Teradek FALCO MD11 User Manual

Hide thumbs Also See for FALCO MD11:
Table of Contents

Advertisement

Quick Links

Download this manual
F
MD11 U
M
ALCO
SER
ANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FALCO MD11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teradek FALCO MD11

Summary of Contents for Teradek FALCO MD11

  • Page 1 MD11 U ALCO ANUAL...
  • Page 3 Amimon. Amimon is part of the Creative Solutions Division, which is part of Videndum PLC. Amimon's products are sold under the TERADEK professional video product line. Contact us International 26 Zarhin St., Raanana, 4366250, Israel...

  • Page 4: Table Of Contents

    Table of Contents 1. Before You Start 1.1 Glossary of Symbols ............5 1.2 S/N Label ................6 1.3 Warning ................8 2. Introduction 2.1 System Description ............8 3. Safety 3.1 Introduction ................ 9 3.2 Operator ................11 3.3 Regulatory Warnings and Information ......11 3.4 Electrical and Mechanical Safety, and Fire Hazards ..
  • Page 5 6. Maintenance 6.1 Maintenance ..............30 6.2 Waste Electrical and Electronic Equipment (WEEE) ..31 7. Troubleshooting 7.1 Troubleshooting ............... 31 8. Technical Specifications 8.1 Technical Specifications ..........33...

  • Page 6: Glossary Of Symbols

    1.1 Glossary of Symbols The following are symbols that you will find throughout this operating manual and their meanings Falco MD11 User Manual Page 5...

  • Page 7: S/N Label

    1.2 S/N Label MD11 Receiver Label on the Device MD11 Transmitter Label on the Device Falco MD11 User Manual Page 6...
  • Page 8 MD11 Receiver Label on the Individual Device Package MD11 Transmitter Label on the Individual Device Package Falco MD11 User Manual Page 7...

  • Page 9: Warning

    Receiver: MD11RX01 Description The Falco MD11 Wireless Video transmitter and receiver devices allow for the seamless connection of live video to secondary monitors, eliminating the need for cables and enhancing mobility and flexibility during surgical procedures. The MD11 transmits 4K 30fps video with high fidelity over a reliable, secure, and robust link, all while maintaining a latency below 1 mSec.

  • Page 10: Introduction

    (except near HF SURGICAL EQUIPMENT), outside the RF shielded space of a system for magnetic resonance imaging. The Falco MD11 is designed to provide wireless video output for a secondary monitor, facilitating training, education, and recording endeavors. Limitations of Use The MD11 is a non-sterile, reusable device not intended for use within a sterile environment.
  • Page 11 EMC and needs to be installed and put into service according to the specific instructions for maintaining basic safety and essential performance with regard to electromagnetic disturbances for the expected service life provided in the regulatory warning section in this chapter. Falco MD11 User Manual Page 10...

  • Page 12: Operator

    The product is provided with approved antennas. Use only antennas supplied by Amimon. Any changes or modifications to the antenna may void the regulatory approvals obtained for the product. FCC STATEMENT The following antennae were approved with the modules listed in the Antenna Information table. Falco MD11 User Manual Page 11...
  • Page 13 à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Falco MD11 User Manual Page 12...
  • Page 14 This equipment should be installed and operated with a minimum distance of 20cm between the device and your body. The device must not be co- located or operated in conjunction with any other antenna or transmitter. Falco MD11 User Manual Page 13...
  • Page 15 • In the 5.925-6.425 GHz band, MD11 receiver devices containing AMN42012 (a client device) must operate under the control of an MD11 transmitter device containing the AMNPTTX01, an indoor access point. Access points may connect to other access Falco MD11 User Manual Page 14...
  • Page 16 1. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. 2. Users should also be advised that high-power radars are allocated as primary users (i.e. Falco MD11 User Manual Page 15...
  • Page 17 5. Utilisation limitée à l’intérieur seulement dans la bande 5 925 – 6 425 MHz; 6. Utilisation interdite à bord de plateformes de forage pétrolier, de voitures, de trains, de bateaux et d’aéronefs, sauf à bord d’un gros aéronef volant à plus de 10,000 pieds d’altitude Falco MD11 User Manual Page 16...

  • Page 18: Electrical And Mechanical Safety, And Fire Hazards

    • MD11TX – Transmitter & AC adapter • MD11RX – Receiver & AC adapter Electrical Requirements The system shall only be powered with the AC adaptor supplied with  GlobTek WR9QE3000CCPNNAR6B. The AC adaptor characteristic: Falco MD11 User Manual Page 17...

  • Page 19: Installation

    • The transmitter and receiver shall be positioned on a flat surface to avoid accidental falls and damage. • When using VESA plate mounting accessories (AMN_VESA_KIT01, AMN_VESA_KIT02), the MD11 transmitter and receiver can be mounted on the back of a monitor. Falco MD11 User Manual Page 18...
  • Page 20 Distance Between Falco Devices This section describes the required distance and limitations between installed Falco devices (such as Falco MD11). • The distance between a paired transmitter and receiver shall be between 1m and 10m. • There is no distance limitation between receivers paired with the same transmitter.
  • Page 21 • The maximum number of Falco devices to be operated in a single room is six transmitters and six receivers. • The room may also contain other RF-emitting devices, such as 2.4GHz or 5GHz Wi-Fi and 2.4GHz Bluetooth. Falco MD11 User Manual Page 20...
  • Page 22 Install this system in an environment that complies with all applicable IEC, CEC, and NEC requirements for the safety of electrical devices. Any installation or connection with other devices shall be evaluated for electrical safety according to the IEC 60601-1. Falco MD11 User Manual Page 21...

