Media Configuration Tool Guide
Media Feed Amount After
Cutting
150 mm, 390 mm
Important
10.Click the OK button to close the Media Type Detailed Settings dialog box.
The Add Media Type wizard displays.
11. Click the Next button.
The Add Media Type moves to display Confirm Addition.
Chapter 4 Adding Media Types
Setting
Sets the media purge amount for media
that does not easily fall into place after
being auto cut. The purged media is
returned to the original position during
cutting and continues to print with no
change in print starting position.
• Place a checkmark in Normally Print Cutline to Reduce Cut Dust
for media that easily produces cut waste, such as backlight film.
These settings can protect against a reduction in print quality and
printhead malfunction. However, do not set this for media that curls
easily, such as plain paper and thin media. The media will not be
properly cut, and the media may become jammed.
• Place a checkmark in Cut with Standard Cutter to use the standard
cutter for auto cut. Remove the checkmark with media that cannot be
cut using the standard cutter.
• When you place a checkmark in Set Printing with Smear
Correction Effective as Standard for media with unwanted yellow
portions in images, or lines in the printing and changes in the image
color balance, the lines may be improved.
• When you place a checkmark in Do Not Cut Until User Operation
After Printing for media that you do not want to drop in the basket
after printing, the media will not be auto cut after purging. Once the
ink has dried, follow the printer operating panel to cut the media.
4-8
