Container Refrigeration
OPERATIONS, SERVICE, AND
PARTS MANUAL
For
EverFRESH™
Controlled Atmosphere Option
T-374 Rev C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EverFRESH and is the answer not in the manual?

Questions and answers

Related Manuals for Carrier TRANSICOLD EverFRESH

Summary of Contents for Carrier TRANSICOLD EverFRESH

  • Page 1 Container Refrigeration OPERATIONS, SERVICE, AND PARTS MANUAL EverFRESH™ Controlled Atmosphere Option T-374 Rev C...
  • Page 2 OPERATIONS, SERVICE, AND PARTS MANUAL EverFRESH™ Controlled Atmosphere Option © Carrier Corporation, 2021 Printed in U. S. A. July 2021...

  • Page 3: Table Of Contents

    3–1 EVERFRESH AIR AND GAS FLOW ..........
  • Page 4 EVERFRESH SYSTEM PREPARATION ........
  • Page 5 2–4 Figure 3.1 EverFRESH Air and Gas Flow Diagram ..........
  • Page 6 5–1 Table 5–2 EverFRESH Function Codes ........... . .

  • Page 7: Safety Summary

    CAUTION - alert to potential hazard or unsafe practice that could result in minor personal injury, product or property damage. The following safety statements are applicable to the EverFRESH option unit used with any container unit and appear elsewhere in this manual. These recommended precautions must be understood and applied during operation and maintenance of the equipment covered herein.
  • Page 8 CAUTION Do not run the Calibration tests under loaded conditions. While the EverFRESH option is operating, the process of inducing ripening by introducing ethylene should not be performed. It is required that the calibration procedure only be performed during pre-trip or when the container has been fully vented.

  • Page 9: Introduction

    (Figure 2.1). The air compressor for EverFRESH is located below the condenser behind a splash guard. A manually operated venting system is located in the upper left access panel. The panel may be removed to allow entry into the evaporator section where the atmosphere sensors, control valves, water separator and air filters are located.

  • Page 10: Figure 2.2 Refrigeration Unit - Evaporator Section (Upper Panel Removed)

    Other than the air compressor, all of the components of the EverFRESH option are mounted in the evaporator 2.2) in addition to the standard refrigeration unit components. section (Figure Figure 2.2 Refrigeration Unit - Evaporator Section (Upper Panel Removed) EverFRESH components located in evaporator section 2.3) include the water separator, particulate filters, Water Drain Valve (WDV), Nitrogen...

  • Page 11: Figure 2.3 Everfresh Components

    1) Air Compressor 10) Nitrogen Supply Orifice 2) Check Valve 11) Nitrogen Sampling Orifice 3) Condensing Loop 12) EverFRESH Nitrogen Valve (EN) 4) Water Separator 13) Cargo Air Sensor Inlet 5) Particulate Filters (2) 14) Cargo Air Sensor Filter Assembly...

  • Page 12: Figure 2.4 Co2 Injection System

    Figure 2.4 CO2 Injection System 1) CO Injection Pressure Transducer (IPT) 4) Internal CO Port 2) CO Injection Solenoid Valve (CSV) 5) External CO Port 3) CO Supply Orifice Cap - - - - - T-374 2–4...

  • Page 13: System Data

    2.4 System Data Table 2–1 System Data Component Data Detail Air Compressor Number of Cylinders Type Three Phase Induction Weight 44 lbs Full Load Amps 1.34 amps 50Hz / 1.4 amps 60Hz. Voltage and Frequency 360 - 460 VAC 50 Hz +/-2.5Hz 400 - 500 VAC 60Hz +/-2.5 Hz Speed 1425/50 Hz 1725/60Hz RPM...

  • Page 15: Operation

    The compressed air then passes through the second particulate filter. This filter drains any remaining moisture from the system through the EverFRESH Air Valve (EA) solenoid. This will open after the WDV operates for draining moisture and when fresh air is required in the system. The EA maintains the desired oxygen levels inside the cargo space.

  • Page 16: Figure 3.1 Everfresh Air And Gas Flow Diagram

    The nitrogen sampling orifice regulates the flow of nitrogen to the EverFRESH Nitrogen Valve (EN). The controller will open EN to allow the gas to flow into the sensor package for testing at the O sensor. Elevated amounts of oxygen indicate the nitrogen membrane may be clogged. EN is only energized during Pre-trip test P20- 5 N2 Check.

