WRT IZM-212CS4-IPM Manual

Cat5 intercom system gate station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAT5 intercom system gate station manual
R
I Z M - 2 1 2 C S 4 - I P M
Thank you for choosing WRT.Please read this manual
before using. WRT reserves the right to change
specifications or designs described in this manual
without notice and obligation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IZM-212CS4-IPM and is the answer not in the manual?

Questions and answers

Related Manuals for WRT IZM-212CS4-IPM

Summary of Contents for WRT IZM-212CS4-IPM

  • Page 1 CAT5 intercom system gate station manual I Z M - 2 1 2 C S 4 - I P M Thank you for choosing WRT.Please read this manual before using. WRT reserves the right to change specifications or designs described in this manual...

  • Page 2: Table Of Contents

    Content 1.0 Features&Functions 2.0 Equipment Description Video Gate Station 3.0 Caution 4～5 4.0 Installation ～ 5.0 Operation 6 22 6.0 Specification 7.0 Terminal Description 8.0 Trouble Shooting 9.0 Wiring 26～28 Content...

  • Page 3: Features&Functions

    & Features Functions CAT5 Intercom System is composed by building gate station, user door phone, PC and other equipments, which is based on TCP/IP. The system is with the technology of multichannel, every channel can work independently. 1.Suit for CAT5 Intercom System. 　　2.Max capacity is 1016 door phones；...

  • Page 4: Equipment Description

    Video Gate Station Front View Back View Welcome! INPUT ROOM ID Input room ID “#” Please input Room No. for call “00#” for center 18V GND UNLOCK DOOR MENCI EARTH-GND 1.Microphone 2.LCD Display 3.Keypad 4.Speaker 5.Camera with IR compensation 6. IC card induction zone 7.Camera adjustment 8.To decoder connector 9.Socket for lift controller and access control...

  • Page 5: Caution

    Caution 1. Avoid direct sunlight, extreme temperature, frost, chemical erosion or dust. 2.Please confirm the height to install the station so that the visitor is within the vision of the camera. 3. Cut off the power when installing the system. 4.

  • Page 6: Installation

    Flush mounting 1 Make a hole in the wall prefer to the dimension of 130×378×65mm box. The bottom of the hole shall be 150cm to 155cm above the ground. (Figure 1) 2. Make a wiring hole on the bottom case and insert the wires through it, install the bottom case into the wall and embed it in the cement.(Figure 2).
  • Page 7 Flush mounting 1 . Drill holes at the suitable place on the front and the back of the door according to the size (Figure 1). 2.Unscrew 4 screws from Gate Station.(Figure 2) . 125.0mm Iron gate Welcome! INPUT ROOM ID Input room ID “#”...
  • Page 8 Operation Please note: 1.All the parameters should be configured by appointed or authorized person in case of any data leakage. Admin password must be kept by specially-assigned person for usage or updating purpose. 2.Access control settings of gate station and wall station in the network system should be operated in center guard unit.
  • Page 9 Operation 0 System info 5 Password setting 1 Network setting 6 Function ON/OFF 2 Device No. 7 Time setting 3 Room Format 8 Access control 4 Room Table Edit 9 Language * " ， " # " Press” to return Press to next page Press“#”to enter next page: 1 Restore factory setting...
  • Page 10 Operation 1 Local IP 192 168 100 001 2 Subnet mask 255 255 255 000 3 Gateway 192 168 100 001 4 Center IP 192 168 100 005 5 Back up center 000 000 000 000 6 Guard Station 192 168 100 005 7 Sub Guard Station 8 Return 000 000 000 000...
  • Page 11 Operation non-input status,press”5”or”* ”to return to previous menu or exit automatically after 60 seconds. Note:Gate Station NO.is composed of 2 digits group NO.+3 digits building NO.+ 2 digits unit NO.+2 digits local NO.,When input should be based on this principle,if digits are not enough ,it could add ”0"...
  • Page 12 Operation The”001- 0”represents decoder and port number;”0101”represent room NO.. Input decoder number and its address code which need to modify,four digits room NO.is automatically generated .Then modify it to the room NO. you need.After finished, the screen shows next address code and room NO.,it means previous modification has been finished, and continue to modify next room NO., repeat above program until complete.
  • Page 13 Operation Decoder NO. 013-0 Room NO. 1301 Input room NO. 0109",it shows: ” Decoder NO. 013 1 - Room NO. 1302 Thus, the first port of the decoder 13 had been modified to room NO.0109. Then input ”0131 0110” (or press”#”, input ”0110” after moved the cursor 4 digits,following the same),”0132 0111”, ”0133 0112”, modify the room NO.
  • Page 14 Operation 1 Modify super password 2 Modify unlock password 3 Return a. Modify super password: modify local super password. Press”1” on the interface of password setting to enter the menu of modify super password. Please input new password Input 8 digits new password . Then the screen prompt to confirm super password again. If entered two new super passwords are the same,it will prompt that new super password is modified successfully.
  • Page 15 Operation Function ON/OFF: turn on or off for some specical functions. Press ”6” on the basic setting menu, the screen will show: 1 Snapshot ON/OFF 2 Disarm by card 3 Return 0 OFF 1 ON Press number keys to clear up the data in the input box.Input ”0” or ”1” to set,screen will prompt modified successfully,it means this group data set succesfully.
  • Page 16 Operation if there is no answer. Disarm by card: Under the ”Disarm by card” status, when the tenant swipe the card to open the door at the Gate Station, it also disarm door phone. Time setting: Set the time of Gate Station. Press”7”...
  • Page 17 Operation ： a Issue card by swiping Issue card by swiping for tenants. On the “Access Control“interface press “1“ the screen will show: 1 Issue card by swiping Please swipe card..2 Delete card by swiping 3 Issue card by room NO. 4 Delete card by room NO.
  • Page 18 Operation 1 Issue card by swiping 2 Delete card by swiping 3 Issue card by room NO. 4 Delete card by room NO. 5 Return Input 6 digits (3-digits floor NO.+ 3-digit room NO.,for example 001001) the room NO.of tenant. Press”#”again, then swipe the card at induction zone,it means issued successfully,the user could continue inputting other room NO.
  • Page 19 Operation Language: There are two languages for option: English and Chinese. Restore factory setting: All the settings are initialized, please be cautious! Press 1 on the basic setting menu on page 2,the screen will show: ” ” Restore factory setting？ 0: NO 1:YES Press 1 then press # all the settings are initialized,Gate Station will restart automatically.
  • Page 20 Operation Station ,it is used to connect door contact,when I and GND open more than 120s without short circuit, it will report alarm. Note:There is a volume adjust electronic equipment at the back of Gate Station. he back of Gate Station , There is a terminal DOOR and GND at the s ocket J...
  • Page 21 Operation Calling Tenants(Divert off): When standby, input room NO. ( 2 digits floor number and 2 digits room NO.), For example, calling room 2 on 3rd floor, input:0302, the screen display the corresponding number at the same time: 0302 Input room ID “#” for c a l l “00#”...
  • Page 22 Operation Talking, * to hang up Input room ID “#” for c a l l “00#” for center Visitors can talk with the tenant ,Press “* ” can hang up . If the conversation last over 60s, the system will return to standby state automatically. The tenant can unlock the electric door by pressing the “unlock”...
  • Page 23 Operation If the center is free, the screen will show: * to hang up Calling Input room ID “#” for c a l l “00#” for center If there is no answer within 30s,system will be back to normal automatically. If someone answers, the call can last 60s.

