Instruction
R
WRT
A6S-801ZCD8S43
Thank you for choosing WRT. Please read this manual before
using. WRT reserves the right to change specifications or
designs described in this manual without notice and obligation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A6S-801ZCD8S43 and is the answer not in the manual?

Questions and answers

Related Manuals for WRT A6S-801ZCD8S43

Summary of Contents for WRT A6S-801ZCD8S43

  • Page 1 Instruction A6S-801ZCD8S43 Thank you for choosing WRT. Please read this manual before using. WRT reserves the right to change specifications or designs described in this manual without notice and obligation.

  • Page 2: Table Of Contents

    Content 1.0 Features & Functions 2.0 Equipment Description A6S-801ZCD8S43 3.0 Caution 4.0 Installation 5 25 ～ 5.0 Operation 6.0 Specification 7.0 Terminal Description 8.0 Trouble Shooting 9.0 Wiring Content...

  • Page 3: Features & Functions

    Features & Functions 801 intercom systems is composed by building gate station, user door phone, PC and other equipments, which is based on TCP/IP. The system is with the technology of multichannel, every channel can work independently. 1. Suit for large community 2.Wall-mounted installation.

  • Page 4: Equipment Description

    A6S-801ZCD8S43 Front View Back View 1.Microphone 2.Screen 3.Reset 4.Status indicator light 5. Alarm 6.Unlock 7. Answer/ Hang up 8.Speaker 11. Socket for Alarm sensor 12. Socket for lift 9.SD Card port 10. Network port 13.Socket for External doorbell/ External alarm button 14.Socket for +18VDC input...

  • Page 5: Caution

    Installation 1. Do not install the stations in any of the location with waterdrop, high temperature and dust. 2.We suggest the installation height to be 145 cm above floor. 3. Be sure to cut off the power during installation. 4. Using wiring tube to avoid signal interference. Leave the terminals outside the tube for maintenance.