  • Page 17: Pre-Trip Inspection

    3.4 Pre-Trip Inspection An EverFRESH Pre-Trip Inspection (PTI) is required to run prior to cargo being loaded in order to test operation of mechanical components and calibrate the sensors. EverFRESH efficiency is directly related to box integrity, so a PTI must only be performed with a well vented container box.
  • Page 18 Then re-run the Pre-trip “AutCA” test under the PRE-TRIP key menu. P20-5 EverFRESH Nitrogen Test will start with EAC off. EN current between 100 and 200mA. Valve (EN) Solenoid Energize EN and wait 5 seconds.

  • Page 19: Enabling Everfresh Operation

    3.5 Enabling EverFRESH Operation EverFRESH is activated via function code Cd71. This code allows the user to select a specific mode of operation and the associated parameters. The modes of operation are: FrESh, OFF, and PUrgE. Within each of these modes of operation are sub menus that have selectable parameters.

  • Page 20: Activate Or Deactivate Purge Mode

    When Purge mode is active, it allows the user to suspend EverFRESH operations while pre-charging gas levels in the container. All EverFRESH control actions and alarm 929 is suspended in order to purge the container to a desired gas concentration. When activated, Purge mode stays active for a period of time selected from the Purge mode sub menu.

  • Page 21: Code 44 (Cd44)

    3.5.4 Code 44 (Cd44) Cd44 allows the user to view the following EverFRESH values: CO setpoint, CO percentage, O setpoint, O percentage, O voltage and Membrane Pressure Transducer (MPT) pressure. 3.5.5 Display Cd44 Values 1. Press the CODE SELECT key on the keypad.

  • Page 23: Troubleshooting

    If during this time the manual fresh air vent is open and EverFRESH is active, an alarm will be generated. If alarm is active, the controller monitors the manual fresh air once per hour. Upon clearing the alarm, the controller goes back to monitoring at the pre-determined time.
  • Page 24 Action: Control O to setpoint. Controlling O may allow CO to increase, replace sensor as soon as possible. If both AL909 and AL910 are active, run the EverFRESH Air Compressor (EAC) and open the EverFRESH Air Valve (EA). Component CO Sensor Troubleshooting Check wiring (refer to schematic), and check for bad connections or wires positioned improperly.
  • Page 25 Troubleshooting Seal container where possible (access panels, rear doors, mounting hardware, etc). AL976 Air Compressor Internal Protector Open Cause: EverFRESH Air Compressor (EAC) internal protector opens. Component EverFRESH Air Compressor (EAC) Troubleshooting Follow steps defined in AL929 EAC testing. Component ML5 Controller Troubleshooting Access function code Cd74 to perform an ML5 self-diagnostic test.
  • Page 26 Membrane Pressure Transducer (MPT) Fault Cause: When the EverFRESH Air Compressor (EAC) is running and pressure is not between -5 psig and 200 psig or the EAC has been OFF for five minutes and pressure is not within the range of -5 psig and 5 psig.
  • Page 27 AL980 Fresh Air Valve (EA) Fault Cause: When the system energizes the EverFRESH Air Valve (EA) solenoid and membrane pressure does not drop 40 psi, the alarm is triggered. The alarm triggers OFF when membrane pressure transducer (MPT) pressure drop is more than 40 psi when EA is opened.

  • Page 28: Everfresh Troubleshooting

    4.2 EverFRESH Troubleshooting This troubleshooting section is for the EverFRESH option only. Prior to testing the EverFRESH unit, verify that the refrigeration system is functioning properly. Condition Possible Causes Recommended Actions EverFRESH Air Compressor EAC contactor not engaging Verify that temperature setpoint is in...
  • Page 29 Perform pressure decay test. Leaky cylinder head Perform minor rebuild. EverFRESH Air Compressor EverFRESH Air Valve (EA) does not open Check F3 fuse. (EAC) Runs But O Does Run a P20 PTI test. P20-2 will check for Not Come Up proper valve operation: electrical and mechanical.

  • Page 31: Service

    Areas affected should be sanded and repainted. 5000 Hours Perform minor rebuild of air compressor. Section 5.2.5 5.2 EverFRESH Air Compressor (EAC) Service Refer to Warnings in the beginning of this Service section before performing maintenance. The air compressor (Figure 2.1) is an oil-less, two cylinder compressor mounted on the front of the unit next to the...

