOW SUCTION SUPERHEAT • ACTIVATION: Alarms 00127 CHECK SUCTION TEMP SENSOR and/or 00131 CHECK EVAP TEMP SENSOR are not active and Compressor suction superheat (Compressor Suction Temperature (CST) minus saturated temperature for Compressor Suction Pressure (CSP) is less than 8°F (4.4°C) for more than 3-4 minutes.
Page 148: A/C Current Over Limit
00023 A/C CURRENT OVER LIMIT • ACTIVATION: The high voltage amp draw is over the limit shown in the following table for more than 10 sec- onds. CONDITION DRAW Standby Cool or Pretrip Standby Heat Defrost Standby Null Standby Natural Defrost (when heaters are de-energized) •...
Page 149 00023 A/C CURRENT OVER LIMIT - CONTINUED 4. Check High Voltage Components Amp Draw (with the unit operating) a. Check condenser fan amp draw on all legs (CDCON). b. Check evaporator fan motor amp WARNING draw on all 3 legs (1EVCON). c.
Page 150: Compression Ratio Exceeded
00024 COMPRESSION RATIO EXCEEDED • ACTIVATION: If the compressor compression ratio is greater than 24 for 20 seconds. • UNIT CONTROL: Refrigeration system shutdown and alarm with PSCON still energized. • RESET CONDITION: Auto reset when compression ratio is less than 24 for 3 minutes or, alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 151: High Suction Pressure
00027 HIGH SUCTION PRESSURE • ACTIVATION: The refrigeration system is running and the suction pressure has been greater than 98 psig (6.7 bar) for more than 10 minutes. • UNIT CONTROL: Alarm only or (if configured for shutdown) refrigeration system shutdown and alarm with PSCON still energized.
Page 152: Check Refrigeration System
00028 CHECK REFRIGERATION SYSTEM • ACTIVATION: The refrigeration system is running and the discharge pressure is less than 5 psig (0.34 bar) higher than suction pressure for more than 30 seconds. • UNIT CONTROL: Alarm only or (if configured for shutdown) refrigeration system shutdown and alarm with PSCON still energized.
Page 153: Alternator (Battery Charger) Not Charging
00051 ALTERNATOR (BATTERY CHARGER) NOT CHARGING • ACTIVATION: Unit is running and the current flow is less than -1.0 amps between the alternator and the battery for 3 continuous minutes. • UNIT CONTROL: Alarm only regardless of configuration setting. • RESET CONDITION: Auto reset (if not shutdown) when battery charger is charging or alarm may be manually reset using the display mounted keys or by turning the unit off, then back on again.
Page 154: Box Temp Out-Of-Range
00053 BOX TEMP OUT-OF-RANGE • ACTIVATION: Condition One: If the unit is running in Pulldown and the SAT is not greater than 1°F (0.56°C) below the RAT or if the unit is running in Pull-Up and the SAT is not above the RAT, the configured action (Alarm only after 30 minutes or Alarm and Shutdown after 45 minutes) will be activated.
Page 155: Defrost Not Complete
00053 BOX TEMP OUT-OF-RANGE - CONTINUED 3. Check For Any Shutdown Alarm(s) - Check the Alarm List for any shutdown alarms. Alarm conditions must be corrected and the alarm cleared to continue. 4. Check For Alarm 00018 LOW REFRIGERANT PRESSURE - Alarm conditions must be corrected and the alarm cleared to continue.
Page 156: Check Defrost Air Switch
00055 CHECK DEFROST AIR SWITCH • ACTIVATION: The defrost air switch has called for a defrost cycle within 8 minutes of a defrost termina- tion for 2 consecutive defrost cycles. (The air switch contacts were closed continuously for 15 seconds before the defrost cycle was started.) •...
Page 157: Check Remote Switch 1 (Rems1)
00057 CHECK REMOTE SWITCH 1 (REMS1) • ACTIVATION: REMS1 is set to trigger an alarm if the switch is activated (opened or closed, depending on switch type) for more than five seconds. • UNIT CONTROL: May be configured as alarm only or alarm and shutdown. •...
Page 158: 00058 Check Remote Switch 2 (Rems2)
00058 CHECK REMOTE SWITCH 2 (REMS2) • ACTIVATION: Remote Switch 2 is set to activate an alarm if the switch is activated (opened or closed, depending on switch type) for more than five seconds. • UNIT CONTROL: May be configured as alarm only or alarm and shutdown. •...
Page 159: 00059 Datalogger (Datalink Data Recorder) Not Recording
Download previous data using a Data Transfer USB memory device, or TRU-Tech. Data retrieval b. Replace and setup main microprocessor. Refer to Section 5.5. NOTE Specific Configurations may be found on the TransCentral Website (Authorized Carrier Transicold Dealers only). 00060 DATALOGGER (DataLink data recorder) TIME WRONG •...
Page 160: Door Open (Ds1)
00061 DOOR OPEN (DS1) • ACTIVATION: DS1 is set to trigger an alarm if the switch is activated (opened or closed, depending on switch type) for more than five seconds. • UNIT CONTROL: May be configured as alarm only or alarm and shutdown. •...
Page 161: No Power-Check Power Cord
00073 NO POWER-CHECK POWER CORD • ACTIVATION: The unit is set to operate AND no AC power; incoming voltage at the High Voltage Trans- former (HVT) is less than 300VAC. • UNIT CONTROL: The refrigeration system will shutdown (because of the loss of power) with the alarm on and PSCON still energized.
Page 162: Phase Reversed
00074 PHASE REVERSED • ACTIVATION: The Stop/Run Switch is ON and the system cannot properly detect the phase. • UNIT CONTROL: Required Shutdown. • RESET CONDITION: Auto reset when and the phase reversed switch = phase reverse okay for 2 sec- onds.
Page 163: Comp Motor Overload
00075 COMP MOTOR OVERLOAD • ACTIVATION: If alarm 00022 LOW SUCTION SUPERHEAT, 00027 HIGH SUCTION PRESSURE and/or 00028 CHECK REFRIGERATION SYSTEM was triggered with current below 5.5 amps. This alarm will also trigger on restart from alarm 00022, 00027 and/or 00028 if compressor current does not rise above 1 amp, and alarm 00013 HIGH DISCHARGE PRESSURE is not active.
Page 164: Condenser Motor Overheated
00076 CONDENSER MOTOR OVERHEATED • ACTIVATION: The condenser fan motor Internal Protectors (IP-CDM1) circuit is open and 00013 HIGH DISCHARGE PRESSURE is not active. • UNIT CONTROL: Refrigeration system shutdown and alarm with PSCON still energized. • RESET CONDITION: Auto Reset when motor overload input is within limits or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 165 00076 CONDENSER MOTOR OVERHEATED - CONTINUED 7. Check IPC circuit a. Use Component Test Mode to energize CDCON1 circuit. (Refer to Section 5.2.4.) Output will come on. b. Verify 12 VDC at CDCON1 A1 and A2. Inspect wiring between condenser and CCB. c.
