Teradek Falco MD62 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
F
MD62 U
M
ALCO
SER
ANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Falco MD62 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teradek Falco MD62

Summary of Contents for Teradek Falco MD62

  • Page 1 MD62 U ALCO ANUAL...
  • Page 2 Amimon. Amimon is part of the Creative Solutions Division, which is part of Videndum PLC. Amimon's products are sold under the TERADEK professional video product line. Contact us International 26 Zarhin St., Raanana, 4366250, Israel...

  • Page 3: Table Of Contents

    Table of Contents 1. Before You Start 1.1 Glossary of Symbols ............5 1.2 S/N Label ................6 1.3 Warning ................8 2. Introduction 2.1 System Description ............8 3. Safety 3.1 Introduction ..............9 3.2 Operator ................11 3.3 Regulatory Warnings and Information ......11 3.4 Electrical and Mechanical Safety, and Fire Hazards ..
  • Page 4 6. Maintenance 6.1 Maintenance ..............35 6.2 Waste Electrical and Electronic Equipment (WEEE) ... 36 7. Troubleshooting 7.1 Troubleshooting ............. 36 8. Technical Specifications Technical Specifications ............38...

  • Page 5: Glossary Of Symbols

    1.1 Glossary of Symbols The following are symbols that you will find throughout this operating manual and their meanings Falco MD62 User Manual Page 5...

  • Page 6: S/N Label

    1.2 S/N Label MD62 Receiver Label on the Device MD62 Transmitter Label on the Device Falco MD62 User Manual Page 6...
  • Page 7 MD62 Receiver Label on the Individual Device Package MD62 Transmitter Label on the Individual Device Package Falco MD62 User Manual Page 7...

  • Page 8: Warning

    Transmitter: MD62TX01 Receiver: MD62RX01 Description Falco MD62 transmitters and receivers are wireless devices that can deliver video in ultra-low latency for use in medical applications such as endoscopy systems, surgical lights, clinical microscopes, and other setups requiring detailed capture of intricate procedures and sharp-clear images.

  • Page 9: Introduction

    (except near HF SURGICAL EQUIPMENT), outside the RF shielded space of a system for magnetic resonance imaging. The purpose of the Falco MD62 is to provide wireless video output for a secondary monitor, facilitating training, education, and recording endeavors. Limitations of Use The MD62 is a non-sterile, reusable device not intended for use within a sterile field.
  • Page 10 EMC and needs to be installed and put into service according to the specific instructions for maintaining basic safety and essential performance with regard to electromagnetic disturbances for the expected service life provided in the regulatory warning section in this chapter. Falco MD62 User Manual Page 10...

  • Page 11: Operator

    The product is provided with approved antennas. Use only antennas supplied by AMIMON. Any changes or modifications to the antenna may void the regulatory approvals obtained for the product. FCC STATEMENT The following antennae were approved with the modules listed in the Antenna Information table. Falco MD62 User Manual Page 11...
  • Page 12 à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Falco MD62 User Manual Page 12...
  • Page 13 20cm or more from a person’s body. FCC RF EXPOSURE STATEMENT This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a Falco MD62 User Manual Page 13...
  • Page 14 • Operation of these devices in the 5.925-6.425 GHz band is prohibited for control of or communications with unmanned aircraft systems. • Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Falco MD62 User Manual Page 14...
  • Page 15 L'exploitation est autorisee aux deux conditions suivantes: 1. l'appareil ne doit pas produire de brouillage. 2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Falco MD62 User Manual Page 15...
  • Page 16 à la limite PIRE spécifiée pour un fonctionnement point à point et non point à point, le cas échéant. 5. Utilisation limitée à l’intérieur seulement dans la bande 5 925 – 6 425 MHz; Falco MD62 User Manual Page 16...

  • Page 17: Electrical And Mechanical Safety, And Fire Hazards

    Do not use the system in an oxygen-rich environment. Equipment List When you receive the system, ensure that it includes the following pieces of equipment: • MD62TX – Transmitter & AC adapter • MD62RX – Receiver & AC adapter Falco MD62 User Manual Page 17...