  • Page 32: Air Compressor Function Codes

    “ReSEt” - Press the ENTER key for five seconds to reset this value to 0. Cd73 Air Compressor Total Cd73 displays the total number of operational hours for the EverFRESH Operational Hours system and air compressor. The total hours are displayed in increments in 10 hours (i.e.
  • Page 33 3. Clean any debris out of the filter housing. 4. Install the new felt filter and then replace the filter cap by pressing up into the slot and turn a 1/4 turn clockwise to lock. 5.2.3 Removing the Air Compressor 1.
  • Page 34 3. Using a 5/8” wrench, remove the air compressor discharge line. 4. Using a 9/16” socket, remove the eight bolts securing the air compressor mounting bracket to the container frame. 5. Pull the air compressor with the bracket away from the container frame to complete removal. 5.2.4 Installing the Air Compressor 1.

  • Page 35: Air Compressor Minor Rebuild

    2. Install the remaining seven bracket bolts and then torque to 30 to 35 ft-lbs. (41 to 47 Nm). 3. Install the discharge line. Tighten with a 5/8” wrench and then torque to 23 in-lbs. (2.6 Nm). 4. Connect the air compressor power connection and wire tie the harness to the drain line and yellow power cable.
  • Page 36 Procedure for Disassembly 1. Remove eight phillips screws from the protective shield. Remove the shield. The fan is not part of a minor rebuild so use caution not to damage. 2. Loosen the two crossover pipe compression nuts for one of the heads using a 3/4” wrench. 3.
  • Page 37 4. Remove crossbars from the air compressor using a 3/4” wrench. 5. Remove the cylinder from the air compressor by removing the 2 - 3/16” hex bolts and pulling off the piston. Use caution not to damage the fan. Discard bolts, do not reuse. 6.
  • Page 38 9. Remove the old gasket material from the cylinder head and cylinder using a gasket removal tool. Ensure all parts are clean and free of debris. Procedure for Reassembly 1. Install silver rings on the piston first. 2. Install the black ring over the silver ring on the piston. Open slightly to get over the piston and slide into place.
  • Page 39 4. Lay the head upside down on a bench. Take the gasket with the material in the middle and place it on the head lettering up and align with the separation in the head and indicator hole. 5. Take the outlet valve plate with the line down the center and align with the indicator hole. 6.
  • Page 40 13. Run the compressor for 10 minutes by setting the CO and O setpoints to 5% and turn on the EverFRESH option in Cd71. 14. Shut off the system and unplug main power to the container then re-torque heads to 150 to 160 in-lbs. (17 to 18 Nm).

  • Page 41: Air Compressor Major Rebuild

    15. Replace the splash shields. 5.2.6 Air Compressor Major Rebuild This procedure is only performed if the cylinder walls or piston is damaged. WARNING Before proceeding with installation, set the ON/OFF switch and circuit breaker to OFF position. Disconnect power plug from the unit. Follow all local Lockout / Tagout Procedures. Required Supplies •...
  • Page 42 3. Remove the head with loosened crossbar nuts using a 3/16” hex key. Remove the four head bolts and pull off the head assembly including valve plates. Discard all components except for the crossbar. 4. Remove crossbars from the air compressor using a 3/4” wrench. 5.

  • Page 43: Filter Assembly

    1. Open the panel needed to gain access to the water separator (Figure 5.1). This component can be accessed from the front of the unit through the upper left access panel, or from inside the container through the EverFRESH access panel door. 5–13 T-374...

  • Page 44: Replacing The Particulate Air Filters

    EverFRESH access panel door. 2. Remove both filter housings by turning counterclockwise until free. Carefully lay down each housing to prevent damage to evaporator fins.
  • Page 45 3. Remove the first filter by rotating the filter counterclockwise. Once removed, install the new filter by rotating clockwise. 4. Remove the second filter from the filter housing by pressing up on the locking tab holding the filter in place. 5.

  • Page 46: Removing The Water Drain Valve (Wdv)

    EverFRESH access panel door. 2. Place cardboard on the evaporator to protect it from any components or tools that may fall.
  • Page 47 4. Turn the stainless steel fitting on the bottom of the water separator using an 11/16” wrench while holding the brass fitting below with a 9/16” wrench. 5. Cut the supporting cable ties and cut the wire at the harness splice. 6.