Page 166: Evap Motor Overheated
00077 EVAP MOTOR OVERHEATED • ACTIVATION: The evaporator fan motor Internal Protector (IP-EVM) is open. • UNIT CONTROL: Shutdown and alarm. • RESET CONDITION: Auto Reset after a 15 minute off time when motor overload input is within limits or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 167: Check Remote Alarm Light
00084 CHECK REMOTE ALARM LIGHT This alarm may be activated with earlier software revisions, follow procedure for alarm 06001 CHECK LIGHT BAR. 00093 CHECK STARTUP BUZZER • ACTIVATION: The Buzzer (B) circuit is shorted or open. (The Buzzer output from the microprocessor [PCM-23 to 3MM15] is negative, so the circuit will not be shorted to ground, but is shorted either within the Buzzer itself, or to a positive wire.) •...
Page 168: 00094 Check Comp Contactor 1
00094 CHECK COMP CONTACTOR 1 • ACTIVATION: Compressor motor contactor (CCON) circuit is shorted or open. • UNIT CONTROL: Shutdown and alarm. • RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 169: Check High Temp Thermostat
00098 CHECK HIGH TEMP THERMOSTAT • ACTIVATION: With the Main Power switch toggled out of the OFF position, the EVHTS circuit is open. • UNIT CONTROL: Alarm AND no heat allowed. • RESET CONDITION: Auto Reset when the EVHTS circuit is okay for 15 minutes, or alarm may be manu- ally reset via keypad or by turning the unit off, then back on again.
Page 170: Overload/Ground Fault
00100 OVERLOAD/GROUND FAULT • ACTIVATION: Unit Operation is being called for and the overload ground fault module is reading more than 40 Amps on any A/C current leg OR there is A/C voltage leaking to ground of more than 150 Milli- amps.
Page 171: Check 1Evcon Coil
00109 CHECK 1EVCON COIL • ACTIVATION: Evaporator fan motor contactor (1EVCON) circuit is shorted or open. • UNIT CONTROL: Alarm only. • RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 172: Check Ambient Air Sensor
00121 CHECK AMBIENT AIR SENSOR • ACTIVATION: Ambient Air Temperature Sensor (AAT) is not within range of -53 to +158°F (-47° to +70° C). • UNIT CONTROL: A value of 122°F (50°C) will be used for any calculations. • RESET CONDITION: Auto reset when sensor is in range or alarm may be manually reset using the dis- play mounted keys or by turning the unit off, then back on again.
Page 173: Check Supply Air Sensor
00123 CHECK SUPPLY AIR SENSOR • ACTIVATION: Supply Air Temperature Sensor (SAT) is not within range of -53 to +158°F (-47 to +70° C). • UNIT CONTROL: • If alarm 00122 CHECK RETURN AIR SENSOR is not active: functional Parameter Temperature Con- trol is set for Supply Air and the setpoint is in the perishable range: alarm and switch to return air control.
Page 174: Check Defrost Term 1 Sensor
00124 CHECK DEFROST TERM 1 SENSOR • ACTIVATION: Defrost Termination Temperature Sensor (1DTT) is not within the range of -53° to +158°F (-47° to +70° C.) • UNIT CONTROL: • If alarm 00122 CHECK RETURN AIR SENSOR is not active: Alarm and initiate defrost if 1RAT is below 45°F (7.2°C).
Page 175: Check Comp Discharge Sensor
00125 CHECK COMP DISCHARGE SENSOR • ACTIVATION: Compressor Discharge Temperature Sensor (CDT) is not within the range of -40° to +392°F (-40° to +200°C). • UNIT CONTROL: Alarm Only. • RESET CONDITION: Auto reset when sensor is in range or, alarm may be manually reset using the dis- play mounted keys or by turning the unit off, then back on again.
Page 176: Check Evap Temp Sensor
00131 CHECK EVAP TEMP SENSOR • ACTIVATION: Evaporator Outlet Temperature Sensor (EVOT) is not within the range of -53 to +158°F (-47 to +70°C). • UNIT CONTROL: Alarm only and superheat for EVXV will be calculated using SAT or DTT if alarm 00123 CHECK SUPPLY AIR SENSOR is active.
Page 177: 00133 Check Remote Temp Sensor 1
00133 CHECK REMOTE TEMP SENSOR 1 00134 CHECK REMOTE TEMP SENSOR 2 00135 CHECK REMOTE TEMP SENSOR 3 • ACTIVATION: Remote Temperature Sensor (REMSN1, REMSN2 or REMSN3) is not within the range of - 53 to +158°F (-47 to +70°C.) •...
Page 178: P00141 Pretrip Stopped By User
P00141 PRETRIP STOPPED BY USER • ACTIVATION: Pretrip cycle was stopped by user before the Pretrip cycle ended automatically. • UNIT CONTROL: Alarm Only. • RESET CONDITION: Alarm may be manually reset using the display mounted keys or by turning the unit off, then back on again.
Page 179: P00157 Check Battery Current
P00157 CHECK BATTERY CURRENT • ACTIVATION: With all circuits off, current flow of more than +1.5 to -2.0 amps is detected in the 12 VDC electrical circuits. NOTE: If this alarm occurs, Pretrip Test #2 will be skipped and Pretrip Test #3 will start. •...
Page 180: P00160 Check Discharge Temp Sensor
P00160 CHECK DISCHARGE TEMP SENSOR • ACTIVATION: Compressor Discharge Temperature Sensor (CDT) is not within the range of -40 to +392°F (-40 to +200°C.) • UNIT CONTROL: Pretrip will fail and display “PRETRIP FAIL AND COMPLETED”. • RESET CONDITION: Auto reset if Pretrip is started again or alarm may be manually reset using the dis- play mounted keys or by turning the unit off then back on again.
Page 181: P00177 Check Exv (Evxv) Superheat
P00177 CHECK EXV (EVXV) SUPERHEAT • ACTIVATION: With the unit running in Test 11, after the APX Control System closes the EVXV to 0%, evaporator pressure fails to drop by 20 psig (1.36 bar) or fails to go below 0 psig / bar OR the EVXV appears not to be opening to the full capacity position.
