Please read this operating instructions thoroughly before using your air conditioner
WWW.GREE.CA
St-Mathieu-de-Beloeil (Québec) Canada
1-866-680-GREE
00526-11/10/11
Room Air Conditioner
OPERATING
INSTRUCTIONS
MODELS
13-04685
13-04686
and keep it for future reference.
© Tous droits réservés, Sunrise Tradex Corp., 2011
Advertisement
Table of Contents
Related Manuals for Gree 13-04685
Summary of Contents for Gree 13-04685
- Page 1 Room Air Conditioner OPERATING INSTRUCTIONS MODELS 13-04685 13-04686 Please read this operating instructions thoroughly before using your air conditioner and keep it for future reference. WWW.GREE.CA St-Mathieu-de-Beloeil (Québec) Canada © Tous droits réservés, Sunrise Tradex Corp., 2011 1-866-680-GREE 00526-11/10/11...
-
Page 2: Table Of Contents
Installation Instructions For Slider Casement Air Conditioners NOTE: These instructions describe installation in a typical wood framed window with a wood SLIDE-BY sash, or installation in a metal CASEMENT window. Modification may be necessary when installing in windows made differently than those shown in these instructions. -
Page 3: Electrical Connection
Electrical Connection Electrical ground is required on this appli- 3 Prong Grounding ance. Type Wall Receptacle 3 Prong Grounding Recommended grounding method: Plug For your personal safety, this appliance must be grounded. This air conditioner includes a power supply cord with a Grounding prong 3-prong grounding plug. -
Page 4: Preparing For Installation
Contenu de la trousse d’installation : 1. Make sure you have all the necessary parts. Platform (1) Support brace (1) Adjustment bolt (1) Hex flange nut - 1/4" (1) Track seal (1) Side channel seal (1) Foam seal strip/Sash seal Safety bracket (1) 9-11. -
Page 5: Installing Unit In A Sliding Window
3. Choose the proper window location. Choose a window that allows the cooled air to flow freely and directly into room(s) you wish to cool. Remember, it is difficult to move air around corners. Also, choose a window that is within 6 feet of an electrical outlet. - Page 6 4. Peel off protective backing from track seal. Apply seal to room side of window Apply track seal to window side of track. track. Center of seal strip should coincide with the line marked in Step 2. The two screw holes drilled in Step 3 should be directly above seal strip in the inner track.
- Page 7 10. Clamp plastic window panel between a board and a work table, and cut along cut- ting line with a fine tooth saw. Remove any Fastening Side burrs with a file. Channels 11. Fasten side channels to the sides of the AC using 3 screws (Item 17) per channel.
-
Page 8: Alternate Window Jamb Applications
16. Slide inner window sash firmly against side of the cabinet. Make sure not to peel the seal strips from the window track and cabinet side channels. If the panel frame does not fit snugly to the inner window sash, secure the panel frame to the sash with #8x3/4-inch screws, or #8- 32x3/4-inch selfthreading screws. -
Page 9: Installing Unit In A Casement Window
Installing the Unit in a Casement Window NOTE: Open the window the maximum amount to allow for clearance of the cabi- net. The crank handle should be removed to allow the platform to be fastened to the jamb. If the window cannot open far enough (more than 15-1/2 inches) for the cabinet to clear the window, remove the window entirely by drilling out the rivets. -
Page 10: Plastic Window Panel
5. Adjust the platform assembly so that the rear of the air conditioner will be 3/16 inch lower than the front. This ensures proper water drainage from the air conditioner. Rear is at least 7/16" lower than front NOTE: A projection below the base of the air conditioner will require the rear of the platform to be 7/16-inch lower than the front to create the 3/16-inch slant from front... - Page 11 11. Cut side channel seal into 2 equal lengths. Remove the protective backing and apply it to the rear side of the cabinet side channels, starting just below the panel frame assembly. Pinch off excess length so the seal is even with the bottom of the cabinet side channel.
-
Page 12: Important Safety Instructions
Important Safety Instructions Read all instructions before using this air NOTE The power supply cord conditioner. with this air conditioner contains a WARNING For Your Safety current detection device designed to Do not store or use gasoline or other flammable reduce the risk of fire. - Page 13 Important Safety Instructions READ THIS SECTION BEFORE ATTEMPTING TO OPERATE AIR CONDITIONER. The power supply cord contains a current device that Plug in & press RESET senses damage to the power cord. To test your power supply cord do the following: 1.
-
Page 14: Operation Of Current Device
Controls Starting YourAir Cond itioner—DigitalControl Lights next to the touch pads on the air conditioner control panel indicate the selected settings. ON/OFF Pad Mode Pad Turns air conditioner on and off. Use to set the air conditioner to Cool, Energy Saver , Fan Only , Dry. or Auto Display mode. - Page 15 Remote Control After 11min, if controller does not receive ambient temperature value which sending by remote controller, it will run with AC ambient temperature; if I FEEL is not set, ambient temperature will adopt sampling value of AC temperature sensor. If power off happens, this function will not be memo- rized.
-
Page 16: Air Conditioner Features
Air Conditioner Features (continued) ADDITIONNAL THINGS YOU SHOULD KNOW Now that you have mastered the operating procedure, here are more features in your con- trol that you should become familiar with: The “Cool” circuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly. -
Page 17: Care And Cleaning
Care and Cleaning Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the Energy Saving Ideas... -
Page 18: Avoid Service Checklist
Avoid Service Checklist INSTALLER L’APPAREIL INTERNE Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workman-ship or materi- als in this appliance. OCCURRENCE SOLUTION Air conditioner will not operate. - Page 19 Avoid Service Checklist INSTALLER L’APPAREIL INTERNE OCCURRENCE SOLUTION Doors, windows, registers, etc. open - cold air escapes. Close doors, windows, registers, etc. Unit recently turned on in hot room. Allow additional time to remove “stored heat” from walls, ceiling, floor and furniture.
- Page 20 Note : The internal compressor is covered by a 5-YEAR limited warranty. During the warranty period, if this air conditioner fails under normal use, GREE will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the air conditioner is returned.