  • Page 48: Everfresh Air Valve (Ea)

    Make note of the direction arrow on the valve body to ensure proper direction of flow. 5.2). This component can 1. Open the panel needed to gain access to the EverFRESH Air Valve (EA) (Figure be accessed from the front of the unit through the upper left access panel, or from inside the container through the EverFRESH access panel door.

  • Page 49: Everfresh Nitrogen Valve (En)

    EA coil. Removing the evaporator fan motor will allow for more space but not necessary. When removing from the back of the unit through the EverFRESH access panel, access to the components is easier.

  • Page 50: Sensor Assembly

    The O sensor monitors O levels and allows the system to prevent O levels from dropping below the lower setpoint. A CO sensor provides levels to the controller to allow the control algorithm to activate the required EverFRESH components. T-374 5–20...

  • Page 51: Replacing The Sensor Air Filter Element

    EverFRESH access panel door. 3. Unscrew and remove the filter cup from the bottom of the sensor air filter assembly.

  • Page 52: Replacing The Everfresh Condensing Loop

    1. Open the panel needed to gain access to the orifice (Figure 5.5). This component can be accessed from the front of the unit through the upper left access panel, or from inside the container through the EverFRESH access panel door. T-374...
  • Page 53 2. Remove rivets from the return air panel and support in an upright position allowing access to orifices. 3. Using a 9/16” wrench on the air line fitting and an 11/16” wrench on the adjacent fitting, remove the air line. 4.

  • Page 54: Replacing Nitrogen Sampling Orifices

    1. Open the panel needed to gain access to the orifice (Figure front of the unit through the upper left access panel, or from inside the container through the EverFRESH access panel door. 2. Remove rivets from the return air panel and support in an upright position allowing access to orifices.

  • Page 55: Replacing Air Compressor Check Valve

    EverFRESH access panel door. 2. Place a 9/16” wrench on the check valve and a 5/8” wrench on the outlet hose. Turn the 9/16” counter clockwise to remove the outlet hose from the check valve.
  • Page 56 4. Note the orientation of the check valve. 5. Reinstall in reverse order. T-374 5–26...

  • Page 57: Everfresh And Container Pre-Trip Preparation

    SECTION 6 EVERFRESH AND CONTAINER PRE-TRIP PREPARATION 6.1 Pre-Trip System Preparation These instructions are provided for proper setup of the EverFRESH system prior to loading with cargo for controlled atmosphere loads. These instructions do not include box preparation. WARNING Before proceeding with preparations, set the ON / OFF switch and circuit breaker to OFF position.

  • Page 58: Container Preparation

    Box Checkout / Leak Test When using the EverFRESH system, the box must conform to leak rates in order to maintain control of the O setpoints. The minimal box requirement is a pressure decay of 2 inch WG (50mm) to 1 inch WG (25mm) of four minutes or more for a 40 foot container.

  • Page 59: Figure 6.1 Pressure Connection Ports

    Figure 6.1 Pressure Connection Ports Schrader Valve Locations Magnahelic connection Portable air compressor If the ports are not available, then a Manual Fresh Air panel disc assembly (part # 79-04098-03) with two charging ports should be installed. Refer to Figure 6.2.

  • Page 60: Figure 6.3 Magnehelic Gauge (Kit # 07-00177-20)

    Figure 6.3 Magnehelic Gauge (Kit # 07-00177-20) Start Timer* Shut Off Air Supply Check Container for Leaks * 40’ Container - at least 4 minutes External Checks: Check for leaks with the following recommended checks. Re-pressurize the container to 2 inches water gauge and look for leaks at the following areas using soapy water (mixture of dish detergent and water) looking for bubbles.

  • Page 61: Container Curtain

    • Inspect for any internal wall damage. Repair and caulk as required • Inspect floor to side wall joint, floor to front bulkhead joint for any damage. Repair and caulk as required 6.4 Container Curtain WARNING Potential hazardous atmosphere and low oxygen levels may exist inside the container. Ventilate before entering.
  • Page 62 NOTE The flat side of the ribbon is pressed into the track. 3. Use retaining clips to align the polysheet curtain line on the curtain into the track across the top of the container. Using the line will keep the curtain square. 4.
  • Page 63 8. Use the Ribbon install tool to finish inserting the curtain ribbon. 9. Repeat steps 3 - 8 on the other side of the door. 10. At the ribbon mating point overlap, by approximately 6 inches (15 cm) and carefully cutoff the excess ribbon allowing for the overlap.