Page 182: P00180 Check Suction Mod Valve
P00180 CHECK SUCTION MOD VALVE • ACTIVATION: With the unit running in Pretrip Test #10, after the microprocessor attempts to close CSMV, the suction pressure fails to drop below 0 psig (0 bar). • UNIT CONTROL: Pretrip will fail and display “PRETRIP FAIL IN TEST 10”. •...
Page 183: P00187 Check Heater 1 Circuit
P00187 CHECK HEATER 1 CIRCUIT This device is checked twice in Pretrip - once in Test 2 and again in Test 7. • ACTIVATION TEST 2: (unit not running): Normal draw for the 1HTCON1 coil is 0.05 to 1.0 Amps (12 VDC).
Page 184 P00187 CHECK HEATER 1 CIRCUIT - CONTINUED 460 VAC CIRCUIT 6. Check Amp Draw of 1HTCON1 Heater Circuit a. With the unit running and calling for Heat, use a clamp-on ammeter to check the current draw of all 3 legs. Must be within range shown in Section 2.9 for all three legs.
Page 185: P00188 Check Heater 2 Circuit
P00188 CHECK HEATER 2 CIRCUIT This device is checked twice in Pretrip - once in Test 2 and again in Test 8. • ACTIVATION TEST 2: (unit not running): Normal draw for the 1HTCON2 contactor coil is 0.05 to 2.0 Amps (12 VDC).
Page 186 P00188 CHECK HEATER 2 CIRCUIT - CONTINUED 460 VAC CIRCUIT 6. Check Amp Draw of 1HTCON2 Heater Circuit a. With the unit running and calling for Heat, use a clamp-on ammeter to check the current draw of all 3 legs. Must be within range shown in Section 2.9 for all three legs.
Page 187: P00189 Check Evaporator Fan Motor
P00189 CHECK EVAPORATOR FAN MOTOR This device is checked twice in Pretrip - once in Test 2 and again in Test 8. • ACTIVATION TEST 2 (unit not running): Normal draw for the 1EVCON contactor coil is 0.05 to 2.0 Amps (12 VDC).
Page 188 P00189 CHECK EVAPORATOR FAN MOTOR - CONTINUED 460 VAC CIRCUIT 5. Check Amp Draw of 1EVCON Evaporator Fan Motor Circuit a. With the unit running in either HEAT or COOL, use a clamp-on ammeter to check the current draw of all 3 legs. Must be within range shown in Section 2.9 for all three legs.
Page 189: P00190 Check Condenser Fan Motor
P00190 CHECK CONDENSER FAN MOTOR • ACTIVATION: Normal draw for the condenser fan motors is 0.8 to 3.5 Amps (460 VAC). The circuit tests outside this range. • UNIT CONTROL: Pretrip will fail and display “PRETRIP FAIL AND COMPLETED”. • RESET CONDITION: Auto Reset if Pretrip is started again, or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 190: P00206 Check Condenser Fan Circuit
P00206 CHECK CONDENSER FAN CIRCUIT • ACTIVATION: Normal draw for the CDCON contactor coil is 0.05 to 2.0 Amps (12 VDC). The circuit tests outside this range. • UNIT CONTROL: Pretrip will fail and display “PRETRIP FAIL AND COMPLETED”. • RESET CONDITION: Auto Reset if Pretrip is started again, or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 191: P00209 Check Standby Cont Circuit
P00209 CHECK STANDBY CONT CIRCUIT • ACTIVATION: Normal amps for the PSCON or PSCON2 contactor coils 0.0 to 1.0 Amps (12 VDC). The circuit(s) test outside this range. (During this test either PSCON or PSCON2 will be tested depending on the phase reversal module.) •...
Page 192: Standby Maintenance Due
00224 STANDBY MAINTENANCE DUE • ACTIVATION: The Standby Hour Meter time has expired. • UNIT CONTROL: Alarm Only. Alarm Light will NOT be turned on. • RESET CONDITION: Alarm may be manually reset via keypad. CORRECTIVE ACTIONS: 1. Check Unit Maintenance Records - Schedule unit into service facility for maintenance. Must be done soon! 2.
Page 193: Service Soon-Pm #2 Due
00227 SERVICE SOON-PM #2 DUE • ACTIVATION: The Maintenance Hour Meter #2 time has expired. • UNIT CONTROL: Alarm Only. Alarm Light will NOT be turned on. • RESET CONDITION: Alarm may be manually reset using the display mounted keys. CORRECTIVE ACTIONS: 1.
Page 194: Service Soon-Pm #4 Due
00229 SERVICE SOON-PM #4 DUE • ACTIVATION: The Maintenance Hour Meter #4 time has expired. • UNIT CONTROL: Alarm Only. Alarm Light will NOT be turned on. • RESET CONDITION: Alarm may be manually reset using the display mounted keys. CORRECTIVE ACTIONS: 1.
Page 195: Setpoint Error
Check Model # in microprocessor. Model Number is on Nameplate. b. Enter correct Model Number. Select the correct model number in the “MODEL NUMBER” Configuration. If correct model number is not found, Install (or have Carrier Transicold dealer install) latest software revision.
Page 196: Function Parameters Error
00237 FUNCTION PARAMETERS ERROR • ACTIVATION: There is an error in one or more of the Functional Parameters that are stored in the main microprocessor memory. • UNIT CONTROL: Incorrect Functional Parameter(s) will be automatically set for default value. • RESET CONDITION: Auto reset when valid Functional Parameters are entered, or alarm may be manu- ally reset by turning the unit off, then back on again.
Page 197: Configurations Error
00238 CONFIGURATIONS ERROR • ACTIVATION: There is an error in the Configuration settings that are stored in the main microprocessor memory. • UNIT CONTROL: Incorrect Configuration(s) will be automatically set for default value. • RESET CONDITION: Auto reset when valid Configuration(s) are entered, or alarm may be manually reset by turning the unit off, then back on again.
Page 198: Cannot Save Setting
CORRECTIVE ACTIONS: 1. Check Microprocessor Software Revision - Check microprocessor software. Unit should have the soft- ware upgraded to the latest version, provided for Carrier Transicold dealers on the TransCentral site. 2. Reset Microprocessor a. Place the START/RUN-OFF switch in the OFF position. Disconnect positive battery cable, remove F7 fuse or unplug 1MM connector, wait 20 seconds and reinstall.
Page 199: Config Mode / Hp2 Error
00248 CONFIG MODE / HP2 ERROR • ACTIVATION: EEPROM Configuration is out of range. • UNIT CONTROL: Shutdown and alarm. • RESET CONDITION: Auto reset only when valid info is entered. NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, clear the alarm(s).
