IP System Instruction
R
WRT
ZZM-801CS6M
Thank you for choosing WRT. Please read this manual before using. WRT
reserves the right to change specifications or designs described in this
manual without notice and obligation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZZM-801CS6M and is the answer not in the manual?

Questions and answers

Related Manuals for WRT ZZM-801CS6M

Summary of Contents for WRT ZZM-801CS6M

  • Page 1 IP System Instruction ZZM-801CS6M Thank you for choosing WRT. Please read this manual before using. WRT reserves the right to change specifications or designs described in this manual without notice and obligation.

  • Page 2: Table Of Contents

    Content 1.0 Features & Functions 2.0 Equipment Description Gate Station Description 3.0 Caution 4.0 Installation 5 14 ～ 5.0 Operation 6.0 Specification 7.0 Terminal Description 8.0 Trouble Shooting 9.0 Wiring Content...

  • Page 3: Features & Functions

    Features & Functions 801 intercom systems is composed by building gate station, user door phone, PC and other equipments, which is based on TCP/IP. The system is with the technology of multichannel, every channel can work independently. 1. Luxury design, Maximum capacity of 400,000 cards and 500,000 door phones 2.

  • Page 4: Equipment Description

    Equipment description Front View Back view J P2 1 2 3 外接口1 外接口2 1.Camera(with Infrared LED Compensation) 2 .LCD Display 3 .Responce Keyboard 4.IC Card Induction Zone 5 . Microphone 6 . Speaker 7 .Camera Adjustment 8.Volume Adjustment 9. Socket for power input and unlock signal output 10.Network Connector 11.

  • Page 5: Caution

    Caution Avoid direct sunlight extreme temperature, frost, chemical erosion or dust. 2.Please confirm the height to install the station so that the visitor is within the vision of the camera. 3. Cut off the power when installing the system. 4. Make sure the wall or surface where the station is installed is flat so as to avoid dust or water. 5.CAT 5 wires is suggested in the system.

  • Page 6: Installation

    Installation 1 Make a hole in the wall prefer to the dimension of 152×350×63mm box. The bottom of the hole shall be 150cm to 155cm above the ground. (Figure 1) 2. Make a wiring hole on the bottom case,fix the fixed bracket on the bottom case.(Fiture2). wall Figure Figure 2...

