Summary of Contents for Teradek Spark 4K
- Page 1 Spark 4K Zero-Delay Wireless Transmitter and Receiver Quick Start Guide...
- Page 2 PHYSICAL PROPERTIES Spark 4K TX - Front Spark 4K RX - Front Back Back A: OLED display C: 6-18V DC power input E: Bluetooth button B: HDMI input/output D: Type-C USB port F: On/Off switch...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 4K Zero-Delay Wireless System .... 2 Power and Connect ......3 Custom/3rd Party Power Cables ... 3 Launchpad App ........4 Launchpad Desktop App ...... 5 Pairing ..........6 Mounting ..........7... -
Page 4: 4K Zero-Delay Wireless System
4K HDR video at a range of up to 500 feet line-of-sight over the unlicensed 5GHz band. Spark 4K can multicast to up to two Spark 4K receivers simultaneously, has portable power, internal antennas, and a compact design making it truly wireless. -
Page 5: Power And Connect
If the battery is depleted, the battery icon will be empty. Spark 4K receivers can use either the included DC adapter, or a USB-C PD source. -
Page 6: Launchpad App
LAUNCHPAD APP Use the Launchpad App to pair your Spark 4K devices, upgrade the Bluetooth firmware (iOS only), and monitor every parameter of Spark 4K. CONNECT VIA BLUETOOTH Download Launchpad from the App Store. Press the Bluetooth button (E) on the back of both the transmitter and receiver. -
Page 7: Launchpad Desktop App
• Settings - Tap the button at the top of the display to monitor and/or customize the transmitter’s settings, perform a firmware upgrade, or to register your Spark 4K. • Signal Quality - Determine the quality and reliability of the signal being received. -
Page 8: Pairing
PAIRING Spark 4K sets (TX and RX), are paired by default, requiring no additional configuration. Spark 4K devices purchased separately need to be paired using Launchpad, or the Launchpad App. NOTE: Before starting any pairing process, ensure that both the transmitter and receiver have the same firmware version and have Bluetooth enabled. -
Page 9: Mounting
MOUNTING Spark 4K devices have a 1/4”-20 threaded hole and two M3 threaded holes on the bottom for mounting the included light stand adapter or any other mounting accessory. • Mount the transmitter onto your camera using the included hot shoe mount adapter, keeping the chassis and fan vents clear of any obstructions. - Page 12 Teradek regularly releases new firmware versions to improve performance, add features, or fix vulnerabilities. teradek.com/pages/downloads contains all the latest firmware and software updates. Visit teradek.com/contact for tips, information, and to submit help requests to Teradek’s support team.
- Page 13 © 2021 Teradek, LLC. All rights reserved.