Page 200: Microprocessor Error
CORRECTIVE ACTIONS: 1. Check Software Revision - Check microprocessor software. Unit should have the software upgraded to the latest version, provided for Carrier Transicold dealers on the TransCentral site. 2. Reset Microprocessor a. Place the START/RUN-OFF switch in the OFF position. Disconnect positive battery cable, remove F7 fuse or unplug 1MM connector, wait 20 seconds and reinstall.
Page 201: Low Discharge Superheat
02002 LOW DISCHARGE SUPERHEAT • ACTIVATION: Compressor discharge superheat is less than 68°F (20°C) after 3 minutes of engaging the Econ SH offset logic, the compressor is on, and Evaporator Flood back control hasn’t been active in the last 3 minutes and suction superheat is greater than 40°F (4.4°C). NOTE This alarm can be caused by a stuck open ECXV or LIV, causing too much liquid to be sent into the compressor at the economizer connection.
Page 202: Display Module Error
Once Emergency Bypass Mode has been activated, the unit will operate normally for 24 hours, a countdown timer will be shown on the display. This 24 hour window of operation will keep the load safe, and provide enough time to contact the nearest Carrier Transicold Service Center for repair of the unit.
Page 203: High Economizer Superheat
04002 HIGH ECONOMIZER SUPERHEAT • ACTIVATION: With unit running in economized mode for 15 minutes, ECXV open greater than 99% for 5 minutes, and a box temperature less than 14°F (-10°C); economizer superheat is above 74°F (23°C) for 5 minutes. NOTE This alarm can be caused by a stuck ECXV, not letting enough liquid into the economizer circuit.
Page 204: Bad F9 Fuse
05005 BAD F9 FUSE • ACTIVATION: CCB Fuse Alarm; Feedback from CCB indicates fuse is missing or blown. Signal must be present for at least 3 seconds. • UNIT CONTROL: Shutdown and Alarm. • RESET CONDITION: Replace or fix fuse issue. NOTE: Follow the steps below until a problem is found.
Page 205: Bad F3 Fuse
05007 BAD F3 FUSE • ACTIVATION: Stepper Board Fuse Alarm; Feedback from Stepper Board indicates fuse is missing or blown. Signal must be present for at least 3 seconds. • UNIT CONTROL: Alarm only. • RESET CONDITION: Replace or fix fuse issue. NOTE: Follow the steps below until a problem is found.
Page 206: Check Standby Contactor One (Pscon)
05009 CHECK STANDBY CONTACTOR ONE (PSCON) • ACTIVATION: Standby contactor one (PSCON) circuit is shorted or open. • UNIT CONTROL: Required Shutdown. • RESET CONDITION: 15 minutes have elapsed since activation or alarm may be manually reset via key- pad or by turning the unit off, then back on again. NOTE: Follow the steps below until a problem is found.
Page 207: Check Standby Contactor Two (Pscon2)
05010 CHECK STANDBY CONTACTOR TWO (PSCON2) • ACTIVATION: Standby contactor two (PSCON2) circuit is shorted or open. • UNIT CONTROL: Required Shutdown. • RESET CONDITION: 15 minutes have elapsed since activation or alarm may be manually reset via key- pad or by turning the unit off, then back on again. NOTE: Follow the steps below until a problem is found.
Page 208: Check Remote Amber Light
05016 CHECK REMOTE AMBER LIGHT • ACTIVATION: A problem has been detected in the alarm (amber) light circuit (LB). If this alarm is acti- vated while the circuit is energized, the circuit is detected shorted. If this alarm is activated at any other time, the circuit is detected open.
Page 209: Check Cdcon2 Coil
05019 CHECK CDCON2 COIL • ACTIVATION: Condenser fan motor contactor (CDCON2) circuit is shorted or open. • UNIT CONTROL: Alarm only. • RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 210: Check Htr Cntr One
05020 CHECK HTR CNTR ONE • ACTIVATION: Heater Contactor 1 (1HTCON1) circuit is shorted or open. • UNIT CONTROL: Alarm only. • RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 211: Check Htr Cntr Two
05021 CHECK HTR CNTR TWO • ACTIVATION: Heater Contactor 2 (1HTCON2) circuit is shorted or open. • UNIT CONTROL: Alarm only. • RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 212: 06000 Condenser Motor2 Overheated
06000 CONDENSER MOTOR2 OVERHEATED • ACTIVATION: The condenser fan motor Internal Protectors (IP-CDM2) circuit is open. • UNIT CONTROL: Refrigeration system shutdown and alarm with PSCON still energized. • RESET CONDITION: Auto Reset when motor overload input is within limits, or alarm may be manually reset via keypad or by turning the unit off, then back on again.
Page 213: Check Light Bar
06001 CHECK LIGHT BAR • ACTIVATION: A problem has been detected in the light circuit (LB). If this alarm is activated while the cir- cuit is energized, the circuit is detected shorted. If this alarm is activated at any other time, the circuit is detected open.
Page 214: 07001 Economizer Press Sensor
07001 ECONOMIZER PRESS SENSOR • ACTIVATION: Economizer Pressure (ECOP) sensor is out of range. • UNIT CONTROL: Alarm only. Economizer forced to STANDARD mode when alarm is active. • RESET CONDITION: Economizer Pressure sensor is in range or alarm may be manually reset using the display mounted keys or by turning the unit off, then back on again.
Page 215: 07008 Check Redundant Return Air Sensor (Rat2)
07008 CHECK REDUNDANT RETURN AIR SENSOR (RAT2) • ACTIVATION: A Redundant Return Air Temperature Sensor (RAT2) is installed, configure, and is not within the range of -53 to +158°F (-47 to +70° C). • UNIT CONTROL: If RAT2 is selected as the active probe, switch active probe to RAT probe. •...
Page 216: P11000 Check Condenser Fan Motor 2
P11000 CHECK CONDENSER FAN MOTOR 2 • ACTIVATION: Normal draw for the condenser fan motors is 0.8 to 3.5 Amps (460 VAC). The circuit tests outside this range. • UNIT CONTROL: Pretrip will fail and display “PRETRIP FAIL AND COMPLETED”. •...
Page 217: 20101 No Comm From Micro To Remote Display
20101 NO COMM FROM MICRO TO REMOTE DISPLAY • ACTIVATION: If alarm 21100 NO COMM FROM ANY BOARD TO MAIN MICRO is not active, and the number of Remote Panels installed is configured as 1, and no sync responses have been received from the Remote Panel Module for 10 seconds.
Page 218: 21100 No Comm From Any Board To Main Micro
21100 NO COMM FROM ANY BOARD TO MAIN MICRO NOTE This alarm will be available in the inactive alarm list and download only. It is an indication that an intermittent problem has occurred and a careful diagnosis is required. • ACTIVATION: Main microprocessor cannot communicate with any modules over the CAN bus.
