  • Page 1 USER’S GUIDE...

  • Page 2: Table Of Contents

    Contents GENERAL ........................2 About ........................ 2 Safety ........................ 3 Battery and components disposal ..........10 PACKAGE CONTENTS ...................11 PREPARATION ......................13 Battery Charging ..................13 Remote Charging .................. 15 ASSEMBLY ........................16 ESC Installation ..................16 ESC Antenna Installation ..............17 Foil and Propulsion Assembly ............18 Propulsion to ESC connection ............

  • Page 3: General

    The following is strictly prohibited: The illustrations are provided to facilitate comprehension. They have no It is strictly prohibited to tow a person with the TAKUMA E-FOIL in any contractual nature. way whatsoever. Doing so would result in serious and even fatal injuries.
  • Page 4 Do not use the TAKUMA E-FOIL in a thunderstorm or severe weather conditions. The TAKUMA E-FOIL is an individual product and should only be used by one The TAKUMA E-FOIL is not a piece of equipment for surfing, it is not suitable for adult at a time.
  • Page 5 Please contact your local TAKUMA dealer for further assistance. Do not operate your TAKUMA E-FOIL when it is not in the water. Doing so will Signs of a damaged battery: cause it to overheat and may permanently damage the motor.
  • Page 6 Doing so can lead to fire. Do not let the connectors come in contact with water or wet hands. Do not use other ESC than the one sold by TAKUMA. Any damage caused by the use of another ESC will not be covered by warranty.

  • Page 7: Battery And Components Disposal

    It is necessary to ensure that it will not be used later. Please contact your local TAKUMA dealer for more information. Fuselage The defective product will be entrusted to authorized technicians for the purposes of control.

  • Page 8: Preparation

    PREPARATION Box 2: 3.1 Battery Charging Before using for the first time, charge the battery 100%. Charge the battery at least once within 3 months after delivery. 4 x M6-70 The battery will reach its full capacity after 3 or 4 charging/ (preassembled in Carver 2) discharging cycles.

  • Page 9: Remote Charging

    3.2 Remote Charging Before using for the first time, charge the remote control 100%. Charge the remote control at least once within 3 months after delivery. The remote control must be completely dry before charging. Once the battery is connected to the charger, the light on the charger should turn red.

  • Page 10: Assembly

    ASSEMBLY 4.2 ESC Antenna Installation To facilitate the assembly of the TAKUMA E-FOIL, we recommend watching the tutorials on our channel http://youtube.takuma.com Clean area with alcohol and allow to dry before attaching clips. Place antenna near the top without obstructing the lid from closing.

  • Page 11: Foil And Propulsion Assembly

    4.3 Foil and Propulsion Assembly M6-14 mm M6-30 mm M6-18mm...
  • Page 12 Efoil Carver 2 M6-70 mm Efoil Cruising 2 M6-T Nuts M6-14mm...

  • Page 13: Propulsion To Esc Connection

    4.4 Propulsion to ESC connection Foil Position For more lift After removing the 2 caps: Screw together the 2 M/F caps of the For less lift connectors. Connector grease The pins will only connect if the notches are properly aligned. No great force is needed.

  • Page 14: Battery Installation

    4.5 Battery Installation After removing the 2 caps: Screw together the 2 M/F caps of the connectors. The pins will only connect if the notches are properly aligned. No great force is needed. Connector grease...

  • Page 15: Use

    5.1 Activation and Pairing Hold down on the power button even after the remote has turned on until it is pared. Keep you finger on the button until all 5 led lights are on.

  • Page 16: Pairing Failure

    5.2 Pairing Failure If the ESC light remains red, this means that the remote control cannot connect to the board. The barred wifi is shown in the middle of the screen. Try to pair again, turn off the remote and battery and repeat the activation and pairing steps.

  • Page 17: How To Use Remote

    5.3 How to use remote 5.3.2 Trigger switch and speed adjustment dial To facilitate learning how to use the TAKUMA E-FOIL, we recommend watching the tutorials on our channel http://youtube.takuma.com We also recommend to start practicing with an instructor. 5.3.1 Remote control...

  • Page 18: Safety Cut Off

    5.4 Safety Cut Off When you release the trigger, the speed adjustment dial must always be set back to the minimum setting before you can start the propulsion again. 5.3.3 Boost mode If the remote hits the water the connection and the motor will cut off. Pressing the boost button increases the speed by 20%.

  • Page 19: Low Battery Warning

    5.6 Power off The speed adjustment dial must be put back to the minimum setting before starting the propulsion again. 5.5 Low battery warning...

  • Page 20: Maintenance & After Use

    Apply TEF GEL on the screws regularly. If needed, contact your TAKUMA authorized dealer for assistance. After each use, rinse your E-FOIL: Open the top cover of the board and rinse with fresh water without disconnecting the cables. Also rinse the propulsion mast and the propeller.
  • Page 21 After-Sales Service: customerservices@takuma.com Please find our tutorial videos on our youtube channel: http://youtube.takuma.com Other languages: Español / Deutsche / Italiano / Português / Polskie / Română / Slovák / Slovenščina / Български / čeština / Русский / Hrvatski / Lietuvių / Magyar /...
