Instruction (Version: H2)
TZS-801ZCD8S7
Thank you for choosing WRT. Please read this manual before
using. WRT reserves the right to change specifications or designs
described in this manual without notice and obligation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TZS-801ZCD8S7 and is the answer not in the manual?

Questions and answers

Summary of Contents for WRT TZS-801ZCD8S7

  • Page 1 Instruction (Version: H2) TZS-801ZCD8S7 Thank you for choosing WRT. Please read this manual before using. WRT reserves the right to change specifications or designs described in this manual without notice and obligation.
  • Page 2: Table Of Contents

    Content 1.0 Features & Functions 2.0 Equipment Description 3.0 Caution 4.0 Installation 5-28 5.0 Operation 6.0 Specification 7.0 Terminal Description 8.0 Trouble Shooting 9.0 Wiring Content...
  • Page 3: Features & Functions

    Features & Functions 801 intercom systems is composed by building gate station, user door phone, PC and other equipments, which is based on TCP/IP. The system is with the technology of multichannel, every channel can work independently. 1. Suit for large community 2.
  • Page 4: Equipment Description

    TZS-801ZCD8S7 Front View Back View 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 .Alarm Microphone Indicator LED Build-in Volume Adjustment 5.Lift 6.Screen 7.Speaker 8. Network port 9.Pin Socket for Alarm mode 10. Pin Socket for Alarm Detector 11.Socket of Alarm Detector 12.
  • Page 5: Caution

    Caution 1. Do not install the stations in any of the following locations, as it can cause fire, electric shock or unit damage: ·High or extreme cold temperature area, under direct sunlight, near equipment that varies in temperature, in front of air conditioner, inside a refrigerated area, etc.
  • Page 6: Installation

    Installation 1. Make a hole in the wall prefer to the dimension of 86.0mm×86.0mm×30.0mm wall box. The bottom of the hole shall be 145mm above the ground.(This depends on the individual's height). Make a hole in the wall box and insert the wires into the wall box through the inlet. (Figure 1) 2.
  • Page 7: Operation