Page 219: 22101 Sensor Input Voltage Low Inp1
22101 SENSOR INPUT VOLTAGE LOW INP1 NOTE This alarm is an indication that there is a short in the transducer or DC current transformer wiring and the voltage supply in the main microprocessor is overloaded. • ACTIVATION: Voltage from main microprocessor to the components is less than 4.5 VDC. •...
Page 220: 22102 Sensor Input Voltage High Inp1
22102 SENSOR INPUT VOLTAGE HIGH INP1 NOTE This alarm is an indication that there is a short in the DC current transformer wiring from another (nominal 12 VDC) circuit into the transducer or CT sensor circuit. • ACTIVATION: Voltage from main microprocessor to the sensors is greater than 5.5 VDC. •...
Page 221: 23100 No Comm From Micro To Outpbd1
23100 NO COMM FROM MICRO TO OUTPBD1 • ACTIVATION: Main microprocessor cannot communicate internally. • UNIT CONTROL: Required Shutdown. If alarm remains active for 2 minutes issue a shutdown command to all modules except the display. • RESET CONDITION: Auto reset when internal communication is restored, alarm reset or alarm may be manually reset by turning the unit off, then back on again.
Page 222: 24100 No Comm From Micro To Ccb1
24100 NO COMM FROM MICRO TO CCB1 • ACTIVATION: If alarm 21100 NO COMM FROM ANY BOARD TO MAIN MICRO is not active and no communication from the CCB1 Module for 10 seconds. • UNIT CONTROL: Required Shutdown. If alarm remains active for 2 minutes issue a shutdown command to all modules except the display.
Page 223: 24102 Sensor Input Voltage High Ccb1
24102 SENSOR INPUT VOLTAGE HIGH CCB1 • ACTIVATION: The Voltage Supply for the Sensors on the CCB1 is above High voltage limit 5.5V. • UNIT CONTROL: Alarm Only. • RESET CONDITION: The Voltage Supply for Sensors on CCB1 is below the High voltage limit 5.5V. NOTE: Follow the steps below until a problem is found.
Page 224: 24201 Sensor Input Voltage Low Ccb2
24201 SENSOR INPUT VOLTAGE LOW CCB2 • ACTIVATION: The Voltage Supply for the Sensors on the CCB2 is below the low voltage limit 4.5V. • UNIT CONTROL: Alarm Only. • RESET CONDITION: The Voltage Supply for Sensors on the CCB2 is above low voltage limit 4.5V. NOTE: Follow the steps below until a problem is found.
Page 225: 25100 No Comm From Micro To Stp1
25100 NO COMM FROM MICRO TO STP1 • ACTIVATION: If alarm 21100 NO COMM FROM ANY BOARD TO MAIN MICRO is not active and main microprocessor cannot communicate with stepper valve module over the CAN bus. • UNIT CONTROL: Required Shutdown. If alarm remains active for 2 minutes issue a shutdown command to all modules except the display.
Page 226: 25102 Check Input Voltage Stp1
25102 CHECK INPUT VOLTAGE STP1 • ACTIVATION: The stepper input voltage is reported out of valid range (9V to 17V) by stepper board 1 for 3 seconds as timed at stepper board. • UNIT CONTROL: Alarm only. Steppers on board with problem disabled (Powered OFF) until good power reported from Stepper Board at which point they are re-enabled.
Page 227: Over Current Stp2
25201 OVER CURRENT STP2 • ACTIVATION: The stepper current is reported to be too high by stepper board 2 (Indicated by Stepper Output Voltage < 5V) for 3 seconds as timed at stepper board. • UNIT CONTROL: Alarm condition. Steppers on board with problem disabled (Powered OFF) until good power reported from Stepper Board at which point they are re-enabled.
Page 228: 28002 No Comm From Door Switch
28002 NO COMM FROM DOOR SWITCH • ACTIVATION: The door switch configuration is configured as 3rd Party and no communications have been received for 15 minutes • UNIT CONTROL: Alarm only. • RESET CONDITION: Communications have been received from the door switch. NOTE: Follow the steps below until a problem is found.
Page 229: Compressor Suction Modulation Valve (Csmv)
SECTION 8 - SERVICE PARAGRAPH NUMBER Page SECTION LAYOUT ............8–1 SCHEDULED MAINTENANCE .
Page 230 62-11785...
Page 231: Section Layout
Unit uses R404A and POE oil. The use of inert gas brazing procedures is manda- WARNING tory for all Carrier Transicold refrigera- tion units; otherwise compressor failure Never use air or gases containing oxygen will occur. For more information Refer to...
Page 232: Table 8-1 Maintenance Schedule
PRE-TRIP INSPECTION Pre-trip inspection should be performed before every trip and at regular maintenance intervals. Pre-trip procedures are provided the Trailer Refrigeration Pre-Trip Inspection document 62-90490. Table 8–1 Maintenance Schedule System Operation Reference Section a. Pre-Trip Inspections 1. Pre-Trip Inspection - Before starting Section 8.3 2.
Page 233: Figure 8.1 Grille Insert Removal And Door Latch Maintenance
EXTERNAL SURFACE SERVICE Procedures for servicing or maintaining the grille, surround, doors, door latches and display module are provided in the following sub-paragraphs. 8.4.1 Remove Grille Insert Figure 8.1 Grille Insert Removal And Door Latch Maintenance NOTE If difficulty is experienced when attempting to remove the grille mounting bolts, the grille GRILLE INSERT may be removed with the surround attached...
Page 234: Figure 8.3 Door Latch Cable Removal
8.4.3 Door Latch Maintenance And Replacement a. Door Latch Maintenance Proper maintenance is important for smooth operation of the latch assemblies and the latch pins that are mounted on the unit’s frame (See Figure 8.1). In order to keep the movable parts clean and lubricated, CTD recommends the use of a de-greasing cleaner and LPS 2 lubricant.
Page 235: Refrigerant System Service Connections
REFRIGERANT SYSTEM SERVICE Service of refrigerant system equipment, refrigerant charge, leak checking and evacuation. Figure 8.4 Refrigerant System Service Vacuum Pump Vacuum Indicator Refrigerant Cylinder Refrigerant Recovery Unit Valve Manifold Gauge Set Economizer Connection Suction Service Valve Liquid Injection Valve 10.
Page 236 b. Checking For Noncondensibles 1. Install a manifold gauge set to allow reading of suction and discharge pressure. See Figure 8.4. 2. Stabilize system to equalize pressure between the suction and discharge side of the system. The refrigerant system needs to be off for several hours. 3.