  • Page 6: Installation

    Installation Make a hole at the height of 145cm and make sure it's fit for the bottom case. (Figure 1) nsert the wires through the wiring hole,and fix the bottom case into the hole ,embed cement.(Figure 2) Wall Wall Hole Bottom case Wires Figure...
  • Page 7 Operation This door phone is operated by touching. It will boot normally after 30s when it is energized. Touch the screen when screen turns off or in screen saver to enter the interface. Intercom Alarm Service Info Settings Media There are 6 icons: Intercom, Alarm, Service, Info, Settings and Media on homepage. Touch”...
  • Page 8 Operation Basic settings:Set time,volume,ring,delay settings and other functions,as follows: Sound Ring Time Adjustment Appendix Function Delay Settings Basic Settings 1.Time:Set date and time Year： 2011 Month： Cancel Day： Hour： Time Adjust Minutes： Time Adjustment Touch" Year”: Bspace Clear Year Input the year, then click ”OK” to confirm. Set other date or time in same way.
  • Page 9 Operation In network system, touch" Time Adjustment"to synchronize the time of door phone with Guard Center. 2.Sound: Set volume of ring tone,speaking and alarm. Ring Volume： Speaking Volume： Alarm Volume: Sound Each volume with 5 levels,touch slide block to adjust volume. After finished adjustment,press"←"...
  • Page 10 Operation Select the ring tone( " " means selected) , press" Play"to play selected ring tone,Press" Stop"can stop playing.Press "OK" to confirm and set selected ring tone as incoming ring. " and " " to turn the page where there are many ring tones. Press"...
  • Page 11 Operation Ring duration(35-60)S Arm delay (1-255)S Upload delay(1-255)S Alarm duration(30-300)S Cancel Input setting time, and press”OK” means set successfully. Ring duration: Set ring duration of door phone when calling. If ring time more than 35s,it will provide 20s message function at the entrance. Alarm delay: Set the time from start arming door phone to armed door phone successfully.
  • Page 12 Operation Alarm Set up alarm zone and arm & disarm alarm zone. There are two lines of indicator lights show on the behind of the main interface.Black means alarm zones disabled, green means unarm, yellow means armed, red means there is a alarm. Press”...
  • Page 13 Operation Old password： Cancel New password： Confirm password: Password Old password: Input previous password(Original password is”88888888"),press”OK”to confirm. New password: Input a new 8-digit password, press ”OK” to confirm. Confirm password: Input the new 8- digit password again. press ”OK” to confirm. Press"...
  • Page 14 Operation Note: ①. Can not arm the disabled alarm zone. ②. If Zone 1 and Zone 2 are enabled, they will stay in arming status at long-term. Disarm(No alarm): Disarm all armed alarm zones. Touch"Disarm",the screen shows: Enter Bspace Clear Input password to disarm Please input password, if tenant input correct password, the screen will return to previous interface,it means disarmed.
  • Page 15 Operation Intercom Can monitor, call, lift and message etc. " " , Press the screen shows Call Room Call Center Monitor Call Lift Recoder Intercom " " , Call Room Call other tenants Touch Call Room the screen shows Call Bspace Clear G(2)-B(3)-U(2)-F(3)-R(3)
  • Page 16 Operation Touch" Call Center”,the screen display call interface, it will cut off automatically if there is no answer in 30s.If answer in 30s,the conversation time is 120s.The tenant could delegate Guard Center to execute the service during the conversation. Press” “...
  • Page 17 Operation Service: Set divert on & No-disturb functions, if services are available ,ask for maintenance and check fee. Press“ ”,the screen shows: Divert on No-disturb Fee check Maintenance Service 1.Divert: Turn on/off the service, or set the time. Touch"Divert on" , the screen shows: On/Off：...
  • Page 18 Operation Touch" No-disturb" ,the screen shows: On/Off： No-disturb：off Hours： Minutes： No-disturb >. On/Off: Turn on/off the service. >. Hours: Set the No-disturb hours. c> . Minutes:Set the No-disturb minutes. Press"←" to save and return after finished setting. No-disturb When is on, there is a call from door station, in the set time, door phone will not rings until No-disturb.
  • Page 19 Operation 4. Maintenance:When this service is available, door phone could ask for maintenance. Touch" Maintenance",the screen shows: Power System Water Pipe Kitchen Gas System Maintenance Click the item you need to repair,it will send your request to center.If succeed, door phone will prompt that the request has been sent to center.
  • Page 20 Operation Info Check message,call log,video and snapshot. Press” “,the screen shows: Message Call Log Video Snapshot Info 1.Message:Check message from center.Touch”Message”,the screen shows: Message 1 2011-01-01 15：30：53 Message 1 2 2011-01-01 15：21：27 Message 2 3 2011-01-01 10：20：00 Message 3 ½ Click the item you need to check(The selected one would be light blue),click one more time to open the message.
  • Page 21 Operation Call Log 1 2011-01-01 15：30 G1 B1 Gate Station 1 call 2 2011-01-01 15：21 Guard Center call 3 2011-01-01 10：20 G1 B1 Gate Station 1 call 4 2011-01-01 07：30 G1 B1Gate Station 1 call ½ Door phone can save latest 200 call logs,” “...
  • Page 22 Operation Media( SD card) Scan photos and enjoy music&video on door phone. Press” ”,the screen shows: Photo Music Video Media 1. Photo Touch”Photo”,the screen shows: Touch any one photo,the screen will enlarge the photo: " ", " "," " on the main interface mean enter previous list,return to previous interface,enter Operation next list.
  • Page 23 Operation Note:Photo support image format is JPG(below 5000x4500px) Photos will order play after about 15s. 2.Music Touch”Music”,the screen shows: Song 1.mp3 Song 2.mp3 Song 3.mp3 Song 4.mp3 Select the music you need to play(” “ means selected),press ” “ to play selected music,press “...
  • Page 24 Operation Select the video you want (Selected one would be grey),touch again to play the selected video.Touch the screen one time can stop playing and return to previous interface. Touch “ “ and “ “ to enter previous page and next page. Note:Video support format :AVI、MP4、3GP etc.
  • Page 25 Operation Being Called & unlock When Gate Station or Entrance Station or Front Door Station is calling, the door phone rings and the screen shows the situation at the entrance, when snapshot function is on, it will automatic take the photo at the entrance after 5s. Tenant press “...
  • Page 26 Operation Alarm processing： When the alarm is triggered, door phone will ring, status indicator red light is flashing, the screen will turn on,status indicator light of the triggered alarm zones become red, red words prompt the alarm zones are triggered. 1.Zone alarm 2.Arm zone 3.Unarm zone...

  • Page 27: Operation

    Operation Others 1. Door phone only can select NO Alarm Sensor Some alarm (control touch spots are open when no alarm ,control touch spots are connecting when there is a alarm).When connecting alarm sensor, touch spots of sensors should connect with -2 2K resistance in parallel(Figure 1).When connecting resistance, should connect terminal of touch spots which is near sensor.Ports of each group sensor can connect with multiple same sensors to monitor multiple places,method is: Touch spots of Alarm sensor are connected in parallel (figure 2) No matter how many sensors are connected in same group,just need...

  • Page 28: Specification

    Specification +18VDC Voltage Input Humidity 45%～95% . " color LCD ≤20mV Sensitivity ≤5% Distortion Back Light Build-in Static Current ≤230mA ≤260mA Working Current ≥7 0 d B A S/ N Ratio Operating Temperature - 1 5 C～+ 5 5 C Power Output ≥50 mW Screen Pixels...

  • Page 29: Terminal Description

    Terminal Description Te r m i n a l m a s k D e s c r i p t i o n Node Make node 1 and node short circuit ,then release, can call the lift. Socket for node Make node 1 and node short circuit for more than 5s ,then release, can enter screen calibration Node External doorbell...

  • Page 30: Trouble Shooting

    Trouble Shooting Description C h e c k Solution Check the power supply wire Connect the wires correctly Door Phone does not work Door Phone can not call Check connection of the network wire. Connect the network wire correctly and set &...

  • Page 31: Wiring

    Z o n e 7 Z o n e 6 Z o n e 5 G a s Fi re Zo ne 8 contact A6S-801ZCD8S43 To lift External doorbell cal External manual swi O U T External - G N D...