    Operation This station is operated by touching the key.It will boot normally after 30 seconds when it is energized. The Status LED will turn to green when standby. Touch the screen when it is in standby state, and can operate it again.
  • Page 8 Operation “#” key to confirm. If you forget the password, you can restore it to PIN through the Control Center. Alarm There are two lines of alarm LEDs show on the up right side of the main interface. The arm is turned off when it is black;...
  • Page 9 Operation Arm/Disarm: it works only if it is “home” mode. Click the arm zone you need, and press √ , if “toot” sound is heard, the alarm LED turns to yellow. Click again the armed zone(s) you want to disarm and click √ to confirm for disarm purpose.
  • Page 10 Operation Option Guard center Ring ”, and press √ to confirm,press ←to back to previous Select the call in locations by “ ” or “ menu. : Delete all ringtones (except for the default ring and locking ring) : Delete the selected ringtones (locked ringtones can't be deleted) : Lock/Unlock the selected ringtones.
  • Page 11 Operation Smart Home(Type A/H)---Set for the home automation function The door phone can be used as control panel in RF wireless home automation system and ECB bus home automation system but the settings are different for the two systems. RF wireless system You should deploy the furnishings before using this function, the step is: Device Register, Device Settings and Scene Settings.
  • Page 12 Operation ECB BUS System Input password to enter into smart home settings,it will display: Device Settings: If there are settings before or default settings are not cancelled, it will show “Clearing all settings?” Yes or No for choices. to choose the room or appliance to control,and click √ to confirm and enter into appliance User press configuration interface,click choose Cbus as devices type.
  • Page 13 Operation Input device address, sub device address, port address etc, click√if it is infrared device. Please note: 1.Device address is the first two-digital physical address No.in computer system; device sub address is the last two-digital physical address No.in computer system; port address is related to port No. 2.Input address according to decimal system ( physical address and port No.in computer system is based on hexadecimal system ) For example, set address No.
  • Page 14 Operation Restart: Press to enter into screen adjustment menu if they system in running. Basic Setting Click “Basic Setting” to set “Divert On” “Color” “Volume” etc. Appendix function: User can set snapshot, screen protection, keytone, connection with analog monitor etc. Touch “Appendix Function”...
  • Page 15 Operation Divert on Touch “Divert on” , input the time of it, and press “#” to confirm. Directly click # without any input of time,it will turn to be default “divert on” time 12 hours. When there is a victor, the system will transfer the call to the Control Center under divert on. Please note: when it is in out of disturb status and “...
  • Page 16 Operation No-disturb on Touch “No-disturb on”.Input the time, and press “#” key and confirm it. Directly click # without any input of time, it will turn to be default No-disturb time 12 hours. The bell will not ring after successful setting. The divert on setting will shut down when No-disturb on. Cancel No-disturb on: The icon will turn to cancel No-disturb on status after setting successfully.
  • Page 17 Operation Network settings: Only operated by engineers, can be set according to the community network layout. Restore settings: Default setting, input password and click # to confirm. Be cautious of this step! Please restart the device after setting all above. Call Touch “Call”...
  • Page 18 Operation Input the numbers according to the tips, and press √ to save the data. Call the Tenant: Input the Room No. according to the dial format you have set for the tenant. If no one answers, it will cut off automatically, or else the call can be kept in 2 mins. You can also add new contacts by inputting the Room No.
  • Page 19 Operation Messages Touch “Messages”. Alarm Record Touch “Alarm Record” to check the records, the screen will show while touched: Delete all the records (except for the locking one) deleted) Delete the records which have been selected (locking records can't be : Lock the records which have been selected, to avoid to be deleted : Unlock the locking records which have been selected, so that it can be deleted : use for page turning when there are lots of records.
  • Page 20 Operation Voice Box Touch “Voice Box” to check the records, the screen will show while touched: : Delete all the voice records (except for the locking one) : Delete the voice records which have been selected (locking records can't be deleting) : Lock the voice records which have been selected, to avoid to be deleted : Unlock the locking voice records which have been selected, so that it can be deleted : Play and voice records which have been selected.
  • Page 21 Operation : Delete all the photos (except for the locking one) : Delete the photos which have been selected (the selected one would be turn to yellow) : Lock the photos which have been selected, to avoid to be deleted : Unlock the locking photos which have been selected, so that it can be deleted : to take a look at the photo functions: use for page turning when there are lots of photos.
  • Page 22 Operation : Delete all the messages (except for the locking one) : Delete the messages which have been selected (the selected one would be turn to yellow) : Lock the messages which have been selected, to avoid to be deleted : Unlock the locking messages which have been selected, so that it can be deleted :Open the selected message.Click the message,the color will become yellow from white,then click the icon to read the message.
  • Page 23 Operation Click “Service” icon in main interface,it will display: There are “Maintenance” “Fee check” “ring download” “Living message” “Voice message” “Service center” icons. Maintenance: all the public system problems such as power supply problem, water supply problem, Kitchen problems etc . ”and “...
  • Page 24 Operation Ring download: To download the ring-tone offered from the guard center, please click the icon and you will see the following screen: :To download the ring-tone from the center to the door phone. You can set the ring-tone downloaded in Ring Setting.
  • Page 25 Operation Click "REC" to leave a message.The voice message can last 20s. Click “Stop” to stop recording.. Service Center:Users can call the service center to get services.To realize this function, an IP telephone server and the telephone traffic platform. Alarm Clock: Users can set alarming time under this menu. Smart Home Touch “Smart Home”...
  • Page 26 Operation In ECB home automation system, “Guest” scene will work for devices with defaulted settings.”Dinner” scene controls all devices in scene 2 ; “Cinema” controls all devices in scene 3; “Sleeping” scene control all devices in scene 4; “Warm” scene controls all devices in scene 5; “Home” scene controls all devices in scene 6;...
  • Page 27 Operation turns on. Press “Intercom” to have a conversation with the visitor; Press “Silent” to shut down the rings; Press “Hand Off” to end the call. Emergence-handing When there is alarm happened, the door phone will alarm during setting time. LCD turns on and the status indicator will be red at the same time.
  • Page 28 Operation Alarm Press “ ” or external alarm switch if you needed, it will alarm and send the message guard center. Lift There are two ways for you to select. Press “lift” under the “call” menu if the system is connecting the lift linkage.
  • Page 29 Operation groups Alarm Sensor. There are eight groups Alarm Sensor on the back of door phone, from right to left: Fire, Gas, PIR, Magnetic Contact and other four customize zones.You must choose right option according to specific condition when installing these socket: the socket which don't need to connect the Alarm Sensor should insert shock block, or it will alarm all the time;...
  • Page 30 Operation Products functions. Type Type A Type A H , Function 7 0 inch 7 0 inch Call Intercom Unlock Monitor Alarm Smart Home Arm/Disarm Lift call Message Divert-on No-disturb Help Ring download Multi monitors Operation Remote upgrade...
  • Page 31: Specification

    Specification Voltage Input +18VDC Humidity 45%~95% 7.0" LCD ≤20mV Sensitivity ≤5% Distortion Back Light Build-in 200mA±20%(LCD Standby Current Closed Working Current 350mA±20% ≥7 0 d B A S/ N Ratio Operating Temperature - 1 0 C~+ 5 5 C 1 2 dots Visual Angle PAL/NTSC Signal System...
  • Page 32: Terminal Description

    Terminal Description Te r m i n a l M a r k s D e s c r i p t i o n ALARM OUTPUT External Alarm Socket of Alarm Ground Wire ALARM INPUT External Emergency Button P O I N T 1 Socket of lift Lift Control Signal P O I N T 2...
  • Page 33: Trouble Shooting

    Trouble Shooting Description Solution C h e c k Check the power supply wire and the Door Phone Connect the wires correctly does not work indicator LED Door Phone can not call Check connection of the network wire. Connect the network wire correctly and &...
  • Page 34: Wiring

    GA S SM OKE D ZH-801C e-lock WRT-SD power to LAN C AT 5 to Li ft 1. Defence Zone 1~4 can connect the short circuit or open circuit probe,but could not be connected to the pulse signal probe as the switching signal time is more than 200 millisecond.
  • Page 35 Shenzhen WRT Intelligent Electrical Appliance Co.,Ltd Add:WRT Industrial Base, Dafu Industrial Park, Guanguang Rd, GuanLan Town, BaoAn District ShenZhen, China Tel: +86 755 29576113 Fax: 86 755 29576023 Http:www.wrtsz.com...