  • Page 24: Operation

    Operation Unlock by Access Control card: When standby the tenant use IC card to close to the induction zone.”Di Di ”tone can be heard if succeed ,the screen will show: Unlock please close the door Input room ID “#” fo r c all “00# ”...

  • Page 25: Specification

    Specification Direct Voltage +18VDC ≤30 Standtic Current 0 m A Working Current ≤ 0 m A Operating Temperature - 3 0 C～+ 5 5 C 4 5 %～9 5 % Humidity ≤5 % Distortion ≤3 0 m V Sensitivity 5-16U.500 wire Automatic backlight compensation Camera Signal System...

  • Page 26: Terminal Description

    Terminal Description Description Terminal Marks +， Power supply input supply DC 18V for the station Power supply input- UNLOCK Unlock signal output, 12V when unlock DOOR Unlock signal input MENIC To Door Contact 485A data wire 485B data wire To decoder To network switch Terminal Description...

  • Page 27: Trouble Shooting

    Trouble shooting C h e c k S o l u t i o n D e s c r i p t i o n Gate Station Connect all the wires correctly check the connection from Gate State can not call to decoder.Can not call a door phone and change another Gate Station door phone...
  • Page 28 Wire size Type Requirements Wiring Description Remark Please pay attention System power Wire between system power 1～20m 2 0～50 m 5 0～10 0 m supply wire to transmission supply and Gate Station RVV3×0.75mm RV V 3×1.0mm RVV3×1. 5m m distance and wire size Wire between system power Electric lock Except special...

  • Page 29: Wiring

    Wiring Gate Station UTP cable 2-core Multi-fiber copper wire Welcome! INPUT ROOM ID Input room ID “#” Please input Room No. for call “00 #” for center Power supply 2-core 3-core Electric decoder decoder 说 明 lock 1、请按中文显示屏提示操作 2、可直接呼叫管理中心并通 话，中心遥控开锁 3、可密码开锁或感应卡开锁...
  • Page 30 Wiring Back view Power supply E-lock wire To other wire decoders PD-V28 PUSH E-lock HD-V18 To network switch To lift controller or access control 1 V 8 GND UNLOCK J2 1 J 2 4 To GND DOOR MENCI Bus input Bus output EARTH-GND Floor code...
  • Page 31 Manufacturer Shenzhen WRT Intelligent Electrical Appliance Co.,Ltd Add:WRT Industrial Base, Dafu Industrial Park, Guanguang Rd, GuanLan Town, BaoAn District ShenZhen, China Tel: +86 755 29576113 Fax: 86 755 29576023 Http:www.wrtsz.com...