  • Page 18: Installation

    USB connector is located. Note: • The transmitter and receiver shall be positioned on a flat surface to avoid accidental fall and damage. Falco MD62 User Manual Page 18...
  • Page 19 Distance Between Falco Devices This section describes the required distance and limitations between installed Falco devices (such as Falco MD62). • The distance between a paired transmitter and receiver shall be between 1m and 10m.
  • Page 20 • The distance between any transmitter and any receiver (not part of the link) shall be no less than 2m. • The distance between receivers (linked to different transmitters) shall be no less than 80 cm. Falco MD62 User Manual Page 20...
  • Page 21 • Do not install near sources of intense heat, such as boilers or radiators. • Install this system in an environment that complies with all applicable IEC, CEC, and NEC requirements for the safety of electrical devices. Any Falco MD62 User Manual Page 21...

  • Page 22: View Of The System

    MD62 Transmitter A. 12G-SDI input E. OLED display I. Power switch B. 12G-SDI output F. Navigation button J. Micro USB C. HDMI 2.0 input G. Network status D. 12V DC power input H. Video status Falco MD62 User Manual Page 22...
  • Page 23 A. 12G-SDI output B E. OLED display I. Power switch B. 12G-SDI output A F. Navigation button J. Micro USB C. HDMI 2.0 output G. Network status D. 12V DC power input H. Video status Falco MD62 User Manual Page 23...

  • Page 24: Power And Connectivity

    1. Press the Navigation Button on the MD62 transmitter (F) for 5 seconds to start the Pairing process. The OLED display will indicate pairing has started. NOTE: Pressing the navigation button for 5 seconds will start the Pairing process without unlocking the menu. Falco MD62 User Manual Page 24...

  • Page 25: Receiver Menu

    4K30 fps and 3D resolutions. 5.3 Receiver Menu Main Status Screen - This screen displays the connection status of the receiver and the transmitter, along with the current video resolution and link quality (if connected). Falco MD62 User Manual Page 25...
  • Page 26 ◦ Dim after 10 sec - Dims the OLED after 10 seconds. ◦ Off after 10 min – Turns off the OLED after 10 minutes (default configuration). ◦ Off after 10 sec – turns off the OLED after 10 seconds. Falco MD62 User Manual Page 26...
  • Page 27 ▪ Video Off - Turns off the video output, when there is no video input connected to the transmitter. ◦ Reset All Settings - Reset all configurable options to their factory defaults. Note: Pairing is not deleted when the settings are reset. • Tools Falco MD62 User Manual Page 27...
  • Page 28 LEDs operate independently from each other. The Power LED is part of the on-off switch, while the Network and Video LEDs are on the front panel. LEDs can be in one of the following states: • Off • On (solid light) Falco MD62 User Manual Page 28...
  • Page 29 No link No video input Video input detected Network connecting Short blink Network connected Pairing in progress Fast blink Receiver Navigation Screen (OLED) Messages STATE MESSAGE No paired devices NOT PAIRED Network is connecting CONNECTING Falco MD62 User Manual Page 29...
  • Page 30 RESTORING DEFAULT SETTINGS * For statuses 7-8, the message will display an option to cancel and abort the operation. ** During operation the OLED may display the message “PLEASE WAIT…” for up to 5 seconds. Falco MD62 User Manual Page 30...

  • Page 31: Transmitter Menu

    ◦ Off after 10 min – Turns off the OLED after 10 minutes (default configuration). ◦ Off after 10 sec – Turns off the OLED after 10 seconds. ◦ Always on – OLED stays On. • 3D Mode - Falco MD62 User Manual Page 31...
  • Page 32 Each unit has three LEDs that indicate the Power, Network, and Video status. These LEDs operate independently from each other. The Power LED is part of the on-off switch, while the Network and Video LEDs are on the front panel. Falco MD62 User Manual Page 32...
  • Page 33 • Fast blink - 200ms On, 200ms Off TRANSMITTER STATUS LEDs Status Network LED Video LED Power LED No power Power on Standby mode Slow Blink No video input Video input detected No paired devices Network connecting Short Blink Network connected Falco MD62 User Manual Page 33...
  • Page 34 Network is connected but no video NO VIDEO is delivered Network connected & unsupported resolution is NO VIDEO connected to the transmitter Pairing before a receiver was PAIRING SEARCHING FOR RX found Pairing in progress PAIRING... Falco MD62 User Manual Page 34...

