2.1. Menu Overview
Use the navigation buttons to navigate within the four main menus (Jobs, Limits, Adjustment, Settings).
Navigating within the menus:
Previous / next menu; when entering values: previous / next decimal place
Previous / next menu item; when entering values: Value up / down (hold button for
fast scan)
OK
Confirm value / go to submenu / confirm selection
Previous; context-based Q button
Home; return to measurement display
context-based button Power / Menu / Home
On / Off
Context and model-based symbols in the menus::
The background colours of the symbols correspond with the colours in the main menu.
Job (only if several jobs exist)
Job contains the enabled area
Defined area
Enabled area
Menu item has a submenu
Menu item contains an entry or selection list
Checkbox, multiple items can be selected
Radio button, only one item can be selected