  • Page 65: Pre-Gassing Procedure

    1. Install the Carrier Transicold disk with charging ports (part # 79-04098-03) if available. Refer to Connect the charging hose and leave the second port open. 2. If Carrier Transicold disk is not installed, open the manual fresh air vent to allow for charging of gas. For units equipped with a Vent Position Sensor (VPS): a.

  • Page 67: Schematics & Diagrams - Standard Units

    SECTION 8 SCHEMATICS & DIAGRAMS - STANDARD UNITS Figure 8.1 Legend, Standard Units 8–1 T-374...

  • Page 68: Figure 8.2 Schematic, Standard Units

    Figure 8.2 Schematic, Standard Units - Page 1 T-374 8–2...

  • Page 69: Figure 8.3 Schematic, Standard Units

    Figure 8.3 Schematic, Standard Units - Page 2 8–3 T-374...

  • Page 70: Figure 8.4 Wiring Diagram, Standard Units

    Figure 8.4 Wiring Diagram, Standard Units T-374 8–4...

  • Page 71: Schematics & Diagrams - Units With Co2 Injection

    SECTION 9 SCHEMATICS & DIAGRAMS - UNITS WITH CO2 INJECTION Figure 9.1 Legend, Units with CO2 Injection 9–1 T-374...

  • Page 72: Figure 9.2 Schematic, Units With Co2 Injection

    Figure 9.2 Schematic, Units with CO2 Injection - Page 1 T-374 9–2...

  • Page 73: Figure 9.3 Schematic, Units With Co2 Injection

    Figure 9.3 Schematic, Units with CO2 Injection - Page 2 9–3 T-374...

  • Page 74: Figure 9.4 Wiring Diagram, Units With Co2 Injection

    Figure 9.4 Wiring Diagram, Units with CO2 Injection T-374 9–4...

  • Page 75: Service Parts List

    All orders and inquiries for parts must include: Parts Identification Number (PID), Model Number, Unit Serial Num- ber, Part Number, Description of part as shown on list and Quantity required. Address all correspondence for parts to the following address: CARRIER TRANSICOLD DIVISION Replacement Components Group, TR-20 P.O. Box 4805, Syracuse, New York 13221 or FAX to: (315) 432-3778 10.2 Letter Designations...

  • Page 76: Parts List For Compressor Kits

    11 Parts List for Compressor Kits 22, 23 4, 5 Item Part Number Description 18-10185-20 Minor Rebuild Kit - Includes: 1/4-20 Shcs Head / Cylinder Bolts Gasket-Head Gasket-Cylinder Piston Seal Piston Ring Valve Cylinder Side of Valve Plate Valve Head Side of Valve Plate Compression Sleeve Rider Ring 18-10185-31...
  • Page 77 11 Parts List for Compressor Kits 18-10185-21 Major Rebuild Kit - Includes Rod Assembly (Includes Eccentric & Piston) Cylinder Fan And Spring Clamp Head Brass Pipe Plug 1/4 SS Valve Plate Machine Key 18-10185-22 Shroud Assembly - Includes: Shroud Motor End Shield Spacer, V.O.Rated Washer Flat #10 Plastite #10-14 X 1.50...

  • Page 78: Parts List For Everfresh Kit (Pid Nt2865)

