iBOX-230
Quick Installation
Guide
M/B
Front Panel
On-/off Switch
Antenna Port
Inside View
Rear Panel
Front View
Power LED
HDD LED
Rear View
Line out (Pink)
Microphone (Lime)
2 x RJ-45 Ports
Kensington Lock Slot
mini-PCIe Slot
mini-SATA Slot
2 x COM Ports
2 x USB 2.0 Ports (Type A)
2 x USB 3.0 Ports (Type A)
HDMI Port
VGA Port (VGA1)
*15G06M059000AK*
P/N: 15G06M059000AK V1.0
SO-DIMM Sockets
Antenna Port
DC Jack (DC IN)
Advertisement
Related Manuals for ASROCK iBOX-230
Summary of Contents for ASROCK iBOX-230
- Page 1 *15G06M059000AK* P/N: 15G06M059000AK V1.0 iBOX-230 Inside View Quick Installation Guide Rear Panel mini-PCIe Slot Front Panel mini-SATA Slot SO-DIMM Sockets Front View 2 x COM Ports Power LED On-/off Switch 2 x USB 2.0 Ports (Type A) HDD LED Rear View...
- Page 2 1. Removing the Bottom Cover 4. Installing the mSATA SSD 2. Secure the hard drive into the place using the four screws. * is step is optional. 1. Remove the four screws on the bo om case. 3. A ach one end of the SATA 1 to 1 Power Cable 1.