Page 237 7. Frontseat (close by turning clockwise) the discharge service valve and the refrigerant will be trapped between the compressor discharge service valve and the liquid line service valve. 8. Before opening up any part of the low side of the system, a slight positive pressure should be indicated on the pressure gauge.
Page 238: Leak Checking
g. Adding a Complete Charge 1. Evacuate unit and leave in deep vacuum. (Refer to Section 8.5.4.) 2. Determine charge required for this unit (refer to the model/serial number nameplate or Table 2–1) and procure a refrigerant cylinder with sufficient weight of refrigerant. Place cylinder on scale and connect charging line from cylinder to liquid line service valve.
Page 239 WARNING Only a refrigerant cylinder containing R404A should be connected to this refrigeration unit in order to pressurize the system. However, dry nitrogen may be used to increase pressure. Any other gas or vapor will contaminate the system and require additional removal and evacuation. Do not vapor charge R404A.
Page 240 3. Ensure that the operator message panel displays “RECOVER/LEAK CHK/EVAC MODE” during the pressurizing and leak checking procedures. (Refer to Section 5.2.5.) If the control system switches to Charge Mode during the process, switch it back to the “RECOVER/LEAK CHK/EVAC MODE”. 4.
Page 241: Evacuation And Dehydration
• Essential tools to properly evacuate any system include a good vacuum pump (5 cfm/8m H volume dis- placement, Carrier Transicold P/N 07-00176-11) and a good vacuum indicator such as a digital vacuum gauge (micrometer). Carrier Transicold P/N 07-00414-00. •...
Page 242 10. Purge nitrogen from system at the suction service valve. 11. Open the vacuum pump valve and start the pump. Evacuate unit to 500 microns. Close the vacuum pump valve and shut off the pump. Wait a few minutes to be sure the vacuum holds below 2000 microns. 12.
Page 243: Figure 8.5 Compressor Kit
COMPRESSOR SERVICE WARNING Before removal of the compressor, relieve the internal pressure by very carefully loosening the couplings to break the seal. The scroll compressor achieves low suction pressure very quickly. Do not use the compressor to evacuate the system below 0 psig. Never operate the compressor with the suction or discharge service valves closed (frontseated).
Page 244: Figure 8.6 Compressor Plug Retaining Clip
Figure 8.6 Compressor Plug Retaining Clip 8. Rotate the compressor to gain access to the power plug. Remove the power plug retaining clip (see Figure 8.6) by pulling out gently on the left side (to clear the shorter left locking tab and rotate the right locking tab) and then slide up and off the Retainer plug.
Page 245: Refrigerant System Component Service
18. Using a backup wrench, torque the compressor connections as follows: Service Valve / Connection Torque Value 80 - 100 ft-lbs Suction and Discharge Rotalocks (109 - 136 Nm) 38 - 42 ft-lbs Economizer Connection (51 - 57 Nm) 19. Connect the new compressor discharge temperature sensor (CDT) connector. Wire-tie any loose wiring as appropriate.
Page 246: Condenser Coil
8.4.2. Unit uses R404A and POE oil. The use of inert gas brazing procedures is mandatory for all Carrier Transicold refrigeration units; otherwise compressor failure will occur. For more information Refer to Technical Procedure 98-50553-00 Inert Gas Brazing. 3. Unbraze refrigerant lines from condenser coil.
Page 247: Figure 8.7 Condenser Assembly
Figure 8.7 Condenser Assembly NOTE: Inlet may be lower on later design. 1. Condenser Frame Assembly 5. Ambient Air Temperature Sensor (ATT) 2. Venturi Frame 6. Condenser Frame Assembly Mounting Bolts 3. Condenser Coil 7. Condenser Frame Mounting Bolts 4. Condenser Frame 8.
Page 248: Filter-Drier
8.7.3 Filter-Drier a. Check Filter-Drier The unit must be running in cool for this test. Check for a restricted or plugged filter-drier by feeling the liquid line inlet and outlet connections of the drier cartridge. If the outlet side feels cooler than the inlet side, then the filter-drier should be replaced. b.
Page 249: Figure 8.8 Economizer Section
-------------- 8.7.6 Stepper Test Harness Figure 8.9 Stepper Test Harness A stepper test harness (Carrier Transicold P/N 07−00515) is available for testing the compressor suc- tion modulation valve (CSMV) and evaporator expan- sion valve (EVXV). The test harness is installed by disconnecting the...
Page 250: Figure 8.10 Suction Modulation Valve (Csmv)
The valve stepper motor may be tested using a stepper motor drive tester or ohmmeter. 1. To test with a stepper motor drive tester (Carrier Transicold P/N 07-00375-00SV), connect the 4 pin test cable supplied with the tester to the valve connector, refer to Figure 8.11, and the cable wires to the tester in...
Page 251 c. Diagnostics - Valve NOTE If the valve failed pretest and passed the preceding diagnostic testing, this is an indication the valve mechanism is damaged and the internal motor/piston assembly is to be replaced. 1. To test the valve internal mechanism, install a manifold gauge set on the suction service valve and a stepper motor drive tester.
Page 252: Figure 8.12 Evaporator Expansion Valve
The stepper test harness, Section 8.7.6, (Carrier Transicold P/N 07-00515) (can also be used to test the EVXV. If the test harness is used, voltages will be different when measured direct or in-line. The stepper test harness cannot be used to test the ECXV.
Page 253 PIN A (ORANGE) PIN B (RED) dance with wire and terminal color. (if a 5 pin tester cable is required, order Carrier Transicold P/N 07-00375-11.) 2. 2. Set the step rate to 50 steps per second and either open or close the valve. Each red LED...
Page 254: Liquid Injection Solenoid Valve
d. Replacing Expansion Valve & Strainer 1. Pump down the low side. Refer to Section 8.5.2. 2. Remove coil and unbraze valve. Clean all tube stubs so new valve fits on easily. 3. Verify the strainer is in place. 4. Use a wet rag to keep the replacement valve cool and braze in place. 5.
Page 255: High Pressure Switch
Figure 8.14 Solenoid Valve (LIV) LIQUID INJECTION VALVE COIL ASSEMBLY INTERNAL COMPONENTS 1. Locking Nut 6. Armature Tube 2. Upper O-Ring 7. Internal O-Ring 3. Threaded Collar 8. Spring6 4. Coil 9. Armature 5. Lower O-Ring - - - - - 8.7.10 High Pressure Switch a.
Page 256: Pressure Transducers
1. Ohmmeter or Continuity Device 2. Adjustment Screw (0.050” socket head size) 3. Low Side Connection 4. Pressure Line or Aspirator Bulb (Carrier Transicold P/N 07-00177-01) 5. Magnehelic Gauge (Carrier Transicold P/N 07-00177-00) 6. High Side Connection - - - - - 62-11785 8–26...