    12 Parts List for EverFRESH Kit (PID NT2865) 57, 58, 60, 91 29, 57, 58, 60 2, 53, 54, 55, 56 98, 99 57, 58, 60, 112 1, 69, 92, 93, 94, 101 Compressor Mounting View 37, 38, 57, 58, 60...
  • Page 79 12 Parts List for EverFRESH Kit (PID NT2865) 43, 109 18, 72 19, 70, 71 Section D-D 7, 57, 58 12, 57, 58 8, 57, 58 9, 57, 58 121, 122, 123 Section C-C H2O Separator / Air Filter Assy...
  • Page 80 12 Parts List for EverFRESH Kit (PID NT2865) Item Part Number Description 18-10185-00 Compressor 86-05336-01 Bracket Assembly 40-00342-03 Elbow, Male 56-09581-00 Tube, Heat Trans 40-00789-00 Adapter 30-00554-00 Separator - Includes: 30-00554-20 O-Ring 68-18588-00 Bracket 68-18642-00 Bracket 34-00373-73 Clamp 40-00671-00 Fitting...
  • Page 81 12 Parts List for EverFRESH Kit (PID NT2865) 68-18541-01 Brace, Support 68-18542-00 Grille 42-00174-132 Gasket 68-14739-00 Bracket 40-00640-00 Union, Bulkhead 58-00065-84 Grommet 58-04497-01 Tube 58-05188-01 Tube 40-00067-04 Nipple, Hex 40-00794-00 Coupling, Pipe 40-00107-02 34-00807-06 Screw, Cap Hxhd 34-00663-13 Washer, Lock...
  • Page 82 12 Parts List for EverFRESH Kit (PID NT2865) 58-00065-100 Grommet 40-00795-00 Valve, Check 40-00345-04 Connector, Fem 58-00079-02 Sta-Strap 58-04026-138 Protector 58-00508-70 Tube 58-00508-92 Tube 58-00508-104 Tube, Black 58-00508-105 Tube 58-00508-106 Tube 58-00507-24 Tube, Black 58-00507-16 Tube, Black 42-00425-163 Insulation, Tube...

  • Page 83: Parts List For Sensor Assembly (Pid Nt2865)

    13 Parts List for Sensor Assembly (PID NT2865) 14, 15, 17, 18 14, 18 11, 14 2, 13 11, 14 5, 14 2, 3 12, 13 5, 14 Top Housing O2 Sensor O2 Sensor and Amplifier Assembly Label Bottom Housing (O2 Amplifier) Item Part Number Description...
  • Page 84 13 Parts List for Sensor Assembly (PID NT2865) 58-04497-06 Tube 10-00398-01 CO2 Sensor 10-00344-01 O2 Sensor (See item 19 for replacement kit) 34-00373-61 Clamp, Tube 48-00297-01 Housing --KA--70PP-048 Fitting, Hose 66-U---1--5371-6 Screw, Mach HXHD 12-00346-01 O2 Amplifier (See item 19 for replacement kit) 58-04152-01 Washer, Spacer 66-U---1--5321-8...

  • Page 85: Parts List For Everfresh Kit (Pids Nt3000 And Higher)

    14 Parts List for EverFRESH Kit (PIDs NT3000 and higher) 130, 131 60, 91, 134, 143 29, 60, 134, 143 2, 53, 54, 55, 56 60, 112, 134, 143 1, 69, 92, 93, 94 37, 38, 57, 58, 60 36, 57, 58, 60...
  • Page 86 14 Parts List for EverFRESH Kit (PIDs NT3000 and higher) Section D-D 7, 57, 58 12, 57, 58 8, 57, 58 Detail G Air Flow 9, 57, 58 See Detail G 44, 57, 58 45, 57, 58 24, 82 Section C-C...
  • Page 87 14 Parts List for EverFRESH Kit (PIDs NT3000 and higher) Section F-F Item Part Number Description 18-10185-25 Compressor 68-18687-00 Bracket 40-00342-03 Elbow, Male 56-09581-00 Tube, Heat Trans 40-00789-00 Adapter 30-00554-00 Separator - Includes: 30-00554-20 O-Ring 68-18588-00 Bracket 68-18642-00 Bracket 34-00373-75...
  • Page 88 14 Parts List for EverFRESH Kit (PIDs NT3000 and higher) 40-00345-02 Connector 68-18564-00 Channel Parts List for Sensor Assembly (PIDs 79-66787-01 Sensor Assembly (See NT3000 and higher)) 68-18541-01 Brace, Support 68-18542-01 Grille 42-00174-134 Gasket 68-14739-00 Bracket 40-00640-00 Union, Bulkhead 58-00065-84...
  • Page 89 14 Parts List for EverFRESH Kit (PIDs NT3000 and higher) 58-04026-138 Protector 58-00508-70 Tube 58-00508-107 Tube 58-00508-104 Tube, Black 58-00508-105 Tube 58-00508-106 Tube 58-00507-24 Tube, Black 58-00507-16 Tube, Black 58-00079-00 Sta-Strap 62-66172-00 Label 44-00102-53 Clamp, Cushioned 40-00121-01 Bushing 06DA-403---844 Valve Assembly...

