- Page 1 Model #217-H40-4DS USE AND CARE GUIDE Sarasota 4pc Cushioned Deep Seating Set Questions, problems, missing parts? Before returning to the store, call Our Customer Service 7.30 a.m. - 4.30 p.m. PST, Monday - Friday, 888-445-6690 CustomerService@PacificCasual.com Ver: 2-24-2021...
- Page 2 Table of Contents Pre-Assembly..............3 Table of Contents ............2 Planning Assembly ..............3 Important Safety Instructions ..........2 Hardware Included..............3 ..............2 Care & Cleaning Package Contents ..............4 Assembly.................5 Important Safety Instructions SAVE THESE INSTRUCTIONS IMPORTANT: Please check the tightness of the bolts CAUTION: Use the table and chairs on flat ground only.
- Page 3 Pre-Assembly PLANNING ASSEMBLY It will take two people about 30 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Lounge Chairs Part Description Quantity Bolt cap (M6) Bolt (M6x32) Washer (M6) Hex wrench Love Seat Part Description Quantity...
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Lounge Chairs Part Description Quantity Back panel Seat panel Right armrest Left armrest Back cushion Seat cushion Love Seat P art Description Quantity Back panel Seat panel Right armrest Left armrest Back cushion Seat cushion Coffee Table Part Description Quantity...
- Page 5 Assemb ly (Lounge Chairs) □ Place the right armrest (C) on its side on a at, smooth surface. Align the seat panel (B) and back panel (A) to the armrest (C). Secure the seat panel and back panel to the armrest (C) with washers(DD) and bolts (BB) using the hex wrench (EE). NOTE: IMPORTANT: Place the back panel (A) with the curve facing outward...
- Page 6 A A s s s s e e m m b b l l y y (Love Seat) □ Place the back panel (A1) on its back on a flat, smooth surface. □ Attach armrests (C1) and (D1) to the back panel with washers (DD) and bolts (BB) using wrench (EE). Do not fully tighten bolts until the end of Step 3.
- Page 7 A A s s s s e e m m b b l l y y (Coffee table) □ Place the table top (A2) upside down on a at, smooth surface. □ Align the table legs (B2) to the table top. □...
- Page 8 Assembly Assembly Placing cushions □ Place cushions (1,2,3 and 4) on the lounge chairs and love seat. □ Level the chairs with foot glides if necessary.