Page 257 3. Unit should remain in defrost until the DTT and SAT both reach 55°F (12.8°C). At this point the defrost cycle will terminate, and the unit will resume automatic operation. 4. If the above test indicates satisfactory operation, test DAS settings using a Magnehelic gauge (Carrier Transicold P/N 07-00177) or similar instrument as follows.
Page 258: Electrical System Componentservice
ELECTRICAL SYSTEM COMPONENTSERVICE 8.8.1 Main Microprocessor Module (MM) For complete Main Microprocessor Module replacement instructions refer to Section 5.5.2. 8.8.2 Power Control Module (PCM) Figure 8.17 Power Control Module NOTE The buzzer, buzzer harness, fuses, door, door seal, hinge pin, door screw (with retainer) and relays may be purchased separately and do not require complete module replacement.
Page 259: Stepper Valve Module (Svm)
8.8.3 Stepper Valve Module (SVM) 1. Ensure unit will not start automatically by placing the START/RUN-OFF switch in the OFF position and removing the negative battery cable. Disconnect the high voltage source and lockout/tagout the receptacle. 2. Unlock tabs on and remove the two 35 pin connectors and 8 pin connector from the front of the module. 3.
Page 260 Figure 8.18 CCB Location in Control Box NOTE At this point the sub panel may start to swing out of the box. It is best to hold it in while removing the last bolt. 9. Slide the sub panel towards the front of the box until the panel clears the lower studs, then tip the sub panel out on the control box, see Figure 8.18...
Page 261: Megohmmeter Test Procedure
Megohmmeter Test Procedure Check of the electrical insulation integrity and connections using a resistance tester (commonly known as a megohmmeter or Megger), such as Carrier Transicold P/N 07-00481-00, that can be set to 1000V. CAUTION Before connecting a megohmmeter, place the Main Power switch in the OFF position.
Page 262: Light Bar
8.8.7 Light Bar The light bar may be tested using a 12 VDC source. 1. Ensure unit will not start automatically by Figure 8.21 Light Bar Connections placing the START/RUN-OFF switch in the OFF position and removing the negative battery cable.
Page 263: Evaporator Heaters
5. Check wiring between CT and pins 1CCB10, 1CCB12, 1CCB31, and 1CCB34 as required. 6. If a problem with the current sensors is suspected, check sensor output. Current sensor inputs to the module are rated at 16.7mV per Amp. For every Amp that is read at the wires coming from the PSCON T1, T2 and T3 terminals with an amp meter, there should be a corresponding voltage reading on the blue, brown &...
Page 264: Figure 8.23 Evaporator Blower Assembly
8. To remove motor remove four bolts that hold motor to the stator. 9. Complete the assembly in reverse order of removal. Coat motor shaft with never-seize before assembly. 10. Reinstall the negative battery cable, start unit and run Pretrip to check operation. Torque: 37 to 43 ft/lbs Fan Nut...
Page 265: Figure 8.24 Condenser Fan Assembly
8.8.11 Condenser Fan Assemblies 1. Ensure the unit will not start automatically by placing the START/RUN-OFF switch in the OFF position. Dis- connect the high voltage source and lockout/tagout the receptacle. 2. Disconnect the motor electrical connector. Note motor is assembled to allow routing of the wiring down the lower right hand leg of the welded support.
Page 266: Battery Charger (Btyc)
8.8.12 Battery Charger (BTYC) NOTE A battery of known good condition must be connected to the charger before doing the following test. The charger operates only when the input voltage is between 275 VAC and 640VAC. If either limit is exceeded it will not function.
Page 267: Temperature Sensor Checkout
8.8.14 Temperature Sensor Checkout An accurate ohmmeter must be used to check resistance values shown in Table 8–3 Table 8–4. Due to variations and inaccuracies in ohmmeters, thermometers or other test equipment, a reading within 2% of the chart value would indicate a good sensor. If a sensor is bad, the resistance reading will usually be much higher or lower than the resistance values given in the tables.
Page 268: Table 8-4 Sensor Resistance (Cdts)
Table 8–4 Sensor Resistance (CDTS) °C °F Ohms °C °F Ohms °C °F Ohms °C °F Ohms 2,889,600 64.4 117,656 168.8 12,306 273.2 2,335 -36.4 2,532,872 68.0 107,439 172.4 11,524 276.8 2,223 -32.8 2,225,078 71.6 98,194 176.0 10,793 280.4 2,119 -29.2 1,987,446 75.2...
Page 269: Table 8-5 Temperature Pressure Chart
Table 8–5 Temperature Pressure Chart Temperature Pressure Temperature Pressure °C °F PSIG °C °F PSIG 72.5 75.6 78.8 12.9 82.1 16.3 85.5 17.7 89.0 19.2 92.5 20.7 96.2 22.3 99.9 23.9 103.7 25.6 115.4 1.88 27.3 126.1 29.1 137.4 30.9 10.3 149.4 32.8...
Page 270: Table 8-6 Compressor Discharge
Table 8–6 Compressor Discharge Table 8–7 Compressor Suction Pressure Transducer Pressure/Voltage Pressure Transducer Pressure/Voltage PSIG Voltage PSIG Voltage -0.7 -5.0 -0.3 10.0 15.0 20.0 25.0 10.2 11.9 13.6 15.3 17.0 18.7 20.4 22.1 23.8 25.5 27.2 30.6 Table 8–8 Current Sensor Millivolt Output vs Current Sensed Amps MV Output Amps...
Page 271 8–41 62-11785...
Page 272 62-11785 8–42...
Page 273: Unit Troubleshooting
SECTION 9 - UNIT TROUBLESHOOTING PARAGRAPH NUMBER Page BATTERY CHARGER ............9–1 REFRIGERATION / TEMPERATURE CONTROL .
Page 274 62-11785...
Page 275: Unit Will Not Cool
SECTION 9 UNIT TROUBLESHOOTING Under no circumstances should anyone attempt to repair sealed module internal components. Should a problem develop with these components, contact your nearest Carrier Transicold dealer for replacement. NOTE Run a Pretrip and check all active alarms before continuing with troubleshooting.
Page 276 Indication/Trouble Possible Causes Action/Reference Section Abnormal pressure Section 9.2.8 Expansion valve malfunction Section 9.2.11 No or restricted evaporator airflow Section 9.2.10 Suction Modulation Valve malfunction Section 8.7.7 Refrigeration system Check system for non-condensibles Section 8.5.2 Check economizer Section 8.5 Check refrigerant charge Section 8.5 Check condenser coil Section 8.5...
