- Page 4 Please do not use tools to assemble this unit unless specifically indicated. Step 1. Insert drawer left panel (part H) and drawer right panel (part I) into drawer front panel (part G) pull down to lock. Slide drawer bottom panel (part K) into grooves of assembled unit (parts G, H &...
- Page 5 Step 2. Attach legs (part F) to bottom panel (part D) using spring washers (part #5), flat washers (part #4), bolts (part #3) and allen wrench (part #8). Step 3. Carefully turn unit upright. Attach left panel (part B) and right panel (part C) to bottom panel (part D) pull down to lock.
- Page 6 Step 4. Insert back panel (part E) into grooves of assembled unit (parts B, C & D). Step 5. Attach top panel (part A) to assembled unit (parts B & C) using wood dowels (part #6) and lock the hardware.
- Page 7 Step 6. Slide assembled drawer into place. Step 7. Secure back brackets (part #7) at the corner of back panel (part E) using screws (part #1) and phillips head screwdriver.
