  • Page 1 CEILING FAN Model : AX70-3B/56 AX70-5B/56 AX70-5B/40 Version: 2020 V1...

  • Page 2: Table Of Contents

    TABLE OF CONTENT SAFETY PRECAUTION Item Page No. CAUTION Please take note of the following important points when installing. 1. Safety Precautions ................1 - 2 The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a 2.

  • Page 3: Parts & Accessories

    Washer, Bolt Nut & Celvis Pin Motor Assembly with Downrod, Fan Blade Coupling Cover, Rod Cover AX70-3B/56: 3 pcs Canopy and Canopy AX70-5B/40: 5 pcs AX70-5B/56: 5 pcs Rod Cover Step 4 Tie the Safety Wire across the hook as shown.
  • Page 4 INSTALLATION INSTRUCTION INSTALLATION INSTRUCTION Step 5 Step 7 Tie the Safety Wire across the hook as shown. Install the Blades on Motor with Screw. Step 8 a) Pull the Rod Cover down. b) Twist the Canopy to the ‘Lock’ position (turn left). Step 6 Connect the Connectors from Fan and Receiver.
  • Page 5 Below shows a complete installation diagram. IMPORTANT : THE CANOPY, ROD COVER AND COUPLING COVER SHOULD BE SECURELY FIT AND THE 3 ARROWS SHOULD ALIGN STRAIGHT IF THE STEPS ARE DONE CORRECTLY. Complete diagram Model: AX70-3B/56 Canopy Slot Model: AX70-5B/56 & AX70-5B/40...

  • Page 6: Transmitter Assembly & Function

    TRANSMITTER LEARNING PROCESS TRANSMITTER FUNCTION IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER SWITCH OR REGULATOR. Power The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more fans using Fan Speed Turn off fan 1 transmitter, the below steps are required.

  • Page 7: Maintenance

    POWER SUPPLY CONNECTION CIRCUIT DIAGRAM IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER SWITCH OR REGULATOR. SWITCH OR REGULATOR. Motor Regulator Dimmer Switch Double Pole Power Switch Supply...

  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS CUSTOMER SERVICE CENTRE If you need any technical assistance or faulty report, please contact our customer service centre at : Model AX70-3B/56 AX70-5B/56 AX70-5B/40 No. of Blades Alpha Home Appliances Sdn. Bhd. (390258-H) Head Office : 6, Jalan Sungai Kayu Ara 32/37, Berjaya Park, Section 32, 40460 Shah Alam, Selangor.
