Microwave Oven
315530
O
ven Capacity: 28 Liter
240
V~50Hz,
1450
Read these instructions
carefully before using your
microwave oven, and keep
it carefully.
If you follow the instructions,
your oven will provide you
with many years of good
service.
W
INSTRUCTION MANUAL
EN-1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 315530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Midea 315530

Summary of Contents for Midea 315530

  • Page 1 INSTRUCTION MANUAL Microwave Oven 315530 ven Capacity: 28 Liter V~50Hz, 1450 Read these instructions carefully before using your microwave oven, and keep it carefully. If you follow the instructions, your oven will provide you with many years of good service.

  • Page 2: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation. SPECIFICATIONS Model: Model: 315530 Rated Voltage: Rated Voltage: 240V~50Hz Rated Input Power (Microwave): Rated Input Power(Microwave): 1450W...

  • Page 3: Important Safety Instructions Warning

    IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 1. Read and follow the specific:"PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY”.
  • Page 4 6. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. 7. WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
  • Page 5 15. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. 16. The appliance must not be installed behind a decorative door in order to avoid overheating.

  • Page 6: Read Carefully And Keep For Future Reference

    25. The rear surface of appliances shall be placed against a wall. 26. Steam cleaner is not to be used. 27. Surface of a storage drawer can get hot. 28. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.

  • Page 7: To Reduce The Risk Of Injury To Persons Grounding Installation

    TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION DANGER Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance. WARNING Electric Shock Hazard Improper use of the grounding can result in electric shock.
  • Page 8 1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. 2. If a long cord set or extension cord is used: (1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.
  • Page 9 UTENSILS CLEANING & UTENSILS CAUTION Be sure to unplug the appliance from the power supply. 1. Clean the cavity of the oven after using with a slightly damp cloth. 2. Clean the accessories in the usual way in soapy water. 3.
  • Page 10 Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven."...
  • Page 11 ▲ Materials you can use in microwave oven Utensils Remarks Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) Browning dish above the turntable. Incorrect usage may cause the turntable to break. Microwave-safe only. Follow manufacturer's Dinnerware instructions.

  • Page 12: Materials To Be Avoided In Microwave Oven

    ▲ MATERIALS TO BE AVOIDED IN MICROWAVE OVEN Utensils Remarks May cause arcing. Transfer food into microwave-safe Aluminum tray dish. Food carton May cause arcing. Transfer food into microwave-safe with metal dish. handle Metal or Metal shields the food from microwave energy. Metal metal- trim may cause arcing.

  • Page 13: Setting Up Your Oven

    SETTING UP YOUR OVEN ▲ Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray Turntable ring assembly Instruction Manual Bake tray A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray...
  • Page 14 ▲ Countertop Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
  • Page 15 ▲ WARNING Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be void. The accessible surface may be hot during operation. EN-15...
  • Page 16 OPERATION INSTRUCTION This microwave oven uses modern electronic controls to meet your cooking needs. ▲ Clock Setting When the microwave oven is Powered On, the oven will display "0:00", and the buzzer will ring once. 1. Press "Timer/Clock" once. "00:00" displays . 2.
  • Page 17 NOTE: The step quantities for the adjustment time of the coding switch are as follow: 0---1 min 5 seconds 1---5 min 10 seconds 5---10 min 30 seconds 10---30 min 1 minute 30---95 min 5 minutes ▲ Microwave Power Chart Press Power/Grill/Convec./Combi.
  • Page 18 Note: During the microwave cooking, each on more press on "Start/+30Sec." could increase the time by 30 seconds. ▲ Note: Combination instructions Instructions Display Microwave Grill Convection ▲ Convection Cooking with preheating The convection cooking can let you to cook the food as a traditional oven.
  • Page 19 ▲ Convection Cooking without preheating 1. Press the "Power/Grill/Convec./Combi." key three times, "140" flash. 2. Press the "Start/+30Sec." to confirm. 3. Turn " " to adjust the temperature. (The range of it is 140- 230°C) 4. Press the "Start/+30Sec." to confirm 5.
  • Page 20 There are 5 modes in the low-temp-control function as below: Pressing Low Temp Mode Display Temp Time Control Slow Cook 90°C/110°C 10:00min~12h 60°C/70°C 00:05~ Keep warm /80°C 95:00min Food dry 40°C~90°C 10:00min~12h yogurt/ 40°C 10:00min~12h ferment 00:05~ Warming box 40°C~100°C 95:00min ▲...

  • Page 21: Crispy Grill

    ▲ HOME FRY 1. In waiting state, press "Home Fry/Crispy Grill" once, "H1" will flash. 2. Turn " " to choose the menu, "H1-H9" are available. 3. Press "Start/+30Sec." to start preheating. When the preheat temperature has arrived, the buzzer will sounds twice. Put the food into the oven and close the door.
  • Page 22 Crispy Grill menu Chart Display Weight Time(min) Power 200g 7:00 300g 8:00 Cordon 400g 9:00 Grill+convection 70% bleu 500g 10:00 +Microwave 30% (fresh mini 600g 11:00 pizza) 700g 12:00 800g 13:00 200g 9:00 300g 10:00 400g 11:00 Grill+convection 70% 500g 12:00 (lasagna) +Microwave 30%...
  • Page 23 Auto menu Chart Menu Weight(g) Display Power 150g 150g 250g 250g Auto 350g 350g 100% Reheat 450g 450g 600g 600g 1 (about 230g) 2 (about 460g) 100% Potato 3 (about 690g) 150g 150g 300g 300g 100% Meat 450g 450g 600g 600g 150g 150g...
  • Page 24 Menu Weight(g) Display Power 200g 200g 300g 300g Pizza 400g 400g 500g 500g 750g 750g Chicken 1000g 1000g 1200g 1200g ▲ Inquiring Function 1. During cooking state(the clock is set), press "Timer/Clock" to check the current time. It will be displayed for 2-3 seconds. 2.

  • Page 25: Troubleshooting

    TROUBLE SHOOTING Normal Radio and TV reception may be interfered when Microwave oven interfering microwave oven operating. It is similar to the interference TV reception of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal. In low power microwave cooking, oven light may become Dim oven light dim.