Page 277: No Evaporator Air Flow Or Restricted Air Flow
Indication/Trouble Possible Causes Action/Reference Section Heater contactor or coil defective Replace Initiates but does not defrost Heater(s) burned out Section 8.8.4 Evaporator fan contactor stuck closed Check Defrost air switch (DAS) out of adjustment Section 8.7.12 Frequent defrost Wet load Normal Defrost air switch (DAS) out of adjustment Section 8.7.12...
Page 278: Expansion Valve (Evxv) Malfunction
Indication/Trouble Possible Causes Action/Reference Section Frost on coil Section 8.7.12 Evaporator coil blocked Dirty coil Section 8.7.1 Evaporator fan rotating backwards Section 8.8.10 No or partial evaporator air flow Evaporator fan defective Section 8.8.10 Evaporator air flow blocked Check 9.2.11 Expansion Valve (EVXV) Malfunction Low refrigerant charge Section 8.5.2...
Page 279: Wiring
SECTION 10 WIRING 10.1 HARNESS CONNECTOR WIRING NOTE All illustrations provided in this Section are looking at the connector connection end (with the wires in the back). WHITE BLACK Component Terminal SAT PWR-A LB-B Component Terminal 3MM-34 PCM-19 3MM-23 HVB7-E HVB7-C PCM-35 SP-15...
Page 280 BLACK GRAY Component Terminal AAT-B Component Terminal AAT-A LIV-1 DP16-G / 1RAT-A LB-H DP16-H / 1RAT-B PCM-26 (AFAR) DP16-C / 1SAT-A DP16-D / 1SAT-B PCM-27 DP16-E / EVOT-A PCM-23 CDT-B SP-23 CSP-3 PCM-16 CDP-3 DAS Common (A) DP16-B / 1DTT-A PCM-9 PCM-29 PCM-28...
Page 281 2SVM BLUE 1SVM BLACK Component Terminal CSMV-A Component Terminal CSMV-B SP-15 CSMV-C DM-2 (CAN-HI) CSMV-D DM-1 (LOGIC GND) DP16-N / EVXV-E DM-6 (CAN-LO) DP16-J / EVXV-A HVB7-H DP16-K / EVXV-B SP-16 DP16-L / EVXV-C HVB7-G DP16-M / EVXV-D DM-10 (LOGIC PWR) SP-17 Unused Terminals: None DS-A...
Page 282 BLACK 3SVM BLUE Component Terminal ECXV-E ECXV-A Component Terminal ECXV-B 1SVM-3 ECXV-C 1SVM-2 ECXV-D SATCOM-B SP-17 ES-G SP-18 J-1A 3SVM-32 SATCOM-C 3SVM-31 1SVM-8 Unused Terminals: 6-10, 12-21, 23-30, 33-35 SATCOM-A Unused Terminals: 4, 5, 9, 11, 13, 14 62-11785 10–4...
Page 283 HVB8 HVB7 Component Terminal Component Terminal SP-15 REM-E SP-16 REM-G 1MM-2 REM-J 1MM-4 SP-26 PCM-10 Unused Terminals: E & F PCM-15 1SVM-7 1SVM-5 SP-10 (GND) SP-23 Unused Terminals: None 10–5 62-11785...
Page 284 Splice Point # Component GNDRING-1 SATPWR-B DP16 LIV-2 SP-10 (Ground) LB-G AFAS-B HVB7-J 1MM-3 SP-15 HVB7-A (Ground) 1SVM-1 1MM-8 Engine Harness Connector Shown SP-16 1SVM-6 (Ground) HVB7-B From Terminal Component 3SVM-11 2MM-22 1DTT--B SP-17 PCM-18 2MM-11 1DTT-A (Power) 2SVM-11 2MM-5 1SAT-A PCM-34 2MM-6...
Page 285: 10.2 Harness Connectors, Control Box
10.2 HARNESS CONNECTORS, CONTROL BOX 2CCB 1CCB Component Terminal Component Terminal SP-62 HVB9-3 CCON-A1 SP-60 SP-52 SP-61 HVB6-8 SP-52 1CCB6 HVB6-3 HVB5-6 2CCB6 HVB5-3 SP-59 SP-63 SP-57 HTCON2-A1 HVB9-2 SP-55 SP-55 SP-51 SP-51 HVB5-7 HVB6-4 HVB6-7 SP-64 2CCB-30 CDCON2-A1 HVB5-5 SP-50 HTCON1-A1 2CCB29...
Page 288 62-11785 10–8...
Page 289: Index
INDEX Data Transfer USB Memory Device 5–9 DataLink Data Recorder Via TRU-Tech 5–20 ADVANCED USER 3–18 DataTrak 3–27 ALARM TROUBLESHOOTING 7–1 DEFROST 4–7 Ambient Air Temperature Sensor (AAT) 2–6 Defrost Air Switch 8–26 Automatic Start-Stop 1–1 2–7 Defrost Initiation 4–7 Defrost Modes 4–8 Defrost Termination 4–8 Battery 1–1...
Page 290 Inspect Mode 3–4 Receiver 2–6 Installing Software 5–13 REFRIGERANT SYSTEM COMPONENT SERVICE 8–15 INTELLISET 3–5 REFRIGERANT SYSTEM SERVICE 8–5 INTRODUCTION 2–1 Refrigerant System Service Connections 8–5 Refrigerants 1–1 REFRIGERATION / TEMPERATURE CONTROL, LANGUAGE SELECTION 3–17 Troubleshooting 9–1 Leak Checking 8–8 REFRIGERATION CIRCUIT DURING COOLING 2–15 Light Bar 2–12 8–32...
Page 291 Technician Hour Meters 5–2 UNIT DATA 3–19 TECHNICIAN MODE 5–1 USB MEMORY DEVICES 5–9 TEMPERATURE CONTROL 4–5 USER SELECTED OVERRIDE OPERATION 4–9 Temperature Control 4–1 Temperature Determination 4–5 Temperature Pressure Chart 8–39 VIEW ACTIVE ALARMS 3–21 Temperature Range Lock 1 & 2 4–10 VIEW HOUR METERS 3–22 Temperature Sensor Checkout 8–37 Transferring Configuration Files 5–15...
Page 294 North America Central America Carrier Transicold and Mexico 700 Olympic Drive Ejercito Nacional 253−A Piso 5700 Athens, GA 30601 USA Colonia Anahuac Tel: 1-706-357-7223 11320 Mexico, D.F. Fax: 1-706-355-5435 Tel: 55315010 Fax: 55315010 ext. 1005 Carrier Transicold P.O. Box 4805 Syracuse, NY 13221 USA www.carrier.transicold.com...