  • Page 35: Maintenance

    • Prior to cleaning, power the device off and unplug all external power sources (i.e., power cables) and video/data cables (i.e., HDMI, SDI, USB). • Cover HDMI, SDI, and USB connections when cleaning the device so the chemical does not penetrate inside the device. Falco MD62 User Manual Page 35...

  • Page 36: Waste Electrical And Electronic Equipment (Weee)

    The MD62 unit shows a “NOT PAIRED” message on the OLED. Make sure the transmitter and receiver units are paired with each other. If not, refer to the Pairing section (page 24) for steps on how to pair your devices. Falco MD62 User Manual Page 36...
  • Page 37 Set the correct 3D mode in the MD62 transmitter’s OLED menu (i.e. Line Alternative). The video is displayed with artifacts. 1. Verify the transmitter and receiver are positioned in the same room, with a distance of less than 10m. Falco MD62 User Manual Page 37...

  • Page 38: Technical Specifications

    Ω (BNC x 1) Outputs 2082-1 standard/75 Ω (BNC x 1) 1x HDMI 2.0 Type-A Color SDI: YCbCr 4:2:2, 10-bit SDI: YCbCr 4:2:2, 10-bit Sampling HDMI: RGB/YCbCr; 4:4:4/4:2:2 HDMI: RGB/YCbCr; 4:4:4/4:2:2 Delay (TX to <0.002sec <0.002sec Falco MD62 User Manual Page 38...
  • Page 39 Embedded SDI/HDMI Audio Audio Output Output (2 Channel) PHYSICAL ATTRIBUTES 5.9”L x 3.6”W x 1.1”H (149 x 5.1”L x 5.5”W x 1.1”H (129 x Dimensions 91.2 x 27.1mm) 138.8 x 27.1mm) Weight 12.7oz (360g) 15.3oz (434g) Falco MD62 User Manual Page 39...
  • Page 40 5.250 - 5.350 GHz, 5.470 - 5.725 Wireless Video Bands Non-DFS Frequencies: Non-DFS Frequencies: 5.150 - 5.250 GHz, 5.725 - 5.850 5.150 - 5.250 GHz, 5.725 - 5.850 NOTE: Frequencies and channels are dependent on regional approvals. Bandwidth 20MHz/40MHz 20MHz/40MHz Falco MD62 User Manual Page 40...
  • Page 41 Noise band. band. Rejection Up to 6 sets at the same Up to 6 sets at the same location. location. BLUETOOTH Frequency 2402-2480MHz 2402-2480MHz band Bandwidth 1MHz 1MHz RF Power 7dBm EIRP 7dBm EIRP Falco MD62 User Manual Page 41...
  • Page 42 FCC, EU, ISED, KC, MIC Compliance CERTIFICATION AND APPROVALS ISO 13485:2016 MDR 2017/745 Class I FDA Manufacturer Registration 3014730563 General FDA Listing Class I, 510K exempt. CFR 21 Parts 801, 807, 820, 880 UK MDR 2002 Falco MD62 User Manual Page 42...
  • Page 43 • This equipment is not likely susceptible to interference from HF surgical instruments in the Special Environment of being near an active HF surgical instrument. In the case that HF surgical interference is observed, adjust the separation distance of the equipment. Falco MD62 User Manual Page 43...
  • Page 44 The MD62 Wireless Transmitter and Receiver are intended for use in the electromagnetic environment specified below. The customer or the user of the MD62 Wireless Transmitter and Receiver should ensure that they are used in such an environment. Falco MD62 User Manual Page 44...
  • Page 45 Falco MD62 User Manual Page 45...
  • Page 46 Falco MD62 User Manual Page 46...
  • Page 47 Falco MD62 User Manual Page 47...