  • Page 7: Operation

    Operation Please note: 1.All the parameters should be configured by appointed or authorized person in case of any data leakage. Admin password must be kept by specially-assigned person for usage or updating purpose. 2.Access control settings of gate station and wall station in the network system should be operated in center guard unit.
  • Page 8 Operation １Device setting ２Access control 专业保障 恒久关爱： ３Dial format Professional Guarantee Forever Concerned ４Device maintenance 按功能前的数字编号选中该功能，否则返回上一界面 ５Language ６Others Choose number for function, or return to previous. ７Return Press number keys before the items to enter the related interface of parameter configuration. Device setting 专业保障...
  • Page 9 Operation Press the device you want(” ” means selected),press”# "to confirm,the screen will prompt modify √ successfully.Press”*” to return to previous menu. Device NO.: Press”2” on device setting menu, the screen shows: 专业保障 恒久关爱： Professional Guarantee Forever Concerned 按功能前的数字编号选中该功能，否则返回上一界面 Choose number for function, or return to previous. 1 Group NO.
  • Page 10 Operation When non-input status, press ”5” ” ” to return to previous menu or exit automatically after 20s Note:Gate Station NO. is composed of 2 digits group NO.+3 digits building NO.+ 2 digits unit NO.+2 digits local NO. , When input should be based on this principle,if digits are not enough ,it could add ”0"...
  • Page 11 Operation Image setting Press “4” on device setting menu, the screen shows: 专业保障 恒久关爱： 1.Screen brightness Professional Guarantee Forever Concerned 2.Screen contrast 按功能前的数字编号选中该功能，否则返回上一界面 3.Screen saturation Choose number for function, or for return to previous. 4.Camera brightness 5.Camera contrast 6.Camera saturation 7.Return "( Press”1"...
  • Page 12 Operation Press”1" to select “Ring duration" ( Highlight means selected),input the time according to actual distribution, press”#” to confirm.The interface will be Talk duration input screen after modified successfully.Input data and press”#” to confirm.Input all time as above. ” ” * When non-input status, press ”5”...
  • Page 13 Operation 选择 设备 安 装位 置 0:室 内 2 :户 外 当前状态:室内模式 Press 0/ 1 can select install location as indoor/outdoor,press”#” to confirm,”*”to return to previous menu. Access control: It is effective for Gate Station with access control, including ”issue card by room NO.”,”issue card by swiping”, ”delete card by room NO.”and”delete card by swiping”.
  • Page 14 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned 输入房号按#键 Input room NO.and press # 1 Issue card by room NO. 2 Issue card by swiping 3 Delete card by room NO. 4 Delete card by swiping 5 Return Input 6 digits room NO.(Like 001001),press”#”to confirm,then swipe the card at the induction zone according to prompt,it means the card issued successfully,the user could continue to swipe other cards.Press “*“to return to previous menu.
  • Page 15 Operation Press “3" on the “Access Control”interface,the screen will show: 专业保障 恒久关爱： Professional Guarantee Forever Concerned 输入房号按#键 Input room NO. 1 Issue card by room NO. 2 Issue card by swiping 3 Delete card by room NO. 4 Delete card by swiping 5 Return Input 6 digits room NO.(Like 001001),it means the card deleted successfully.
  • Page 16 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned 按功能前的数字编号选中该功能，否则返回上一界面 Choose number for function, or return to previous. 1 Group NO. digit 2 Building NO.digit 3 Unit NO. digit 4 Floor NO.digit 5 Room NO.digit 6 Return Room NO, of tenant adopt 13-digit encode(2-digit group NO. + 3-digit building NO. + 2-digit unit NO.
  • Page 17 Operation NO. and press"#" to conform.Input all datas as above. When non-input status, press ”6” ” ” to return to previous menu or exit automatically after 20s. Device maintenance Restart or not? 　０: NO １: YES ２Auto- restart interval ３Auto- restart time ４Return Status:Self test is enabled.
  • Page 18 Operation thers 专业保障 恒久关爱： 1. Volume setting 2.Snapshot ON/OFF Professional Guarantee Forever Concerned 3.Password setting 按功能前的数字编号选中该功能，否则返回上一界面 4.Restart Choose number for function, or return to previous. 5.Check-on-line 6.Modify date 7.Modify time 8.Modify week 9.Key tone ON/OFF 0.System info Volume setting Press"1" on others menu,the screen shows: 专业保障...
  • Page 19 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned Talk volume There are 5 levels of ring volume and talk volume(Escalate from 1 to 5),press “#” to modify,press “*” to cancel modification. Snapshot ON/OFF Press"2" on others menu,the screen shows: 专业保障 恒久关爱： Professional Guarantee Forever Concerned Snapshot or not? 0: NO 1:YES...
  • Page 20 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned 1 Modify super password 2 Modify unlock password 3 Modify special password Return a. Modify super password 专业保障 恒久关爱： Professional Guarantee Forever Concerned Please input new super password Input 1- 8 digits new password and press”#” to confirm.Then the screen prompt to confirm super password again.
  • Page 21 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned Please input new unlock password Input 6 digits new password and press”#” to confirm.Then the screen prompt to confirm unlock password again. If entered two new unlock passwords are the same,it will prompt that new unlock password is modified successfully.
  • Page 22 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned Input 6 digits new password, press”#” to confirm.Then the screen prompt to confirm special password again,tenant input new password again,press”#” to confirm. If entered two new special passwords are the same,it will prompt that new special password is modified successfully. Note:New password is 6-digit.
  • Page 23 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned Please input time Input the time and press “#” to confirm. Modify week Press"8" on others menu,the screen shows: 专业保障 恒久关爱： Professional Guarantee Forever Concerned Please input week Input the week and press “#” to confirm. Key tone ON/OFF Press"9"...
  • Page 24 Operation 专业保障 恒久关爱： Professional Guarantee Forever Concerned Turn on key tone? 0:NO 1.YES Press" 0" to set not to turn on key tone,press"1" to turn on key tone. Magnetic Alarm: ENC , At t he back of Gate Station ,there is a magnetic terminal I GND on the s ocket J and a JP2 which is 3 cores short circuit pin socket they are used to connect door contact.
  • Page 25 Operation Calling Tenants(Divert off): When standby, input room NO. ( 1 digit floor number and 1 digit room NO.), For example, calling room 2 on 3rd floor, input:32, the screen display the number ( If set as alphabet,it will display the alphabet): Welcome 呼叫格式: 位层号+ 位房号...
  • Page 26 Operation When the tenant answers the phone,the screen will show: Welcome 呼叫格式:1位层号+1位房号 Dial format: 1 digit floor NO. + 1 digit room NO. 通话中，挂机按*：T alking, * t o ha ng up Input room NO. “#” for call “00# ” for center Visitors can talk with the tenant ,Press “* ”...
  • Page 27 Operation When the station calls the tenant and the line is not busy,the system will transfer the call to Guard Center. You can also leave a message to Guard Center,the message will be delivered to the household. Calling Center: Press“00#”,you can call the Center(sequence of call:Master Station>Sub Master Station>Guard Center>Back up Guard Center) If the center is free, the screen will show: Welcome...
  • Page 28 Operation For example,the unlock password is ”000001”, input”*000001”to unlock Welcome 呼叫格式:1位层号+1位房号 Dial format: 1 digit floor NO. + 1 digit room NO. 已开锁，请进： Unlock,come in Input room NO. “#” for call “00# ” for center tenant can use special password to unlock.The method is to input“ * ” +Room NO.+ password + “ #”. When tenant use special password to unlock,input room NO.
  • Page 29 Operation Welcome 呼叫格式:1位层号+1位房号 Dial format: 1 digit floor NO. + 1 digit room NO. Input room NO. “#” for call 已开锁，请进： “00#” for center Unlock,come in If IC card fails validation, “Du Du”tone can be heard, the screen will prompt invalid card. Operation...

  • Page 30: Specification

    Specification + 1 8 V D C Direct Voltage ≤ 3 7 0 m A Static current ≤5 7 0 m A Working current - 3 0 C～+ 5 5 C Operating Temperature 4 5 %～9 5 % Humidity ≤5 % Distortion ≤3 0 m V Sensitivity...

  • Page 31: Terminal Description

    Power supply input +，supply DC +18V for the station J1 0 LOCK Unlock signal output, output pulse +12V voltage to system power supply to unlock MENCI To door contact controller 485A To WRT lift controller 485B To WRT lift controller Network port Data transmission Terminal Description...

  • Page 32: Trouble Shooting

    Trouble Shooting Description Solution C h e c k 1.Check the power supply Connect wires between Gate Station and G a t e S t a t i o n 2.Check the wire connection between Gate d o e s n o t w o r k power supply correctly Station and power supply 1.Check the network port and connection...

  • Page 33: Wiring

    W i r i n g Gate Station To LAN Cable 1 2 3 External External connector 2 connector 1 To lift controller 1 8 V G N D Door contact PUSH RVV3×1mm RVV2×1mm Electric lock H D-V18 Note:There 2 ways of electric lock:unlock when energized and unlock when power off,please connect W i r i n g according to actual situation..