  • Page 23: View Of The System

    5.1 Power and Connectivity 1. Connect power to the transmitter and receiver using the included AC adapter. 2. Connect the output from your video source to the HDMI input (A) on the MD11 transmitter. Falco MD11 User Manual Page 22...

  • Page 24: Pairing

    3. When pairing two to four receivers with one transmitter, repeat steps 1 and 2 for each receiver to be paired. Once a receiver is paired, turning it off before pairing the next receiver device is recommended. Falco MD11 User Manual Page 23...

  • Page 25: Receiver Menu

    This receiver will stop showing video. 5. Falco MD11 devices can also pair with Falco MD62 devices. To pair the MD11 device with a Falco MD62 device, follow the pairing instructions for the MD62 device and the MD11 device.
  • Page 26 ▪ Enable Bluetooth – Enables/disables Bluetooth connectivity. The default configuration is On. ▪ Use Bluetooth PIN – Enables/ Disables Bluetooth PIN code for a secured Bluetooth connection. The default configuration is Off. ▪ Change PIN – Change the Bluetooth PIN code. Falco MD11 User Manual Page 25...
  • Page 27 Network connected but no video is NO VIDEO delivered Pairing before a transmitter was PAIRING SEARCHING FOR TX found Pairing in progress PAIRING... Pairing completed successfully PAIRING COMPLETED SUCCESSFULLY Pairing failed PAIRING FAILED Unpairing UNPAIRING... PLEASE WAIT... Falco MD11 User Manual Page 26...

  • Page 28: Transmitter Menu

    ◦ Model – Displays the device model type and serial number. ◦ Device Info – Displays the device’s input voltage level and temperature. • Display Settings - Use the Display Settings to control the Navigation screen (OLED) display operation. Falco MD11 User Manual Page 27...
  • Page 29 Bluetooth connection. The default configuration is Off. • Change PIN – Change the Bluetooth PIN code. ◦ Reset All Settings - Reset all configurable options to their factory defaults. Note: Pairing is not deleted when the settings are reset. Falco MD11 User Manual Page 28...
  • Page 30 PAIRING SEARCHING FOR RX Pairing in progress PAIRING... Pairing completed successfully PAIRING COMPLETED SUCCESSFULLY Pairing failed PAIRING FAILED Unpairing UNPAIRING... PLEASE WAIT... Firmware update UPGRADING FIRMWARE PLEASE WAIT… Restore default settings RESTORING DEFAULT SETTINGS Falco MD11 User Manual Page 29...

  • Page 31: Maintenance

    • Use isopropyl alcohol-based disinfectant solutions containing at least 70% alcohol since they will evaporate faster. • When using a cleaner for the first time, test it in a small hidden area before cleaning the whole device. Falco MD11 User Manual Page 30...

  • Page 32: Waste Electrical And Electronic Equipment (Weee)

    1. Verify that the transmitter is placed at least 1m away from other Falco devices. 2. Allow five minutes for the system to find a vacant channel before power cycling the unit by turning the MD11 transmitter OFF and ON. Falco MD11 User Manual Page 31...
  • Page 33 It takes over five minutes to get a video link on all the devices in the room In case of multiple links in the same room (over two transmitters), it’s recommended to power up the transmitters one-by-one, for a faster room setup. Falco MD11 User Manual Page 32...

  • Page 34: Technical Specifications

    4Kp30/29.97/25/24/23.98 1080p60/59.94/50/30/29.97/25/24/23.98 Supported 1080i60/59.94/50 Resolutions 720p60/59.94/50 NOTE: Resolutions higher than 1080p60Hz are supported in 40MHz bandwidth only. AUDIO Audio 48kHz 24-bit PCM 48kHz 24-bit PCM Compression Embedded HDMI Audio Input Audio Input (2 Channel) Falco MD11 User Manual Page 33...
  • Page 35 Device RS-232 (for future use) RS-232 (for future use) Control WIRELESS VIDEO NETWORK DFS Frequencies: DFS Frequencies: Wireless 5.250 - 5.350 GHz, 5.470 - 5.725 5.250 - 5.350 GHz, 5.470 - 5.725 Video Bands Falco MD11 User Manual Page 34...
  • Page 36 5GHz band. devices working on the 5GHz band. Rejection Up to 6 sets at the same location. Up to 6 sets at the same location. BLUETOOTH BT Frequency 2402-2480MHz 2402-2480MHz Band Bandwidth 1MHz 1MHz Falco MD11 User Manual Page 35...
  • Page 37 Mountability and be placed in any position. and be placed in any position. FCC, EU, ISED, KC, MIC FCC, EU, ISED, KC, MIC Compliance CERTIFICATION AND APPROVALS ISO 13485:2016 General MDR 2017/745 Class I Falco MD11 User Manual Page 36...
  • Page 38 • This equipment is not likely susceptible to interference from HF surgical instruments in the Special Environment of being near an active HF surgical instrument. In the case that HF surgical interference is observed, adjust the separation distance of the equipment. Falco MD11 User Manual Page 37...
  • Page 39 The MD11 Wireless Transmitter and Receiver are intended for use in the electromagnetic environment specified below. The customer or the user of the MD11 Wireless Transmitter and Receiver should ensure that they are used in such an environment. Falco MD11 User Manual Page 38...
  • Page 40 Falco MD11 User Manual Page 39...
  • Page 41 Falco MD11 User Manual Page 40...
  • Page 42 Falco MD11 User Manual Page 41...
  • Page 43 URM-000003 Version 1.0...

This manual is also suitable for:

Md11rx01Md11tx01
