- Page 1 Model # 211-H41-9D USE AND CARE GUIDE Terra Linda 9pc Cushioned Dining Set (4 Chairs) Questions, problems, missing parts? Before returning to the store, call Our Customer Service 7.30 a.m. ~4.30p.m.PST, Monday - Friday, 888-445-6690 CustomerService@PacificCasual.com Ver: 10-08-2021...
- Page 2 Table of Contents Pre-Assembly..............3 Table of Contents ............2 Planning Assembly ..............3 Important Safety Instructions ..........2 Hardware Included..............3 ..............2 Care & Cleaning Packag e Contents ..............3 Assembly................4 Important Safety Instructions SAVE THESE INSTRUCTIONS IMPORTANT: Please check the tightness of the bolts CAUTION: Use the table and chairs on flat ground only.
- Page 3 Pre-Assembly PLANNING ASSEMBLY It will take two people about 40 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x38) Bolt (M6x32) Washer (M6) Bolt cap (M6) Hex wrench PACKAGE CONTENTS Part Description Quantity...
- Page 4 Assemb ly Attaching the right armrest □ Place the right armrest (C) on its side on a flat, smooth surface. □ Attach the seat panel (A) to the armrest with washers (CC) and bolts (BB) using hex wrench (EE). □ Attach the back panel (B) to the armrest with washers (CC) and bolts (AA) using hex wrench (EE).
- Page 5 Assembly Attaching bolt caps □ Cover all bolts (AA) and (BB) with bolt caps (AA). Placing cushions □ Place cushions (1 and 2) on the chair and secure the seat cushion to the frame with hook and loop straps. □ Repeat steps 1 through 4 for the other dining chairs.