  • Page 90: Parts List For Sensor Assembly (Pids Nt3000 And Higher)

    15 Parts List for Sensor Assembly (PIDs NT3000 and higher) 14, 18 2, 13, 19 5, 14 2, 3, 19 4, 19 5, 14 Item Part Number Description 79-66787-01 Sensor Assembly - Includes: 68-17351-01 Plate 40-00297-00 Coupling 40-00108-03 Coupling 30-00415-01 Filter Assembly 34-00373-07 Clamp, Tube...

  • Page 91: Parts List For Control Box Components

    16 Parts List for Control Box Components Item Part Number Description 22-04043-01 Fuse FEF1 22-04043-01 Fuse FEF2 22-04043-01 Fuse FEF3 10-00431-00 Air Compressor AC Contactor 16–1 T-374...

  • Page 92: Parts List For Co2 Injection Kit (Option)

    17 Parts List for CO2 Injection Kit (Option) See Detail C See Detail B See Detail A Detail B 4, 5 4, 5 Detail A View B-B View A-A Detail C 18, 19, 20 16, 18, 19 18, 19, 45 17, 18, 19 See Detail D Section F-F...
  • Page 93 17 Parts List for CO2 Injection Kit (Option) Item Part Number Description 68-18715-00 Plate --DD--19CA-061 --EC--39DM-070 Core 40-00483-01 Fitting, Bulkhead 34-06053-07 Washer 34-00663-14 Washer, Lock 58-00065-12 Grommet 40-00671-00 Fitting 40-00343-01 Connector, Male 40-00805-00 Tee, Union 68-18744-00 Bracket, Mounting 58-00065-14 Grommet 68-18723-00 Bracket 68-18792-00...
  • Page 94 China RoHS per SJ/T 11364-2014 产品中有害物质的名称及含量 有害物质 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 部件名称 (Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE) 金属板部件 塑料部件 加热部件 马达与风扇组件 接触器 变压器 传感器 阀组件 电缆线 标签与绝缘材料 本表格依据 SJ/T 11364 的规定编制。 O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。 62-66122-03, Rev A T-374...

  • Page 95: Index

    INDEX Numerics 34-06053-02 12-4 14-4 34-06053-07 14-5 17-2 06DA-403---844 12-5 14-5 34-06053-15 12-4 14-4 10-00344-02 13-2 34-06212-08 12-5 14-5 10-00398-01 13-2 15-1 34-06212-13 12-4 14-4 10-00431-00 16-1 40-00060-09 12-3 14-3 12-00346-01 13-2 40-00067-02 12-3 14-3 12-00352-08 12-5 14-5 17-2 40-00067-04 12-4 14-4 12-00852-02...
  • Page 96 42-00425-163 12-5 66-U---1--5321-8 12-4 13-2 14-4 15-1 42-66643-00 14-5 66-U---1--5361-25 12-4 14-4 17-2 44-00102-51 12-3 14-3 66-U---1--5361-50 14-5 44-00102-53 12-5 14-5 66-U---1--5371-11 12-5 14-5 44-00102-57 12-4 14-4 66-U---1--5371-6 12-4 13-2 14-4 15-1 44-00102-72 14-4 66-U---1--5732-19 12-3 48-00297-01 13-2 68-14739-00 12-4 14-4 48-00515-00 12-5...
  • Page 97 Optional CO2 Injection System 2-3 --EC--39DM-070 14-5 17-2 Orifices and Check Valves Service 5-22 EverFRESH Air and Gas Flow 3-1 EverFRESH Air Compressor (EAC) Operation 3-1 EverFRESH Air Compressor (EAC) Service 5-1 Particulate Filters Location 2-3 EverFRESH Air Valve (EA) Location 2-3...
  • Page 98 Solenoid Valves System Data 2-5 Troubleshooting, EAC Will Not Start 4-6 Start-Stop Switch (ST) 5-1 Troubleshooting, MPT Reading High 4-7 Troubleshooting, MPT Reading Low 4-6 Troubleshooting Alarms 4-1 Troubleshooting, CO2 Injection Mode 4-7 Vent Position Sensor (VPS) 4-1 Troubleshooting, CO2 IPT Not In Range 4-7 Troubleshooting, CO2 Stays Low 4-7 Water Drain Valve (WDV) Location 2-3 Troubleshooting, EAC Hums But Does Not Start 4-6...
  • Page 100 Carrier Transicold Division, Carrier Corporation P.O. Box 4805 Syracuse, NY 13221 USA https://www.carrier.com/container-refrigeration...
